ViewSonic ND4210w User manual

This page left blank for dual-sided printing.

ViewSonic ND4210w i
Copyright © ViewSonic Corporation, 2006. All rights reserved.
ViewSonic and the three birds logo are registered trademarks of ViewSonic Corporation.
Tivella and the Tivella logo are trademarks of Tivella, Inc.
Cisco is a registered trademark and this document may include service marks of Cisco Systems,
Inc. and/or its affiliates in the U.S. and other countries.
Corporate names and trademarks are the property of their respective companies.
Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or omissions
contained herein; nor for incidental or consequential damages resulting from furnishing this
material, or the performance or use of this product.
In the interest of continuing product improvement, ViewSonic Corporation reserves the right to
change product specifications without notice. Information in this document may change without
notice.
No part of this document may be copied, reproduced, or transmitted by any means, for any
purpose without prior written permission from ViewSonic Corporation.
Product Registration
To meet your future needs, and to receive any additional product information as it becomes
available, please register your product on the Internet at: www.viewsonic.com. The ViewSonic
product may come with a CD-ROM that has a registration form to print and mail or fax to
ViewSonic Corporation.
Product disposal at end of product life
ViewSonic is concerned about the preservation of our environment. Please dispose of this
product properly at the end of its useful life. Your local waste disposal company may provide
information about proper disposal.
For Your Records
Model Name:
Model Number:
Document Number:
Serial Number:
Purchase Date:
ND4210w
VS11571
ND4210w_UG_ENG_REV 1B 11-OCT-2006
_______________
_______________

ii ViewSonic ND4210w
This page left blank for dual-sided printing.

Contents
ViewSonic ND4210w iii
INTRODUCTION
Packaged Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Optional Accessory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Two Modes of Operation . . . . . . . . . . . . . . . . . . . . . . . . 2
Standalone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
TAS Managed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Two Modes of Communication . . . . . . . . . . . . . . . . . . . . 3
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Front View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Back View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
SETTING UP THE NETWORK DISPLAY
Connect to a Switch or Router . . . . . . . . . . . . . . . . . . . . 7
Turn Power On to the Network Display . . . . . . . . . . . . . 9
Put Batteries in Remote Control . . . . . . . . . . . . . . . . . . .10
Login . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
MANAGEMENT
Startup URL/Network Configuration . . . . . . . . . . . . . . . .11
Browser Configuration . . . . . . . . . . . . . . . . . . . . . . . . . .13
VNC Client (Management) . . . . . . . . . . . . . . . . . . . . . . .15
TAS Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
FTP Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
System Services Configuration . . . . . . . . . . . . . . . . . . . .19

iv ViewSonic ND4210w
ACTIONS
Video UDP/RTP Multicast . . . . . . . . . . . . . . . . . . . . . . . 20
Video HTTP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Video IPTV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Video File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Playlist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
VNC Client (Actions) . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Transparency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Go to URL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
ADMINISTRATION
Advanced Video Configuration . . . . . . . . . . . . . . . . . . . 28
Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Save Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Default Settings/Reset . . . . . . . . . . . . . . . . . . . . . . . . . 31
Reboot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Firmware Upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
HELP
Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
License . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Serial Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
About . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

ViewSonic ND4210w v
APPENDIX
Screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Actions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Administration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Customer Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Compliance and Safety Notices . . . . . . . . . . . . . . . . . . 43
FCC Class A Compliance Notice (United States) . . . 43
Mercury Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Canadian Compliance Notice . . . . . . . . . . . . . . . . . . 44
GOST-R Certification . . . . . . . . . . . . . . . . . . . . . . . . . 44
European Compliance Notice . . . . . . . . . . . . . . . . . . 45
For Taiwan and Other Traditional Chinese Markets . 46
China CCC Mark . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Declaration of RoHS Compliance . . . . . . . . . . . . . . . 47
Cleaning the Device . . . . . . . . . . . . . . . . . . . . . . . . . 49
Data Loss Disclaimer . . . . . . . . . . . . . . . . . . . . . . . . . 49
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

vi ViewSonic ND4210w
This page left blank for dual-sided printing.

ViewSonic ND4210w 1
INTRODUCTION
Thank you for buying the ViewSonic®Network Display. This section introduces you to the
ND4210w Network Display.
PACKAGED CONTENTS
Please check that all the following items are in the package:
OPTIONAL ACCESSORY
The Wall Mount Kit accessory is available at viewsonic.com
REQUIREMENTS
The ND4210w Network Display requires:
•ViewSonic ND4210w Network Display connected to AC power and a network or internet
connection
• Streaming video server and/or live encoder
• If using the VNC Client feature, be sure to install VNC software on your PC (sold separately)
ND4210w Network Display
with detachable speakers
Remote Control
with two AA batteries
User Guide
Quick Start Guide Multi-Region
Power Cords

2ViewSonic ND4210w
TWO MODES OF OPERATION
STANDALONE
The setup allows the ND4210w Network Display to act as an independent network device controlled
by one server.
TAS MANAGED
You can purchase Tivella Administration Server (TAS) separately through Tivella (www.tivella.com
or a Tivella dealer/reseller). A TAS server should be used to configure and manage multiple
Network Displays remotely. TAS provides centralized scheduling of video content presentation
on multiple Network Displays, as well as management and seamless operation of a Cisco®
ACNS Content Distribution Networking infrastructure if one is installed. This configuration greatly
reduces maintenance overhead, when TAS and the Network Display are connected to the
network (LAN/WAN) with the TAS acting as a manager for multiple Network Displays.
PC
ND4210w
Network Display Switch or
Router
Ethernet cable
Ethernet cable
TAS
ND4210w
Network Display
Switch or Router
PC to
control
TAS

ViewSonic ND4210w 3
TWO MODES OF COMMUNICATION
There are two modes of communication with the ND4210w Network Display: an HTTP web
interface and a Telnet advanced command line interface. This document focuses on the web
interface only.
FEATURES
• Integrated display for A/V IP delivery
• Multiple Network Displays can be daisy chained with different IP addresses
• Supports scheduling of different video content across multiple displays
• No need for additional external PC or set-top box with a switch
• Remote management control and status reporting
• MPEG A/V decoding, MPEG 1/2/4, Macromedia Flash
• Auto-MDIX (no crossover cabling)
• Powerful combination of the Sigma Design®EM8621L and the Freescale®MPC8247 for
smooth playback
• Can be installed with an optional wall mount
• Uses Tivella®content management software
• Devices can be remotely controlled from virtually anywhere with a network or internet
connection
• Wireless Ethernet support eliminates the need to run cables to an existing network
• Remote management allows you to adjust the screen and see valuable information without
being physically in front of the unit
• Network ready, easy installation
• Local content buffering or storing in hard drive
• AJAX support in browser

4ViewSonic ND4210w
FRONT VIEW
Detachable
speaker
Detachable
speaker
VOL +raises the volume
VOL – lowers the volume
CH changes stream channel
(in development)
POWER turns screen/
audio power off
MENU shows the IP address on the screen
INPUT cycles the screen from Video,
Browser, or 50/50 transparency
CH changes stream channel
(in development)

ViewSonic ND4210w 5
BACK VIEW
RESET button
Press and hold the RESET
button for five (5) seconds to
restore the default settings.

6ViewSonic ND4210w
REMOTE CONTROL
POWER button
On/Standby
Show IP

ViewSonic ND4210w 7
SETTING UP THE NETWORK DISPLAY
1. CONNECT TO A SWITCH OR ROUTER
Connect an RJ-45 Ethernet cable from the Network Display to either a switch or a router
with DHCP services. See your IT Administrator for a code to the switch or a router. Connect
the AC power cord from the Network Display to an AC power source like a wall outlet.
AC Power cord
ND4210w Network Display (back view)
Switch or Router
RJ-45 Ethernet cable
PC
RJ-45 Ethernet cable

8ViewSonic ND4210w
Connect Multiple Network Displays (optional)
You can daisy chain several Network Displays together. The two built-in Ethernet ports make
the ViewSonic Network Displays unique because you do not need separate network switches
or PCs for each Network Display. Media content on each Network Display can be scheduled
independently when connected to an external server.
Plug another RJ-45 Ethernet cable into an Ethernet port of another Network Display. You can
connect either of the two Ethernet ports of one unit to either of the two Ethernet ports of another unit.
Ethernet cable to
Ethernet ports
Back view
Ethernet cable to
Ethernet ports

ViewSonic ND4210w 9
Connect External Speakers (optional)
2. TURN POWER ON TO THE NETWORK DISPLAY
Wait for the splash screen to appear with the IP address. Make a note of the IP address
on a piece of paper because you will need this in another step.
speaker
Back of Network Display
speaker
Power Button

10 ViewSonic ND4210w
3. PUT BATTERIES IN REMOTE CONTROL
Remove the back cover from the remote control as shown below. Put two AA batteries in
the remote control. Be sure to match the positive end of the battery with the positive end of
the compartment. Put the cover back on the remote control.
4. LOGIN
Open an Internet Browser, i.e., Internet Explorer on a PC in the same network. In the
URL address field, type the IP address of the ND4210w noted in a previous step > press
Enter. The Login screen appears. Type the defaults Login: admin and Password:
admin. For security purposes, we recommend that you change the default IP address,
Login and Password. For more information, see the Security section in this user guide.
After logging in successfully, the Network Configuration screen appears as shown on
the next page. Note: The ND4210w automatically logs you out after fives minutes of
inactivity.
For information on how to change network settings on an OS other than Windows, please
consult the OS user guide or your Network Administrator.

ViewSonic ND4210w 11
MANAGEMENT
STARTUP URL/NETWORK CONFIGURATION
The Network Configuration screen allows you to select the video that appears on-screen when you
boot up the ND4210w. To go to the Network Configuration screen after logging into the ND4210w,
select Management > Startup. The Startup URLs screen and the Network Configuration screen
appears as shown below.
1. To play a particular video at startup, in the Video field, enter a valid HTML page. Here are
some examples:
•http://<ip-address->/<mpeg-1/2-file-located on WEB Server>
•udp://<ip-multicast-address>/port
•rtp://<multicast-address>/port
•iptv://<ip-multicast-address>/videoport/audioport
•playlist=http://<ip-address>/<playlist-file-located-on-WEB-server. For more
information about creating and playing a playlist with specific content, in a specific
order, looped or not looped, see the PLAYLIST section in this guide.
Continued . . .
Displays the IP address
Displays the Video source
Displays the Browser

12 ViewSonic ND4210w
2. In the Browser field, enter a startup web screen (for example, http://www.viewsonic.com).
Note: The MAC address is a read-only field that displays the built-in MAC address of the unit.
3. In the DHCP field of the Network Configuration screen, tap the down arrow for the pull-
down menu and select Enabled to dynamically get network parameters. Make sure there are
values in the IP address,Mask,Gateway, and DNS fields although DHCP assigns values to
these fields automatically. If you select Disabled, type valid network parameters in these
fields.
4. If any changes were made to this screen, do the following:
• To enable the changes, click Apply
• To save the changes, click the Administration menu > click Save Configuration >
click Save.
