ViewSonic LiteBird PJ853 User manual

User Guide
Guide de l’utilisateur
Bedienungsanleitung
(International Spanish)
(Italian)
(Brazilian Portuguese)
(Swedish)
(Russian)
(Polish)
(Japanese)
(Traditional Chinese)
(Simplified Chinese)
(Korean)
(Arabic)
Image Size 30” – 300”
Super Bright SVGA LCD Projector
LITEBIRD
TM
PJ853-.book Page 1 Wednesday, August 16, 2000 11:41 AM

ViewSonic PJ853 i
E
N
G
L
I
S
H
Contents
For Your Records ............................................................................1
Getting Started
Package Contents ...........................................................................2
Important Safety Warnings ..............................................................2
Connect Input and Output Devices..................................................3
Installation Steps .............................................................................4
Adjusting the Projector Angle ....................................................5
Projector Placement Distance ...................................................5
Using The Projector
Control Buttons ................................................................................6
OnView Indicators............................................................................8
Setup Main Menu .....................................................................8
Input Menu ...............................................................................9
Image Menu .............................................................................9
Options Menu .........................................................................10
Other Information
Specifications ................................................................................11
Timing Chart ............................................................................12
Troubleshooting .............................................................................13
Power Indicator Lights .............................................................14
Screen Messages ....................................................................14
Maintenance ..................................................................................15
Lamp Replacement .............................................................15
Installing Battery (for remote control) ......................................16
Cleaning Instructions ...............................................................16
Air-Filter ...................................................................................17
Customer Support..........................................................................18
LIMITED WARRANTY
VIEWSONIC Projector ............................................................19
Appendix
Power Cord Safety Guidelines.......................................................20
FCC Information ............................................................................21
PJ853-.book Page i Wednesday, August 16, 2000 11:41 AM

1ViewSonic PJ853
E
N
G
L
I
S
H
Copyright © ViewSonic Corporation, 2000. All right reserved.
Macintosh, Mac and Power Macintosh are registered trademarks of Apple Computer, Inc.
Microsoft, Windows, Windows NT, and the Windows logo are registered trademarks of Microsoft
Corporation in the United States and other countries.
ViewSonic, the three birds logo and OnView are registered trademarks of ViewSonic Corporation.
VESA is a registered trademark of the Video Electronics Standards Association. DPMS and DDC
are trademarks of VESA.
ENERGY STAR®is a registered trademark of the U.S. Environmental Protection Agency (EPA).
As an ENERGY STAR®partner, ViewSonic Corporation has determined that this product meets the
ENERGY STAR®guidelines for energy efficiency.
Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or omissions
contained herein; nor for incidental or consequential damagesresulting from furnishing this material,
or the performance or use this product.
In the interest of continuing product improvement, ViewSonic Corporation reserves the right to
change product specifications without notice. Information in this document may change without
notice.
No part of this document may be copied, reproduced, or transmitted by any means, for any purpose
without prior written permission from ViewSonic Corporation.
Electronic WarrantyRegistration
To meet your future needs, and to receive any additional product
information as it becomes available, please register your projector's
warranty on the Internet at:
http://www.viewsonic.com
For Your Records
Product Name:
Model Number:
Document Number
Serial Number:
Purchase Date:
ViewSonic PJ853
VPROJ21732
PJ853_UG_59
_______________
_______________
PJ853-.book Page 1 Wednesday, August 16, 2000 11:41 AM

ViewSonic PJ853 2
E
N
G
L
I
S
H
Getting Started
Congratulations on purchasing a ViewSonic PJ853 LITEBIRD™ LCD projector. Save the original
box and all packing material for future shipping needs.
Package Contents
• ViewSonic PJ853 LITEBIRD LCD Projector
• Remote Control Unit including 3V micro-lithium battery
• Three (3) AC power cords (U.S., European and China)
• Computer video cable (15-pin mini D-sub connector)
• Video cable (RCA connectors)
• Audio mini-stereo cable (RCA connectors)
• User guide
• Carrying Case
Important SafetyWarnings
• Unplug the projector immediately if you detect an abnormal smell or see smoke.
• Do not look directly into the lighted lens; doing so will cause severe eye injury.
•Keep small children away from the projector. Children can be severely burned by the hot lens.
Also, children are more likely to look directly into the lens.
• Never touch the lens or the lamp when hot or warm; doing so will cause a severe burn. Unplug the
projector and allow the unit to cool down for 45 minutes before replacing the lamp or storing the
projector.
• Do not service the unit yourself; doing so could cause injury.
• Do not operate the projector near water or in a humid area. Do not sit drinks on or near the
projector; doing so could cause a burn or short an electrical circuit.
• Do not block the ventilation openings in the projector. Place the projector so that there is adequate
air circulation
• Keep the air filter clean.
• Do not place the projector on a shelf or on any other unstable surface.
Figure 1: Package Contents
PJ853
Power Cord
US Type
Power Cord
Europe Type
RGB Cable

3ViewSonic PJ853
E
N
G
L
I
S
H
Connect Input and Output Devices
The figure below shows the ports and configurations for connecting external devices to the
ViewSonic PJ853. See “Installation Steps” on page 4.
Figure 2: ViewSonic PJ853 Projector
Figure 3: Connections and Projector Control Buttons
MENU
ST
ANDBY/ONINPUTMUTERESET
LAMP
TEMP
POWER
Power Switch
AC Inlet
(to the power cord)
Air Vent
(Intake) Foot Adjuster
Lens
Remote Control Sensor
Projector control
panel
ViewSonic
PJ853
Video IN port Audio IN port
S-video IN port
RGB IN port
Control port
Remote control sensor
Standby/ON
Input
Mute
Reset Lamp indicator
Temperature indicator
Power indicator
Menu button
Air vent
(exhaust)
Speaker
Power Outlet
Power
ON/OFF
Power Cord
MENU
ST
ANDBY/ONINPUTMUTERESET
LAMP
TEMP
POWER
PJ853-.book Page 3 Wednesday, August 16, 2000 11:41 AM

ViewSonic PJ853 4
E
N
G
L
I
S
H
Installation Steps
1Verify Input/Output Connections
Make sure that you have properly connected all input cables before powering on the projector.
2Remove the lens cap.
3Power on the Projector.
•Turn on the Main Power Switch located on the side of the projector. The power indicator will
remain a steady orange. See “Using The Projector” on page 6.
4Press (and hold for 1 second) the Standby/ON button on the projector control pad.
•The power indicator flashes green during warm-up.
•The power indicator will remain a steady green after warm-up. The steady green light indicates
that the ViewSonic PJ853 is ready to use.
•To shut off the lamp – Press the Standby/ON button (and hold for about 3 seconds). The unit
will remain in cool-down mode with the fan on and the orange power LED blinking for 1
minute. The power switch on the side of the projector may be turned off after 1 minute, when
the power light is a steady orange.
5Position the Projector
Make sure that the projector is properly positioned on a level and stable surface. Determine the
distance the projector will be from the screen then adjust the angle of the projection by
positioning the foot adjusters. (See "Adjusting the Projector Angle on page" 5.)
6Power on Input Devices
•Press either the Input button on the projector control pad or the Video/RGB button on the
remote control to select the signal to be projected.
•The selected input signal source displays in the lower right section of the screen.
7Adjust the Focus
Turn the lens ring to adjust the focus
Caution:The projector requires a warm-up period after the power is turned on, and the projector
requires a cool-down period after the power is turned off.
NOTE: The power cannot be turned on for at least 1 minute after the unit has been powered off; this
is a safety feature.
Figure 4: System Setup
Video recorder with S jack
Video recorderDesktop Computer
Notebook Computer
ViewSonic
PJ853
(Note: S-video cable not included)
PJ853-.book Page 4 Wednesday, August 16, 2000 11:41 AM

5ViewSonic PJ853
E
N
G
L
I
S
H
Adjusting the Projector Angle
Adjust the projection angle using the foot adjusters shown in the illustration. See also KEYSTONE
under "Input Menu on page" 9.
1Press the release button to lower the front foot, then tilt the projector up as shown in Figure 5
below.
•The front foot locks into place when you release the button.
•The front foot adjusts the vertical height of the projected image.
2Rotate the rear foot adjuster to align the image.
The rear foot adjusts the horizontal alignment of the projected image.
Projector Placement Distance
Place the projector on a level table-top or other flat surface. Use the chart in Table 1 below to
determine the optimal placement distance from the screen.
Figure 5: Level Adjustments
Figure 6: Recommended Projector Distances
Table 1: Distance in Inches
Screen Size
(Inches)
a (Inches)
Minimum and Maximum
b (Inches)
40 37 46 3
60 57 69 5
80 77 93 7
100 96 116 9
120 116 139 10
150 145 174 13
200 194 233 17
Rotate the rear
foot adjuster
Press the release button
to lower the front foot adjuster
Front foot adjuster
a
Top View Side View
a
b

ViewSonic PJ853 6
E
N
G
L
I
S
H
Using The Projector
The control buttons display menus that are explained in detail in the section: “OnView Indicators” on
page 8.
Control Buttons
Press a control button to display a menu then use the arrow buttons to adjust the control. The buttons
on the projector control pad and on the remote control are explained below:
Figure 7: Projector and Remote Controls
Standby/on Button
Press the STANDBY/ON button to begin the warm-up period. The ON indicator
blinks green during warm-up and stays green when the projector is ready to use.
NOTE: The projector cannot be restarted within 60 seconds after it is turned off because
the projector enters a cool-down mode. This is a safety feature.
Input Button (Video and RGB Buttons)
The INPUT button shown is on the projector only. Use the Video and RGB buttons on
the remote control to select the input source.
Press the Input button on the projector to toggle between input sources, computer
(RGB), Composite or S-Video. The remote control has both a Video and an RGB
button.
-Press RGB to select a computer as the input source.
-Press Video to toggle between Composite and S-Video.
Projector control pad
Remote control
PJ853-.book Page 6 Wednesday, August 16, 2000 11:41 AM

7ViewSonic PJ853
E
N
G
L
I
S
H
Menu Button
The MENU button is a small button on the remote control and the large button on the
projector control pad.
Press the Menu button and then use the up, down, right or left arrowindicators (▲▼)to
display OnView®menus and adjust or select a menu item.
Position Button
The POSITION button is on the remote control only.
Press this button to adjust the position of the screen image. After pressing the
Position button use the up, down, right or left arrow indicators. (▲▼).
-Use the Position button when the input is from a computer (RGB).
NOTE: Position only works on a magnified image.
MagnifyButtons
The MAGNIFY buttons are on the remote control only.
The Magnify buttons are used to zoom in on part of the projected image.
-Use the + button to enlarge the projected image.
-Use the - button to decrease the projected image.
-Use the OFF button to turn off magnification.
Reset Button
The RESET button shown with the arrow and dot icon is on the projector only. The
RESET button on the remote control has no marking but is labeled RESET.
Press the Reset button to restore the factory default settings.
-Use Reset to restore the factory default settings if you have made several
adjustments to the projected image and are not satisfied with the result and
want to start over.
Volume Buttons
The VOLUME buttons are on the remote control only.
Use the Volume buttons to adjust the loudness of the audio signal.
-The up indicator increases the volume.
-The down indicator decreases the volume.
Mute Button
Use the Mute button to temporarily turn off the audio.
BlankButton
The BLANK button is on the remote control only.
Use the Blank button to display a blank screen showing only the background color.
Freeze Button
The FREEZE button is on the remote control only.
Use the Freeze button to freeze (or hold) an image on screen.
PJ853-.book Page 7 Wednesday, August 16, 2000 11:41 AM

ViewSonic PJ853 8
E
N
G
L
I
S
H
OnView Indicators
Use the OnView®menus shown below to adjust the projected image.
To access and adjust the OnView screens do the following:
1Press the MENU button on the projector control pad or remote control to access on-screen
options and display the SETUP Main Menu.
2Press the ARROW buttons, as explained below, to select and adjust options that are displayed on
the screen.
NOTE: After you have used the ARROW buttons to adjust a value, the value will automatically
apply after a few seconds.
Setup Main Menu
Timer Button
The TIMER button is on the remote control. You can set the timer from the OPTIONS
menu explained in the next section.
Use the Timer button to activate the on-screen timer.
-Press once to display the time on the lower left part of the screen.
-Press again to turn off the display.
Auto Button
Use the Auto button to automatically adjust the vertical position and horizontal
position, phase, and size.
SETUP Main Menu RGB
The setup RGB menu displays 9 adjustment options.
1Press an arrow button (▲▼) to display the menu.
2Press the right or left arrow buttons to select a menu option other than Setup.
3Press the up and down arrow buttonsto move through theSetup menu options.
4After a menu option has been selected, use the right or left arrow buttons to
increase or decrease the value of the selected option.
SETUP Main Menu Video
The Video setup menu displays 8 adjustment options.
1Press an arrow button to display the menu.
2Press the right or left arrow buttons to select a menu option other than Setup.
3Press the up and down arrow buttonsto move through theSetup menu options.
4After a menu option has been selected, use the right or left arrow buttons to
increase or decrease the value of the selected option.
Use the arrow buttons on the projector control pad or on the remote control to
move through the menu options and to increase or decrease the value of a selected
option.
0
-2
+1
0
0
100
100
800
SETUP INPUT OPT.IMAGE
BRIGHT
CONTRAST
V POSIT
H POSIT
H PHASE
H SIZE
COLOR BAL R
COLOR BAL B
ASPECT
BRIGHT
CONTRAST
SHARPNESS
COLOR
TINT
COLOR BAL R
COLOR BAL B
ASPECT
SETUP INPUT OPT.IMAGE
0
0
0
0
0
+1
+1
PJ853-.book Page 8 Wednesday, August 16, 2000 11:41 AM
