Advanced Connectivity for Large Classrooms and Conference Rooms
Networkable XGA Projector
PJD6345
Bright in Classroom & Conference Room
Packed with 3500 lumens and a high contrast ratio of 15,000:1 (w/ DynamicEco™), the
PJD6345 is guaranteed to shine bright–even in large classrooms and meeting rooms.
The ViewSonic®PJD6345 is an advanced
networkable XGA DLP®projector that delivers
vivid and brilliant images in any setting, from
large classrooms to corporate boardrooms.
Equipped with Crestron®LAN controller, the
PJD6345 makes it easy for IT admin to remotely
control and manage multiple projectors from
their workstations. Built with BrilliantColor™
technology, this projector produces vibrant
colors, while 3500 ANSI lumens and 15000:1
contrast ratio deliver stunning, razor-sharp
images. Certied with AMX®Device Discovery™,
the PJD6345 easily integrates into any size
campus or enterprise. In addition, the PJD6345
is packed with advanced features including wired
and wireless LAN display, USB display, a mobile
app for smart phones and tablets, capability
for PC-less presentations, 3D Blu-ray ready
HDMI, and integrated speakers. The PJD6345
is the perfect projector for both classroom and
corporate LAN environments.
Network Monitoring & Control
IT admin can monitor, schedule, and manage the projector remotely, as well as receive
projector status alerts, with the integrated Crestron®e-Control™system and RoomView
Express™management software. Because the PJD6345 is Crestron® and AMX® certied,
IT admin can control and monitor multiple projectors for any size campus or enterprise.
PC-less Presentation
Jump start your presentation without waiting for the PC to boot up. With a PC-less
presentation feature, you can display MS Ofce documents, PDFs, videos or images directly
from a USB ash drive.
Wireless & Wired LAN Display
With its advanced networking capability, the projector can project images via wireless,
or wired, LAN. The LAN display offers a quad split screen for simultaneously projecting
content from up to 4 PCs, with the ability to broadcast from up to 8 projectors. The
WPD-100 wireless adapter is required for wireless display.
Plug n’ Play USB Display
Project your presentations using a quick and simple plug-and-play USB connection
without running a bulky VGA cable. Plug n’ Play also features automatic resolution
detection for the best imaging experience.
Mobile App for Smart Phones & Tablets
With the optional WPD-100 wireless USB adapter, you can use ViewSonic's app on your
Android™ or iOS devices as a remote control for the projector. In addition, you can send
and project content such as MS Ofce documents, PDFs, videos, or images directly from
your mobile device. The ViewSonic mobile
app offers live draw and live cam functions
to create an interactive experience for
your presentation.

Specications
Sales: [phone] or [email protected] • More product information: www.ViewSonic.com
*Lamp life may vary based on actual usage and other factors. **One year Express Exchange®service requires product registration. Programs, specications and availability are subject to change without notice. Selection, offers and
programs may vary by country; see your ViewSonic representative for complete details.Corporate names, trademarks stated herein are the property of their respective companies, DLP®and DLP logo are registered trademarks of Texas Instruments
and BrilliantColor™ is a trademark of Texas Instruments. HDMI, the HDMI Logo, and High-Denition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. Copyright © 2013
ViewSonic Corporation. All rights reserved. [16453-00B-12/12]
ViewSonic Corporation’s QMS & EMS
have been registered to ISO 9001 & ISO
14001, respectively, by TUV NORD.
DISPLAY Type 0.55" Digital Micromirror Device (DLP™)
Resolution XGA 1024x768 (native)
Lens 1.1x Manual optical zoom / manual optical focus
Keystone Vertical digital keystone correction (+/- 40º)
Size 28 – 300 in. / 0.7 – 7.6 m (diagonal)
Throw Distance 3.9– 43.4 ft. / 1.2 – 13.2 m
Throw Ratio 1.97~2.17:1
Lamp 240 watt
Lamp Life 3500 / 5000 / 7000 hours* (Normal / Eco-mode / DynamicEco)
Brightness 3500 Lumens
Contrast Ratio 15,000:1 (w/ DynamicEco™)
Aspect Ratio 4:3 (native)
Color Depth 30 bits, 1.07B Color (10+10+10)
Color Wheel 5-seg RGBYW / 7200rpm
INPUT SIGNAL Computer and Video NTSC M (3.58 MHz), 4.43MHz, PAL (B, D, G, H, I, M, N, 60),
SECAM (B, D, G, K, K1, L), SD 480i and 576i, ED 480p and
576p, HD 720p, 1080i, 1080p
Frequency Fh: 31–100KHz, Fv: 48–120Hz
COMPATIBILITY PC VGA to 1600x1200 UXGA
Mac® Up to UXGA (may require MAC adaptor)
CONNECTOR RGB Input 15-pin mini D-sub (x2)
RGB Output 15-pin mini D-sub
Digital Input HDMI
Component Input 15-pin mini D-sub (x2, shared with RGB)
Composite Input RCA jack
S-Video Input 4-pin mini-DIN
Audio Input 3.5mm mini jack (x2)
Microphone Input 3.5mm mini jack (shared with Audio 2)
Audio Output 3.5mm mini jack
Control RS-232 (DB-9)
LAN RJ45
USB Type A (card reader and wireless dongle)
Type B (mouse control and service)
Mini Type B (USB display)
AUDIO Speaker 16-watt (x1)
POWER Voltage 100~240VAC (Auto Switching), 50/60Hz (universal)
Consumption 305W (typ) / <0.5W (stand-by mode)
CONTROLS Basic Power, keystone/arrow keys, left, menu/exit, right, source,
mode/enter, auto
OSD Picture, Video/Audio, Setting, Option, Language, Information
(See user guide for full OSD functionality)
OPERATING Temperature 32ºF–104ºF (0ºC–40ºC)
CONDITIONS Humidity 10%–90% (non-condensing)
Altitude 0~6,000 ft (1,800m), operational up to 10,000 ft (3,048m)
NOISE LEVEL Normal / Eco-mode 34dB / 32dB
DIMENSIONS Physical 11.6 x 4.5 x 8.6 in. / 294 x 113 x 219 mm
(W x H x D) Packaging 13.9 x 12.2 x 7.1 in. / 352 x 310 x 180 mm
WEIGHT Net 4.7 lbs. / 2.1 kg
Gross 7.4 lbs. / 3.3 kg
REGULATIONS CB, UL/cUL, FCC-B, NOM, KC, REACH, ErP, SVHC
UL-Argentina, PSB, C-tick, SASO, CE, GOST-R,
CCC, RoHS, WEEE, UkrSEPRO
WARRANTY 3-year limited warranty on parts and labor, 1-year limited
warranty on lamp, 1st year free Express Exchange® service**
Networkable XGA Projector
PJD6345
PJD6345 projector, power cable, VGA cable, remote control with batteries, Quick Start Guide,
ViewSonic Wizard DVD (with User Guide).
What's in the box?
Optional Accessories
Replacement Lamp ........................................RLC-084
Wall Mount Kit ..............................................WMK-005
3D Active Shutter Glasses......................... PGD-series
Wireless Presentation Gateway ................WPG-series
Wireless USB Adapter.................................. WPD-100
Soft Case................................................PJ-CASE-001
Extended 5-Year Limited Warranty.......PRJ-EW-07-02
Audio In / Out
AC Power Monitor Out
S-Video/Video Inputs
Type B USB
(Mouse Control &
Service)
3D Blu-ray Ready HDMI
HDMI delivers the highest picture and sound quality without degradation.
Equipped with the latest HDMI, ViewSonic's PJD6345 projector can
display 3D images directly from 3D Blu-ray® players—perfect for
connecting to any HDMI-enabled devices such as PCs, laptops, tablets,
and media players.
Long Lamp Life up to 5000 Hours
New and advanced lamp technology extends the
projector’s lamp life up to 5000* hours, resulting in huge
savings on lamp replacement costs.
RGB/Component
Video Inputs
Focus Ring
Control Panel
IR Remote Sensor
Projection Lens
Elevation Foot
Kensington®
Lock Slot
Projection Distance Screen Size (4:3)
Diagonal
Feet
5.2 - 5.8
10.5 - 11.6
15.8 - 17.4
19.7 - 21.7
26.2 - 29.0
32.8 - 36.2
39.4 - 43.4
Inches
40
80
120
150
200
250
300
Meters
1.6 - 1.8
3.2 - 3.5
4.8 - 5.3
6.0 - 6.6
8.0 - 8.8
10.0 - 11.0
12.0 - 13.2
Meters
1.0
2.0
3.0
3.8
5.1
6.4
7.6
Superior Color Performance
BrilliantColor™technology provides multi-color processing to produce
stunning, vibrant colors. Unlike other technologies that use just 3 primary
colors to produce the image (such as LCD), the PJD6345 uses up to
5 separate colors. The sophisticated 5-segment color wheel enhances
the yellow color performance that is key to accurate and vivid color
reproduction. With multi-color processing, colors are richer and more
vibrant with exquisite and precise detail.
Zoom Ring
Type A USB
(For card reader and
wireless dongle)
LAN RJ45
HDMI
Mini Type B USB
(USB Display)
RS-232
