PJ557D
LIGHT, BRIGHT AND
PORTABLE PROJECTOR
with BrilliantColor™
The ViewSonic®PJ557D DLP®projector features 2,300 lumens, native
1024x768 resolution, ultra-high 2000:1 contrast ratio and BrilliantColor™
for precise images in virtually any setting. This full-featured projector
includes MULTIPLE INPUTS for connecting a computer or video source,
DUAL 5-WATT SPEAKERS for complete multimedia presentations,
VERTICAL KEYSTONE CORRECTION for easy image adjustment
and DIRECT OFF FEATURE. Choose from whiteboard, blackboard
or greenboard mode for the best picture on your projected surface.
Eco-mode extends lamp life and reduces fan noise as low as 32 dB.
Protect your projector from theft and unauthorized use with the Kensington®
security port.
High brightness,
full-featured projector.
BRILLIANT PRESENTATIONS MADE EASY
>Bright in virtually any setting with 2,300 lumens
Packs 2,300 lumens in just 6 pounds. It’s the bright choice
for mobile presenters.
>BrilliantColor™technology
DLP®projectors with BrilliantColor™feature multi-color processing
to produce nearly 50% brighter colors for a vibrant image on the
screen that won’t fade over time.
>Ultimate video source flexibility
Connect a computer or add a video source for dynamic
meetings and presentations.
>Supports HD signals including 720p and 1080i
Capable of displaying HDTV signals as well as other
video and data sources.*
>Mulitple color correction modes
Blackboard, greenboard and whiteboard modes give you the best
possible picture regardless of the projection surface.
>OnView®controls for superior screen adjustability
Screen geometry and color adjustments are precisely
made via an easy-to-use on-screen menu.
>Eco-mode extends lamp life
Extend the life of your lamp up to
4,000 hours** and reduce noise output.
>My Screen Startup
Customize your startup with a company
logo or favorite picture using the
MyScreen function.

PJ557D
LIGHT, BRIGHT AND PORTABLE PROJECTOR WITH BrilliantColor™
PROJECTOR Type 0.55 DDR DMD, DLP®
Pixel Format 1024x768 XGA
Lens Manual zoom, manual focus
Zoom Factor 1.1
Keystone Vertical ± 40º
DISPLAY Size 27.2"–250" (diagonally)
Throw Distance 47.2"–393.6"
Throw Ratio 1.97–2.16:1
Lamp 180W, 3,500 hrs. normal, up to 4,000 hrs. eco-mode**
Brightness (max) 2,300 ANSI lumens
Contrast Ratio 2,000:1
Aspect Ratio 4:3 (native), 16:9
AUDIO Speakers 2x5-watt
INPUT SIGNAL Computer and Video RGB analog, NTSC, NTSC 4.43, PAL, SECAM,
HDTV (480p, 720p, 1080i)
Frequency Fh:31–79kHz; Fv:50–85Hz
COMPATIBILITY PC Analog: from VGA up to SXGA (scaled)
Mac®†Analog: up to SXGA
CONNECTOR RGB (input/output) 15-pin HD, D-sub (x2)
Composite Video (input) RCA jack
S-video (input) Mini-Din 4-pin
Component Video (input) VGA DB-15 to HDTV/component cable*
Audio (input/output) Stereo mini-jack
RS-232 6-pin D-sub
USB Type B for mouse control only and for firmware upgrade
POWER Voltage 100–240VAC, 50–60Hz (universal)
Consumption 250W (typ)
CONTROLS Basic Standby/on, input, menu
OnView®Display mode, brightness, contrast, keystone, aspect ratio, blank
screen, gamma, white peaking, color temperature, user color, video
(sharpness, saturation, tint), display (phase, tracking, H. postion, V.
postion), advance (auto source, select, rear, ceiling, eco-mode, lamp
hours, lamp reset, auto shutdown, OSD timeout, menu position,
factory reset), audio (audio mute)
OPERATING Temperature 32–104ºF (0–40ºC)
CONDITIONS Humidity 10–90% (non-condensing)
Altitude 0–10,000 ft.
NOISE LEVELS Normal / Eco-mode 34 dB (typ) / 32 dB (typ)
DIMENSIONS Physical (W x H x D) 8.9" x 4.3" x 8.8" (277mm x 109mm x 223mm)
WEIGHT Net 6.0 lb. (2.7 kg)
Gross 13.0 lb. (5.9 kg)
REGULATIONS UL/cUL, FCC-B, CE, CB, CCC, IRAM, NOM, ICES 003, RoHS
RECYCLE/DISPOSAL The lamp in this product contains mercury. Please
dispose of in accordance with local, state or federal laws.
PACKAGE CONTENTS Projector, power cable, VGA cable, S-video cable, remote
control with built-in laser, soft case, lens cap, Quick Start
Guide, ViewSonic Wizard CD (with User Guide)
WARRANTY 3-year limited warranty on parts and labor, 1-year limited
warranty on lamp, 1-year free Express Exchange®service.***
For more product information, visit us on the web at ViewSonic.com
Sales: [phone] • [email protected] • ViewSonic.com
*Optional cables required. **Running eco-mode exclusively can extend lamp life. ***See ViewSonic.com for full details. †Adapter may be required. Analog adapter available from ViewSonic. DLP®and the DLP logo are
registered trademarks of Texas Instruments and BrilliantColor™is a trademark of Texas Instruments. Specifications subject to change without notice. Selection, offers and programs may vary by country; see your ViewSonic
representative for complete details. Corporate names, trademarks stated herein are the property of their respective companies. Copyright © 2009 ViewSonic Corporation. All rights reserved. [14306-00B-02/09] PJ557D-1
ViewSonic Corporation’s QMS & EMS have been
registered to ISO 9001 & ISO 14001, respectively,
by the British Standards Institution.
Optional Accessories
• Replacement lamp............................RLC-034
• Soft case with wheels........................CASE-006
• Extended Express Exchange®..........PRJ-EE-05-03
• Universal ceiling mount kit ...............WMK-005
• VGA to component video adapter...ADPT-002
• Wireless G Presentation Gateway....WPG-150
