ViewSonic PJD7533w User manual

Advanced Connectivity for Large Classrooms and Boardrooms
High Bright
Networkable WXGA Projector
PJD7533w
High Bright for Large Classrooms & Corporate Boardrooms
Packed with 4,000 lumens and a high contrast ratio of 15,000:1 (w/ DynamicEco™), the
PJD7533w is guaranteed to shine bright – even in large lecture halls and meeting rooms.
The ViewSonic®PJD7533w is a high brightness
networkable WXGA DLP®projector that offers bright
widescreen images and advanced connectivity
for large university classrooms and corporate
boardrooms. Equipped with Crestron®LAN controller,
the PJD7533w makes it easy for IT admin to remotely
control and manage multiple projectors from their
workstations. Built with BrilliantColor™technology, this
projector produces vibrant colors, while 4000 ANSI
lumens and 15000:1 contrast ratio deliver bright,
razor-sharp images. Certified with AMX®Device
Discovery™, the PJD7533w easily integrates into any
size campus or enterprise. In addition, the PJD7533w
is packed with advanced features including wired and
wireless LAN display, USB display, a mobile app for
smart phones and tablets, DICOM mode, capability
for PC-less presentations, HDMI that is 3D Blu-ray
ready, 1.6x optical zoom lens, and integrated speaker.
The PJD7533w is the perfect projector for university
classrooms and corporate settings where a powerful
widescreen projection is necessary.
Network Monitoring & Control
IT admin can monitor, schedule, and manage the projector remotely, as well as receive
projector status alerts, with the integrated Crestron®e-Control™system and RoomView
Express™management software. Because the PJD7533w is Crestron®and AMX® certied,
IT admin can control and monitor multiple projectors for any size campus or enterprise.
PC-less Presentation
Jump start your presentation without waiting for the PC to boot up. With a PC-less
presentation feature, you can display MS Ofce documents, PDFs, videos or images directly
from a USB ash drive.
Wireless & Wired LAN Display
With its advanced networking capability, the projector can project images via wireless,
or wired, LAN. The LAN display offers a quad split screen for simultaneously projecting
content from up to 4 PCs, with the ability to broadcast from up to 8 projectors. The
WPD-100 wireless adapter is required for wireless display.
Mobile App for Smart Phones & Tablets
With the optional WPD-100 wireless USB adapter, you can use ViewSonic's app on your
Android™or iOS devices as a remote control for the projector. In addition, you can send and
project content such as MS Ofce documents, PDFs, videos, or images directly from your
mobile device. The ViewSonic mobile app
also offers live draw and live cam functions
to create an interactive experience for
your presentation.
Widescreen Brilliance
With a native 1280x800 (WXGA) resolution, the PJD7533w wide format projector offers
a tremendous degree of exibility and compatibility. Whether connecting a widescreen
notebook in the conference room, or watching 720p / 1080p HD content in the
classroom, a distortion-free image with matching aspect ratio is guaranteed.

Mini Type B USB
(USB Display)
Specications
Sales: [phone] or [email protected] • More product information: www.ViewSonic.com
*Lamp life may vary based on actual usage and other factors. **One year Express Exchange® service requires product registration. Programs, specications and availability are subject to change without notice. Selection, offers and
programs may vary by country; see your ViewSonic representative for complete details.Corporate names, trademarks stated herein are the property of their respective companies, DLP®and DLP logo are registered trademarks of Texas Instruments
and BrilliantColor™ is a trademark of Texas Instruments. HDMI, the HDMI Logo, and High-Denition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. Copyright © 2013
ViewSonic Corporation. All rights reserved. [16455-00B-12/12]
ViewSonic Corporation’s QMS & EMS
have been registered to ISO 9001 & ISO
14001, respectively, by TUV NORD.
DISPLAY Type 0.65" Digital Micromirror Device (DLP™)
Resolution WXGA 1200x800 (native)
Lens 1.6x Manual optical zoom / manual optical focus
Keystone Vertical digital keystone correction (+/- 40º)
Size 30 – 300 in. / 0.7 – 7.6 m (diagonal)
Throw Distance 3.9 – 32.8 ft. / 1.2 – 10.0 m
Throw Ratio 1.47~1.83:1
Lamp 330 watt
Lamp Life 2000 / 3500 hours* (Normal / Eco-mode)
Brightness 4000 Lumens
Contrast Ratio 15,000:1 (w/ DynamicEco™)
Aspect Ratio 16:10 (native)
Color Depth 30 bits, 1.07B Color (10+10+10)
Color Wheel 6-seg RGBCYW / 7200rpm
INPUT SIGNAL Computer and Video NTSC M (3.58 MHz), 4.43MHz, PAL (B, D, G, H, I, M, N, 60),
SECAM (B, D, G, K, K1, L), SD 480i and 576i, ED 480p and
576p, HD 720p, 1080i, 1080p
Frequency Fh: 31–100KHz, Fv: 24–120Hz
COMPATIBILITY PC VGA to 1600x1200 UXGA
Mac®Up to UXGA (may require MAC adaptor)
CONNECTOR RGB Input 15-pin mini D-sub (x2)
RGB Output 15-pin mini D-sub
Digital Input HDMI
Component Input 15-pin mini D-sub (x2, shared with RGB)
Composite Input RCA jack
S-Video Input 4-pin mini-DIN
Audio Input 3.5mm mini jack (x2)
Microphone Input 3.5mm mini jack (shared with Audio 2)
Audio Output 3.5mm mini jack
Control RS-232 (DB-9)
LAN RJ45
USB Type A (card reader and wireless dongle)
Type B (mouse control and service),
Mini Type B (USB display),
DC 12V Trigger 3.5mm plug 12V/1A
AUDIO Speaker 16-watt (x1)
POWER Voltage 100~240VAC (Auto Switching), 50/60Hz (universal)
Consumption 350W (typ) / <0.5W (stand-by mode)
CONTROLS Basic Power, keystone/arrow keys, left, menu/exit, right, source, enter
OSD Picture, Video/Audio, Setting, Option, Language, Information
(See user guide for full OSD functionality)
OPERATING Temperature 32ºF–104ºF (0ºC–40ºC)
CONDITIONS Humidity 10%–90% (non-condensing)
Altitude 0~6,000 ft (1,800m), operational up to 10,000 ft (3,048m)
NOISE LEVEL Normal / Eco-mode 34dB / 32dB
DIMENSIONS Physical 13.2 x 5.1 x 10.4 in. / 335 x 128.3 x 265 mm
(W x H x D) Packaging 15.0 x 13.5 x 9.5 in. / 383 x 342 x 242 mm
WEIGHT Net 6.7 lbs. / 3.0 kg
Gross 11.2 lbs. / 5.1 kg
REGULATIONS CB, UL/cUL, FCC-B, NOM, KC, REACH, ErP, SVHC
UL-Argentina, PSB, C-tick, SASO, CE, GOST-R,
CCC, RoHS, WEEE, UkrSEPRO
WARRANTY 3-year limited warranty on parts and labor, 1-year limited
warranty on lamp, 1st year free Express Exchange®service**
PJD7533w
PJD7533w projector, power cable, VGA cable, remote control with batteries, carrying case,
Quick Start Guide, ViewSonic Wizard DVD (with User Guide).
What's in the box?
Optional Accessories
Replacement Lamp ........................................RLC-081
Wall Mount Kit ..............................................WMK-005
3D Active Shutter Glasses......................... PGD-series
Wireless Presentation Gateway ................WPG-series
Wireless USB Adapter.................................. WPD-100
Soft Case................................................PJ-CASE-002
Extended 5-Year Limited Warranty.......PRJ-EW-07-02
Audio In / Out
AC Power Monitor Out
S-Video/Video Inputs
Type B USB
(Mouse Control &
Service)
RGB/Component
Video Inputs
3D Blu-ray Ready HDMI
HDMI delivers the highest picture and sound quality without
degradation. Equipped with the latest HDMI, ViewSonic's
PJD7533w projector can display 3D images directly from 3D
Blu-ray®players—perfect for connecting to any HDMI-enabled
devices such as PCs, laptops, tablets, and media players.
Focus Ring
Control Panel
IR Remote Sensor
Projection Lens
Quick elevation button
Kensington®
Lock Slot
Projection Distance Screen Size (16:10)
Diagonal
Feet
3.3 - 4.1
8.3 - 10.3
10.4 - 12.9
15.6 - 19.4
20.8 - 25.9
26.0 - 32.3
31.2 - 38.8
Inches
32
80
100
150
200
250
300
Meters
1.0 - 1.3
2.5 - 3.2
3.2 - 3.9
4.7 - 5.9
6.3 - 7.9
7.9 - 9.9
9.5 - 11.8
Meters
0.8
2.0
2.5
3.8
5.1
6.4
7.6
Zoom Ring
Type A USB
(For card reader and
wireless dongle)
LAN RJ45
HDMI
RS-232
Plug n’ Play USB Display
Project your presentations using a quick and simple plug-
and-play USB connection without running a bulky VGA cable.
Plug n’ Play also features automatic resolution detection for
the best imaging experience.
High Bright
Networkable WXGA Projector
DC 12V Out
DICOM SIM Mode Support
With the DICOM (Digital Imaging and Communications in Medicine) SIM mode,
ViewSonic’s PJD7533w is able to simulate and display multiple screens of X-rays,
sonograms, and nuclear magnetic resonance (NMR) images. Whether for medical
or educational presentations, the PJD7533w delivers the
most accurate and detailed images.
Wide Optical Zoom Lens
Equipped with a 1.6x optical zoom lens,
the PJD7533w provides mounting exibility
with a wider throw distance range. This
zoom lens also enables the projector to
project images up to 50% larger than
a conventional projector equipped with
a 1.1x lens.
