PJ258D
MICRO-PORTABLE PROJECTOR
WITH 2,000 LUMENS
ViewSonic’s PJ258D ViewDock™projector sets the bar for ultra-por-
table projectors for work and play by converging entertainment ex-
citement with professional practicality. The integrated iPod with video
dock lets you project video content directly from your iPod for larger-
than-life images. The array of connectivity options allows you to con-
nect a PC, DVD player, game console, and more for versatile presenta-
tions. The PJ258D uses Texas Instruments DLP®technology for RAZOR
SHARP DIGITAL IMAGES and brilliantly displays 2,000 lumens for use
in virtually any setting. The PJ258D is perfect for table top use in meet-
ing rooms and for the business traveler who needs a lightweight but
powerful projector. Its stylishly contoured design is sophisticated for
the contemporary professional on the go and the entertainment afi-
cionado by night.
Digital lifestyle iPod® projector.
VERSATILE PRESENTATIONS ANYWHERE.
Bright in virtually any setting with 2,000 lumens>
Packs 2,000 lumens in just 3.9 pounds. It’s the bright choice
for mobile presenters.
DLP>®technology
Stunning all-digital clarity delivers lifelike color, sharp graphics,
and outstanding video.
Ultimate video source flexibility>
Connect a computer or add a video source for dynamic meetings
and presentations.
Supports HD signals including 720p and 1080i>
Capable of displaying HD signals as well as other video
and data sources.*
Unplug and go>
Direct off feature lets you unplug the projector and go.
Life-size your iPod>®with video
Dock and charge your iPod with video in the projector’s docking
station. Share your videos, podcasts, games and presentations in
larger-than-life fashion.
3+1+1 warranty>
Covered by a three-year parts and labor limited warranty,
first-year Express Exchange®and one-year
limited lamp warranty.***

PJ258D
MICRO-PORTABLE VIEWDOCK™ PROJECTOR WITH 2,000 LUMENS
PROJECTOR Type 0.55 DDR DMD, DLP®
Pixel Format 1024x768 SVGA
Lens Manual zoom, manual focus
Zoom Factor 1.2
Keystone Vertical ± 15º
DISPLAY Size 40"–300" (diagonally)
Throw Distance 62.4"–468"
Throw Ratio 1.94–2.27:1
Lamp 200W, 2,000 hrs. normal, up to 3,000 hrs. eco-mode**
Brightness (max) 2,000 ANSI lumens
Contrast Ratio 2000:1 (max)
Aspect Ratio 4:3 (native), 16:9
AUDIO Speakers 1x1-watt
INPUT SIGNAL Computer and Video RGB analog, NTSC M, NTSC 4.43, PAL, (B, D, G, H, I, M,
N60), SECAM, (B,D, G, K, K1, L), 480i, HDTV (720p, 1080i)
Frequency Fh:31.5–79.8kHz; Fv:56–85Hz
COMPATIBILITY PC Analog: from VGA up to SXGA (scaled)
Mac®†Analog: to SXGA (may require a Mac adapter)
CONNECTOR RGB (input)/(output) 15-pin HD, D-sub cable
Composite Video (input) RCA jack (x1)
S-video (input) Mini-Din 4-pin (x1)
Component Video (input) VGA to RCA component adapter* (optional)
iPod Dock
POWER Voltage 100–240VAC, 50/60Hz (universal)
Consumption 280W (typ)
CONTROLS Basic Standby/on, input, menu
OnView®Display (mode, brightness, contrast, white intensity,
color temp, saturation), management (menu location,
projection, keystone, source lock, high altitude, translucence,
reset), frequency, phase, H. position, V. position, degamma,
aspect ratio, V. shift 16:9, OSD language, color setting,
lamp setting
OPERATING Temperature 32–104ºF (0–40ºC)
CONDITIONS Humidity 10–90% (non-condensing)
NOISE LEVELS Normal 37 dB (typ)
Eco-mode 34 dB (typ)
DIMENSIONS Physical (mm) 288mm x 190mm x 83mm
11.3” x 7.5” x 3.5”
WEIGHT Net 3.9 lb. (1.8 kg)
Gross 10.1 lb. (4.6 kg)
REGULATIONS UL, C-UL, FCC-B, CB, CE, GS, CCC, PSB, NOM
OTHER Whisper mode, iPod dock, optical zoom, wireless remote
control, soft carrying case, progressive scan, direct off for
unplug, and go, daylight mode
PACKAGE CONTENTS iPod dock, projector, power cords, VGA cable, RCA video
cable, remote control, soft case, lens cap, ViewSonic Wizard
CD, Quick Start Guide
WARRANTY Three-year limited warranty on parts and labor, first-year
Express Exchange®Service. One-year limited warranty on
lamp.***
RECYCLE/DISPOSAL The lamp in this product contains mercury. Please
dispose of in accordance with local, state or federal laws.
For more product information, visit us on the web at ViewSonic.com
Sales: [phone] • [email protected] • ViewSonic.com
*Optional cables required. **Running eco-mode exclusively can extend lamp life. ***Visit ViewSonic.com for full details. †Adapter may be required. Analog adapter available from ViewSonic. Specifications subject to
change without notice. Selection, offers and programs may vary by country; see your ViewSonic representative for complete details. DLP®is a registered trademark of Texas Instruments Inc in the United States and other
countries. Corporate names, trademarks stated herein are the property of their respective companies. Copyright © 2008 ViewSonic Corporation. All rights reserved. [14001-01B-10/08] PJ258D-1
Optional Accessories
• Replacement lamp............................ RLC-025
• Soft case with wheels........................CASE-006
• Extended Express Exchange®..........PRJ-EE-05-03
• VGA to component video adapter...ADPT-002
• Wireless G Presentation Gateway....WPG-150
