PJD5122 PJD5123 PJD6211 PJD5223 PJ260D PJL3211
Native Resolution SVGA
800×600
SVGA
800×600
XGA
1024x768
XGA
1024x768
XGA
1024x768
XGA
1024x768
Technology DLP®DLP®DLP®DLP®DLP®3LCD
Brightness Lumens (max) 2,700 2,700 2,500 2,700 2,000 3,000
Contrast Ratio (max) 3000:1 3000:1 2000:1 3000:1 2000:1 500:1
Display Size (in.) 30–300 27–300 30–300 27–300 40–300 30–300
Aspect Ratio 4:3 (native), 16:9 4:3 (native), 16:9 4:3 (native), 16:9 4:3 (native), 16:9 4:3 (native), 16:9 4:3 (native), 16:9
Minimum Projection
Throw Distance (in.) 47 47 47 47 63 31
Throw Ratio 1.86–2.04:1 1.97–2.17:1 1.6–1.9:1 1.97–2.17:1 1.9–2.25:1 1.3–1.5:1
Digital Keystone Correction Yes Yes Yes Yes Yes Yes, auto vert
Zoom/Focus Control Manual/Manual Manual/Manual Manual/Manual Manual/Manual Manual/Manual Manual/Manual
Energy Saving/Eco-mode Yes Yes Yes Yes Yes Yes
Noise Level (dB)
Normal/Eco-mode 32/26 32/30 31/29 32/30 38/32 41/34
Lamp Life** (hrs.)
Normal/Eco-mode 4,000/6,000 5,000/6,000 4,000/5,000 5,000/6,000 2,000/3,000 2,000/3,000
Altitude (ft.) 0–10,000 0–10,000 0–10,000 0–10,000 0–10,000 0–10,000
Lamp Type (watts) 220 180 180 180 200 190
Net Weight (lb.) 5.1 5.7 5.9 5.7 2.9 4.1
Integrated Speakers 1x5-watt 1x2-watt 1x2-watt 1x2-watt 1x1-watt 1x1-watt
Mac®Compatible* Yes Yes Yes Yes Yes Yes
Remote Control/Mouse Yes/No Yes/Yes Yes/Yes Yes/Yes Yes/No Yes/No
RGB Inputs/Outputs 2/1 2/1 2/1 2/1 1/– 2/–
Additional Inputs
S-video, component
(DB-15), composite,
audio, RS-232
S-video, component
(DB-15), composite,
audio, RS-232
S-video, component
(DB-15), composite,
audio, RS-232
S-video, component
(DB-15), composite,
audio, RS-232
S-video, composite,
audio
S-video, component
(DB-15), composite,
audio x2, RS-232
120Hz/3D Ready Yes Yes Yes Yes No No
Video Compatibility (typ) NTSC, PAL,
SECAM, HDTV
NTSC, PAL,
SECAM, HDTV
NTSC, PAL,
SECAM, HDTV
NTSC, PAL,
SECAM, HDTV
NTSC, PAL,
SECAM, HDTV
NTSC, PAL,
SECAM, HDTV
Dimensions W x H x D (in.) 10.4 x 3.8 x 8.86 11.2 x 3.2 x 9.2 11.0 x 4.5 x 8.6 11.2 x 3.2 x 9.2 8.6 x 2.7 x 6.7 10.8 x 2.3 x 8.1
Power Consumption - watts (typ) 280 235 235 235 260 310
Includes Soft Case No No No No Yes Yes
Limited Lamp Warranty 1-year 1-year 1-year 1-year 1-year 1-year
First-Year Express Exchange®FREE FREE FREE FREE FREE FREE
Limited Warranty 3-year 3-year 3-year 3-year 3-year 3-year
For the most current product accessories and specications, visit ViewSonic.com. *Adapter may be required. Analog adapter available from ViewSonic. **Running eco-mode or whisper-mode exclusively can extend lamp life. †Optional
RGB to component video adapter required. DLP is a registered trademark of Texas Instruments, Inc. in the United States and/or other countries. Specications subject to change without notice. Selection, offers and programs may vary by
country; see your ViewSonic representative for complete details. Corporate names, trademarks stated herein are the property of their respective companies. Copyright © 2011 ViewSonic Corporation. All rights reserved. [15509-01B-04/11]
page 1 of 4
Support
Unmatched
ViewSonic has on of
the best product
warranty and
service support
in the business!
3-Year
Parts and labor limited warranty
1-Year
Free Express Exchange®service
1-Year Limited lamp warranty
ViewSonic®Projectors
2011
Sales: [phone] . [email protected] . ViewSonic.com
ViewSonic Projectors
Award-winning. Innovative. Dependable.
ViewSonic brings you the most complete line
of performance LCD and DLP®projectors from
road-ready portables to models designed for
large venues and entertainment. When you’re
navigating through a forest of projector options,
let the visual experts at ViewSonic guide you.
Entry SVGA Entry XGA Ultra Portable

Short Throw Interactive Short Throw
PJD5152 PJD5352 PJD6381 PJD7382 PJD7383 PJD7583w PJD7383i PJD7583wi
Native Resolution SVGA
800x600
XGA
1024x768
XGA
1024x768
XGA
1024x768
XGA
1024x768
WXGA
1280x800
XGA
1024x768
WXGA
1280x800
Technology DLP®DLP®DLP®DLP®DLP®DLP®DLP®DLP®
Brightness Lumens (max) 2,600 2,600 2,500 3,000 3,000 3,000 3,000 3,000
Contrast Ratio (max) 3000:1 3000:1 2400:1 3000:1 3000:1 3000:1 3000:1 3000:1
Display Size (in.) 30-300 30-300 30–300 30-300 30-300 30-300 30-300 30-300
Aspect Ratio 4:3 (native), 16:9 4:3 (native), 16:9 4:3 (native), 16:9 4:3 (native), 16:9 4:3 (native) 16:10 (native), 16:9,
4:3 4:3 (native) 16:10 (native), 16:9, 4:3
Minimum Projection
Throw Distance (in.) 27 22 16 19.6 15 13 15 13
Throw Ratio 0.9:1-1.08:1 0.9:1 0.68:1 0.61:1 0.61:1 0.5:1 0.61:1 0.5:1
Digital Keystone Correction Yes Yes Yes Yes Yes Yes Yes Yes
Zoom/Focus Control Manual/Manual Manual/Manual Manual/Auto Digital/Manual Digital/Manual Digital/Manual Digital/Manual Digital/Manual
Energy Saving/Eco-mode Yes Yes Yes Yes Yes Yes Yes Yes
Noise Level (dB)
Normal/Eco-mode 32/26 32/26 30/29 32/27 32/27 32/27 32/27 32/27
Lamp Life** (hrs.)
Normal/Eco-mode 4,000/6,000 4,000/6,000 4,000/6,000 4,000/6,000 4,000/6,000 4,000/6,000 4,000/6,000 4,000/6,000
Altitude (ft.) 0–10,000 0–10,000 0–10,000 0–10,000 0–10,000 0–10,000 0–10,000 0–10,000
Lamp Type (watts) 220 220 230 210 210 210 210 210
Net Weight (lb.) 5.5 5.5 5.9 7.7 7.7 7.7 7.7 7.7
Integrated Speakers 1x5-watt 1x5-watt 2x5-watt 1x10-watt 1x10-watt 1x10-watt 1x10-watt 1x10-watt
Mac® Compatible* Ye s Ye s Ye s Ye s Ye s Ye s Ye s Ye s
Remote Control/Mouse Yes/No Yes/No Yes/Yes Yes/no Yes/Yes Yes/Yes Yes/Yes Yes/Yes
RGB Inputs/Outputs 2/1 2/1 2/1 2/1 2/1 2/1 2/1 2/1
Additional Inputs
S-video, component (DB-
15), composite, audio,
RS-232
S-video, component (DB-
15), composite, audio,
RS-232
S-video, component (DB-
15), composite, audio x2,
RJ-45, RS-232
S-video, component (DB-
15), composite, audio x2,
RJ-45, RS-232
S-video, component (DB-
15), composite, audio x2,
RJ45, USB, RS-232
S-video, component (DB-
15), composite, audio x2,
RJ45, USB, RS-232
S-video, component (DB-
15), composite, audio x2,
RJ45, USB, RS-232
S-video, component (DB-
15), composite, audio x2,
RJ45, USB, RS-232
120Hz/3D Ready Yes Yes Yes Yes Yes Yes Yes Yes
Video Compatibility (typ) NTSC, PAL,
SECAM, HDTV
NTSC, PAL,
SECAM, HDTV
NTSC, PAL,
SECAM, HDTV
NTSC, PAL
SECAM, HDTV
NTSC, PAL
SECAM, HDTV
NTSC, PAL
SECAM, HDTV
NTSC, PAL
SECAM, HDTV
NTSC, PAL
SECAM, HDTV
Dimensions- W x H x D (in.) 10.4 x 3.8 x 8.9 10.4 x 3.8 x 8.9 11 x 4.5 x 8.6 11.4x5.0x10.0 11.4x5.0x10.0 11.4x5.0x10.0 11.4x5.0x10.0 11.4x5.0x10.0
Power Consumption - watts (typ) 280 280 305 296 298 296 298 296
Includes Soft Case No Yes Yes No No No Yes Yes
Limited Lamp Warranty 1-year 1-year 1-year 1-year 1-year 1-year 1-year 1-year
First-Year Express Exchange®FREE FREE FREE FREE FREE FREE FREE FREE
Limited Warranty 3-year 3-year 3-year 3-year 3-year 3-year 3-year 3-year
page 2 of 4
For the most current product accessories and specications, visit ViewSonic.com. *Adapter may be required. Analog adapter available from ViewSonic. **Running eco-mode or whisper-mode exclusively can extend lamp life. †Optional
RGB to component video adapter required. DLP is a registered trademark of Texas Instruments, Inc. in the United States and/or other countries. Specications subject to change without notice. Selection, offers and programs may vary by
country; see your ViewSonic representative for complete details. Corporate names, trademarks stated herein are the property of their respective companies. Copyright © 2011 ViewSonic Corporation. All rights reserved. [15509-01B-04/11]
ViewSonic®Projectors
2011
Sales: [phone] . [email protected] . ViewSonic.com

page 3 of 4
For the most current product accessories and specications, visit ViewSonic.com. *Adapter may be required. Analog adapter available from ViewSonic. **Running eco-mode or whisper-mode exclusively can extend lamp life. †Optional
RGB to component video adapter required. DLP is a registered trademark of Texas Instruments, Inc. in the United States and/or other countries. Specications subject to change without notice. Selection, offers and programs may vary by
country; see your ViewSonic representative for complete details. Corporate names, trademarks stated herein are the property of their respective companies. Copyright © 2011 ViewSonic Corporation. All rights reserved. [15509-01B-04/11]
ViewSonic®Projectors
2011
Sales: [phone] . [email protected] . ViewSonic.com
PJD5523w PJD6531w PJD6221 PJD6241 PJD6251 PJL6233 PJL6243
Native Resolution WXGA
1280x800
WXGA
1280x800
1080p
1920x1080
1080p
1920x1080
WXGA
1280x800
XGA
1024x768
XGA
1024x768
Technology DLP®DLP®DLP®DLP®DLP®3LCD 3LCD
Brightness Lumens (max) 2,700 3,200 2,000 4,000 4,500 2,600 3,000
Contrast Ratio (max) 3000:1 3200:1 4000:1 3000:1 4300:1 500:1
4200:1 (with active IRS)
Display Size (in.) 27–300 27–300 30–300 30–300 30–350 40–300 40–300
Aspect Ratio 16:10 (native), 16:9, 4:3 16:10 (native), 16:9, 4:3 16:9 (native), 4:3 16:9 (native), 4:3 16:10 (native),
16:9, 4:3 4:3 (native), 16:9 4:3 (native), 16:9
Minimum Projection
Throw Distance (in.) 55 27 36 36 47 51 43
Throw Ratio 1.47–1.83:1 1.7:1–2.1:1 1.4–2.14:1 1.4–2.14:1 1.46–2.2:1 1.62–1.92:1 1.43–1.72:1
Digital Keystone Correction Yes Yes Yes Yes Yes Yes Yes
Zoom/Focus Control Manual/Manual Manual/Manual Manual/Manual Manual/Manual Manual/Manual Manual/Manual Manual/Manual
Energy Saving/Eco-mode Yes Yes Yes Yes Yes Yes Yes
Noise Level (dB)
Normal/Eco-mode 32/30 34/29 31/27 33/29 32/27 34/29 34/29
Lamp Life** (hrs.)
Normal/Eco-mode 5,000/6,000 4,000/6,000 4,000/6,000 4,000/5,000 4,000/5,000 4,000/6,000 4,000/6,000
Altitude (ft.) 0–10,000 0–10,000 0–10,000 0–10,000 0–10,000 0–10,000 0–10,000
Lamp Type (watts) 180 230 230 280 280 215 215
Net Weight (lb.) 5.7 5.9 8.5 8.5 8.6 5.7 6.4
Integrated Speakers 1x2-watt 2x5-watt 2x10-watt 2x10-watt 2x10-watt 1x1-watt 1x10-watt
Mac® Compatible* Yes Yes Yes Yes Yes Yes Yes
Remote Control/Mouse Yes/Yes Yes/Yes Yes/Yes Yes/Yes Yes/Yes Yes/No Yes/No
RGB Inputs/Outputs 2/1 2/1 2/1 2/1 2/1 2/1 2/1
Additional Inputs
HDMI, S-video, compo-
nent (DB-15), composite,
audio, RS-232
HDMI, S-video, compo-
nent (DB-15), composite,
audio x2, RJ-45, RS-232
HDMI x2, S-video, compo-
nent, composite, audio x3,
RS-232
HDMI x2, S-video, compo-
nent, composite, audio x3,
RJ-45, USB, RS-232
HDMI, S-video, compo-
nent, composite, audio x3,
RJ-45, USB, RS-232
S-video (DB-15), compo-
nent (DB-15), composite,
audio x2, RJ-45, RS-232
S-video (DB-15), compo-
nent (DB-15), composite,
audio x2, RJ-45, RS-232
120Hz/3D Ready Yes Yes No No Yes No No
Video Compatibility (typ) NTSC, PAL,
SECAM, HDTV
NTSC, PAL,
SECAM, HDTV
NTSC, PAL,
SECAM, HDTV
NTSC, PAL,
SECAM, HDTV
NTSC, PAL,
SECAM, HDTV
NTSC, PAL,
SECAM, HDTV
NTSC, PAL,
SECAM, HDTV
Dimensions- W x H x D (in.) 11.2 x 3.2 x 9.2 11.0 x 4.5 x 8.6 13.0 x 4.3 x 10.4 13.0 x 4.8 x 10.4 13.1 x 4.8 x 10.4 13.4 x 4.2 x 9.9 13.4 x 4.6 x 9.9
Power Consumption - watts (typ) 235 305 310 360 350 284 286
Includes Soft Case No Yes Yes Yes Yes No No
Limited Lamp Warranty 1-year 1-year 1-year 1-year 1-year 1-year 1-year
First-Year Express Exchange® FREE FREE FREE FREE FREE FREE FREE
Limited Warranty 3-Year 3-year 3-Year 3-Year 3-Year 3-Year 3-Year
Business & Education
Wide Format

Projector Replacement Lamps
ViewSonic offers longlife, user-installable
replacement lamps for all our projectors.
Projectors Cases and Mounts
Visit ViewSonic.com for a full list of projector
accessories.
page 4 of 4
For the most current product accessories and specications, visit ViewSonic.com. *Adapter may be required. Analog adapter available from ViewSonic. **Running eco-mode or whisper-mode exclusively can extend lamp life. †Optional
RGB to component video adapter required. DLP is a registered trademark of Texas Instruments, Inc. in the United States and/or other countries. Specications subject to change without notice. Selection, offers and programs may vary by
country; see your ViewSonic representative for complete details. Corporate names, trademarks stated herein are the property of their respective companies. Copyright © 2011 ViewSonic Corporation. All rights reserved. [15509-01B-04/11]
ViewSonic®Projectors
Sales: [phone] . [email protected] . ViewSonic.com
Model # Lamp for:
RLC-023 PJ558D
RLC-025 PJ258D
RLC-026 PJ588D
RLC-027 PJ358
RLC-030 PJ503D
RLC-031 PJ759
RLC-033 PJ260D
RLC-034
PJ551D
PJ557D
PJD6220
RLC-036 PJ559D
PJD6230
RLC-037 PJ560D
PJD6240
RLC-038 PJ1173
RLC-039 PJ359w
PJL3211
RLC-041 PJD5111
RLC-047 PJD5351
RLC-049
PJD6381
PJD6241
PJD6531w
Model # Description
WMK-005 Universal ceiling mount
(not compatible with 2 lb. projectors)
WMK-027 Short throw wall mount
(short throw and interactive short throw projectors)
Model # Lamp for:
RLC-050
PJD6211
PJD6221
PJD5112
RLC-051 PJD6251
RLC-052 PJD2121
RLC-053 PJL9371
RLC-054 PJL7211
RLC-055
PJD5122
PJD5152
PJD5352
RLC-057
PJD7382
PJD7383
PJD7583w
PJD7383i
PJD7583wi
RLC-059
Pro8450w
Pro8500
Pro8400
RLC-061 Pro8200
RLC-063 Pro9500
RLC-065 PJL6233
PJL6243
RLC-072
PJD5123
PJD5223
PJD5523w
PJL9371 PJ1173 Pro8200 Pro8400 Pro8450w Pro8500 Pro9500
Native Resolution XGA
1024x768
XGA
1024x768
1080p
1920x1080
1080p
1920x1080
WXGA
1280x800
XGA
1024x768
XGA
1024x768
Technology 3LCD 3LCD DLP®DLP®DLP®DLP®3LCD
Brightness Lumens (max) 4,000 5,000 2,000 4,000 4,500 5,000 5,000
Contrast Ratio (max) 2000:1 1000:1 4000:1 3000:1 4300:1 4900:1 3500:1
Display Size (in.) 30–300 30–350 30–300 30–300 30–350 30–300 30–300
Aspect Ratio 4:3 (native),
16:9
4:3 (native),
16:9
16:9 (native),
4:3
16:9 (native),
4:3
16:10 (native),
16:9, 4:3
4:3 (native),
16:9
4:3 (native),
16:9
Minimum Projection
Throw Distance (in.) 35 35 36 36 47 47 35
Throw Ratio 1.5–1.8:1 1.5–1.8:1 1.4–2.14:1 1.4–2.14:1 1.46–2.2:1 1.45–2.18:1 1.5–2.5:1
Digital Keystone Correction Yes, auto vert Yes, auto vert Yes Yes Yes Yes Yes
Zoom/Focus Control Manual/Manual Manual/Manual Manual/Manual Manual/Manual Manual/Manual Manual/Manual Manual/Manual
Energy Saving/Eco-mode Yes Yes Yes Yes Yes Yes Yes
Noise Level (dB)
Normal/Eco-mode 36/29 39/33 31/27 33/29 32/27 32/27 36/29
Lamp Life** (hrs.)
Normal/Eco-mode 3,000/5,000 2,000/3,000 4,000/6,000 4,000/5,000 4,000/5,000 4,000/5,000 3,000/5,000
Altitude (ft.) 0-12,000 0–12,000 0–10,000 0–10,000 0–10,000 0–10,000 0–6,000
Lamp Type (watts) 260 275 230 280 280 280 245
Net Weight (lb.) 9.5 15.6 8.5 8.5 8.6 8.5 10.4
Integrated Speakers 2x8-watt 4x4-watt 2x10-watt 2x10-watt 2x10-watt 2x10-watt 2x8-watt
Mac® Compatible* Yes Yes Yes Yes Yes Yes Yes
Remote Control/Mouse Yes/Yes Yes/Yes Yes/Yes Yes/Yes Yes/Yes Yes/Yes Yes/Yes
RGB Inputs/Outputs 2/1 3/1 2/1 2/1 2/1 2/1 1/1
Additional Inputs
S-video, component,
composite, audio x2,
RS-232
HDMI, RGB-BNC,
S-video, component,
composite, audio x3,
RJ-45, RS-232
HDMI x2, S-video,
component, compos-
ite, audio x3, RS-232
HDMI x2, S-video,
component, compos-
ite, audio x3, RJ-45,
USB, RS-232
HDMI, S-video, com-
ponent, composite,
audio x3, RJ-45,
USB, RS-232
HDMI, S-video, com-
ponent, composite,
audio x3, RJ-45,
USB, RS-232
HDMI, RGB-BNC,
S-video, component,
composite, audio x3,
RJ-45, USB, RS-232
120Hz/3D Ready No No No No Yes Yes No
Video Compatibility (typ) NTSC, PAL,
SECAM, HDTV
NTSC, PAL,
SECAM, HDTV
NTSC, PAL,
SECAM, HDTV
NTSC, PAL,
SECAM, HDTV
NTSC, PAL,
SECAM, HDTV
NTSC, PAL,
SECAM, HDTV
NTSC, PAL,
SECAM, HDTV
Dimensions- W x H x D (in.) 9.5 x 3.9 x 12.5 16.5 x 5.5 x 12.6 13.0 x 4.3 x 10.4 13.0 x 4.8 x 10.4 13.1 x 4.8 x 10.4 13.1 x 4.8 x 10.4 16.0 x 4.0 x 12.5
Power Consumption - watts (typ) 390 460 310 360 350 350 420
Includes Soft Case No No Ye s Ye s No No No
Limited Lamp Warranty 1-year 1-year 1-year 1-year 1-year 1-year 1-year
First-Year Express Exchange® FREE FREE FREE FREE FREE FREE FREE
Limited Warranty 3-Year 3-Year 3-Year 3-Year 3-Year 3-Year 3-Year
2011
Installation / Large Venue
