ViewSonic PX701HDH User manual

PX701HD
PX701HDH
Projector
User Guide
Model No. VS17689
Model Name: PX701HD | PX701HDH
IMPORTANT: Please read this User Guide to obtain important information on installing and using your product
in a safe manner, as well as registering your product for future service. Warranty information contained in this
User Guide will describe your limited coverage from ViewSonic Corporation, which is also found on our web site at
http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right
corner of our website.

2
Thank you for choosing ViewSonic®
As a world-leading provider of visual soluons, ViewSonic® is dedicated to exceeding the
world’s expectaons for technological evoluon, innovaon, and simplicity. At ViewSonic®,
we believe that our products have the potenal to make a posive impact in the world, and
we are condent that the ViewSonic® product you have chosen will serve you well.
Once again, thank you for choosing ViewSonic®!

3
Safety Precautions - General
Please read the following Safety Precautions before you start using the projector.
• Keep this user guide in a safe place for later reference.
• Read all warnings and follow all instructions.
• Allow at least 20“ (50 cm) clearance around the projector to ensure proper
ventilation.
• Place the projector in a well-ventilated area. Do not place anything on the
projector that prevents heat dissipation.
• Do not place the projector on an uneven or unstable surface. The projector may
fall over, causing personal injury or projector malfunction.
• Do not use if the projector is tilted at an angle of more than 10° degrees left or
right, nor at an angle of more than 15° degrees forwards or backwards.
• Do not look straight at the projector lens during operation. The intense light
beam may damage your eyes.
• Always open the lens shutter or remove the lens cap when the projector lamp is
on.
• Do not block the projection lens with any objects when the projector is under
operation as this could cause objects to become heated and deformed or even
cause a fire.
• The lamp becomes extremely hot during operation. Allow the projector to
cool for approximately 45 minutes prior to removing the lamp assembly for
replacement.
• Do not use lamps beyond the rated lamp life. Excessive use of lamps beyond the
rated life could cause them to break on rare occasions.
• Never replace the lamp assembly or any electronic component unless the
projector is unplugged.
• Do not attempt to disassemble the projector. There are dangerous high voltages
inside which may cause death if you should come into contact with live parts.
• When moving the projector, be careful not to drop or bump the projector on
anything.
• Do not place any heavy objects on the projector or connection cables.
• Do not stand the projector on end vertically. Doing so may cause the projector
to fall over, causing personal injury or projector malfunction.
• Avoid exposing the projector to direct sunlight or other sources of sustained
heat. Do not install near any heat sources such as radiators, heat registers,
stoves, or other devices (including amplifiers) that may increase the
temperature of the projector to dangerous levels.

4
• Do not place liquids near or on the projector. Liquids spilled into the projector
may cause it to fail. If the projector does become wet, disconnect it from the
power supply and call your local service center to have the projector serviced.
• When the projector is under operation, you may sense some heated air and
odor from its ventilation grill. It is a normal operation and not a defect.
• Do not attempt to circumvent the safety provisions of the polarized or
grounding-type plug. A polarized plug has two blades with one wider than the
other. A grounding-type plug has two blades and a third grounding prong. The
wide and third blade are provided for your safety. If the plug does not fit into
your outlet, obtain an adapter and do not attempt to force the plug into the
outlet.
• When connecting to a power outlet, DO NOT remove the grounding prong.
Please ensure grounding prongs are NEVER REMOVED.
• Protect the power cord from being treaded upon or pinched, particularly at the
plug, and at the point where it emerges from the projector.
• In some countries, the voltage is NOT stable. This projector is designed to
operate safely within a voltage between 100 to 240 volts AC, but could fail if
power cuts or surges of ±10 volts occur. In areas where voltage may fluctuate
or cut out, it is recommended that you connect your projector through a power
stabilizer, surge protector, or uninterruptable power supply (UPS).
• If smoke, an abnormal noise, or a strange odor is present, immediately switch
the projector off and call your dealer or ViewSonic®. It is dangerous to continue
using the projector.
• Use only attachments/accessories specified by the manufacturer.
• Disconnect the power cord from the AC outlet if the projector is not being used
for a long period of time.
• Refer all servicing to qualified service personnel.
CAUTION: Possibly hazardous optical radiation is emitted from this product. As
with any bright light source, do not stare into the beam,
RG2 IEC 62471-5:2015.

5
Safety Precautions - Ceiling Mounting
Please read the following Safety Precautions before you start using the projector.
If you intend to mount the projector on the ceiling, we strongly recommend
that you use a proper fitting projector ceiling mount kit and that you ensure it is
securely and safely installed.
If you use an inappropriate projector ceiling mount kit, there is a safety risk that the
projector may fall from the ceiling due to an improper attachment through the use
of the wrong gauge or length screws.
You can purchase a projector ceiling mount kit from the place you purchased your
projector. We recommend that you also purchase a separate security cable and
attach it securely to both the anti-theft lock slot on the projector and the base of
the ceiling mount bracket. This will perform the secondary role of restraining the
projector should its attachment to the mounting bracket become loose.

6
Contents
Safety Precautions - General ....................................... 3
Safety Precautions - Ceiling Mounting ......................... 5
Introduction .............................................................. 10
Features................................................................................................................10
Package Contents .................................................................................................10
Product Overview.................................................................................................11
Projector................................................................................................................ 11
Controls and Functions ............................................................................................... 11
Connection Ports......................................................................................................... 12
Remote Control..................................................................................................... 13
Controls and Functions ............................................................................................... 13
Remote Control Effective Range................................................................................. 14
Replacing the Remote Control Batteries..................................................................... 14
Initial Setup............................................................... 15
Choosing a Location..............................................................................................15
Projection Dimensions..........................................................................................16
16:9 Image on a 16:9 Screen................................................................................. 16
16:9 Image on a 4:3 Screen................................................................................... 17
Mounting the Projector........................................................................................18
Preventing Unauthorized Use...............................................................................19
Using the Security Slot .......................................................................................... 19
Using the Password Function................................................................................ 20
Setting a Password...................................................................................................... 20
Changing the Password............................................................................................... 21
Disabling the Password Function ................................................................................ 21
Forgetting the Password............................................................................................. 22
Password Recall Procedure......................................................................................... 22
Locking the Control Keys....................................................................................... 23

7
Making Connections.................................................. 24
Connecting to Power ............................................................................................24
Connecting to Video Sources................................................................................25
HDMI Connection.................................................................................................. 25
Connecting to Computer Sources.........................................................................26
VGA Connection .................................................................................................... 26
VGA Out Connection ............................................................................................. 26
Connecting to Audio.............................................................................................27
Operation.................................................................. 28
Turning the Projector On/Off ...............................................................................28
Starting Up the Projector ...................................................................................... 28
First Time Activation ................................................................................................... 28
Shutting Down the Projector................................................................................. 29
Selecting an Input Source.....................................................................................30
Adjusting the Projected Image .............................................................................31
Adjusting the Projector's Height and Projection Angle............................................... 31
Auto-Adjusting the Image ........................................................................................... 31
Fine-Tuning the Image Size and Clarity ................................................................. 31
Correcting Keystone.............................................................................................. 32
Controllability of the Projected Image .................................................................. 32
Hiding the Image ..................................................................................................33
Menu Functions ........................................................ 34
General On-Screen Display (OSD) Menu Operation .............................................34
On-Screen Display (OSD) Menu Tree....................................................................35
DISPLAY Menu ......................................................................................................40
IMAGE Menu ........................................................................................................43
POWER MANAGEMENT Menu .............................................................................47
BASIC Menu..........................................................................................................50
ADVANCED Menu .................................................................................................52
SYSTEM Menu.......................................................................................................55
INFORMATION Menu ...........................................................................................57

8
Appendix................................................................... 58
Specifications........................................................................................................58
Projector Dimensions............................................................................................ 59
Timing Chart .........................................................................................................59
Analog RGB............................................................................................................ 59
HDMI (PC).............................................................................................................. 60
HDMI (Video)......................................................................................................... 62
IR Control Table ....................................................................................................62
Address Code........................................................................................................63
RS-232 Command Table .......................................................................................64
Pin Assignment...................................................................................................... 64
Interface................................................................................................................ 64
Command Table .................................................................................................... 64
Glossary ................................................................................................................70
Troubleshooting ...................................................................................................73
Common Problems................................................................................................ 73
LED Indicators........................................................................................................ 74
Maintenance.........................................................................................................75
General Precautions.............................................................................................. 75
Cleaning the Lens .................................................................................................. 75
Cleaning the Case.................................................................................................. 75
Storing the Projector............................................................................................. 75
Disclaimer.............................................................................................................. 75
Lamp Information.................................................................................................76
Lamp Hour............................................................................................................. 76
Extending Lamp Life .............................................................................................. 76
Lamp Replacement Timing.................................................................................... 77
Replacing the Lamp............................................................................................... 77

9
Regulatory and Service Information .......................... 78
Compliance Information.......................................................................................78
FCC Compliance Statement................................................................................... 78
Industry Canada Statement................................................................................... 78
CE Conformity for European Countries ................................................................. 78
Declaration of RoHS2 Compliance......................................................................... 79
Indian Restriction of Hazardous Substances ......................................................... 80
Product Disposal at End of Product Life................................................................ 80
Copyright Information ..........................................................................................81
Customer Service .................................................................................................. 82
Limited Warranty .................................................................................................. 83
Mexico Limited Warranty...................................................................................... 86

10
Introduction
The ViewSonic PX701HD/HDH is a high brightness 3,500 ANSI Lumens projector
featuring a Full HD 1080p resolution that offers impressive visual performance in
a brightly lit living room or meeting room. The projector adopts the latest lamp
design to extend lamp life of up to 20,000 hours under SuperEco+ mode, effectively
reducing lamp replacement and maintenance costs. A digital lens shift allows users
to make adjustments by remote control. It’s also compatible with the vColorTuner
function for color profile exchange and adjustments. The dual HDMI inputs and
USB power supply allow users to connect to a multitude of multimedia devices for
gaming, movies, or a wireless dongle for wireless presentation.
Features
• Amazing 20,000 hours lamp life.
• Power saving funcon that decreases the lamp power consumpon by up to 60%
when no input signal is detected for a set me period.
• Firmware updates via USB Type A.
• USB Type A port can provide streaming with an HDMI wireless dongle and supply power.
• 7 color modes for dierent projecon purposes.
• Presentaon mer for beer me management during presentaons.
• Vercal Lens Shi by remote control.
• 3D display supported.
• Less than 0.5W power consumpon when power saving mode is turned on.
• Quick Auto Search, thus speeding up the signal detecng process.
• One-key auto-adjustment for displaying the best picture quality (only for analog signal).
• Digital keystone correcon.
• Ability to display 1.07 billion colors.
• Mul-language On-Screen Display (OSD) menus.
• HDMI CEC (Consumer Electronics Control) funcon allowing synchronized power
ON/OFF operaon between the projector and a CEC-compable DVD player
device connected to the HDMI input of the projector.
Package Contents
• Projector
• Power cord
• Video cable
• Remote Control & Baeries
• Quick Start Guide
NOTE: The power cord and video cables included in your package may vary depending
on your country. Please contact your local reseller for more informaon.

11
Product Overview
Projector
Controls and Functions
EXIT
MENU
SOURCE
ENTER
BLANK
MODE
COLOR
Power Indicator
Light
Temperature Indicator Light
Lamp Indicator Light
Focus Ring
Zoom Ring
Projection Lens
Vent (heated air
exhaust)
Remote IR sensor
Key Description
[ ] Power Toggles the projector between standby mode and Power On.
[ / ] Keystone Keys Manually corrects distorted images resulting from an angled
projection.
[ / / / ]
Left/Right/Up/Down
Selects the desired menu items and makes adjustments
when the On-Screen Display (OSD) Menu is activated.
Menu/Exit Turns on or off the On-Screen Display (OSD) Menu.
Source Displays the input source selection bar.
Blank Hides the screen picture.
Enter Enacts the selected On-Screen Display (OSD) Menu item
when the OSD Menu is activated.
[ ] Volume Up Increases the volume level.
[ ] Volume Down Decreases the volume level.
Color Mode Displays the color mode selection bar.

1212
Connection Ports
12 3 5 6 7 8
4
AC Power Cord Inlet
Ceiling Mount Holes
Security Slot
Security Bar
Adjuster Foot
Port Description
1 AUDIO OUT Audio signal output socket.
2 AUDIO IN Audio signal input socket.
3HDMI 1 HDMI port.
4 HDMI 2 HDMI port.
5USB 5V/1.5A Out
(Service) USB Type A port for power supply.
6 COMPUTER IN1RGB (PC) signal input socket.
7 MONITOR OUT1RGB (PC) signal output socket.
8 RS-232 RS-232 control port.
1 - Available for PX701HD

13
Remote Control
Controls and Functions
Button Description
On/ Off Toggles between standby
mode and Power On.
COMP2
Selects source from
COMPUTER IN port for
display.
VIDEO Not available.
HDMI
Selects source from HDMI 1
or HDMI 2 port for display.
Press this button repeatedly
to switch between the 2
ports.
Auto Sync
Automatically determines
the best picture timings for
the displayed image.
Source Displays the source selection
bar.
2 - Available for PX701HD
Button Description
[ / ]
Keystone Keys
Manually corrects distorted
images resulting from an
angled projection.
Enter Enacts the selected OSD
Menu item.
Left/ Right
Up/ Down
Selects the desired
menu items and makes
adjustments.
Menu
Turns on/off the On-Screen
Display (OSD) Menu or goes
back to previous OSD Menu.
(INFORMATION)
Displays the INFORMATION
menu.
Exit Exits and saves menu
settings.
Aspect Displays the aspect ratio
selection bar.
Freeze Freezes the projected image.
Pattern Displays embedded test
pattern.
Blank Hides the screen picture.
PgUp (Page Up)/
PgDn (Page
Down)
Operates your display
software program
(on a connected PC) which
responds to
page up/down commands
(like Microsoft
PowerPoint).
NOTE: Only available when
a PC input signal is
selected.
Eco Mode Selects the Eco mode.
(Volume Up) Increases the volume level.
(Volume
Down) Decreases the volume level.
(Mute) Toggles audio between on
and off.
Magnifies the projected
picture size.
Reduces the projected
picture size.
Color Mode Displays the color mode
selection bar.

14
Remote Control Effective Range
To ensure proper function of the remote control
follow the steps below:
1. The remote control must be held at an angle
within 30° perpendicular to the projector’s IR
remote control sensor(s).
2. The distance between the remote control and
the sensor(s) should not exceed 8 m (26 ft.)
NOTE: Refer to the illustration for the location of
the infrared (IR) remote control sensor(s).
Approx. 30°
Replacing the Remote Control Batteries
1. Remove the battery cover from the rear of the remote control by pressing the
finger grip and sliding it down.
2. Remove any existing batteries (if necessary) and install two AAA batteries.
NOTE: Observe the battery’s polarities as indicated.
3. Replace the battery cover by aligning it with the base and pushing it back into
position.
NOTE:
• Avoid leaving the remote control and batteries in excessive heat or a humid
environment.
• Replace only with the same or equivalent type recommended by the battery
manufacturer.
• Dispose of the used batteries according to the manufacturer’s instructions and
local environment regulations for your region.
• Never throw the batteries into a fire. There may be danger of an explosion.
• If the batteries are drained or if you will not be using the remote control for an
extended period of time, remove the batteries to avoid damage to the remote
control.

15
Initial Setup
This section provides detailed instructions for setting up your projector.
Choosing a Location
Personal preference and room layout will decide the installation location. Consider
the following:
• Size and Position of your screen.
• Location of a suitable power outlet.
• Location and Distance between the projector and other equipment.
The projector is designed to be installed in one of the following locations:
Front
The projector is placed near the floor in
front of the screen.
Front Ceiling
The projector is suspended upside-down
from the ceiling in front of the screen.
Rear Ceiling1
The projector is suspended upside-down
from the ceiling behind the screen.
Rear1
The projector is placed near the floor
behind the screen.
1 - A special rear projection screen is required.

16
Projection Dimensions
NOTE: See “Specifications” on page 58 for the native display resolution of this
projector.
• 16:9 Image on a 16:9 Screen
(a)
(d)
(c)
(b)
(e)
(f)
(a)
(c)
(b)
(e)
(f)
(d)
• 16:9 Image on a 4:3 Screen
(a)
(c)
(b)
(e)
(f)
(d)
(a)
(c)
(b)
(e)
(f)
(d)
NOTE: (e) = Screen / (f) = Center of Lens
16:9 Image on a 16:9 Screen
(a) Screen
Size
(b) Projection Distance (c) Image
Height
(d) Vertical Offset
minimum maximum minimum maximum
in. mm in. mm in. mm in. mm in. mm in. mm
60 1524 79 1996 86 2195 29 747 1.5 37.4 1.5 37
70 1778 92 2328 101 2561 34 872 1.7 43.6 1.7 44
80 2032 105 2661 115 2927 39 996 2.0 49.8 2.0 50
90 2286 118 2994 130 3293 44 1121 2.2 56.0 2.2 56
100 2540 131 3326 144 3659 49 1245 2.5 62.3 2.5 62
110 2794 144 3659 158 4025 54 1370 2.7 68.5 2.7 68
120 3048 157 3992 173 4391 59 1494 2.9 74.7 2.9 75
130 3302 170 4324 187 4757 64 1619 3.2 80.9 3.2 81
140 3556 183 4657 202 5123 69 1743 3.4 87.2 3.4 87
150 3810 196 4989 216 5488 74 1868 3.7 93.4 3.7 93
160 4064 210 5322 230 5854 78 1992 3.9 99.6 3.9 100
170 4318 223 5655 245 6220 83 2117 4.2 105.8 4.2 106
180 4572 236 5987 259 6586 88 2241 4.4 112.1 4.4 112
190 4826 249 6320 274 6952 93 2366 4.7 118.3 4.7 118
200 5080 262 6653 288 7318 98 2491 4.9 124.5 4.9 125

17
16:9 Image on a 4:3 Screen
(a) Screen
Size
(b) Projection Distance (c) Image
Height
(d) Vertical Offset
minimum maximum minimum maximum
in. mm in. mm in. mm in. mm in. mm in. mm
60 1524 72 1832 79 2015 27 686 1.4 34 1.4 34
70 1778 84 2137 93 2351 32 800 1.6 40 1.6 40
80 2032 96 2443 106 2687 36 914 1.8 46 1.8 46
90 2286 108 2748 119 3023 41 1029 2.0 51 2.0 51
100 2540 120 3053 132 3358 45 1143 2.3 57 2.3 57
110 2794 132 3358 145 3694 50 1257 2.5 63 2.5 63
120 3048 144 3664 159 4030 54 1372 2.7 69 2.7 69
130 3302 156 3969 172 4366 59 1486 2.9 74 2.9 74
140 3556 168 4274 185 4702 63 1600 3.2 80 3.2 80
150 3810 180 4580 198 5038 68 1715 3.4 86 3.4 86
160 4064 192 4885 212 5374 72 1829 3.6 91 3.6 91
170 4318 204 5190 225 5709 77 1943 3.8 97 3.8 97
180 4572 216 5496 238 6045 81 2057 4.1 103 4.1 103
190 4826 228 5801 251 6381 86 2172 4.3 109 4.3 109
200 5080 240 6106 264 6717 90 2286 4.5 114 4.5 114
NOTE: There is a 3% tolerance among these numbers due to optical component
variations. It is recommended to physically test the projection size and
distance before permanently installing the projector.

18
Mounting the Projector
NOTE: If you buy a third-party mount, please use the correct screw size. Screw size
can vary depending on the thickness of the mounting plate.
1. To ensure the most secure installation, please use a ViewSonic® wall or ceiling
mount.
2. Ensure the screws used to attach a mount to the projector meet the following
specifications:
• Screw type: M4 x 8
• Maximum Screw length: 8 mm
65.89
65.89
113.54 60.01
NOTE:
• Avoid installing the projector near a heat source.
• Keep at least a 10 cm gap between the ceiling and the bottom of the
projector.

19
Preventing Unauthorized Use
The projector has several built-in security features to prevent theft, access, or
accidental setting changes.
Using the Security Slot
To help prevent the projector from being stolen, use a security slot locking device
to secure the projector to a fixed object.
Below is an example of setting up a security slot locking device:
NOTE: The security slot can also be used as a safety anchor if the projector is
mounted to the ceiling.

2020
Using the Password Function
To help prevent unauthorized access or use, the projector offers a password
security option. The password can be set through the On-Screen Display (OSD)
Menu.
NOTE: Make note of your password, and keep it in a safe place.
Setting a Password
1. Press Menu to open the OSD Menu and go to: SYSTEM > Security Settings and
press Enter.
2. Highlight Power On Lock and select
On by pressing / .
3. As pictured to the right, the four
arrow keys ( , , , ) represent
4 digits (1, 2, 3, 4). Press the arrow
keys to enter a six digit password.
5. Confirm the new password by re-entering the new password. Once the password
is set, the OSD Menu will return to the Security Settings page.
6. Press Exit to leave the OSD Menu.
NOTE: Once set, the correct password must be entered every time the projector is
started.
