ViewSonic ViewBoard GD1330 User manual

IMPORTANT: Please read this User Guide to obtain important information on installing and using your product in
a safe manner, as well as registering your product for future service. Warranty information contained in this User
Guide will describe your limited coverage from ViewSonic® Corporation, which is also found on our web site at
http://www.viewsonic.com in English, or in specific languages using the Regional selection box of our website.
GD1330
ViewBoard Pen Display
User Guide
Model No. VS18342
P/N: GD1330

2
Thank you for choosing ViewSonic®
As a world-leading provider of visual solutions, ViewSonic® is dedicated to exceeding
the world’s expectations for technological evolution, innovation, and simplicity.
At ViewSonic®, we believe that our products have the potential to make a positive
impact in the world, and we are confident that the ViewSonic® product you have
chosen will serve you well.
Once again, thank you for choosing ViewSonic®!

3
Safety Precauons
Please read the following Safety Precautions before you start using the device.
• Keep this user guide in a safe place for later reference.
• Read all warnings and follow all instructions.
• Allow at least 4" (10 cm) clearance around the device to ensure proper
ventilation.
• Place the device in a well-ventilated area. Do not place anything on the device
that prevents heat dissipation.
• Do not use the device near water. To reduce the risk of fire or electric shock, do
not expose the device to moisture.
• Avoid exposing the device to direct sunlight or other sources of sustained heat.
• Do not install near any heat sources such as radiators, heat registers, stoves, or
other devices (including amplifiers) that may increase the temperature of the
device to dangerous levels.
• Use a soft, dry cloth to clean the external housing. Please see the "Maintenance"
section for more information.
• Oil may collect on the screen if you touch it. Please see the "Maintenance"
section for more information.
• Do not touch the screen surface with sharp or hard objects, as it may cause
damage to the screen. Only use the supplied pen, or fingers for models that
support touch input.
• When moving the device, be careful not to drop or bump the device on
anything.
• Do not place the device on an uneven or unstable surface. The device may fall
over resulting in an injury or a malfunction.
• Do not place any heavy objects on the device or connection cables.
• If smoke, an abnormal noise, or a strange odor is present, immediately turn the
device off and call your dealer or ViewSonic®. It is dangerous to continue using
the device.
• When connecting to a power outlet, DO NOT remove the grounding prong.
• Please ensure grounding prongs are NEVER REMOVED.
• Protect the power cord from being treaded upon or pinched, particularly at the
plug, and at the point where it emerges from the equipment. Ensure that the
power outlet is located near the equipment so that it is easily accessible.
• Only use attachments/accessories specified by the manufacturer.
• Disconnect the device if it is not going to be used for a long period of time.

4
Safety Precautions....................................................... 3
Introduction ................................................................ 6
Package Contents ...................................................................................................6
System Requirements.............................................................................................7
Product Overview...................................................................................................8
Front and Side View ................................................................................................ 8
I/O Ports ................................................................................................................. 8
Making Connections.................................................... 9
Connecting to the Pen Display..................................... 9
HDMI and USB Type C ............................................................................................. 9
USB Type C ............................................................................................................ 10
Driver Installation, Use, and Removal........................ 11
Installing Drivers and Software (Windows) ..........................................................11
ViewSonic Pen Manager........................................................................................ 11
Setting the Display Area ........................................................................................ 12
Pen Input Settings ................................................................................................13
Uninstalling the Driver..........................................................................................15
Installing Drivers and Software (macOS X) ...........................................................16
Pen Display Driver ................................................................................................. 16
Pen Input Settings ................................................................................................19
Uninstalling the Driver..........................................................................................20
Using the Pen Display................................................ 21
Turning the Device On/Off ...................................................................................21
On-Screen Display (OSD) Menu............................................................................22
Configuring the Settings .......................................................................................23
General Operations ............................................................................................... 23
On-Screen Display (OSD) Menu Tree .................................................................... 24
Contents

5
Appendix................................................................... 26
Specifications........................................................................................................26
Pen ........................................................................................................................ 26
Troubleshooting ...................................................................................................27
Pen ........................................................................................................................ 27
FAQ .......................................................................................................................28
Maintenance.........................................................................................................29
General Precautions.............................................................................................. 29
Cleaning the Screen............................................................................................... 29
Cleaning the Case .................................................................................................. 29
Disclaimer.............................................................................................................. 29
Accessories................................................................ 30
Pen Holder Stand..................................................................................................30
Drawing Glove ......................................................................................................31
Replacing a Pen Nib ..............................................................................................32
Regulatory and Service Information .......................... 33
Compliance Information.......................................................................................33
FCC Compliance Statement................................................................................... 33
Industry Canada Statement................................................................................... 33
CE Conformity for European Countries ................................................................. 33
Declaration of RoHS2 Compliance......................................................................... 34
Indian Restriction of Hazardous Substances ......................................................... 35
Product Disposal at End of Product Life ................................................................ 35
Copyright Information ..........................................................................................36
Customer Service..................................................................................................37
Limited Warranty .................................................................................................. 38
Mexico Limited Warranty...................................................................................... 41

6
Introducon
Package Contents
GD1330 Pen Display Pen Display Cover Electromagnetic Pen
HDMI to Mini HDMI Cable USB Type C to USB Type C Cable USB Type C to USB Type A Cable
Nib Removal Tool Replacement Pen Nib Pen Holder Stand
Drawing Glove Quick Start Guide
NOTE: The power cord and video cables included in your package may vary
depending on your country. Please contact your local reseller for more
informaon.

7
System Requirements
• Operang System:
PC: Windows 7/8/10/11
Mac: macOS X 10.15 and above
• CPU:
 Penum 233 MHz or above
• Memory:
64 MB or above
• Hard Disk Space:
 128 MB or above
• Interface:
HDMI and USB interface
 Full funcon USB Type C or Thunderbolt 3 interface

8
Product Overview
Front and Side View
5
4
3
2
1
1. Express Keys 2. I/O Ports 3. LED Indicator
4. Power Key 5. Menu Key
I/O Ports
1 2 3
1. Mini HDMI 2. USB Type C 3. USB Type C

9
Making Connecons
Connecng to the Pen Display
The pen display can be connected to a computer by either HDMI and USB Type C, or
only USB Type C.
HDMI and USB Type C
1. Ensure the power of the computer and pen display are o before connecng
them.
2. Connect one end of the HDMI cable to the HDMI port of your computer. Then
connect the Mini HDMI end of the cable to the Mini HDMI port of the pen
display.
3. Connect the USB Type A end of the USB cable to your computer. Then connect
the USB Type C end to the pen display.
Mini HDMI to HDMI Video Signal
USB Type C to USB Type A
Pen Touch Control and Power Supply
Mini HDMI Port
USB Type C Ports
NOTE: If connected to a desktop computer, and a monitor was already
connected to the computer itself, then the tablet and monitor must be
connected to the same graphics card of the desktop computer.

10
USB Type C
1. Ensure your computer is equipped with a full funcon USB Type C interface or
Thunderbolt 3 interface.
2. Connect one end of the double-sided USB Type C cable to the USB Type C port
of the pen display. Then connect the other end to the USB Type C port of the
computer.
USB Type C to USB Type C
Pen Touch Control and Power Supply
USB Type C Ports
NOTE: If the power supply from the USB Type C port of the computer is
insucient, the screen of the pen display might ash. In this case,
connect a USB Type C to USB Type A cable to the USB Type C power
supply port of the pen display, and connect the other end of the USB
cable to the computer or a USB power adapter to ensure that sucient
power is supplied to the pen display.
