ViewZ TIM Series User manual

Temp. 98.06°F Normal
V Z-7T IM-S USER MANUAL
Please read this manual thoroughly before use, and keep it handy for future reference.
7" TEMPERATURE MEASUREMENT &
FACE RECOGNITION MONITOR
TIM SERIES

2 3User Manual User ManualVisit the ViewZ USA website at https://www.viewzusa.com Visit the ViewZ USA website at https://www.viewzusa.com
Safety Instrucon
Package
System Parameters
Network
List Management
Comparison
Aendance
Trouble Shoong
Monitor Installaon
RMA
Specicaon
Warranty
1. Mark Indicaon & Substance HTTP Upload Sengs
List Management
Batch Import
Upgrade
Video Parameter (Camera Video Setup)
Video Coding (Main & Sub Video Streaming)
RTSP
FTP
System Info
User Management
System Time
LAN Setup
Mobile
Smart Face (Face Recognion)
FA Black & Alarm (Alarm Setup)
Access Control (Light On/O, Monitor On/O)
Device Informaon
Restore
Restart
Device Seng
Audio
2. Warning
Connecon
3. Cauon
4. Operaonal Temperature & Humidity
5. Dot Defect (dead pixel) of TFT
6. FCC RF INTERFERENCE STATEMENT
3
8
46
41
47
45
48
527
35
37
29
30
31
33
34
11
12
13
14
15
16
18
20
22
23
24
25
26
5
9
6
6
6
7
10
27
35
38
39
CONTENTS CONTENTS
.......................................................................................................................................................................................
.............................................................................................................................................................................................................
..........................................................................................................................................................................................
.......................................................................................................................................................................................................
..................................................................................................................................................................................................................
...................................................................................................................................................................................................
........................................................................................................................................................................................................
....................................................................................................................................................... ...........................................................................................................................................................................
...................................................................................................................................................................................
.............................................................................................................................................................................................
......................................................................................................................................................................................................
.....................................................................................................................................
...........................................................................................................................
..............................................................................................................................................................................................................
................................................................................................................................................................................................................
................................................................................................................................................................................................
.................................................................................................................................................................................
...........................................................................................................................................................................................
.................................................................................................................................................................................................
.......................................................................................................................................................................................................
.........................................................................................................................................................
.......................................................................................................................................................
........................................................................................................................
..............................................................................................................................................................................
.......................................................................................................................................................................................................
.........................................................................................................................................................................................................
.......................................................................................................................................................................................
............................................................................................................................................................................................................
................................................................................................................................................................................................
......................................................................................................................................................................................................
..................................................................................................................................................................................................
.....................................................................................................................................
.....................................................................................................................................................
..........................................................................................................................................
................................................................................................................................................................................. ...
...........................................................................................................................................................................................................
.........................................................................................................................................................................................
....................................................................................................................................................................................................
....................................................................................................................................................................................................

4 5User Manual User ManualVisit the ViewZ USA website at https://www.viewzusa.com Visit the ViewZ USA website at https://www.viewzusa.com
1. Read all warnings.
2. Follow all instrucons to ensure longevity of monitor.
3. Do not place the monitor near water.
4. Clean only with dry cloth.
5. Do not block any venlaon openings. Install in accordance with the manufacturer’s instrucons.
6. Do not install near any heat sources such as radiators, heat registers,stoves, or other heat generang
devices.
7. Do not override the safety purpose of the polarized or grounding-type plug.
8. A polarized plug has two blades with one wider than the other.
9. A grounding type plug has two blades and a third grounding prong.
10. The wide blade and the third prong are provided for your safety.
11. If the provided plug does not t into your outlet, consult with an electrician for replacement of the outlet.
12. Protect the power cord from being walked on or pinched parcularly the plugs, convenience receptacles
and the point where it connects to the monitor.
13. Only use aachment/accessories specied by the manufacturer.
14. Use only with the cart, stand, tripod, bracket or table specied by the manufacturer or sold with the
monitor. When a cart is used, use cauon when moving the cart & monitor in combinaon to avoid
injuries.
15. Unplug the monitor during lightning storms or when unused for long periods of me.
16. Refer all servicing to qualied service personnel. Servicing is required when the monitor has been
damaged in any way.
The monitor shall not be exposed to dripping or splashing and objects containing liquids, such as vases
shall not be placed near the monitor.
The monitor should have ample distance (e.g. 10cm) from the wall for sucient venlaon.
Important Safety Instruction
SAFETY INSTRUCTION
This symbol is intended to alert the user to the presence of uninsulated & dangerous voltage
within the monitor’s enclosure that may be of sucient magnitude to constute a risk of
electric shock to persons.
This symbol is intended to alert the user to the presence of important operang and
maintenance (servicing) instrucons in the literature accompanying the monitor.
Important Safety Instruction
Mark Indication and Substance
Warning
SAFETY INSTRUCTION
CAUTION : TO REDUCE THE RISK OF ELECTRICAL SHOCK,
DO NOT REMOVE COVER (OR BACK). NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL
• Do not use damaged or loose cables and plug.
• Do not pull the plug out by the wire nor touch the plug with wet hands.
• Use only a properly grounded plug and receptacle.
• Do not connect too many extension cords or plugs to one outlet.
• Do not excessively bend the plug and wire.
• Do not disconnect the power cord while it's sll plugged into the monitor.
• Do not place any heavy objects on the power cord. Damage to the cord may cause shock or re.
• Never open the monitor. There are no user-serviceable parts inside and opening will void warranty.
• Removing covers may expose you to dangerous shock hazards or other risks.
• Keep any heang devices away from the power cable and monitor.
• Do not place the monitor near water.
• Do not insert objects of any kind into the monitor's open slots, as they may touch dangerous voltage points.
• Please follow the laws and regulaons of your municipality to dispose the monitor properly.
• Do not use the monitor in high temperature, humid, dusty or oily areas.
• Do not install the monitor where it will be exposed to connual vibraon.
• Keep the plasc packaging out of children’s reach.
• If any damage is detected upon rst opening the box, contact agency from which you bought the monitor directly.
• If your monitor does not operate normally – in parcular, if there is any unusual sound or smell coming from the
monitor – unplug it immediately and contact an authorized dealer or the service center.

6 7User Manual User ManualVisit the ViewZ USA website at https://www.viewzusa.com Visit the ViewZ USA website at https://www.viewzusa.com
Important Safety Instruction
Caution
Available Temperature & Humidity
Dot Defect (dead pixel) of TFT
SAFETY INSTRUCTION
• If the connector between the plug and the pin is dusty or dirty, clean it properly using a dry cloth.
• Make sure to unplug the power cord before cleaning the monitor.
• Make sure to leave a gap between monitor and wall.
• Do not drop the monitor when moving it.
• Place your monitor in a locaon with low humidity and minimum dust.
• Install the monitor base on a showcase or shelf so that the end of the base does not protrude from the
showcase or shelf.
• Do not place the monitor on an unstable or small surface area.
• Do not install inside a vehicle.
• Disconnect the plug from the outlet during storms or lightning or if it has not been used for a long me.
• Do not try to move the monitor by pulling on the power cord.
• Do not cover the vents on the monitor.
• When moving the monitor, turn o and unplug the power cord. Make sure that all cables, including HDMI
cable and cables connected to other devices, are disconnected before moving it.
• Place the monitor out of children’s reach, as they could damage it by hanging onto it.
• Operang Temperature : 32°F ~ 122°F / 0°C ~ 50°C
• Operang Humidity : 5 ~ 90% RH
ViewZ monitors are manufactured using high-end semiconductor technology with precision rangs of 99.9%
and above. However, it may be the case that certain RGB and white pixels seem darker (or enrely unlit i.e.
black).
Modern producon methods cannot guarantee an absolute fault-free monitor. To this eect, no LED
manufacturer can guarantee a defect free panel. A few isolated pixel or sub-pixel faults are considered
tolerable and dierent policies exist that govern the amount of these tolerable values.
While most pixel faults occur in isolated regions, a cluster of dead pixels or sub-pixels can somemes form for
which a separate ruling applies. A cluster is dened as an area of 5x5 pixels. ViewZ’s policy on pixel failure:
either as an isolated fault or in the form of a cluster is outlined on the website: www.viewzusa.com
Note
FCC RF INTERFERENCE STATEMENT
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable protecon against harmful interference when the
equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instrucon manual, may cause harmful interference to radio communicaons. Operaon of this equipment
in a residenal area is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
• Reorient or relocate the receiving antenna.
• Increase the separaon between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio, TV technician for help.
• Only shielded interface cable should be used.
Finally, any changes or modicaons to the equipment by the user not expressly approved by the grantee or
manufacturer could void the users authority to operate such equipment.
► DOC COMPLIANCE NOTICE
This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus set out in the
radio interference regulaon of Canadian Department of communicaons.

8 9User Manual User ManualVisit the ViewZ USA website at https://www.viewzusa.com Visit the ViewZ USA website at https://www.viewzusa.com
Temp.98.06°F Normal
The following tools may be required depending on your installaon.
Mount
Your ViewZ monitor is shipped with all proper installaon hardware and components. If there are parts missing
and/or damaged, please stop the installaon and contact ViewZ USA at (888)-998-4399.
Your ViewZ monitor is compable with ViewZ monitor mounts. For more informaon, please contact ViewZ USA at (888)-998-4399.
Electronic Stud Finder Protecve Eye-wearPencil Level Phillips Screwdriver
Assembly Components - provided
Mounting Option
Installation Tools
Temerpature Measurement
Monitor (Qty 1)
DC12V Power Supply &
110V Power Cable (Qty 1)
User Manual (Qty 1)
Program CD (Qty 1)
INSTALLATION
• Part # • Part # VZ-7TIM-FS VZ-7TIM-DS
• Dimension : 3.93 x 41.14 x 2.55 " (Pole)
Free Stand Mount
Ø 11.10 x 2.16 ” (Base)
• Weight : 10.9 lbs
• Dimension : 10.23 x 10.x23 x 1.77"
Desktop Mount
26 x 26 x 4.5 cm
• Net Weight : 4.4 lbs
If VZ-7TIM-S is installed indoors, we recommend VZ-7TIM-S should have over 6 feets distance from the light source and over 10
feets from any window.
Warning
The following image describes the interface input ports
Interface Input Ports
CONNECT EXTERNAL EQUIPMENTS
1. USB - N/A
2. RJ45 - 10/100M (IPC OUT)
3. WG OUT - 1:D0 2:D1 3:GND
Face Recognition & Temperature Measurement Display
q
e
t
w
r
y
Real-me temperature display
Detecng Area
Face recognion comparison results
4. WG IN - N/A
5. Alarm OUT - Relay Switch
6. DC 12V- Power IN 12V/3A

10 11User Manual User ManualVisit the ViewZ USA website at https://www.viewzusa.com Visit the ViewZ USA website at https://www.viewzusa.com
Log-In
SYSTEM PARAMETERS
Aer you connect all cables and have secure Internet or Intranet connecon, please access the VZ-7TIM-S monitor via
web browser. You can use IE,Chrome or Edge.
• The default IP address : 192.168.0.120 | Gateway address : 192.168.0.1 | Subnet Mask : 255.255.255.0
• The default ID & password : admin / admin
Type the IP Address on the address bar
Type the User Name & Password
q
w
If you don't have secure Internet or Intranet connecon, you cannot login to the system.
If you want to connect to the monitor without network, for instance, via P-to-P connecon, you just need to connect the
ethernet cable between VZ-7TIM-S and computer. And follow the instrucons step as step as delineated below:
• On Window OS, Open Control Panel / Network and Sharing Center / Change Adapter Sengs / Local Area
Connecon (which connect VZ-7TIM-S) / Local Area Connecon Properes / Internet Protocol Version 4 (TCP/
IPv4) Properes
• Selects 'Use the following IP address' on the window of Internet Protocol Version 4 (TCP/IPv4) Properes
• Type the proper info - IP address 192.168.0.XX, Subnet mask 255.255.255.0, Default gateway 192.168.0.1
If you want to use your own IP address, please change the VZ-7TIM-S info and use it.
Warning
SYSTEM PARAMETERS
System Info
When you login to the system, you will see the main interface with system parameters.
You can also change the display language, video format and device name.
LANGUAGE
VO STANDARD
DEVICE NAME
Sets the language of the menu
Selects the video output
Changes the device name
English, Spanish, French
Russian, Portuguese, Italian
German, Turkish, Japanese
Default - English
NTSC / PAL | Default - NTSC
FUNCTION VALUE

12 13User Manual User ManualVisit the ViewZ USA website at https://www.viewzusa.com Visit the ViewZ USA website at https://www.viewzusa.com
VALIDATE MODE 1)
SELECT USER 1)
USER NAME 2)
PASSWORD 3)
CONFIRM PASSWORD
The accessible method of software
Selects the user to change the password
Displays the selected user name
Types the password to update existing one
Types the same password to confirm it
Administrator, User 1, User 2
FUNCTION VALUE
SYSTEM PARAMETERS
User Management
Change the account password. The system provides 3 accounts - Administrator, USER 1 & USER 2.
1) This mode and user account is xed value.
2) You cannot create a new user - it is a factory default account.
3) Password may consist of 8-15 digits, including but not limited to a-z, A-Z, 0-9, underscores and dot.
SYSTEM PARAMETERS
System Time
Setup the system me of VZ-7TIM-S monitor.
NTP Server
Date
SYNC. LOCAL COMPUTER
SET THE TIME MANUALLY
TIME ZONE CONV.
RTC SWITCH
Synchronizes the VZ-7TIM-S time with NTP server
Displays the current time of VZ-7TIM-S
Synchronizes the VZ-7TIM-S time with local computer
Type the time manually
Selects the time zone
Turn on and off the real time switch (RTC)
GMT time zone
Default - Set the Time Manually
Time zone : 1, 2 | Default - 1
Open, Close | Default - Open
FUNCTION VALUE
Select the GMT zone based on your locaon
q

14 15User Manual User ManualVisit the ViewZ USA website at https://www.viewzusa.com Visit the ViewZ USA website at https://www.viewzusa.com
DHCP ENABLE
IP
SUBNET MASK
GATEWAY
Preferred DNS
Alternate DNS
MAC
Turn on or off the DHCP. If you check on, VZ-7TIM-S
monitor will have an auto-assigned IP address
Type the IP address
Type the subnet mask address
Type the Gateway IP address
Type the 1st DNS address
Type the 2nd DNS address
The given device ID of VZ-7TIM-S
ON, OFF | Default - OFF
xxx.xxx.xx.xxx| Default - 192.168.0.120
xxx.xxx.xx.xxx | Default - 255.255.255.0
xxx.xxx.xx.xxx
xxx.xxx.xx.xxx
xxx.xxx.xx.xxx | Default - 8.8.8.8
Provided (Non editable)
FUNCTION VALUE
SYSTEM PARAMETERS
LAN Setting
Setup the IP address of VZ-7TIM-S to control.
If you already have a device which is assigned the IP address '192.168.0.120', you might not be able to access this SW
dashboard. To prevent that situaon, please change the IP address of exisng device or VZ-7TIM-S monitor.
Warning
This funcon is not available.
SYSTEM PARAMETERS
Mobile
This interface is made to support the access control aendants.
PORT SERVER
P2P SERVER QR code for mobile APP.
N/A
N/A
FUNCTION VALUE

16 17User Manual User ManualVisit the ViewZ USA website at https://www.viewzusa.com Visit the ViewZ USA website at https://www.viewzusa.com
SYSTEM PARAMETERS
Smart Face
1) The higher sensivity value means the captured image quality is low. The lower sensivity value means the captured image quality is high.
The best eect of sensivity is normally 3-5.
2) When many people pass the VZ-7TIM-S monitor, the monitor will only scan the 1st person.
So, if you want to scan more people, please adjust these values.
3) If you set the MIN-face snapshot pixel less than 100 pixel means, the monitor will not capture the face when the displayed face size is
smaller than 100 pixel size (far away status). If you set the MAX-face snapshot pixel higher than 400, the monitor will not capture the face
when the displayed face size bigger than 400 pixel size (too close to the monitor).
ENABLE
TIME 1 & 2
SENSITIVITY 1)
SNAPSHOT MODE 2)
FACE RECOGNITION MAX
3)
CAPTURE TIMES
FACE RECOGNITION MIN
3)
FACE CHECK MIN. PIXEL
Turns on the face recognition algroithm
Sets the deployment times of face recognition
Selects the sensitivity of face recognition
Cooperates with Capture times and Interval between snap
Sets the maximum pixel of face recognition
Sets the number of capture
Sets the minimum pixel of face recognition
Sets the minimum pixel of face temperature detect
measurement.
ON, OFF | Default - ON
00:00 ~ 23:59 | Default - 00:00 ~ 23:59
0 ~10 | Default - 9
Single Mode
300 ~500 | Default - 500
Keep tapping, 1 ~20 | Default - 8
30 ~300 | Default - 70
0 ~500 | Default - 100
FUNCTION VALUE
EVERY NTH FRAME Sets the captured frame number per 'N'TH frame 1 ~1500 | Default - 5
Setup the face recognion of VZ-7TIM-S monitor.
SYSTEM PARAMETERS
Smart Face (Continued)
FACE SCENE
FACE TRACK
FTP UPLOAD
IMAGE TYPE
FACE QUALITY
HUMAN
LIVE DETECTION
FUNCTION FIRST
Selects the proper circumstance of monitor
Turns on/off the face tracking mark (box shape) on the screen
Turns on/off to upload the screenshot to the FTP server
Selects what kind of captured image will be created
Selects the image quality captured by the camera (to upload)
Selects the VZ-7TIM-S will only capture the people or not
Sets the live detection mode
Sets the priority of capture mode
The conventional scene is for using the product outdoors.
The lobby scene is for using the product indoors.
Conventional, Lobby
| Default - Lobby Scene
Filter Tracking, Close | Default - Filter Tracking
NO(On), NC(Off) | Default - NO
Fac, FACE & Original
| Default - Face
1 ~99 | Default - 99
OPEN, CLOSE | Default - OPEN
Filter Tracking, Close | Default - Filter Tracking
Speed, Living | Default - Speed
FUNCTION VALUE

18 19User Manual User ManualVisit the ViewZ USA website at https://www.viewzusa.com Visit the ViewZ USA website at https://www.viewzusa.com
SYSTEM PARAMETERS
FA Black & Alarm Setting
ALARM SWITCH
BLACKLIST ALARM
WHITELIST ALARM
VIP LIST
ALARM OUTPUT
NON-WHITELIST ALARM
IO OUTPUT TYPE
RECOGNIZE MODE
COMPARISON SIMILARITY
ID SIMILARITY
Turns on the alarm
Turns on the alarm of the black listed person
Turns on the alarm of the registered person
Turns on the alarm of the VIP listed person
Sets the alarm output time
Turns on the alarm of the unregistered person
Sets the IO output type - NO means 'Normal Open'
Sets the number of recognization per a person
Sets the level of recognition by detecting face
Sets the level of recognition by detecting ID
ON, OFF | Default - ON
ON, OFF | Default - OFF
ON, OFF | Default - ON
ON, OFF | Default - ON
1 ~60 seconds | Default - 1
ON, OFF | Default - OFF
NO (On), NC (Off) | Default - NO
Numbers Recognized Mode (1-10),
Always Identify, Single Recognize
| Default - Single Recognize
1 ~100 | Default - 75
1 ~100 | Default - 60
FUNCTION VALUE
IO OUTPUT Sets the IO output mode Continuous, Pulse | Default - ON
Setup the alarm seng of VZ-7TIM-S monitor.
SYSTEM PARAMETERS
FA Black & Alarm Setting (Continued)
MATCHING MODE
MASK DETECT
TEMP. CORRECTION 1)
COMPENSATED TEMP.
2)
ABNORMAL TEMP.
OPEN THE DOOR
TEMP. THRESHOLD 3)
TEMPERATURE UNIT
TIME 1 & TIMR 2
Selects the detection mode
Turns on/off the mask wearing detection
Selects the temperature calculation algorithm
Sets the basic temperature based on circumstances
Sets the alarm when detecting a person
who has abnormal (high or low) temperature
Sets the maximum temperature of alarming
Sets the temperature type
Sets the time which do not detect the temperature
Face, Temperature, Face + Temperature
| Default - Face detect
Intelligent, Low Temperature
1 ~ 212°F (1 ~ 100°C) | Default - 32°F
| Default - Intelligent
OPEN(On), CLOSE(Off) | Default - CLOSE
1 ~ 212°F (1 ~ 100°C) | Default - 99°F
Fahrenheit, Celsius | Default - Fahrenheit
Input the time | Default - 24 hrs
FUNCTION VALUE
OPEN(On), CLOSE(Off) | Default - CLOSE
1) When you choose 'High Temperature Algorithm,' you can have the extra me set of alarm.
2) If the install locaon has the high temperature, you need to add values. If the install locaon hsa the low temperature,
you need to minus values.
3) Based on the CDC guideline, Any temperature 100.4 °F or greater is considered a fever.
hps://www.cdc.gov/coronavirus/2019-ncov/community/homeless-shelters/screening-clients-respiratory-infecon-symptoms.html

20 21User Manual User ManualVisit the ViewZ USA website at https://www.viewzusa.com Visit the ViewZ USA website at https://www.viewzusa.com
SYSTEM PARAMETERS
Access Control
You can control the display info, scan record, wiegand output format, front 2 white-lights on/o, screen display on/
o and temperature measurement mode.
WIEGAND OUTPUT
SCREEN DISPLAY MODE
WHITE LIGHT
CONTROL 1)
FAN FILTERING
Selects the wiegand output
Selects the screen is always on & off
Selects the 2 front white lights on & off
Selects the face recognition skip time when showing
same face
CLOSE, WG26, WG34 | Default - CLOSE
Turn off screen display after no one
1 ~10 seconds | Default - 3
Always on, Always off, Time control,
Turn off screen display after no one
Default - Turn off the light after no one
Default - Turn off the light after no one
Always display,
FUNCTION VALUE
1) When you select 'White light me control,' you can type the me to turn on & o by military me - 00:00:00 ~ 23:59:59.
SYSTEM PARAMETERS
Access Control (Continued)
DATE FORMAT
COMPARISON
RECORD STORAGE
TEMPERATURE
MEASUREMENT MODE
Selects the displaying date format on screen
Selects the captured data will be saved or not
Selects the temperature measurement mode
YYYY-MM-DD, MM-DD-YYYY,
DD-MM-YYYY
| Default - YYYY-MM-DD
Open, Close | Default - Open
Precision, Quick mode
| Default - Precision mode
FUNCTION VALUE

22 23User Manual User ManualVisit the ViewZ USA website at https://www.viewzusa.com Visit the ViewZ USA website at https://www.viewzusa.com
SYSTEM PARAMETERS
Device Information
You can display the IP address, direcon, longitude, dimension and manfacturer's info of VZ-7TIM-S.
DEVICE IP
DRIECTION
LONGITUDE
DIMENSION
MANUFACTURER CODE
IP address of VZ-7TIM-S
Enter important system information
Enter Longitudinal value to indicate location
Enter System dimensions
Enter the manufacturer code
FUNCTION VALUE
SYSTEM PARAMETERS
Restore
Sets the restore to the factory default of VZ-7TIM-S.
NETWORK
USER NAME
Restores the IP address by factory default
Restores the user name by factory default
FUNCTION VALUE
Choose the opon and click 'Submit'
Click the 'Restore factory seng' buon w
q

24 25User Manual User ManualVisit the ViewZ USA website at https://www.viewzusa.com Visit the ViewZ USA website at https://www.viewzusa.com
RESTART THE SYSTEM
AUTOMATICALLY
REBOOT
Sets the time of rebooting VZ-7TIM-S
Reboots the VZ-7TIM-S manually
Never, Daily, Monday ~Sunday
| Default - Never
FUNCTION VALUE
SYSTEM PARAMETERS
Restart
Sets the restore to the factory default of monitor & restart the monitor by the setup.
SYSTEM PARAMETERS
Device Setting
FORMAT
REFRESH
Clears all data of VZ-7TIM-S
Loads the storage data of VZ-7TIM-S
FUNCTION VALUE
Clear or format all saved data of VZ-7TIM-S.

26 27User Manual User ManualVisit the ViewZ USA website at https://www.viewzusa.com Visit the ViewZ USA website at https://www.viewzusa.com
SYSTEM PARAMETERS
Audio
Sets the audio seng of VZ-7TIM-S.
ENABLE
AUDIO INPUT
COMPRESSION TYPE
SAMPLING RATE
INPUT VOLUME
OUTPUT VOLUME
AUDIO BITRATE
Enables Audio
Selects the audio input source
Selects the audio compression type
Selects the audio sampling rate
Selects the audio input volume
Selects the audio output volume
Selects the audio bitrate
Enable, Disable | Default - Enable
MIC, Line-in | Default - MIC
AAC, G.726, G.711A, G.711U
| Default - AAC
44.1khz | Default - 44.1khz
0 ~15 | Default - 15
0 ~15 | Default - 15
128000 | Default - 128000
FUNCTION VALUE
NETWORK
HTTP Upload Settings
CAPTURE UPLOAD
CAPTURE UPLOAD TYPE
CAPTURE INFO CONTENT
UPLOAD PICTURES
NUM OF RETRANSMISSION
CAPTURE INFORMATION
UPOLOAD ADDRESS
Turns on or off this function
Selects which personal info will be uploaded
Selects which captured data will be uploaded
successfully uploaded to the server
Selects which captured image will be uploaded
Types the re-upload times when uploading is not
Types the server address which will get
the captured data
All, Does not, Blackllist, Whitelist, VIP,
Face, Compare | Default - Both
List library photo | Default - Face
Stranger, Non-whitelist | Default - All
Face, Background (& Face),
Number 0 ~| Default - 0
FUNCTION VALUE
This funcon is for uploading captured info to the server.
This funcon is not supported on the VZ-7TIM-S.
Warning

28 29User Manual User ManualVisit the ViewZ USA website at https://www.viewzusa.com Visit the ViewZ USA website at https://www.viewzusa.com
REGISTERED 1)
HEARBEAT UPLOAD
HEARTBEAT INTERVAL
SIGN VERIFICATION
OPERATING MODE
HTTP VERSION
REGISTERED INFO.
HEARTBEAT INFO.
EVENT ADDRESS
UPLOAD ADDRESS
UPLOAD ADDRESS
RESULT ADDRESS
Turn this function on or off
Turn on or off this function
Types the scan interval of heartbeat
Selects the HTTP version
Selects the authentification is required or not
Selects the mode of connection
Types the server address which will get
Types the server address which will get
Types the server address of event
the registration data
the heartbeat data
Types the server address of task report
Number 0 ~seconds | Default - 30
V1.0.0, V2.0.0 | Default - V2.0.0
Open, Close | Default - Close
Online, Offline | Default - Offline
FUNCTION VALUE
NETWORK
HTTP Upload Settings (Continued)
1) When you check 'Registered' check box, the non-registered person who captured by VZ-7TIM-S monitor, will be automacally registered
into the system.
NETWORK
Upgrade
Upgrades the system of VZ-7TIM-S.
VERSION
UPGRADE FILE
Displays the current version of software
Selects a upgradable file from file browser N / A
FUNCTION VALUE
The upgrade/update of VZ-7TIM-S is not available via this funcon
Warning

30 31User Manual User ManualVisit the ViewZ USA website at https://www.viewzusa.com Visit the ViewZ USA website at https://www.viewzusa.com
NETWORK
Camera Video Setup
Adjusts the video seng of VZ-7TIM-S.
BRIGHTNESS
CONTRAST
HUE
SATURATION
ACCURACY
GAMMA
BLC VALUE
SCENE
MIRROR
LSC
3D-DNR
FLIP
VIDEO STANDARD
Adjusts the brightness
Adjusts the contrast
Adjusts the hue
Adjusts the color saturation
Selects the audio compression type
Adjusts the gamma rate
Adjusts the exposure to properly display the subject
Adjusts the image color setting
Selects the bright level of the camera
Selects displaying mirror image or not
Turns on/off to adjust shading of the outside of image
Reduces the noise of display image
Selects the flipped image or not
Selects the frequency of video
0 ~255 | Default - 128
0 ~255 | Default - 128
0 ~255 | Default - 128
0 ~255 | Default - 128
0 ~255 | Default - 75
0 ~255 | Default - 20
0 ~255 | Default - 64
Transparent, True | Default - Transparent
Indoor 1, 2, Outdoor | Default - Outdoor
NC (Off), NO (On) | Default - NC
NC (Off), NO (On) | Default - NC
NC, Low, Normal, High | Default - NC
NC (Off), NO (On) | Default - NC
60 hz, 50 hz | Default - 60 hz
FUNCTION VALUE
NETWORK
Video Streaming
Adjusts the main and sub stream of VZ-7TIM-S.
MAIN/SUB STREAM 1)
CODING LEVEL
CODING
RESOLUTION
QUALITY
ADVANCED 2)
Adjusts the value of video stream for each stream
Selects the streaming video profile
Selects the video compression method
Selects the streaming video resolution
Selects the streaming video quality
Turn on/off the manual adjustment for camera
Baseline, Main, High | Default - Main
MJPEG, H.264, H.265| Default - H.264
Default - 1920 x 1080 pixel
Fine, Normal, Basic | Default - Fine
FUNCTION VALUE
1) The 'Main Stream' means the highest quality stream that gets recorded to your HDD and 'Sub Stream' means typically what gets streamed
to your HDD or other devices. This funcon will help you when you have limited Internet bandwidth.
2) If you check on the 'Advanced' box, you can control 'VBR/CBR, quality, bitrate, frame rate and GOP(F)'. If you check o 'Advanced' box, you
cannot control these.

32 33User Manual User ManualVisit the ViewZ USA website at https://www.viewzusa.com Visit the ViewZ USA website at https://www.viewzusa.com
RATE CONTROL Selects the video compression methods
Selects the streaming video quality
Type the proper streaming video bitrate
Type the proper streaming video frame rate
Type the frame of group of pictures
Setup the current value as LAN preferences
Setup the current value as WAN preferences
CBR, VBR | Default - VBR
Bad, Worse, Worst | Default - Better
| Default - ± 10 %
VBR - Best, Better, Good,
0 ~| Default - Main - 4096 / Sub - 1024
1 ~30| Default - 30
1 ~200| Default - 60
CBR - Self-adaption, ± 10 ~ 50%
FUNCTION VALUE
1) When you click 'LAN or WAN' buon, system will load the default value. If you update the value and want to use it, please click 'Save'
buon to apply.
NETWORK
Video Streaming (Continued)
QUALITY
BITRATE (KB/S)
FRAME RATE (F/S)
GOP (F)
LAN 1)
WAN 1)
NETWORK
RTSP
Sets the RTSP streaming of VZ-7TIM-S.
ENABLE
ENABLE AUTHENTICATION
PACKET SIZE
PORT
COMMUNICATE
MULTICAST SERVER ADDRESS
MAIN STREAM VIDEO PORT
MAIN STREAM AUDIO PORT
SUB STREAM VIDEO PORT
SUB STREAM AUDIO PORT
ONVIF PASSWORD
Enable or disable the RTSP streaming
Turn on or off the authentication when using RTSP
Types the RTSP streaming packet size
Types the RTSP port number
Selects the RTSP communication protocol
Types the multicast server address
Types the main stream multicast video port number
Types the main stream multicast audio port number
Types the sub stream multicast video port number
Types the sub stream multicast audio port number
Turn on or off the authentication when using ONVIF
0 ~| Default - 1440
0 ~| Default - 554
Default - Multicast
xxx.xxx.xxx.xxx | Default - 239.0.0.0
0 ~| Default - 1234
0 ~| Default - 1236
0 ~| Default - 1240
0 ~| Default - 1242
FUNCTION VALUE

34 35User Manual User ManualVisit the ViewZ USA website at https://www.viewzusa.com Visit the ViewZ USA website at https://www.viewzusa.com
SERVER URL
SERVER PORT
FTP CATALOG
CLASSIFICATION 1)
USER NAME
PASSWORD
FILE UPLOAD MODE
TEST 2)
Types the FTP server address
Types the port number of FTP server
Types the specific folder name to upload
Selects where the screenshot will be saved on
the FTP server
Types the username of FTP server
Types the password of FTP server
Types the main stream multicast video port number
Tests the connection of FTP server
0 ~| Default - 21
Default - / (root)
There is no, Date, Serial #,
The IP Address | Default - There is no
Direct Upload, Read and Upload
| Default - Direct Upload
FUNCTION VALUE
NETWORK
FTP
Sets the FTP of VZ-7TIM-S.
LIST MANAGEMENT
List
1) You can add a person with the info of Whitlist/Blacklist/VIP Type, Name, Gender, Naon, Cercate Type, ID Number, Date of Birth, Phone
Number, Hometown, Address, IC, Note, Access Control, List Type.
1) When you select the 'Date, Serial#, The IP Address' opon, the folder will be automacally created.
'There is no' - Save the le at the locaon of 'FTP catalog' | 'Date' - Save the le under the date name folder | 'Serial #' - Save the le under
the serial number folder | 'The Ip Address' - Save the le under the IP address name folder
2) There are many dierent possible reasons for connecon to fail. However, if you see the FTP server directly and nd the 'Test.jpg' on the
FTP server, it means the connecon is conrmed.
1) To add a person to list;
1-1) Click 'Add list' buon to popup the 'Add list' window.
1-2) Click 'Browse' buon to add a face/upper body photo.
1-3) Fill in the proper informaon.
1-4) Click 'Save' buon to save the wrien informaon
ADD LIST1)
FIND
DELETE ALL
SEARCH METHOD
NAME
Adds a person to the list among white, black or VIP
Displays the search result on the list
Deletes all registered information
Selects what kind of search methods will be used
for search
Types the desired keyword to search
Conditional, Fuzzy name, Duplicate ID #,
Duplicated access card #| Default - Fussy name
FUNCTION VALUE
Manages the registered persons or add new person into the system.

36 37User Manual User ManualVisit the ViewZ USA website at https://www.viewzusa.com Visit the ViewZ USA website at https://www.viewzusa.com
ADD LIST - POPUP
BROWSE
ACCESS CONTROL CARD #
GENERATION METHOD
ACCESS CONTROL CARD #
TYPE
Selects a photo from local computer
Selects a method to create the new ID number
for registering a person
Types the new ID number manually
Selects a registered type of person
Public card #, Automatic generate,
Manual input | Default - Public card #
Black, White, VIP | Default - Whitelist
FUNCTION VALUE
When you're uploading a photo, use an image below 960x960 pixels & 2MB le size. Also, you should upload a clear face photo
to prevent recognion errors.
Warning
LIST MANAGEMENT
List (Continued)
Click 'Browse' buon to add a photo
Click 'Save' buon to add a person into the list
Types the proper informaon
Click the 'Add list' buon
w
r
e
q
REFRESH
BULK IMPORT 1)
Refresh the list page
Adds a person to the list among white, black or VIP
FUNCTION VALUE
LIST MANAGEMENT
Batch Import
The batch import funcon is a simple way to add new persons into the database.
Click 'Browse' buon to add a photo
Click 'Save' buon to add a person into the list
Selects & types the proper informaon
Click the 'Bulk import' buon
w
r
e
q
1) To add a group of people to list;
1-1) Click 'Bulk Import' buon to popup the 'Modify List' window.
1-2) Click 'Browse' buon to add a picture - face or upper body.
1-3) Select one of the access control card number generaon method or type the manual ID.
1-4) Select one of the group type.
1-5) Click 'Save' buon to save & register the current informaon.
ACCESS CONTROL CARD #
GENERATION METHOD
TYPE
Selects a method to create the new ID number
Selects a registered type of person
Public card #, Automatic generate,
Manual input | Default - Public card #
Black, White, VIP | Default - Black
ACCESS CONTROL CARD # Types the new ID number manually
This funcon is not supported on the VZ-7TIM-S.
Warning

38 39User Manual User ManualVisit the ViewZ USA website at https://www.viewzusa.com Visit the ViewZ USA website at https://www.viewzusa.com
COMPARISON
Log Record
This funcon displays the log record for scanned people. VZ-7TIM-S can provide 22,000 records with the captured
photo (registered or new captured), name, ID, person's group (guest, white, black or VIP), body temperature, me,
mask worn, visit me, rst me visit and similarity (with registered photo).
TIME PERIOD
SEARCH TYPE 1)
NAME & NUMBER
Finds the recognition record under the specific time
Choose which user type will be searched
Finds the recognition record under the name or
ID number
Owner, Blacklist, Whitelist, VIP list
| Default - Owner
FUNCTION VALUE
1) ID card authencaon is not supported on VZ-7TIM-S model.
ATTENDANCE
Attendance
SET TIME
GO TO WORK
OFF DUTY
ADVANCED
WORKING DAYS SETTING
NAME / NUMBER
ATTENDANCE STATUS
QUERY TYPE
Finds a record from the specific day
Sets the time which come to work
Sets the time which out of work
Sets the time by a week day
Sets the working day
Finds a record by specific name and ID number
Sets the finding record based on the specific condition
Selects a display type based on record or statistic data
Monday ~Sunday
00:00 ~00:00
00:00 ~00:00
Monday ~Sunday
Monday ~Sunday
All, Late, Leave Early,
Record, Statistic
| Default - Record
No attendance | Default - All
FUNCTION VALUE
Find the aendance data of registered people under the aendance tab.
