Viking VK1815 User manual

Viking VK1815
Egress 18 IP Par Light
User Manual
Please read the instruction carefully before use

Caution!
Be careful with your operations. With a dangerous voltage you can suffer a dangerous
electric shock when touching the wires!
Keep this device away from rain and moisture!
Make sure it is grounded when using it!
Unplug mains lead before opening the housing!
For your own safety, please read this user manual carefully before you initial start-up.
Introduction
Thank you for having chosen this Item. You will see you acquired a powerful and versatile
device. Unpack your item. Before you initial start-up, please make sure that there is no
damage caused by transportation. Should there be any, consult your dealer and do not
use the device.
Safety instructions
This device has left our premises in absolutely perfect condition. In order to maintain this
condition and to ensure a safe operation, it is absolutely necessary for the user to follow
the safety instructions and warning notes written in this user manual. Always disconnect
from the mains, when the device is not in use or before cleaning it. Keep away children
and amateurs from the device! There are no serviceable parts inside the device.
Specifications
Input power：AC100-240V 50/60 Hz
Power consumption：165w
LED：18 pcs15W RGBWA+UV LED
Light effect：pure color ,light is evenly spread
DMX channel：2/3/6/9/11 channel
Display: Touch panel menu with LCD display
Control mode：DMX512/Master-Slave/Auto run/IR remote control
0-100% linear dimmer
With RDM function
IP-Rating：IP65
product size：220×280×230mm
packing size：290×290×275mm
N.W：4.6Kg
G.W：5.3Kg

Control menu
[MENU] Main menu to select or return to the previous menu
[UP] Menu selection or parameter increase
[DOWN] Menu selection or parameter decrease
[ENTER] OK / enter or select sub menu
First
Manual
Secondary
Menu Value 1 Value 2 Value 3 Function
DMX
Address 001-512 DMX512 Address Code Setting
DMX
Channel
11CH Channel 11Mode
9CH Channel 9 Mode
6CH Channel 6 Mode
3CH Channel 3 Mode
2CH Channel 2 Mode
Stand Alone
Auto
Program 1 Dim 000-255
Program 2 Speed 000-255
Program 3
……
……
Program 16
Color Macro
Color Off
Color1
001-255
Color2
Color3
Color4
Color5

Color6
Color7
Color8
Color9
Color10
Color11
Color12
Color13
Color14
Color15
Color16
Color17
Color18
Color19
Color20
Color21
Color22
Color23
Color24
Color25
Color26
Color27
Color28
Color29
Color30
Color31
Color32
Color33
Color34
Color35
Static
Dimmer
000-255
Strobe
Red
Green
Blue
White
Amber
UV
Tunable
White
Dimmer 000-255
CTC 2800~8000K
User Color Color1 Dimmer 000-255

Color2 Strobe 000-255
Color3 Red 000-255
Color4 Green 000-255
Color5 Blue 000-255
Color6 White 000-255
Color7 Amber 000-255
Color8 UB 000-255
Slave Yes/No
Settings
Output Set Standard Normal output 150W
Full High power output 180W
Display
Reverse
On The display is reversed
Off Normal display
Display
Backlight
On The display is always on
Off
Automatically turn off after
displaying for one minute
DMX Fail
Hold Keep the last state
Blackout Blackout
Emergency Light
Bright and cool white as an
emergency light
Dimmer
Curve
Linear Dimming curve 1 (straight line)
Exponential Dimming curve 2 (index)
Logarithmic Dimming curve 3 (logarithmic)
S-Curve Dimming curve 4 (S curve)
Dimmer
Response
LED LED effect
Halogen Halogen bubble effect
Auto Lock On
The screen will automatically lock
after one minute. The screen can
also be locked manually: press "up"
& "down" button for 5 seconds at
the same time, then will display "
Locked". To unlock, press "up" &
"down" button for 5 seconds at the
same time.
Off Turn off screen lock
IR Remote On
Off
Factory
Reset
ENTER-Reset
Now-ENTER
System Info
Firmwre V1.0 Display version number
Operation
Hours xxxHrs Total hours for the light run
RDMxxxxx
Press the "ENTER" button for 5
seconds into the backstage to set
the RDM value

DMX Controlling:
After having addressed all items, you may now start operating these via your lighting
controller. After switching on, the item will automatically detect whether DMX 512 data is
received or not.
Channel modes:
2 channel mode
3 channel mode
2 CH Mode
Ch. Function Values Sub-Group
1 Dimmer 000 - 255 0% to 100% Dimmer
2 Full White RGBW 000 - 255 7200K - 3200K @ Full on
3 CH Mode
Ch. Function Values Sub-Group
1 Dimmer 000 - 255 0% to 100% Dimmer
2 Strobe functions
000 - 005 Strobe open
Multifunctional-Strobe
006 - 010 Strobe closed
011 - 033 Puls Random, slow -> fast
034 - 056 Ramp up Random, slow -> fast
057 - 079 Ramp down Random, slow -> fast
080 - 102 Random Strobe Effect, slow -> fast
103 - 127
Strobe Break Effekt, 5s…..1s (Sh
ort
burst with break)
128 - 250 Strobe slow -> fast <1Hz - 20Hz
251 - 255 Strobe open
3
Colour Macro
(override RGBAWV)
000 - 010 Colour off
Colour Macro
011 - 013 Color1
014 - 016 Color2
017 - 019 Color3
020 - 022 Color4
023 - 025 Color5
026 - 028 Color6
029 - 031 Color7
032 - 034 Color8
035 - 037 Color9
038 - 040 Color10

6channel mode
6 CH Mode
Ch. Function Values Sub-Group
1 Red 000 - 255 0% to 100% Red
2 Green 000 - 255 0% to 100% Green
3 Blue 000 - 255 0% to 100% Blue
4 White 000 - 255 0% to 100% White
5 Amber 000 - 255 0% to 100% Amber
6 UV 000 - 255 0% to 100% UV
041 - 043 Color11
044 - 046 Color12
047 - 049 Color13
050 - 052 Color14
053 - 055 Color15
056 - 058 Color16
059 - 061 Color17
062 - 064 Color18
065 - 067 Color19
068 - 070 Color20
071 - 073 Color21
074 - 076 Color22
077 - 079 Color23
080 - 082 Color24
083 - 085 Color25
086 - 088 Color26
089 - 091 Color27
092 - 094 Color28
095 - 097 Color29
098 - 100 Color30
101 - 105 Color31
106 - 110 Color32
111 - 115 Color33
116 - 120 Color34
121 - 125 Color35
126 - 127 Colour Jumping Stop
128 - 191
Colour Jumping Speed slow -> fast
/ Colour 1 -> 12
192 - 255
Colour Fading Speed slow -> fast /
Colour 1 -> 12

9channel mode
9 CH Mode
Ch. Function Values Sub-Group
1 Dimmer 000 - 255 0% to 100% Dimmer
2 Strobe functions
000 - 005 Strobe open
Multifunctional-Strobe
006 - 010 Strobe closed
011 - 033 Puls Random, slow -> fast
034 - 056 Ramp up Random, slow -> fast
057 - 079 Ramp down Random, slow -> fast
080 - 102 Random Strobe Effect, slow -> fast
103 - 127
Strobe Break Effekt, 5s…..1s (Short
burst with break)
128 - 250 Strobe slow -> fast <1Hz - 20Hz
251 - 255 Strobe open
3 Red 000 - 255 0% to 100% Red
4 Green 000 - 255 0% to 100% Green
5 Blue 000 - 255 0% to 100% Blue
6 White 000 - 255 0% to 100% White
7 Amber 000 - 255 0% to 100% Amber
8 UV 000 - 255 0% to 100% UV
9
Colour Macro
(override RGBAWV
Cover up 3-8
channels at startup)
000 - 010 Colour off
Colour Macro
011 - 013 Color1
014 - 016 Color2
017 - 019 Color3
020 - 022 Color4
023 - 025 Color5
026 - 028 Color6
029 - 031 Color7
032 - 034 Color8
035 - 037 Color9
038 - 040 Color10
041 - 043 Color11
044 - 046 Color12
047 - 049 Color13
050 - 052 Color14
053 - 055 Color15
056 - 058 Color16
059 - 061 Color17
062 - 064 Color18
065 - 067 Color19

068 - 070 Color20
071 - 073 Color21
074 - 076 Color22
077 - 079 Color23
080 - 082 Color24
083 - 085 Color25
086 - 088 Color26
089 - 091 Color27
092 - 094 Color28
095 - 097 Color29
098 - 100 Color30
101 - 105 Color31
106 - 110 Color32
111 - 115 Color33
116 - 120 Color34
121 - 125 Color35
126 - 127 Colour Jumping Stop
128 - 191
Colour Jumping Speed slow -> fast
/ Colour 1 -> 12
192 - 255
Colour Fading Speed slow -> fast /
Colour 1 -> 12
11channel mode
11 CH Mode 2
Ch. Function Values Sub-Group
1 Dimmer 000 - 255 0% to 100% Dimmer
2 Strobe functions
000 - 005 Strobe open
Multifunctional-Strobe
006 - 010 Strobe closed
011 - 033 Puls Random, slow -> fast
034 - 056 Ramp up Random, slow -> fast
057 - 079 Ramp down Random, slow -> fast
080 - 102 Random Strobe Effect, slow -> fast
103 - 127
Strobe Break Effekt, 5s…..1s (Short
burst with break)
128 - 250 Strobe slow -> fast <1Hz - 20Hz
251 - 255 Strobe open
3 Red 000 - 255 0% to 100% Red
4 Green 000 - 255 0% to 100% Green
5 Blue 000 - 255 0% to 100% Blue
6 White 000 - 255 0% to 100% White
7 Amber 000 - 255 0% to 100% Amber

8 UV 000 - 255 0% to 100% UV
9
Colour Macro
(override RGBAWV
Cover up 3-8
channels at startup)
000 - 010 Colour off
Colour Macro
011 - 013 Color1
014 - 016 Color2
017 - 019 Color3
020 - 022 Color4
023 - 025 Color5
026 - 028 Color6
029 - 031 Color7
032 - 034 Color8
035 - 037 Color9
038 - 040 Color10
041 - 043 Color11
044 - 046 Color12
047 - 049 Color13
050 - 052 Color14
053 - 055 Color15
056 - 058 Color16
059 - 061 Color17
062 - 064 Color18
065 - 067 Color19
068 - 070 Color20
071 - 073 Color21
074 - 076 Color22
077 - 079 Color23
080 - 082 Color24
083 - 085 Color25
086 - 088 Color26
089 - 091 Color27
092 - 094 Color28
095 - 097 Color29
098 - 100 Color30
101 - 105 Color31
106 - 110 Color32
111 - 115 Color33
116 - 120 Color34
121 - 125 Color35
126 - 127 Colour Jumping Stop
128 - 191
Colour Jumping Speed slow -> fast
/ Colour 1 -> 12

192 - 255
Colour Fading Speed slow -> fast /
Colour 1 -> 12
10
Colour Temperature
(Cover up 3-8
channels at startup)
000 - 005 off
Colour Temperature
Correction
006 - 031 2800K
032 - 063 3500K
064 - 095 4000K
096 - 127 5000K
128 - 159 6000K
160 - 191 7000K
192 - 223 7500K
224 - 255 8000K
11 Set dimmer curve
000 005 no function
Set dimmer curve
006 - 063 Linear Dimmer Curve
064 - 127 Exponential Dimmer Curve
128 - 191 Logarithmic Dimmer Curve
192 - 255 S-Curve Dimmer Curve
Set DMX address
Display the DMX 512 value of each channel. With this function you can display the DMX
512 value of each channel. The display automatically shows the channel with a value changing.
