Viking Professional VISB548D User manual

FINISH DETAILS FOR VCSB/VISB MODEL
• Stainless Steel (SS), Black (BK), White
(WH), Metallic Silver (MS), Graphite Gray
(GG), Stone Gray (SG), Taupe (TP), Biscuit
(BT), Cotton White (CW), Oyster Gray
(OG), Gol en Mist (GM), Lemona e (LE),
Sage (SA), Mint Julep (MJ), Sea Glass
(SE), Iri escent Blue (IB), Viking Blue (VB),
Pumpkin (PM), Racing Re (RR), Apple
Re (AR), Burgun y (BU), Plum (PL),
Chocolate (CH), an Cobalt Blue (CB).
• Finish co es esignate oor fronts.
Stainless steel upper grille, si e trim,
an han les (with chrome-plate brack-
ets); black lower kickplate.
• Brass Accent Option (BR)—nameplate
an han le en caps. Brass components
have a urable protective coating for
maintenance-free normal use.
REFRIGERATION
Quiet Cool™ Built-In 48”W. Side-By-Side
Re rigerator/Freezer with Dispenser
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 7 / 1 2 / 1 0
© 2 0 1 0 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
All models include
• Total capacity—27.1 cu. ft. (767.0 L)
oRefrigerator - 18.5 cu. ft.
oFreezer - 8.6 cu. ft.
o 84”H./24”D.
• ProChill™ Temperature Management
System
oVariable-spee DC Over rive™
Compressor is one of the quietest,
most technologically a vance com-
pressors available
oElectronic controls maintain the tem-
perature selection within 1ºF
oMulti-channel airflow system an
O or Eliminator™ Evaporator
removes o ors an excess humi ity
•Exclusive Plasmacluster™* Ion Air
Purifier
oEliminates airborne bacteria an mol
spores
oRemoves o ors
oEnhances foo preservation
oNever nee s replacing
• Refrigerator Compartment
oFour a justable tempere glass spill-
proof shelves
• A justable Col Zone™ rawer with
precision ball-bearing gli es
oSeparate temperature control can be
set for pro uce or fresh meat storage
oQuick chill option chills foo s an
beverages in minutes
• A justable Humi ity Zone™ rawers
with precision ball-bearing gli es
oHumi ity can be set high for leafy
greens or low for fruits an vegeta-
bles with skins
• Two in-the- oor seale airy
compartments with covers
• Four patente a justable aluminum
oor bins with tempere glass fronts
• Top-shelf provi es quick chill- own
area
• Freezer Compartment
oA aptive efrost
oThree wire shelves an two sli e-out
baskets
oThree patente a justable aluminum
oor bins with tempere glass fronts
• Ice/Water Dispenser
oThrough-the- oor ispenser
provi es cube ice, crushe ice an
water in easy on-han operation
oPremium water filter provi es clean-
er water an ice supply by filtering
ba tastes, o ors, se iment an
harmful contaminants.
• Super Clog-Resistant™ Con enser is
maintenance-free un er normal use
• Tru-Flush™ esign
oAllows Professional Integrate an
Custom Panel mo els to fit flush into
24” eep installation cutout
• Open oor alarm soun s an glows to
warn that oor has been ajar for three
minutes
• A justable oor stops stan ar —90°,
110°, or 120° swing
• Sabbath Mo e
*Plasmacluster is a registere tra emark
of Sharp Corporation.
FINISH DETAILS FOR DDSB MODEL
• Stainless Steel (SS), Black (BK), White
(WH), Metallic Silver (MS), Graphite Gray
(GG), Stone Gray (SG), Taupe (TP),
Biscuit (BT), Cotton White (CW), Oyster
Gray (OG), Gol en Mist (GM),
Lemona e (LE), Sage (SA), Mint Julep
(MJ), Sea Glass (SE), Iri escent Blue (IB),
Viking Blue (VB), Pumpkin (PM), Racing
Re (RR), Apple Re (AR), Burgun y
(BU), Plum (PL), Chocolate (CH), an
Cobalt Blue (CB).
• Finish co es esignate oor fronts.
Stainless steel upper grille, si e trim,
an han les; black lower kickplate.
Standard Features & Accessories
Model Options
ORDERING INSTRUCTIONS
First specify mo el number, an then color co e (VCSB548DSS). If or ering optional brass accent, specify co e at en (VCSB548DSSBR).
VCSB548D/VISB548D
Pro essional/Pro essional
Integrated
DDSB548D
Designer
FINISH DETAILS FOR DFSB MODEL
• Han les not inclu e —opt for custom
han les, or purchase a Viking
Professional Series or Designer Series
han le kit (see Installation Notes &
Accessories).
• See Custom Panels section for more
information an a itional
specifications.
DFSB548D
Custom Panel

REFRIGERATION
Quiet Cool™ Built-In 48”W. Side-By-Side
Re rigerator/Freezer with Dispenser
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 7 / 1 2 / 1 0
© 2 0 1 0 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E

Please see
Installation Notes &
Accessories
for important
information,
inclu ing panel, an
han le kits, an
water filters.
22-3/16”
(56.4cm)
24-11/16”
(62.7cm)
75-15/16”
(192.9cm)
3-19/32”
(9.1cm)
48”
(121.9cm)
27-1/4”
(69.2cm)
47”
(119.4cm)
82-3/4”
(210.2cm)
min.
to
84-1/16”
(213.5cm)
max.
23-3/8”
(59.4cm)
24”
(61.0cm)
75-15/16”
(192.9cm)
48”
(121.9cm)
26-1/2”
(67.3cm)
47”
(119.4cm)
82-3/4”
(210.2cm)
min.
to
84-1/16”
(213.5cm)
max.
3-19/32”
(9.1cm)
PROFESSIONAL PROFESSIONAL
INTEGRATED
VCSB548D VISB548D
Overall width 48” (121.9 cm)
Overall height (fro botto ) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max.
Overall depth (fro rear)
To front edge of side tri 22-3/16” (56.4 c ) 23-3/8” (59.4 c )
To front of top grille 24-11/16” (62.7 c ) 24” (61.0 c )
To front of handle 27-1/4” (69.2 c ) 26-1/2” (67.3 c )
Approx. ship weight 735 lbs. (330.8 kg)
VCSB548D/VISB548D
Pro essional/Pro essional
Integrated
Dimensions & Speci ications
PRODUCT DIMENSIONS
Star-K Kosher
Certi ication or
use on the Jewish
Sabbath or Jewish
holidays
ALL MODELS

REFRIGERATION
Quiet Cool™ Built-In 48”W. Side-By-Side
Re rigerator/Freezer with Dispenser
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 7 / 1 2 / 1 0
© 2 0 1 0 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E

Please see
Installation Notes &
Accessories
for important
information,
inclu ing panel, an
han le kits, an
water filters.
DDSB548D
Overall width 48” (121.9 cm)
Overall height (fro botto ) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max.
Overall depth (fro rear)
To front edge of side tri 23-3/8” (59.4 cm)
To front of top grille 24” (61.0 cm)
To front of handle 26-1/2” (67.3 cm)
Approx. ship weight 735 lbs. (330.8 kg)
DDSB548D
Designer
Dimensions & Speci ications
PRODUCT DIMENSIONS
Star-K Kosher
Certi ication or
use on the Jewish
Sabbath or Jewish
holidays
ALL MODELS
23-3/8”
(59.4cm)
24”
(61.0cm)
75-15/16”
(192.9cm)
48”
(121.9cm)
47”
(119.4cm)
82-3/4”
(210.2cm)
Min.
to
84-1/16”
(213.5cm)
max.
26-1/2”
(67.3 cm)
3-19/32”
(9.1cm)
DESIGNER

REFRIGERATION
Quiet Cool™ Built-In 48”W. Side-By-Side
Re rigerator/Freezer with Dispenser
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 7 / 1 2 / 1 0
© 2 0 1 0 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E

Please see
Installation Notes &
Accessories
for important
information,
inclu ing panel, an
han le kits, an
water filters.
DFSB548D
Overall width 48” (121.9 cm)
Overall height (fro botto ) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max.
Overall depth (fro rear)
To front edge of side tri 23-13/16” (60.5 cm)
To front of top grille 24-3/4” (62.9 cm)
To front of handle Varies
Approx. ship weight 675 lbs. (303.8 kg)
DFSB548D
Custom Panel
See Custom Panels section for
more information an a itional
specifications.
Dimensions & Speci ications
PRODUCT DIMENSIONS
Star-K Kosher
Certi ication or
use on the Jewish
Sabbath or Jewish
holidays
ALL MODELS
23-13/16”
(60.5cm)
24-3/4”
(62.9cm)
75-15/16”
(192.9cm)
48”
(121.9cm)
47”
(119.4cm)
82-3/4”
(210.2cm)
Min.
to
84-1/16”
(213.5cm)
max.
Varies
3-1/2”
(8.9cm)
CUSTOM PANEL

PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 7 / 1 2 / 1 0
© 2 0 1 0 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
REFRIGERATION
Quiet Cool™ Built-In 48”W. Side-By-Side
Re rigerator/Freezer with Dispenser
41-27/32”
(106.3 cm)
15-13/32”
(39.1 cm)
11-9/16”
(29.4 cm)
2-1/2”
(6.4 cm)
41-1/8”
(104.4 cm)
39-15/16”
(101.4 cm)
48-1/4”
(122.6 cm)
50-1/8”
(127.3 cm)
51-7/16”
(130.7 cm)
2-31/32”
(7.5 cm)
2-31/32”
(7.5 cm)
8-1/8”
(20.6 cm)
10-19/32”
(26.3 cm)
48”
(121.9cm)
47”
(119.4cm)
90° 90°
110° 110°
120° 120°
24-23/32”
(62.8 cm)
7-3/8”
(18.7 cm)
1-27/32”
(4.7 cm)
9-13/16”
(25.0 cm)
24-3/32”
(61.2 cm)
39-15/16”
(101.4cm)
41-27/32”
(106.3cm)
47”
(119.4cm)
48-11/32”
(122.8cm)
10-21/32”
(27.1cm)
1-27/32”
(4.7cm)
14-5/8”
(37.2cm)
51-7/16”
(130.7cm)
50-3/16”
(127.5cm)
48”
(121.9cm)
41-3/32”
(104.4cm)
90°
110°
120°
90°
110°
120°
2-1/2” (6.4 cm)
Professional Integrated/
Designer
PROFESSIONAL INTEGRATED/
DESIGNER
PROFESSIONAL
Dimensions & Speci ications
DOOR SWING
• A justable oor stops stan ar —90°, 110°, or 120° swing
See Custom Panels section for
more information an a itional
specifications.
VCSB548D/VISB548D
Pro essional/Pro essional
Integrated
DDSB548D
Designer
DFSB548D
Custom Panel

PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 7 / 1 2 / 1 0
© 2 0 1 0 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
REFRIGERATION
Quiet Cool™ Built-In 48”W. Side-By-Side
Re rigerator/Freezer with Dispenser
Door
Wall
1-13/16”
(4.6 cm)
space if 24” standard
cabinet depth is used
3/4”
(1.9 cm)
full end panel
24”
(61.0 cm)
standard
cabinet
depth
2-1/2”
(6.4 cm) offset
5/16”
(0.8 cm)
1-13/16”
(4.6 cm)
space if 24” standard
cabinet depth is used
Door
24”
(61.0 cm)
standard cabinet depth
Wall
3/4”
(1.9 cm)
full end panel
2-1/2”
(6.4 cm) offset
Countertop
overhang
Dimensions & Speci ications
CLEARANCE DIMENSIONS—PROFESSIONAL
1-13/16”
(4.6 cm)
space if 24” standard
cabinet depth is used
Door
24”
(61.0 cm)
standard cabinet depth
Wall
3/4”
(1.9 cm)
full end panel
2-1/2”
(6.4 cm) offset
Partial overlay
cabinet door
TOP VIEW
TOP VIEW
TOP VIEW

PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 7 / 1 2 / 1 0
© 2 0 1 0 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
REFRIGERATION
Quiet Cool™ Built-In 48”W. Side-By-Side
Re rigerator/Freezer with Dispenser
Door
Wall
1”
(2.5 cm)
if 25” (63.5 cm)
cabinet depth is used
3/4”
(1.9 cm)
full end panel
25”
(63.5 cm)
Flush
Door
24”
(61.0 cm)
standard
cabinet
depth
25”
(63.5 cm)
countertop
depth
Wall
3/4”
(1.9 cm)
full end panel
1”
(2.5 cm)
if 25” (63.5 cm)
cabinet depth is used
Flush
Dimensions & Speci ications
CLEARANCE DIMENSIONS—PROFESSIONAL INTEGRATED/DESIGNER
Door
24”
(61.0cm)
standard
cabinet
depth
24-3/4”
(62.9 cm)
Wall
3/4”
(1.9 cm)
full end panel
3/4”
(1.9 cm)
if 25” (63.5 cm)
cabinet depth is used
Flush
Cabinet
door
TOP VIEW
TOP VIEW
TOP VIEW
Overlapping cabinet doors

REFRIGERATION
Quiet Cool™ Built-In 48”W. Side-By-Side
Re rigerator/Freezer with Dispenser
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 7 / 1 2 / 1 0
© 2 0 1 0 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
UTILITY
REQUIREMENTS
GAS
Not applicable
ELECTRICAL
• Three-wire cor
with groun e
three-prong plug
attache to
pro uct
• 115 VAC/60 Hz;
15 amp e icat-
e circuit
• Maximum amp
usage—11.5
• Estimate
energy usage—
727 kWh/year
PLUMBING
• Inlet waterline
requirements—
1/4”copper
tubing
• 35 psi min.;
120 psi max.
Installation Requirements
Anti-tipboard
6”
(15.2cm)
9”
(22.9cm)
6-3/4”
(17.1cm)
7-5/8”
(19.4cm)
3”
(7.6cm)
5/8”
(1.5cm)
5/8”
(1.5cm)
10-1/2”
(26.7cm)
5/8”
(1.5cm)
10-3/4”
(27.3cm)
1”
(2.5cm)
3-5/8”
(9.2cm)
Optionalfloor
waterlineentry
9”
(22.9 cm)
73-3/8”
(186.4cm)
82-7/8”
(210.5cm)min.
anti-tipboard&
openingheight
84-1/16”
(213.5cm)max.
anti-tipboard&
openingheight
24”*
(61.0cm)min.
47-1/2”min.
(120.7cm)
to
47-3/4”max.
(121.3cm)
Professional
48”
(121.9cm)
ProfessionalIntegrated/
Custom Front
ACCESS REQUIREMENTS
VCSB548D VISB548D/DDSB548D DFSB548D
Cutout width 47-1/2” (120.7 c ) in. to 48” (121.9 c ) 48” (121.9 c )
47-3/4” (121.3 c ) ax.
Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max.
Cutout depth 24” (61.0 cm) min.*
ELECTRIC OUTLET LOCATION
WATERLINE ENTRY AREA
*Custo panel odels fit flush in 25”-deep (63.5 c )
cabinet openings. They can be installed in standard
24”-deep openings. The door faces and top grille
will protrude 3/4” (1.9 c ) into the roo .
See Custom Panels section for
more information an a itional
specifications.
VCSB548D/VISB548D
Pro essional/Pro essional
Integrated
DDSB548D
Designer
DFSB548D
Custom Panel

REFRIGERATION
Quiet Cool™ Built-In 48”W. Side-By-Side
Re rigerator/Freezer with Dispenser
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 7 / 1 2 / 1 0
© 2 0 1 0 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
Side Panel Kits
• Stainless Steel (SS)
• Panels provi e finishe , freestan ing look; unit must still be secure to the wall
•Kit inclu es one panel an installation har ware
Side Panel Hardware Kit
• For use with Designer built-in refrigerator/freezers
• Har ware allows installation of custom si e panels
• Kit inclu es brackets, screws, an installation instructions to mount panels on left an right si e
Top Panel Kit
• Stainless Steel (SS)
• Panel provi es finishe , freestan ing look; unit must still be secure to the wall
• Kit inclu es one panel an installation har ware
Handle Kits
• For use with custom panel refrigerator/freezers
• For use on locally supplie custom panels
• Han les allow refrigerator/freezers with custom panels to coor inate with other Professional an Designer pro ucts
• Kit inclu es two han les an installation har ware
Replacement Water Filter
• Re uces se iment, taste, an o or
• Re uces cysts, particulates, turbi ity, lea , chlorine, atrazine, an lin ane
• NSF-certifie
• Rea y to install—no assembly require
• Replacement recommen e every nine months
Compliance In ormation
WARRANTY SUMMARY*
• Two-year full warranty—complete unit
• Six-year full warranty—seale refrigeration system
• Twelve-year limite warranty—seale refrigeration system (inclu es compressor, con enser,
ryer/strainer, evaporator, an connecting tubing)
• Ninety- ay limite warranty—cosmetic parts such as glass, painte , an ecorative items
*For complete warranty see Use & Care Guide. Warranty vali on Viking pro ucts shippe within the Unite States an Cana a.
Installation Notes & Accessories
Model Description Approx. ship wt. lbs. (kg)
RWF-DISP Replace ent water filter 5 (2.3)
Model Description Approx. ship wt. lbs. (kg)
PHK-DFSB5-SS Professional handles (Stainless Steel) 10 (4.5)
DDHK-DFSB5-SS Designer handles (Stainless Steel) 10 (4.5)
Model Description Approx. ship wt. lbs. (kg)
PSSPL2 Professional side panel left (VSCB) 45 (20.2)
PSSPR2 Professional side panel right (VSCB) 45 (20.2)
DSSPL2 Designer side panel left (VISB/DDSB/DFSB) 45 (20.2)
DSSPR2 Designer side panel right (VISB/DDSB/DFSB) 45 (20.2)
Model Description Approx. ship wt. lbs. (kg)
TOP-48 48”W. top panel 24 (10.8)
Model Description Approx. ship wt. lbs. (kg)
SPHKDS Side panel hardware 3 (1.4)
