P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1
R E V I S E D 5 / 2 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE
VENTILATION
Built-In 10”H. Wall Hood w/Ventilator/
12”H. Chimney Wall Hood w/Ventilator/
All models include
• Heavy- uty construction
o Virtually seamless stainless steel
esign with no visible screws
• Heat sensor turns the ventilator on full
power when cooking temperatures
reach uncomfortable levels
• Recommen e for 24”W., 30”W. &
36”W. non-gri le/grill ranges,
rangetops, an cooktops
• Two 50-watt halogen lights with
immer control
o Power switch an immer control
are separate, allowing you to leave
immer at favorite position
• Easy cleanup
o Design of low-profile filter system
means less interior hoo space to
be cleane
o Canopy interior is completely line
in stainless steel for increase
rigi ity, seamless appearance, an
easy cleaning
Pro essional 10”H. hoods include
• Commercial-type size, esign, an styling
• Commercial-type baffle filter system
efficiently removes grease an heate
vapors from the air; especially esigne
for use with commercial-type pro ucts
• 460 CFM interior-power ventilator
comes stan ar with pro uct
o Variable spee controls for custom
venting—separate on/off switch
allows you to leave ventilator at
favorite/most-use setting
Designer 12”H. hoods include
• Professional-type size, esign, an styling
• Delay function—can be set to shut off
from 10 – 30 minutes later (10 min.
increments)
• 12-hour timer built into controls
• Two ishwasher-safe stainless steel
mesh filters are easily remove for
quick cleaning (frame an mesh are
stainless steel)
• 460 CFM interior-power ventilator
comes stan ar with pro uct
o Variable spee controls for custom
venting—separate on/off switch
allows you to leave ventilator at
favorite/most-use setting
Model numbers
PROFESSIONAL WALL HOODS, 10”H./21”D.
• VWH2410—24”W.
o Recommen e for use with 24”W.
non-gri le/grill ranges (for larger
equipment, use 18”H. hoo )
• VWH3010—30”W.
o Recommen e for use with 30”W.
ranges, 30”W. non-gri le/grill
rangetops, an 30”W. cooktops
• VWH3610—36”W.
o Recommen e for use with 36”W.
non-gri le/grill ranges, 36”W.
non-gri le/grill rangetops, an
36”W. cooktops
DESIGNER CHIMNEY WALL HOODS,
12”H./24”D.
• DCH3042—30”W.
o Recommen e for use with 30”W.
ranges, 30”W. non-gri le/grill
rangetops, an 30”W. cooktops
• DCH3642—36”W.
o Recommen e for use with 36”W.
ranges, 36”W. non-gri le/grill
rangetops, an 36”W. cooktops
Burgun y (BU), Plum (PL), Chocolate
(CH), an Cobalt Blue (CB).
• Finish esignates front an si es.
• Accessory Rail Option (DCH Only)—
Front of hoo . (Must be or ere
factory installe )
o Stainless Steel/Chrome (CR)—
Stainless steel rail with chrome
supports/brackets an hooks
(inclu e ).
o Brass Trim Option (DCH Only) (BR)—
rail, supports/brackets, an hooks
(inclu e ). Brass components have a
urable protective coating for
maintenance-free normal use.
o Brass Trim Option (BR)—nameplate,
rail, supports/brackets, an hooks
(inclu e ). Brass components have a
urable protective coating for
maintenance-free normal use.
FINISH DETAILS DESIGNER MODELS
• Stainless Steel (SS), Black (BK), White
(WH), Metallic Silver (MS), Graphite
Gray (GG), Stone Gray (SG), Taupe
(TP), Biscuit (BT), Cotton White (CW),
Oyster Gray (OG), Gol en Mist (GM),
Lemona e (LE), Sage (SA), Mint Julep
(MJ), Sea Glass (SE), Iri escent Blue
(IB), Viking Blue (VB), Pumpkin (PM),
Racing Re (RR), Apple Re (AR),
FINISH DETAILS FOR PROFESSIONAL MODELS
• Stainless Steel (SS), Black (BK), White
(WH), Metallic Silver (MS), Graphite Gray
(GG), Stone Gray (SG), Taupe (TP), Biscuit
(BT), Cotton White (CW), Oyster Gray
(OG), Gol en Mist (GM), Lemona e (LE),
Sage (SA), Mint Julep (MJ), Sea Glass
(SE), Iri escent Blue (IB), Viking Blue (VB),
Pumpkin (PM), Racing Re (RR), Apple
Re (AR), Burgun y (BU), Plum (PL),
Chocolate (CH), an Cobalt Blue (CB).
• Finish esignates front an si es.
• Accessory Rail Option—Front of hoo .
(Must be or ere factory installe )
o Stainless Steel/Chrome (CR)—Stainless
steel rail with chrome supports/
brackets an hooks (inclu e ).
VWH Professiona
Wa Hood
DCH Designer Chimney
Wa Hood
Standard Features & Accessories
Model Options
ORDERING INSTRUCTIONS
First specify mo el number, followe by color co e (VWH2410SS). If or ering optional ecorative rail, specify co e at en
(VWH2410SSCR).

VENTILATION
6”H. Wall Hood w/Ventilator
P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1
R E V I S E D 5 / 2 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE
Designer 6”H. hoods include
• Heavy- uty construction
o Virtually seamless stainless steel
esign with no visible screws
• Allows true replacement of ol er
hoo s with minimal cabinet alteration
• Recommen e for 24”W., 30”W. &
36”W. non-gri le/grill ranges,
rangetops, an cooktops
• 300 CFM interior-power ventilator
comes stan ar
• Heat sensor turns the ventilator on full
power when cooking temperatures
reach uncomfortable levels
• Ships set to recirculate, but may be
converte to vent out top or rear
• Two 50-watt halogen lights with
immer control
o Power switch an immer control
are separate, allowing you to leave
immer at favorite position
• Easy cleanup
o Design of low-profile filter system
means less interior hoo space to
be cleane
o Canopy interior is completely line
in stainless steel for increase
rigi ity, seamless appearance, an
easy cleaning
o Two ishwasher-safe stainless steel
mesh filters are easily remove for
quick cleaning (frame an mesh are
stainless steel)
Model numbers
DESIGNER 6” WALL HOODS, 6”H./20”D.
• DWH3006—30”W.
o Recommen e for use with 30”W.
non-gri le/grill ranges, 30”W.
non-gri le/grill rangetops, an
30”W. cooktops
• DWH3606—36”W.
o Recommen e for use with 36”W.
non-gri le/grill ranges, 36”W.
non-gri le/grill rangetops, an
36”W. cooktops
FINISH DETAILS DESIGNER MODELS
• Stainless Steel (SS), Black (BK), White
(WH), Metallic Silver (MS), Graphite
Gray (GG), Stone Gray (SG), Taupe (TP),
Biscuit (BT), Cotton White (CW), Oyster
Gray (OG), Gol en Mist (GM),
Lemona e (LE), Sage (SA), Mint Julep
(MJ), Sea Glass (SE), Iri escent Blue (IB),
Viking Blue (VB), Pumpkin (PM), Racing
Re (RR), Apple Re (AR), Burgun y
(BU), Plum (PL), Chocolate (CH), an
Cobalt Blue (CB).
• Finish esignates front an si es.
DWH Designer Rep acement
Wa Hood
Standard Features & Accessories
Model Options
ORDERING INSTRUCTIONS
First specify mo el number, followe by color co e (DWH3006SS).

24”
(61.0 cm)
16”
(40.6 cm)
12”
(30.5cm)
2”
(5.1 cm)
12”
(30.5 cm)
A
2”
(5.1 cm)
21”
(53.3cm)
A
12”
(30.5 cm)
10 ”
(25.4cm)
4”
(10.2cm)
6”
(15.2 cm)
VENTILATION
Built-In 10”H. Wall Hood w/Ventilator/
12”H. Chimney Wall Hood w/Ventilator/
P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1
R E V I S E D 5 / 2 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE
24”
(61.0 cm)
16”
(40.6 cm)
12”
(30.5cm)
18”
(45.7cm)
to
30”
(76.2cm)
12”
(30.5 cm)
A
2”
(5.1 cm)
✪
Please see
Insta ation Notes &
Accessories for
important information,
including conversion
kits, filters, duct
covers, backsplashes,
and warming shelf
panels.
21”
(53.3cm)
A
12”
(30.5cm)
10 ”
(25.4 cm)
12 ”
(30.5cm)
6”
(15.2 cm)
Dimensions & Speci ications
PRODUCT DIMENSIONS
VWH Professiona
Wa Hood
DCH Designer Chimney
Wa Hood
PROFESSIONAL DESIGNER
Model Hood Duct Cover Lights Filters Heat Approx.
Width (A) Height Width Depth Height Lamps Ship. wt.
VWH2410 23-7/8” (60.6 cm) 10” (25.4 cm) 23-7/8” 12” (30.5 cm) 12” (30.5 cm) 22N/A 48 lbs.
(60.6 cm) (21.7 kg)
VWH3010 29-7/8” (75.9 cm) 10” (25.4 cm) 29-7/8” 12” (30.5 cm) 12” (30.5 cm) 22N/A 56 lbs.
(75.9 cm) (25.2 kg)
VWH3610 35-7/8” (91.1 cm) 10” (25.4 cm) 35-7/8” 12” (30.5 cm) 12” (30.5 cm) 22N/A 60 lbs.
(91.1 cm) (27.0 kg)
DCH3042 29-7/8” (75.9 cm) 12” (30.5 cm) 16” (40.6 cm) 12” (30.5 cm) 18” (45.7 cm)— 22N/A 56 lbs.
30” (76.2 cm) (25.2 kg)
DCH3642 35-7/8” (91.1 cm) 12” (30.5 cm) 16” (40.6 cm) 12” (30.5 cm) 18” (45.7 cm)— 22N/A 60 lbs.
30” (76.2 cm) (27.0 kg)
PROFESSIONAL
W/RECIRCULATING KIT
DESIGNER
W/RECIRCULATING KIT

P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1
R E V I S E D 5 / 2 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE
VENTILATION
6”H. Wall Hood w/Ventilator
✪
Please see
Insta ation Notes &
Accessories for
important information,
including conversion
kits, filters, duct
covers, backsplashes,
and warming shelf
panels.
20”
(50.8cm)
A
6”
(15.2cm)
2”
(5.1cm)
Dimensions & Speci ications
PRODUCT DIMENSIONS
DWH Designer Rep acement
Wa Hood
DESIGNER
Model Hood Lights Filters Heat Approx.
Width (A) Height Lamps Ship. wt.
DWH3006 29-7/8” (75.9 cm) 6” (15.24 cm) 22N/A 45 lbs. (20.4 kg)
DWH3606 35-7/8” (91.1 cm) 6” (15.24 cm) 22N/A 48 lbs. (21.9 kg)

30”min.
(76.2cm)
to
33”max.
(83.8cm)
66”min.
(167.6cm)
to
69”max.
(175.3cm)
36”
(91.4cm)
P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1
R E V I S E D 5 / 2 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE
VENTILATION
Built-In 10”H. Wall Hood w/Ventilator/
12”H. Chimney Wall Hood w/Ventilator
6”H. Wall Hood w/Ventilator
24”min.
(61.0cm)
to
27”max.*
(68.6cm)
60”min.
(152.4 cm)
to
63”max.
(160.0cm)
36”
(91.4 cm)
Dimensions & Speci ications
CLEARANCE DIMENSIONS
PROFESSIONAL DESIGNER CHIMNEY HOOD
21”min.
(53.3cm)
to
27”max.*
(68.6cm)
57”min.
(144.8cm)
to
63”max.
(160cm)
36”
(91.4cm)
DESIGNER REPLACEMENT WALL HOOD
*Note: When in talling with a 24” high- helf, the 27” (68.6 cm) max. dimen ion mu t be u ed.

VENTILATION
Built-In 10”H. Wall Hood w/Ventilator/
12”H. Chimney Wall Hood w/Ventilator
6”H. Wall Hood w/Ventilator
P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1
R E V I S E D 5 / 2 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE
Proper insta ation/ ducting is
extreme y important to ensure
maximum performance. Use a qua ified
and trained insta er.
DUCTING
• VWH/DCH – 460 CFM interior
(blower inclu e )
• DWH – 300 CFM interior
(blower inclu e )
• Check with a qualifie an
traine installer for local co es
an makeup air requirements,
if any.
• Max. uct run length—50’
(152.4 m)
o Duct run length is for general
reference only; for longer
uct runs, increase uct size
an contact a qualifie an
traine installer.
o Straight runs an gra ual
turns are best; for example,
each 90° elbow is equivalent
to 5’ – 10’ (1.52 – 3.05 cm) of
straight run.
• VWH/DCH – 7” roun uct
• DWH – 3-1/4” x 10” roun
uct or equivalent
o Never use flexible uct; it
creates back pressure/air
turbulence an greatly
re uces performance.
GAS
Not applicable
ELECTRICAL
• Har wire irect with two-wire
with groun
• 120 VAC/60 Hz
• Max. amp usage—5.6
PLUMBING
Not applicable
VWH Professiona
Wa Hood
DCH Designer Chimney
Wa Hood
DWH Designer Rep acement
Wa Hood
UTILITY REQUIREMENTS
Installation Requirements
Model Interior Ventilator Kits Interior Duct Size Interior Max. Amps
VWH2410 460 CFM standard 7” (17.8 cm) 5.6
VWH3010 460 CFM standard 7” (17.8 cm) 5.6
VWH3610 460 CFM standard 7” (17.8 cm) 5.6
DCH3042 460 CFM standard 7” (17.8 cm) 5.6
DCH3642 460 CFM standard 7” (17.8 cm) 5.6
DWH3006 300 CFM standard 3-1/4” (9.5 cm) x 10” (25.4 cm) 5.6
DWH3606 300 CFM standard 3-1/4” (9.5 cm) x 10” (25.4 cm) 5.6
Note: All CFM are ba ed on te t with 0.1 tatic pre ure. Without applying tatic pre ure ( ome brand do not), CFM could be
greatly over tated.

P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1
R E V I S E D 5 / 2 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE
VENTILATION
Built-In 10”H. Wall Hood w/Ventilator/
12”H. Chimney Wall Hood w/Ventilator
6”H. Wall Hood w/Ventilator
Recirculating Hood Conversion Kits
• Stainless Steel (SS)
• For use with VWH & DCH mo els only
•Eliminates ucting
• Kit inclu es
o Two charcoal filters
o Installation har ware
o Top vent/grille
•Professional—4”H. x 12”D.
•Designer—2”H. x 12”D.
Charcoal Filters
• For use with VRK & DRK conversion kits an DWH 6”H. hoo
• Recommen e replacement every 6 – 12 months
Duct Covers
• Specify finish co e following accessory mo el number (for example, DCW24-SS)
o Professional mo els
•For VWH hoo s
•12”D.
•Exten s height of hoo by 12”—conceals uct
•Available in Stainless Steel (SS), Black (BK), White (WH), Almon (AL), Biscuit (BT), Stone Gray (SG), Graphite Gray
(GG), Burgun y (BU), Lemona e (LE), Mint Julep (MJ), Forest Green (FG), Viking Blue (VB), Cobalt Blue (CB), an
Eggplant (EP).
o Designer mo els
•For DCH hoo s
•For 8’ – 9’ ceilings
•Available in Stainless Steel (SS), Black (BK), White (WH), Biscuit (BT), Stone Gray (SG), Graphite Gray (GG).
•Not nee e if using a DCCE1610
✪Installation Notes & Accessories
Model Description Approx. ship wt. lbs. (kg)
VRK24 Profess onal 24”W. convers on k t 10 (4.5)
VRK30 Profess onal 30”W. convers on k t 13 (5.9)
VRK36 Profess onal 36”W. convers on k t 16 (7.3)
DRK30 Des gner 30”W. convers on k t 15.4 (7)
DRK36 Des gner 36”W. convers on k t 15.4 (7)
Model Description Approx. ship wt. lbs. (kg)
CFV11 Profess onal hood f lter for 24”W. 1 (0.5)
CFV13 Profess onal hood f lter for 30”W. & 36”W. 2 (0.9)
CF-D12 Des gner hood f lter for 30”W. 2 (0.9)
CF-D14 Des gner hood f lter for 36”W. 2 (0.9)
CF-D06 Des gner hood f lter for 6”H. models 1 (0.5)
Model Description Approx. ship wt. lbs. (kg)
DCW24 Profess onal 24”W. duct cover 9 (4.0)
DCW30 Profess onal 30”W. duct cover 10 (4.5)
DCW36 Profess onal 36”W. duct cover 11 (5.0)
DCC16 Des gner adjustable duct cover – for DCH 30” & 36” models 20 (9.0)

P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1
R E V I S E D 5 / 2 / 1 1
© 2 0 1 1 V R C — INFORMATION SUBJECT TO CHANGE
VENTILATION
Built-In 10”H. Wall Hood w/Ventilator/
12”H. Chimney Wall Hood w/Ventilator
6”H. Wall Hood w/Ventilator
Duct Cover Extension
• For DCH hoo s
• 16”W. x 12”D. x 28 – 40”H.
•Exten s height of hoo by up to 12” (for 10’ ceilings)
• Replaces a justable uct cover supplie stan ar with hoo
• Specify finish co e following accessory mo el number (for example, DCCE1610-SS)
• Available in Stainless Steel (SS), Black (BK), White (WH), Biscuit (BT), Stone Gray (SG), Graphite Gray (GG).
Backsplashes
• Stainless Steel (SS)
• 30”H.
• For all hoo s
• Backsplashes protect the wall space below hoo
• Create a continuous finish between cooking surface an hoo
• Low maintenance, easy to clean
• Hemme e ges with screw holes
• Kit inclu es backsplash an fastening screws
Warming Shel Panels
• Stainless Steel (SS)
• 12”D. X 12”H.
• For all hoo s
• Shelf panels hol cookware an con iments
• Kit inclu es shelf (or shelves) an fastening screws
• Fol up/ own, heavy- uty warming shelves (non-removable), factory installe on stainless steel backsplash
• 5-7/8”W. X 10-1/8”D.
Compliance In ormation
WARRANTY SUMMARY*
• Three-year full warranty—complete pro uct (Professional an Designer)
• Five-year limite warranty—all ventilator motors (Professional an Designer)
• Ninety- ay limite warranty—cosmetic parts such as glass, painte , an ecorative items (Professional an Designer)
* For complete warranty see U e & Care Guide. Warranty vali on Viking pro ucts shippe within the Unite States an Cana a.
✪Installation Notes & Accessories
Model Description Approx. ship wt. lbs. (kg)
DCCE1610 Des gner duct cover extens on 7 (15.4)
Model Description Approx. ship wt. lbs. (kg)
BKS24 24”W. backsplash 5 (2.3)
BKS30 30”W. backsplash 7 (3.2)
BKS36 36”W. backsplash 9 (4.1)
Model Description Approx. ship wt. lbs. (kg)
WGP24 24”W. warm ng shelf panel (one shelf) 6 (2.7)
WGP30 30”W. warm ng shelf panel (one shelf) 9 (4.1)
WGP36 36”W. warm ng shelf panel (two shelves) 12 (5.4)
