Vimar Idea 16577 Manual

MALU ME GI VE SA DO ON
0 4 8 12 16 20
T3
T2
T1

3
Electronic chronothermostat for
the ambient air temperature control
90716577.L.E 19-09-2003 8:49 Pagina 3

5
1. Description
The electronic chronothermostat for the ambient air temperature
control art. 16577 is one among the 200 functions of the idea series
for flush installation.
The equipment controls the ambient air temperature acting on the
supply circuit of the burner or of the water circulation pump (heating ,
or on the air-conditioner supply circuit (air-conditioning and it
guarantees an ideal ambient air temperature every day, during the
whole week.
Thanks to its various functions, it allows to choose between a factory
preset program that can be changed at one’s will, and an own, easy
to obtain, program setting.
Its wide data display indicates at any time the selected program or the
operating state of the installation.
The hysteresis, the maximum gap between the ambient air
temperature and the assigned value, can also be set between ±0.1 °C
and ±0.9 °C.
The chronothermostat is supplied through 3 1.5 V LR03 AAA alkaline
batteries (not delivered , lasting approximately 1 year.
A 2 minutes power reserve is granted to allow the batteries
replacement without losing the set regulations.
Index
1. Description .................................................................................. 5
2. Data display and external controls ........................................ 6
3. Internal controls ......................................................................... 8
4. Setting the present time and day ......................................... 12
5. Preset standard programs ..................................................... 14
6. MANUAL operation ................................................................. 17
7. TIME-DELAY MANUAL operation ....................................... 18
8. Own setting of the temperature levels values .................. 20
9. Own setting of the daily program ......................................... 24
10. JOLLY program ........................................................................ 28
11. ANTIFREEZE program ........................................................... 31
12. TIME-DELAY ANTIFREEZE operation .............................. 32
13. Installation working time ................................................. 34
14. Display of the temperature levels ........................................ 35
15. Exclusion of the installation ................................................... 37
16. Time-delay exclusion of the installation ............................. 39
17. Cancellation of the own programs ....................................... 42
18. Restart ........................................................................................ 43
19. Hysteresis .................................................................................. 44
20. Batteries replacement ............................................................ 45
21. Technical characteristics ............................................... 48
4
90716577.L.E 19-09-2003 8:49 Pagina 4

7
Data display
5 When the figures of the present time and temperature
blink, the batteries capacity is no longer sufficient
6 Day of the week
7 Exclusion of the installation
8 JOLLY program
9 AIR-CONDITIONING program
10 HEATING program
11 ANTIFREEZE function
12 Installation in operation
Controls
13 Selection of the MANUAL or AUTOMATIC operating
mode of the equipment
14 Decrease (temperature, hour, day, etc.
15 Increase (temperature, hour, day, etc.
16 Multifunction
17 Exclusion of the installation
÷
6
2. Data display and external controls
Data display
1 Time scale of the daily program diagram
The blinking point in the diagram matches the time displayed
2 Temperature levels
3 Digital thermometer
4 Digital clock
MALU ME GI VE SA DO ON
048121620
T3
T2
T1
117
5
4
316
15
14
2
6*
6*: Days of the wee 

LUMonday
MATuesday
MEWednesday
GIThursday
VEFriday
SASaturday
DOSunday
7 8 9 10 11 12 13
90716577.L.E 19-09-2003 8:49 Pagina 6

8
3. Internal controls
To access to the internal controls panel, seize the equipment by
both sides (picture 3.1 and take it out to the stop.
picture 3.1
To insert the equipment again, press the two side lugs (1 on the
symbol and push it thoroughly (2 , until it comes to the stop
(picture 3.2 .
2
1
1
picture 3.2
90716577.L.E 19-09-2003 8:49 Pagina 8

10
230LUDO
®© T
18 19 20 21 22 23 24 25
11
Controls
18 Restart
19 Setting the present time and day
20 Setting and displaying of the temperature levels
T1-T2-T3
Setting the hysteresis (the maximum gap between
the ambient air temperature and the assigned value
21 Selection of the HEATING or AIR-CONDITIONING
program
22 Time decrease on the daily program diagram
23 Time increase on the daily program diagram
24 Selection of the day of the week
25 Copy of the program
90716577.L.E 19-09-2003 8:49 Pagina 10

4. Setting of the present time and day
Take out the body of the equipment.
12
MALU
048 1620
ME GI VE SA DO ON
T3
T2
T1
12
MALU
048 1620
ME GI VE SA DO ON
T3
T2
T1
12
4.1
Press the pushbutton : the
minutes figures blink. Press
the pushbutton or to set
the minutes value
4.2
Press the pushbutton :
the hour figures blink.
Press the pushbutton
or to set the hour value.
13
MALU
048 1620
ME GI VE SA DO ON
T3
T2
T1
12
MALU
048 1620
ME GI VE SA DO ON
T3
T2
T1
12
4.3
Press the pushbutton :
the indicator of the day of
the week blinks. Press the
pushbutton or to set
the day of the week.
4.4
To end the operation, press
the pushbuttone : the two
points between the hour and
the minutes figures blink.
60 seconds after the last
setting, the equipment
automatically ends the
operation, confirming the
last settings.
90716577.L.E 19-09-2003 8:49 Pagina 12

14
Insert again the body of the equipment.
Note
The figures displayed increase or decrease in single units at
every pression on the pushbutton or .
To increase the speed of the display, keep the pushbutton
or pressed.
5. Preset standard programs
The chronothermostat is provided with two preset standard
programs, one for HEATING and one for AIR-CONDITIONING .
To select the desired program, press the pushbutton .
5.1 HEATING Program
The HEATING program provides two different daily thermic cycles,
one from Monday to Friday (picture § 5.1.1 , and one for Saturday
and Sunday (picture § 5.1.2 .
15
MALU ME GI VE SA DO ON
048121620
T3
T2
T1
5.1.1
HEATING program :
thermic cycle from Monday
to Friday.
Temperature levels:
T1 16 °C
T2 18 °C
T3 20 °C
5.1.2
HEATING program :
thermic cycle for Saturday
and Sunday.
Temperature levels:
T1 16 °C
T2 18 °C
T3 20 °C
MALU ME GI VE SA DO ON
048121620
T3
T2
T1
90716577.L.E 19-09-2003 8:49 Pagina 14

17
6. MANUAL operation
Use the MANUAL operation if you wish a temperature different
from the preset one, without any other change of the program in use.
MALU
048 1620
ME GI VE SA DO ON
T3
T2
T1
12
6.1 MANUAL operation
Press the pushbutton : the
diagram of the program in use
disappears from the display
and, in its place, the preset
temperature is displayed (the
equipment is delivered with a
preset temperature of 20 °C .
Set the desired temperature (from 2 °C to 35 °C with the
pushbutton or .
The new temperature value will be kept until a new temperature or a
new operating mode is selected.
The ambient air temperature will be displayed about 5 seconds after
the last setting.
To verify, at any moment, the set temperature value, press twice the
pushbutton .
16
5.2 AIR-CONDITIONING program
The AIR-CONDITIONING program provides a single thermic cycle
for the whole week.
MALU ME GI VE SA DO ON
048121620
T3
T2
T1
5.2.1
AIR CONDITIONING
program : thermic cycle
for the whole week.
Temperature levels:
T1 24 °C
T2 26 °C
T3 28 °C
Note
If these preset standard programs meet your requirements, the
chronothermostat is ready for use, without any further
operation.
If this is not the case, follow the instructions of the next
paragraphs.
90716577.L.E 19-09-2003 8:49 Pagina 16

19
7.2.1
Press twice the
pushbutton : d01 is
displayed.
Set the desired number of
days pressing the
pushbutton or (from 1
to 99 days .
Note
The day in which the setting is done is included in the countdown and
is considered a whole day.
MALU
048121620
ME GI VE SA DO ON
T3
T2
T1
7.1.2
Press the pushbutton if
you wish to restore the
AUTOMATIC operating
mode before the end of the
countdown.
MALU
048121620
ME GI VE SA DO ON
T3
T2
T1
7.2 Programming by days
Make sure the MANUAL operating mode is in use and set the
desired temperature (see paragraph 6 .
18
7.1.1
Press once the
pushbutton : h01 is
displayed.
Set the desired number of
hours pressing the
pushbutton or from 1 to
99 hours .
Note
The hour in which the setting is done is included in the countdown
and is considered a whole hour.
7. TIME-DELAY MANUAL operation
If you wish to keep the manual temperature for a certain time (hours
or days , you can use the TIME-DELAY MANUAL operation: once
the desired time has been set, the equipment starts a countdown
and after that the AUTOMATIC operating mode is restored.
7.1 Programming by hours
Make sure the MANUAL operating mode is in use and set the
desired temperature (see paragraph 6 .
MALU
048121620
ME GI VE SA DO ON
T3
T2
T1
90716577.L.E 19-09-2003 8:49 Pagina 18

20
MALU
048121620
ME GI VE SA DO ON
T3
T2
T1
7.2.2
Press the pushbutton if
you wish to restore the
AUTOMATIC operating
mode before the end of the
countdown.
8. Own setting of the TEMPERATURE LEVELS VALUES
It is possible to change the value of the preset temperature levels,
both for the HEATING and for the AIR-CONDITIONING
program.
Each T value may be selected as follows:
T1: from 2 °C to T2-0.1 °C
T2: from T1+0.1 °C to T3-0.1 °C
T3: from T2+0.1 °C to 35 °C
Example
If the level of T1 corresponds to 1 °C and the level of T3 to 22 °C,
the level of T2 can be varied from 1 .1 °C to 21.9 °C.
8.1.2
Press the pushbutton : the
range of temperatures of T1
and the temperature value
to be changed are displayed.
Set the desired temperature
value pressing the
pushbutton or .
Press the pushbutton to confirm the operation and to proceed with
the next temperature value.
21
8.1 HEATING program
Take out the body of the equipment.
MALU
048121620
ME GI VE SA DO ON
T3
T2
T1
MALU
048121620
ME GI VE SA DO ON
T3
T2
T1
8.1.1
Press the pushbutton
and select the HEATING
program .
90716577.L.E 19-09-2003 8:49 Pagina 20

22
To change the value of T2 and T3, repeat the instructions indicated in
paragraph 8.1.2.
At the end of the settings of the temperature levels, the daily program
diagram will be displayed again.
About 10 seconds after the last setting, the equipment automatically
ends the operation, storing all the settings.
Insert again the body of the equipment.
8.2 AIR-CONDITIONING program
Take out the body of the equipment.
MALU
048121620
ME GI VE SA DO ON
T3
T2
T1
8.2.1
Press the pushbutton
and select the
AIR-CONDITIONING
program .
23
8.2.2
Press the pushbutton : the
range of temperatures of T1
and the temperature value to
be changed are displayed. Set
the desired temperature value
pressing the pushbutton
or .
Press the pushbutton to confirm the operation and to proceed with
the next temperature value.
To change the value of T2 and T3, repeat the instructions
indicated in paragraph 8.2.2.
At the end of the settings of the temperature levels, the daily program
diagram will be displayed again.
About 10 seconds after the last setting, the equipment automatically
ends the operation, storing all the settings.
Insert again the body of the equipment.
MALU
048121620
ME GI VE SA DO ON
T3
T2
T1
90716577.L.E 19-09-2003 8:49 Pagina 22

9.2
Press the pushbuttons
until the blinking
point in the daily program
diagram matches with
0 o’clock: 0 o’clock will be
displayed; the two points
between the hour and the
minutes figures become still; the temperature displayed takes the value
of the level selected at the time indicated by the blinking point of the
diagram.
24
9. Own setting of the DAILY PROGRAM
Take out the body of the equipment.
MALU ME GI VE SA DO ON
T3
T2
T1
048121620
MALU
048121620
ME GI VE SA DO ON
T3
T2
T1
9.1
Press the pushbutton
and put the day indicator
of the display on the LU
position (Monday .
25
MALU
04 8 12 16 20
ME GI VE SA DO ON
T3
T2
T1
9.3
Select the desired
temperature level pressing
the pushbutton or .
MALU
048121620
ME GI VE SA DO ON
T3
T2
T1
9.4
Progress to the next hour
pressing the pushbutton
.
90716577.L.E 19-09-2003 8:49 Pagina 24

9.6
If you wish a different program
for the next days, press the
pushbutton and repeat
the operations indicated in
paragraphs 9.3 and 9.4.
26
Repeat the operations indicated in paragraphs 9.3 and 9.4 until
23 o’clock.
The program setting for Monday is now ended.
MALU
048121620
ME GI VE SA DO ON
T3
T2
T1
MALU
048121620
ME GI VE SA DO ON
T3
T2
T1
9.5
If the set program is also
suitable for the next days,
press the pushbutton .
27
MALU
048121620
ME GI VE SA DO ON
T3
T2
T1
9.7
At the end of the settings,
press the pushbutton : the
present time and day will be
displayed.
About 10 seconds after the
last setting, the equipment
automatically ends the
operation, storing all the
settings.
Insert again the body of the equipment.
Note
At any moment it is possible to make any program setting.
Every user’s own setting will be saved, even after a supply
interruption or after pressing the pushbutton .
90716577.L.E 19-09-2003 8:49 Pagina 26

29
Proceed, if you wish, with the own settings, as indicated in
paragraphs 8 and 9 (excluding 9.5 and 9.6 .
At midnight the AUTOMATIC operating mode is restored.
To end the JOLLY program, press the pushbutton again.
If you wish to make the JOLLY program start in a day different from
the present day, act as follows:
Take out the body of the equipment and make sure the
AUTOMATIC operating mode is in use.
MALU
048121620
ME GI VE SA DO ON
T3
T2
T1
10.2
Press the pushbutton
and put the day indicator
on the desired day. Press the
pushbutton : a dash is
displayed under the symbol
to confirm the JOLLY program
is set for the desired day.
28
10. JOLLY Program
The equipment is provided with a JOLLY program, suitable for
holidays or festivities during the week, etc. This program can be
started at any moment of the day and kept in operation till the end
of that day, or else it can be scheduled for any day of the week.
The preset thermic cycle is the cycle provided for Saturday and
Sunday (see paragraph 5 , but it is also possible to obtain an own
setting, following the instructions indicated in paragraphs 8 and 9
(excluding 9.5 and 9.6 .
To start the JOLLY program, act as follows:
Make sure the AUTOMATIC operating mode is in use.
MALU
048121620
ME GI VE SA DO ON
T3
T2
T1
10.1
Press the pushbutton : a
dash is displayed under the
symbol to confirm that
the JOLLY program has
been started.
90716577.L.E 19-09-2003 8:49 Pagina 28

11.1
Press once the
pushbutton : a dash is
displayed under the
symbol to confirm that the
program is on.
Instead of the daily program
diagram, the preset
antifreeze temperature is displayed: to change it, press the
pushbutton or .
It is possible to select a temperature value between 2 °C and 35 °C,
which will be kept until a new temperature or a new operating mode
is selected.
The ambient air temperature will be displayed about 5 seconds after
the setting of the antifreeze temperature.
31
11. ANTIFREEZE program
The ANTIFREEZE operating mode is used either to maintain a
temperature level that prevents the water mains from damages, or
not to let the temperature arrive under a security level.
MALU
048121620
ME GI VE SA DO ON
T3
T2
T1
30
Proceed, if you wish, with the own setting of the Jolly program, as
indicated in paragraphs 8 and 9 (excluding 9.5 and 9.6 .
MALU
048121620
ME GI VE SA DO ON
T3
T2
T1
10.3
Press the pushbutton to
restore the AUTOMATIC
operating mode.
The JOLLY program will start
at 0 o’clock of the selected
day.
The JOLLY program may be cancelled either pressing twice the
pushbutton or putting the day indicator on the desired day using
the pushbutton and pressing once the pushbutton .
Press the pushbutton to restore the AUTOMATIC operating mode
and to return to the present day. In any case, it is automatically done
by the equipment about 10 seconds after the last setting.
The JOLLY program ends at the end of the day.
Insert again the body of the equipment.
90716577.L.E 19-09-2003 8:49 Pagina 30

33
12.2.1
Press twice the
pushbutton : d01 is
displayed.
Set the desired number of
days pressing the
pushbutton or (from 1
to 99 days .
Note
The day in which the setting is done is included in the countdown and
is considered a whole day.
MALU
048121620
ME GI VE SA DO ON
T3
T2
T1
12.1.2
Press the pushbutton if
you wish to restore the
AUTOMATIC operating
mode before the end of the
countdown.
MALU
048121620
ME GI VE SA DO ON
T3
T2
T1
12.2 Programming by days
Make sure the ANTIFREEZE operation is in use and set the
desired temperature (see paragraph 11 .
32
12.1.1
Press once the
pushbutton : h01 is
displayed.
Set the desired number of
hours pressing the
pushbutton or (from 1
to 99 hours .
Note
The hour in which the setting is done is included in the countdown
and is considered a whole hour.
12. TIME-DELAY ANTIFREEZE operation
The time-delay antifreeze operation is used to maintain a safety
temperature for a certain time (hours or days : once the desired time
has been set, the equipment starts a countdown and after that the
AUTOMATIC operating mode is restored.
12.1 Programming by hours
Make sure the ANTIFREEZE operating mode is in use and set
the desired temperature (see paragraph 11 .
MALU
048121620
ME GI VE SA DO ON
T3
T2
T1
90716577.L.E 19-09-2003 8:49 Pagina 32

MALU
048121620
ME GI VE SA DO ON
T3
T2
T1
12.2.2
Press the pushbutton if
you wish to restore the
AUTOMATIC operating
mode before the end of the
countdown.
34
13. Installation wor ing time
The equipment is provided with a timer to count the installation
working hours (till 9,999 hours .
MALU ME GI VE SA DO ON
T3
T2
T1
048121620
13.1
Press the pushbutton to
select the MANUAL operating
mode.
Take out the body of the
equipment.
Press the pushbutton :
the installation working time is
displayed for about 5 seconds.
35
13.2
To reset the timer and start
a new count, press the
pushbutton while the
figures of the installation
working time are still
displayed.
Insert again the body of the equipment.
MALU ME GI VE SA DO ON
T3
T2
T1
048121620
14. Display of the temperature levels
Take out the body of the equipment.
MALU
048121620
ME GI VE SA DO ON
T3
T2
T1
14.1
Press the pushbutton : the
temperature range of T1 and
the value assigned to it are
displayed.
90716577.L.E 19-09-2003 8:49 Pagina 34

36
Repeat the operation indicated in paragraph 14.1 to display the
levels values of T2 and T3.
Press the pushbutton to end the operation.
Insert again the body of the equipment.
It is also possible to operate as follows: make sure the
AUTOMATIC operating mode is in use.
MALU
048121620
ME GI VE SA DO ON
T3
T2
T1
14.2
Press the pushbutton or
the temperature values
assigned to each level are
diplayed.
If necessary, restore the
temperature level of the
present hour.
37
15. Exclusion of the installation
The chronothermostat can also be used only as a thermometer and a
clock, excluding any control on the heating or on the air-conditioning
installation. This operating mode is particularly useful in case the
equipment is not in use for a long period, in case of maintenance or
of a long absence, etc.
15.1 Exclusion of the installation during the
HEATING program
MALU
048121620
ME GI VE SA DO ON
T3
T2
T1
15.1.1
Press twice the
pushbutton : s instead of
the daily program diagram,
the indicator under the
symbol is displayed,
confirming the exclusion
of the temperature control.
The ambient air temperature disappears for about 5 seconds and the
symbol is displayed.
90716577.L.E 19-09-2003 8:49 Pagina 36

MALU
048121620
ME GI VE SA DO ON
T3
T2
T1
16.1.1.1
Press once the
pushbutton : h01 is
displayed.
Set the desired number of
hours pressing the
pushbutton or (from 1
to 99 hours .
Note
The hour in which the setting is done is included in the countdown
and is considered a whole hour.
16. Time-delay exclusion of the installation
The time-delay exclusion operation is used to exclude the installation
for a certain time (hours or days : once the desired time has been
set, the equipment starts a countdown and after that the
AUTOMATIC operating mode is restored.
16.1 Time-delay exclusion of the HEATING PROGRAM
Exclude the heating installation as indicated in paragraph 15.1.
16.1.1 Programming by hours
39
15.2.1
Press once the
pushbutton : instead of
the daily program diagram,
the indicator under the
symbol is displayed,
confirming the exclusion
of the temperature control.
The ambient air temperature disappears for about 5 seconds and the
symbol is displayed
Press the pushbuttons or to restore the AUTOMATIC operating
mode.
38
15.2 Exclusion of the installation during the AIR-CONDITIONING
program
MALU
048121620
ME GI VE SA DO ON
T3
T2
T1
90716577.L.E 19-09-2003 8:49 Pagina 38
