Use the arrow buttons [ ] to select the desired
video and press the button [ ] to play.
Note:
Collision detection sensitivity can be adjusted in
settings under the “G-sensor” option. Locked files are
saved to SD card: DCIM \ Movie \ RO
There are three options for parking mode.
1. Auto Event Detection
The camera will automatically record a video sequence
while a moving object is being detected during parking
mode. It will stop recording when no new movement is
detected.
2. Time Lapse Recording
Time lapse record a video at low frames at 1 / 2 / 3 / 5 /
10 fps, it keeps recording continuously without audio
recorded.
Note: Audio cannot be recorded in time-lapse mode.
3. Low Bitrate Recording
This mode uses low bitrate to record video and audio,
and uses small file sizes for continuous recording.
Disable / Enable Audio Recording
Pressing the [ ] button once to turn off / on audio
recording, [ ] LED light will be off / solid Blue.
Parking Mode
Note:
Parking mode provides surveillance of your parked
vehicle only when the engine is off and the USB Type-C
Hardwire Kit is used to provide continuous power.The
Hardwire Kit also protects your car battery from being
drained. We recommend buying the VIOFO HK4 ACC
hardwire kit cable for parking mode recording.
Long press the Wi-Fi button to enable Wi-Fi. Connect Wi-Fi
on your phone first. Open VIOFO app and choose
"Connect your camera" to use your phone to control the
dashcam. You can play and manage files through the
APP. You can check the app introduction refer to [Review
and Control on Smartphone].
Playback Video on VIOFO APP
Playback Video on Dashcam
Playback Video on PC
1. Remove memory card from dashcam.
Before removing the memory card, make sure you
have switched off the Dashcam.
2. Insert the memory card into a memory card reader
connected to your PC.
3. Open the DCIM folder, using VLC or another video
player to playback the video.
Playback and Manage Videos
Press the [ ] button to exit.
1.
2.
3.
Note:
The default video resolution of the dashcam is
2560 x 1440P 30fps.
Under standby mode (not recording), click once [ ]
button to enter the playlist.
14 15
