Vision grills CADET Series Manual

ENGLISH
Step 1: Assemble Top Lid
Vent
Parts for Assembly:
Tools Included:
Wrench:
For handle assembly
CADET SERIES
A
C
D
E
F
G
H
1 pc. - Top Vent
1 pc. - Charcoal Grate
1 pc. - Cooking Grate
1 pc. - Ash Drawer
1 pc. - Fire Bowl
1 pc. - Kamado Grill
1 pc. - Stand
I1 pc. - Wood Handle
Close lid and press Top Vent onto top of Kamado.
Be sure spring clips are fully engaged with
calibrations facing the front of the grill.
Step 3: Insert Grill into Stand
Take all parts out of the grill before lifting. With
the help of a second person, lower the grill into
the Stand by holding the back hinge and bottom of
grill. As grill is lowered into stand, carefully switch
out hands from bottom of grill to the ash drawer
opening before reaching the outer ring of stand.
Completely lower grill to bottom of stand.
Step 4: Add Components to
Grill
Lower re bowl into the grill with the ash drawer
opening facing the front of the grill. Place cast iron
Charcoal Grate inside re bowl. Place stainless
steel cooking grate on top of the re bowl.
Step 5: Grill Handle Assembly
Attach the Handle by placing handle bracket over
studs, opposite the hinge. On each stud use at
washers, then screw on acorn nuts and tighten
with provided wrench.
Step 6: Ash Drawer Usage
Slide Ash Drawer into ash drawer opening.
When grill is cool, it is safe to remove ash
from Ash Drawer. To remove Ash Drawer, use
bottom knob on Ash Drawer, lift slightly and
pull drawer out.
SET UP
WARNING: ALWAYS WAIT FOR ASHES TO COOL
BEFORE REMOVING ASH DRAWER. NEVER PULL
OUT ASH DRAWER WHILE GRILL IS HOT. 092816
B2 pc. - Stand Handle
Step 2: Stand Handle Assembly
Attach Stand Handles to the left and
right of the Stand by placing handle
brackets over stand studs.
On each stud use at washers, then
screw on acorn nuts and tighten with
provided wrench.

11.1
22.1
3
4
5
6
7
8
9
10
11
11.1
12
ENGLISH
Vision Grills, LLC • 1531 Fairview, Suite B, St. Louis, MO 63132 • 877.917.4273 • www.visiongrills.com
Visit
www.visiongrills.com/register
to register your grill.
CADET SERIES
PARTS
PART NAMES PART NUMBERS
1 Cast Iron Top Vent
1.1 Bakelite Tab
2 Ceramic Dome Lid
2.1 Thermometer
3 Top Ring Assembly
4
Stainless Steel Cooking Grate
5 Charcoal Grate
6 Handle
(with nuts & washers)
7 Fire Bowl
8 Bottom Ring Assembly
9 Felt Gasket
10 Ceramic Dome Bottom
11 Ash Drawer Body
11.1 Ash Drawer Knob
12 Stainless Steel Stand
12.1 Stand Handle (x 2)
12.1
VGC TV-VC
VGC TV-VC-K
VGC CDL-VC
VGC TMT-VC
VGC RA1-VC
VGC CGD-VC
VGC CG-VC
VGC HDL-VC
VGC FB-VC
VGC RA2-VC
VGC FLT-VC
VGC CDB-VC
VGC ADB-VC
VGC ADB-VC-K
VGC SSS-VC
VGC SSS-H-VC
092816
12.1
