Vision X Dura Mini Manual

VISIONXLIGHTING.COM
Installation Instructions & User’s Manual

VISION X DURA MINI LED WORK LAMP
WARNING: Bolts, Nuts, and Washers are Stainless Steel.
DO NOT USE Pneumatic or Electric Tools to Tighten and
Loosen. The Hardware Will Permanently Lock Together.
WIRING INSTALLATION INSTRUCTION
1. Supplied with the light is a 3” Pigtail, Part (P1).
2. Connect the positive red wire Part (R1), and negative black
wire Part (B1), into an existing power source.
MOUNTING INSTALLATION INSTRUCTION
1. Determine where the light/lights will be placed.
2. Place mounting bracket with light to desired location. Using
a marker or pick tool, mark the center point of the bolt hole
on the mounting surface.
3. Set the light aside. Drill out a large enough hole to fi t the
[M6] bolt Part (B1).
4. Line up the mounting bracket with the hole you just drilled,
slide the [M6] Bolt (B1) through both.
5. On the other side of mounting surface slide the [M6]
Washer Part (W1) and [M6] Nylock Nut Part (N1) onto the
[M6] Bolt (B1). Tighten Nut & Bolt to desired tightness.
TIP: For complete application guide see website
FEATURES
1. IP-69K waterproof/high pressure spray.
2. Compact fi xture for universal applications.
3. Four 3 watt LEDs produces 2000 raw lumens.
DURA MINI LED WORK LAMP SPECIFICATION
1. Warranty : Extended
2. Amp Draw : 1.00A @ 12V DC
3. Input Voltage : 9-32V DC
4. Beam Patterns : 60°
5. LED Lifespan : 50,000 Hours
PREPARATION
1. We recommend completely reading instructions before
installing.
2. Consult your local state regulatory agency regarding the
use of LED lighting.
3. The placement of LED lighting should not restrict airfl ow to
the radiator, or block head lamps, turn signals, or parking
lights.
About The Dura Mini LED Work Lamp:
123
Qty: 1 Qty: 1
Dura Mini Pigtail Hex Head Bolt
[M6]
[M6]
LIGHT PART (P1) Qty: 1
PART (B1)
4
Qty: 1
Washer
[M6]
PART (W1)
5
Qty: 1
Nylock Nut
[M6]
PART (N1)
COMPONENTS KEY
Part (P1) Pigtail
Part (R1) Power Wire
a. 9-32V DC Positive (+) Input Wire
Part (B1) Ground Wire
a. 9-32V Negative (-) Input Wire
(+) Red (R1)
(-) Black (B1)
WIRING DIAGRAM
(P1)
To Light

VISIONXLIGHTING.COM
MAINTENANCE
All Vision X models have been designed for maintenance free use.
In the case that an LED lamp or other part replacement is needed
please contact your authorized service center.
LIGHT ANGLE ADJUSTMENTS
1. Use a 10mm socket to loosen the 1 Hex head bolts Part (B2)
on the side of the light.
2. Adjust the light to your desired angle and tighten Bolt (B2).
ADJUSTMENT KEY
Part (B2) Bolt
a. 10mm Hex Head Bolt
(B2)
(B1)
(Mounting Bracket)
(W1)
(N1)
MOUNTING KEY
Part (B1) Bolt
Part (Mounting Bracket)
Part (W1) Washer
Part (N1) Nut
MOUNTING DIAGRAM
1.94”/49mm
