Vissani HVBC430ST User manual

THANK YOU
USE AND CARE GUIDE
4.3 CU FT BEVERAGE AND WINE CENTER
Questions, problems, missing parts? Before returning to the store,
call Vissani Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-847-7264
HOMEDEPOT.COM
Item #1006 634 064
Model #HVBC430ST

2
Table of Contents
Safety Information.....................................................2
Warranty.....................................................................4
Pre-Operation ............................................................5
Before You Begin....................................................5
Transport................................................................5
Ventilation ..............................................................5
Stabilization ...........................................................5
Protect From Heat..................................................5
Clean Before Use....................................................5
Tools Required .......................................................6
Product Description ...............................................6
Door Reversal Instructions........................................7
Operating Instructions.............................................10
Startup .................................................................10
Setting Temperature – Adjustable Thermostat
Control .................................................................10
Loading Beverages and Wine Bottles...................10
LED Light..............................................................11
Shutdown.............................................................11
Defrosting ............................................................11
Care and Cleaning ...................................................11
Protect from Moisture..........................................11
Troubleshooting .......................................................12
Safety Information
IMPORTANT SAFETY INSTRUCTIONS
Before you use your beverage cooler, please read this
owner’s manual carefully. Use this appliance only
for its intended purpose as described in this owner’s
manual.
DANGER: Risk of child entrapment. Before you
throw away your old refrigerator or freezer:
□Take off the doors.
□Leave the shelves in place so that children
may not easily climb inside.
□This beverage cooler must be positioned so that
the plug is accessible. Never unplug the unit by
pulling on the power cord. Always grasp the plug
rmly and pull straight out from the outlet.
□When transporting the beverage cooler, keep
the unit in the upright position. Do not tilt the
appliance beyond 45° or place the unit in upside-
down position. Do not tip over.
□Do not touch the cooled surfaces while the
appliance operates, especially not with wet
hands, because the skin may stick to the cold
surfaces.
□If the unit fails to cool properly, dispose of spoiled
food as needed.
□Unplug your unit before cleaning.
NOTE: If for any reason this product requires
service, we strongly recommend that a certied
technician perform the service. Repairs made by
non-qualied personnel will void the warranty.
□Do not defrost the appliance with other electrical
devices (hair dryer, etc.), and never scrape the
ice or frost layer with sharp tools.
WARNING: Do not damage the refrigerant
circuit.
□The rating plate is inside the appliance or outside
on the rear or side wall.
□This appliance is not intended for use by persons
(including children) with reduced physical,
sensory, or mental capabilities, or lack of
experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible for
their safety. Children should be supervised to
ensure that they do not play with the appliance.
□Do not operate your beverage cooler in the
presence of explosive fumes.
WARNING: Do not use ammable materials on
or near the unit. This can result in re and cause
irreparable harm or damage to the unit.
DANGER: Risk of re or explosion. Flammable
refrigerant used. To be repaired only by trained
service personnel. Do not puncture refrigerant
tubing.
CAUTION: Risk of re or explosion. Dispose
of property in accordance with federal or local
regulations. Flammable refrigerant used.

3 HOMEDEPOT.COM
Please contact 1-855-847-7264 for further assistance.
POWER SUPPLY
IMPORTANT: Do not cut or remove the third
ground prong from the power cord.
□The appliance must be correctly installed and
connected to the power supply in accordance
with the installation instructions before it is used.
□The main power supply must be properly
grounded.
□This beverage cooler is equipped with a 115V/60
Hz single phase motor. Do not use a ground-fault
circuit interrupter (GFCI) outlet to connect the
unit.
POWER CORD
□Do not run cord over carpeting or other heat
insulators. Do not cover the cord. Keep cord
away from trafc areas, and do not submerge in
water. If the supply cord is damaged, it must be
replaced by the manufacturer or its service agent
or a similarly qualied person in order to avoid a
hazard. Repair or replace immediately all electric
cords that have become frayed or otherwise
damaged. Do not use a cord that shows cracks
or abrasion along its length, the plug, or the
connector end.
□The power cord length is 5 feet long (1,524 mm).
Never shorten or lengthen the power cord. Do not
fold or coil the power cord.
DANGER: Never place excess length of the
power cord into the compressor enclosure in the
back of the beverage cooler. This action creates a
dangerous heat buildup which can melt the cord,
cause an electrical hazard, and may potentially
cause a re.
IMPORTANT: Touching the power cord to
the compressor at the back of the unit during
operation can create an electrical hazard and
damage the compressor.
CAUTION: Young children should be supervised
to ensure that they do not play with the appliance.
IMPORTANT: This beverage cooler should
not be positioned within a recessed or enclosed
cabinet. It is designed for freestanding installation
only.
IMPORTANT: This unit is not designed to
be installed in a RV, garage, or any outside
installation.
CAUTION: The surface of the compressor may
become hot during normal operation. Do not touch
as this may cause injury.
WARNING: Keep the beverage cooler away
from any combustible or volatile liquids or gases,
including gasoline, oil, alcohol, paint, paint
thinners, and solvents. Such chemicals should
never be stored in the unit.
IMPORTANT: Never use with an extension
cord. The grounded three-power plug must be
connected to the outlet directly.
SAVE THESE INSTRUCTIONS

4
Warranty
MC Appliance Corporation warrants this beverage
cooler to be free from defects in material and
workmanship, and agrees to remedy any such defect
or to furnish a new part(s), at the company’s option,
for any part(s) of the unit that have failed during
the warranty period. Parts and labor expenses are
covered on this unit for a period of one year from the
date of purchase. A copy of the dated sales receipt or
invoice is required to receive warranty service by an
authorized service agent.
□Damages due to shipping or improper
installation.
□Damages due to misuse or abuse.
□Content losses due to failure of the unit.
□Repairs performed by unauthorized service
agents.
□Service calls that do not involve defects in
material and workmanship such as instructions
on proper use of the product or improper
installation.
□Replacement or resetting of house fuses or
circuit breakers.
□Failure of this product if used for other purposes
than its intended purpose.
□Disposal costs for any failed unit not returned to
our factory.
□Any delivery/installation costs incurred as the
result of a unit that fails to perform as specied.
□Expenses for travel and transportation for
product service if your appliance is located in
a remote area where service by an authorized
service technician is not available.
□The removal and reinstallation of your appliance
if it is installed in an inaccessible location or
is not installed in accordance with published
installation instructions.
□Refunds for non repairable products are limited
to the price paid for the unit per the sales receipt.
LIMITATIONS OF REMEDIES AND
EXCLUSIONS
Product repair in accordance with the terms herein,
is your sole and exclusive remedy under this limited
warranty. Any and all implied warranties including
merchantability and tness for a particular purpose
are hereby limited to one year or the shortest period
allowed by law. MC Appliance Corporation is not
liable for incidental or consequential damages and
no representative or person is authorized to assume
for us any other liability in connection with the sale of
this product. Under no circumstances is the consumer
permitted to return this unit to the factory without the
prior written consent of MC Appliance Corporation.
Some states prohibit the exclusion or limitation of
incidental or consequential damages, or limitations on
implied warranties. This warranty gives you specic
legal rights, and you may also have other rights which
vary from state to state.

5 HOMEDEPOT.COM
Please contact 1-855-847-7264 for further assistance.
Pre-Operation
BEFORE YOU BEGIN
IMPORTANT: Before you begin, do not plug the
beverage cooler into a power outlet until it has
been resting in its upright position for at least six
(6) hours.
IMPORTANT: If the beverage cooler has been
laid on its side, placed upside down, or tilted more
than 45° during moving or transport, it is extremely
important to allow the refrigerant and compressor
oil to separate and settle so the compressor
operates properly. Failure to do so will cause
severe mechanical problems with the unit’s motor/
compressor, and will void the warranty.
□The beverage cooler is shipped with the door
hinge brackets attached on the right side.
□The door may be reversed to allow opening from
the left side.
IMPORTANT: If you plan to reverse the door
hinges, do not plug the beverage cooler into the
power outlet.
TRANSPORT
Use two or more people to move the beverage cooler.
VENTILATION
□In order for the beverage cooler to function
efciently, it must be placed in an adequately
ventilated space to allow for heat dissipation. It
is important to allow at least 2 inches (50 mm)
of space on each side and above the unit, and 4
inches (100 mm) of space behind the unit.
□To fully utilize the beverage cooler, approximately
22 inches (558 mm) of space should be allowed
in front of the unit for the door to open fully to
160°.
STABILIZATION
□The beverage cooler must be placed on a at,
stable surface. Adjust the unit’s front leveling
legs to assure quiet operation and prevent
rattling when the compressor activates.
□Never place the unit on soft materials such as
foam, plastic, or thick textured carpeting.
□Make sure the unit and door are aligned. Use the
adjustable legs (front only) to align the unit and/
or the screws under the triangular bracket cover
to align the door. See page 7 for more detailed
instructions on accessing the metal bracket.
PROTECT FROM HEAT
□Place the beverage cooler away from heat source
or direct sun.
□Do not operate your beverage cooler outdoors or
in an environment with high temperatures and/or
high humidity, such as garages, attics, or outdoor
patios. The temperature variances will create
condensation on the glass door.
□Do not cover the beverage cooler with tarps or
other items while operating, as this may cause
overheating.
CLEAN BEFORE USE
To remove any manufacturing dust and residual odors,
wipe the beverage cooler inside and out with a damp
cloth and a solution of baking soda and warm water
(2 tbsp baking soda to 1 qt water). Wipe away any
residual baking soda with a clean, moist cloth. Allow to
dry before operating.

6
Pre-Operation (continued)
TOOLS REQUIRED
#2 Phillips
screwdriver
5/16-inch (8mm)
Socket tool
Flat head
screwdriver
PRODUCT DESCRIPTION
B
C
E
F
D
A
Part Description Part Description
A 4.3 cu ft beverage and wine center D Adjustable wine bottle racks
B Adjustable glass shelves E Adjustable front leveling legs
C Reversible double-pane glass door
with stainless-steel frame
F Fan and LED light

7 HOMEDEPOT.COM
Please contact 1-855-847-7264 for further assistance.
Door Reversal Instructions
IMPORTANT: Remove glass shelves before reversing the door.
IMPORTANT: Never lay the beverage cooler on its back. The compressor and motor components are installed at the
back of the beverage cooler and may easily be damaged if the unit is placed on its back.
1 Removing Plastic Hole Insert
Plugs
□Gently remove plastic hole insert plugs (1)
from the left side of the beverage cooler (A)
with a thin athead screwdriver. Save the
plugs for step 5.
A
1
2 Removing the Triangular Bracket
and Door from Right Side
□Loosen the triangular bracket cover (2) by
simultaneously pushing it towards the back of
the unit and pulling up.
□Slide the bracket cover (2) toward the front of
the beverage cooler and lift off.
□Remove the metal bracket (3) by unscrewing the
three screws (4).
2
4
3

8
Door Reversal Instructions (continued)
3 Removing the Bottom Base
Bracket from Right Side
□Carefully place the unit on its side.
□Remove the bottom metal base bracket with
nylon washer (5).
□Unscrew the axle insert (6) with a athead
screwdriver. Screw into the opposite hole of
the metal base bracket.
5
6
4 Reattaching the Bottom Base
Bracket to Left Side
□Gently place the beverage cooler on its opposite
side.
□Remove screw (7) and re-insert it into the
opposite side of the unit.
□Reattach the metal base bracket with nylon
washer (5) on the new hinge side.
□Lift the unit to an upright position.
7
5

9 HOMEDEPOT.COM
Please contact 1-855-847-7264 for further assistance.
Door Reversal Instructions (continued)
5 Reattaching the Triangular
Bracket and Door to Right Side
□Place the top bracket into the door, and align
the metal bracket holes over the holes in the
top of the unit cabinet.
□Tighten the three screws (4) to hold it in place.
IMPORTANT: The rubber gasket should be
compressed on all sides of the door. If the gasket
is more compressed on one side, the metal bracket
position should be adjusted.
IMPORTANT: Make sure the door is level.
□Once the door position is nalized, securely
tighten the screws (4).
□Reinstall the triangular bracket cover (2) by
carefully threading it onto the metal bracket (3)
and pressing down.
□Reinstall all plastic hole insert plugs (1).
IMPORTANT: The plastic hole insert plugs
maintain the seal and integrity of the insulation.
Extra inserts are included in case the plugs are
damaged during removal.
IMPORTANT: It is extremely important to wait
at least six hours before plugging the beverage
cooler into a power outlet. During the door reversal
process, the refrigerant and compressor oil uids
mixed. It is important to allow the refrigerant
and compressor oil to separate and settle so the
compressor operates properly. Failure to do so will
cause severe mechanical problems, perhaps even
the destruction of the unit’s motor/compressor, and
will void the warranty.
2
4
3
1

10
Operating Instructions
STARTUP
Connect the power cord to a standard wall outlet. Do not use a GFCI outlet to connect the unit (see Safety
Information). After connection, you will immediately hear a short beep.
SETTING TEMPERATURE – ADJUSTABLE THERMOSTAT CONTROL
The default temperature is 43 °F (6 °C). Use the ▲ and ▼buttons to set the desired temperature between the
range of 37 °F to 61 °F (3 °C to 16 °C).
temperature reading. The digital display reading will adjust as the unit cools. While the unit is adjusting to the new
setting, press the ▲ and ▼buttons to view the selected temperature setting.
If there is a power outage, the unit will revert to the last temperature setting once power is restored.
LOADING BEVERAGES AND WINE BOTTLES
When loading the beverage cooler to full capacity, we recommend the following steps to effectively cool a large
number of beverages and wine bottles.
1. Use the Adjustable Thermostat Control to set
the temperature to 43 °F (6 °C) (also the default
temperature).
2. Allow the beverage cooler to cool for a minimum of
two hours.
3. Load the wine bottles. To achieve maximum capacity,
refer to the loading diagrams.
4.
temperature will rise as indicated on the display.
5. Once the beverage cooler has cooled the wine bottles
to 43 °F (6 °C), use the Adjustable Thermostat Control
to select a desired cooler internal temperature (the
lowest temperature setting is 37 °F (3 °C).
6. Allow several hours for the beverage cooler to cool to
the desired lower temperature.
NOTE: It is normal for temperature variances to occur inside the unit, and areas near the door will have slightly
warmer temperatures.
Standard 12-Ounce Cans
The beverage cooler accommodates 126 standard 12-ounce cans. To accommodate all 126 cans, position the glass
shelves and load the beverages.
Wine Bottles
The beverage cooler accommodates a range of wine bottles, and the capacity
varies depending on the position of the shelves and width of the wine bottles.
Nest the wine bottles to gain greater capacity.
Other Beverages
The glass and wire shelves can be adjusted to accommodate varying sizes of beverage cans and bottles depending
upon storage needs.
ROW 1
7 wine bottles
ROW 2
7 wine bottles
ROW 3
7 wine bottles
ROW 4
7 wine bottles
ROW 5
5 wine bottles
ROW 6
5 wine bottles
ROW 7
5 wine bottles

11 HOMEDEPOT.COM
Please contact 1-855-847-7264 for further assistance.
Operating Instructions (continued)
LED LIGHT
Press the button to turn the LED light on and off.
To enhance the lifespan of the LED light and conserve energy, it is recommended to predominantly utilize the light
for loading and selecting beverages.
SHUTDOWN
If the beverage cooler will not be in use for a long period of time, disconnect it from the power outlet, clean inside
thoroughly, and leave the door open to prevent mildew.
DEFROSTING
Frost may develop on the interior back panel of the unit when the temperature setting is very low and the unit is
not fully stocked with beverages. The presence of frost may force the unit to run continuously and thus increase
internal temperature.
To defrost the beverage cooler:
1. Use the ▲ and ▼ buttons to increase the temperature until the compressor turns off.
2. Allow the internal ice/frost buildup to melt. Ensure the internal drain (located at the middle back of the lower
shelf) is not clogged.
3. During this time, the melted frost ows through an internal drain into a holding pan on top of the compressor.
The heat of the compressor evaporates the liquid.
4. Reset the temperature to 43 °F (6 °C) and allow to cool for at least one hour.
5. Adjust the unit to the desired temperature setting.
Care and Cleaning
PROTECT FROM MOISTURE
Heavy moisture in the environment can cause
degradation to the insulation, as well as rust to the
cabinet, compressor, and/or power supply.
It is important to periodically clean and maintain the
beverage cooler. When performing maintenance, make
certain the unit is unplugged from the power outlet.
Wipe the inner and outer surfaces of the beverage
cooler clean with a damp cloth. If needed, use a gentle
detergent or a solution of baking soda and water.
Remove any residue with clean water and a soft cloth,
then dry with another cloth.
Once clean, you may use a common kitchen appliance
wax on outer surfaces.
Inspect, clean, and maintain the rubber gasket around
the door. A small amount of petroleum jelly applied to
the bracket side of gaskets will keep the gasket pliable
and ensure a good seal.
IMPORTANT:
□Do not use hot water, harsh detergents,
gasoline, kerosene, solvents, acids, or anything
ammable to clean the beverage cooler. These
can damage the paint and degrade the plastic
components.
□Do not spray the beverage cooler with water
as this may cause rust and degrade the
insulation.
□Do not clean glass shelves with hot water
when they are cold. Shelves may break if
exposed to sudden temperature changes or
impact. For your protection, tempered glass is
designed to shatter into many small pebble-
size pieces.
□For replacement components, they must be
obtained from Vissani Customer Service. This
ensures the correct replacement components
are provided, and minimizes risk of possible
ignition due to incorrect parts or improper
service.

12
Troubleshooting
Problem Solution
Beverage cooler doesn’t work. □Check for power failure.
□Verify unit is plugged into a standard power outlet and not a GFCI
outlet.
□Check if control panel is on.
Beverage cooler is too cold. □Adjust thermostat to higher number.
Beverage cooler is not cooling
sufciently.
□Adjust thermostat to lower number.
□Ensure door is closed properly.
□Ensure the door gasket provides a proper seal. If you can slide a
piece of paper between the gasket and unit body, the gasket is
not sealing properly.
□Unit may not have enough ventilation space around it.
□Check if the sides of the unit are warm. If not, please contact
Vissani Customer Service.
□Do not put hot beverages in the beverage cooler.
Beverage cooler compressor runs for
long periods.
□Hot weather and/or frequent door opening will force the unit to
work harder to keep cool.
□Do not overload the beverage cooler.
Beverage cooler door does not close
properly.
□Unit may be tilted. Adjust front legs to level the unit.
□Align the door using a 5/16-inch (8 mm) socket, adjusting the
screws under the triangular bracket cover. For assistance, please
contact Vissani’s Customer Service Department.
Side panel of beverage cooler is hot. □The unit exchange heats through the side walls; therefore, does
not indicate malfunction.
□Usually happens when door is opened and closed frequently or
when operated in high temperature weather. Results from dis-
sipation of heat from within the unit. Do not touch the panel. Does
not indicate a malfunction.
Condensation forms on the glass door. □Condensation forms under conditions of high humidity; does not
indicate a failure. Wipe condensation with dry towel.
□Relocate unit to a cooler area or adjust thermostat to a higher
setting to balance out the exterior and interior temperatures.
Condensation will dissipate as time goes on.
Sound of trickling water. □This is the refrigerant owing. Does not indicate a malfunction.
Buzzing sound. □A buzzing noise is typically generated by the compressor when
starting up or shutting down.
Odor. □Unit may require cleaning.

13 HOMEDEPOT.COM
Please contact 1-855-847-7264 for further assistance.

Questions, problems, missing parts? Before returning to the store,
call Vissani Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-847-7264
HOMEDEPOT.COM
Retain this manual for future use.
