vita Huron Planter With Trellis User manual

1. Post Caps (4) - 10810
2. Trellis Top and Bottom Rails (2) - 11089
3. Trellis Left Post (1) - 11090
4. Trellis Horizontal Slats (4) - 11091
5. Trellis Vertical Slats (5) - 11092
6. Trellis Right Post (1) - 11093
7. Pre-Assembled Side Panels (2) - 11094
8. Pre-Assembled Front & Back Wall Panels with Posts Connected (2) - 11097
9. Planter Box Post Trims (4) - 10730-1
10. Floor - Left (1) - 11098
11. Floor - Middle (1) - 11099
12. Floor - Right (1) - 11100
13. Floor Supports (2) - 11101
14. 5/8”(1.6 cm) Self-AugeringStainlessSteelScrews (12) - 20016
Tools You Will Need
• Cordless Drill
General Information
•Read Instructions through carefully before beginning assembly.
• When assembling components, place on a non-abrasive surface
(i.e. shipping box) to avoid scratching.
•We recommend an area approx 4’x 8’ for (1.2 m x 2.4 m) unobstructed
assembling.
•You should not need to use excessive force when assembling
components.
Huron Planter With Trellis
Please read through before starting assembly.
Check Box for These Contents
In the event of missing or defective parts please call our customer service dept.at 1800 282 9346 (Mon.to Fri.8:00 AM to 5:00 PM EST).
ASSEMBLY INSTRUCTIONS
1
Ver2.2 10272020
15.88 in
40.3 cm
36 in
91 cm
33 in
84 cm
13.88 in
35 cm
11.83 in
30 cm
15 in
38 cm
48 in
122 cm
32.125 in
81.6 cm
2
1
3
4
5
7
8
12 1310 11
6
914
Not to scale
www.wearevita.com

3
2
2
2
STEP ONE
Place the pre-assembled back panel on its side as shown and
insert the two pre-assembled side panels. Note the location of
the rail support and the top and bottom of the back panel.
Push until the tabs on the pre-assembled side panel rails lock into
place.
Add a second pre-assembled front panel as shown and push
until the side panel rails lock into place.
Stand the planter box right side up an insert the two floor supports
as shown. The notches at both ends should slide into the notches
on the side panel supports.
Assemble the Planter Box
1
1
Huron Planter with Trellis
3
Rail Supports
Top of back panel
(screws present)
Bottom of back panel
(no screws present)

STEP T WO
Connect the tounge-and-groove boards together as shown and place
onto the support rails inside the planter box.
Lift one post at a time and insert the post trims as shown.
Note: the post trims have pre-drilled holes to allow the
planter to be secured to the surface with screws (purchase
separately from your local hardware store)
Insert Floor Panels
1
2
3
Huron Planter with Trellis
2
1

STEP T HREE
Insert the five vertical slats into the top and bottom trellis rails as
shown. Once inserted, the slats will lock into place.
Align and insert the assembly from the previous step into one of
the trellis post as shown. Four horizontal slats should also be inserted
at this point.
Align and insert the second trellis post to complete the assembly.
Fasten the trellis using four of the provided screws; two at each
locations where the top rail meets the posts as shown.
Assemble the Trellis
1
2
4Huron Planter with Trellis
3
4
1
3
4
2
Top Rail
Post

STEP FOUR
Place the trellis assembly onto the planter box.
Note: insert the trellis onto the posts without locking tabs and have the
screws facing the rear of the planter.
Fasten the trellis in place using a total of eight screws, four per post
from all four sides as shown.
Insert the four post caps into place as shown.
Final Assembly & Post Caps Installation
1
2
North America, Toll Free Phone: [phone]
www.wearevita.com
5
1
2
3
3
Screws facing the
rear of the planter.
