Vive MOB1010RED Installation guide

Vive Rollator
FAQ
Does it come pre-assembled?
Yes, the rollator is pre-assembled, needing only the front wheels to be snapped into place
before use.
Do you have to remove the wheels to fold it?
Although the front wheels can be removed for more compact storage, it is not necessary
to remove them before folding the rollator.
Will a rollator be good for someone with knee pain?
Yes, the rollator provides support for those with limited mobility, relieving pressure on
the knees.
Can it be easily folded to take in a car?
Yes, to fold the rollator, simply pull upward on the center strap. The front wheels can
also be removed with the push pins for more compact storage.
Is the rollator height adjustable?
Yes! The handle height can be adjusted in one-inch increments from 31” to 36”.
What is the weight limit for the rollator?
The rollator safely supports up to 300 pounds.
How wide is the rollator?
The rollator is 25” wide.
Will the hand brakes be easy to use for someone with arthritis?
Yes, the hand brakes are designed for easy use.
How much does the rollator weigh?
The rollator weight 20 pounds.
Can I lock the wheels when resting on the seat?
Yes, the front wheels lock in place for extra stability when seated.

Specifications
Uses:
•Mobility aid
Dimensions:
•Base when open: Width: 25” Length: 28”
•Adjustable Height: 31” to 36”
•Wheels: 8”
•Folded: 10” by 20” by 32”
•Seat: 17.5" x 9.5"
•Seat Height: 21"
•Bag Dimensions: 15" w x 13" h x 3.5" d
How To Assemble:
•Insert front wheels into the frame
•Attach storage bag to the frame with the fastener loops
Braking:
•Walker is equipped with a dual wheel braking system
•To adjust the brakes, turn black cable adjuster screw located near each rear wheel behind tension
spring
Adjusting Handle Height:
•Handle height can be adjusted in 1” increments with the push pins located on the sides of the
rollator
Care Instructions:
•Wipe down with a damp cloth and disinfectant solution as necessary
•Dry immediately with a lint-free cloth
What’s Included:
•Euro rollator
•Storage basket
•Lifetime Guarantee
UPC: 028841241444 (Red); 028841241451 (White)
Product Number: MOB1010RED (Red); MOB1010WHT (White)

Shipping Weight: 20 Pounds
User Manual: Rollator Walker
