VIVOTEK PZ7111 (PoE) / 7112 (WLAN) is a high-performance
network camera featuring 10x optical zoom and pan/tilt
functionality. The camera is designed for indoor surveillance
applications such as retail stores, offices or banks.
The built-in 10x motorized optical zoom module provides
greater depth of field when zoomed in. Therefore, it can
display clear-cut images on near or distant objects. With
flexible 300-degree pan and 135-degree tilt, PZ7111/7112
can give users more comprehensive control over the
monitored site. PZ7111/7112 is incorporated with VIVOTEK's
self-developed Bach SoC, giving users the advantages of
dual-codec (MPEG-4 and MJPEG), dual streams and
two-way audio by SIP protocol. With support of dual streams,
it simultaneously delivers dual video streams with different
resolutions, frame size and image quality to different
platforms such as web browser or 3G cell phones.
In addition, PZ7111 is integrated with Power over Ethernet
function while PZ7112 with wireless connection, making
installation easier and more cost-efficient. The free-bundled,
multi-lingual 16-channel recording software helps users to
set up an easy-to-use IP surveillance system.
Features
10x Optical Zoom Lens
Motorized Pan/Tilt
(Pan: -150˚~ +150˚; Tilt: -45˚~ +90˚)
Real-time MPEG-4 and MJPEG Compression
(Dual Codec)
Supports Dual Streams Simultaneously
3GPP Mobile Surveillance
Two-way Audio via SIP Protocol
Built-in/External Microphone Switch
Built-in 802.3af Compliant PoE (PZ7111)
Built-in 802.11b/g WLAN (PZ7112)
HTTPS Encrypted Data Transmission
Digital I/O for External Sensor and Alarm
>>
>>
>>
>>
>>
>>
>>
>>
>>
>>
>>
Pan/Tilt/Zoom Network Camera
PZ7111/7112
10x Zoom Dual Streams PoE

Accessories
External View
．CE, LVD, FCC, VCCI, C-Tick
．CPU: Bach SoC
．Flash: 8MB
．RAM: 64MB + 32MB
．Embedded OS: Linux 2.6
．PZ7111 (NTSC CCD, PoE)
．PZ7121 (PAL CCD, PoE)
．PZ7112 (NTSC CCD, WLAN)
．PZ7122 (PAL CCD, WLAN)
．10x optical zoom lens, f=4.2 ~ 42 mm, F1.8 (wide),
F2.9 (tele), auto iris, auto focus
．1/60 sec. to 1/10000 sec. (PZ7111/PZ7112)
．1/50 sec. to 1/10000 sec. (PZ7121/PZ7122)
．4.9° ~ 46° (horizontal)
．3.6° ~ 35° (vertical)
．1/4” CCD sensor in D1 resolution
．1.5 Lux / F1.8 (typical)
．0.05 Lux / F1.8 (low light mode)
Specifications
Networking
Alarm and
Event Management
Security
Users
Dimension
Weight
LED Indicator
Power
Approvals
Operating Environments
System
Models
Lens
．Pan range: 300° (-150° ~ +150°)
．Tilt range: 135° (-45° ~ +90°)
．10x optical zoom, 10x digital zoom
．Auto pan mode
．Auto patrol mode
Pan/Tilt/Zoom
Shutter Time
Image sensor
Angle of View
Minimum
Illumination
Video
Image Settings
Audio
Viewing System
Requirements
Installation, Management,
and Maintenance
Applications
．10/100 Mbps Ethernet, RJ-45
．Built-in 802.11b/g WLAN (PZ7112/PZ7122)
．Protocols: IPv4, TCP/IP, HTTP, HTTPS, UPnP, RTSP/
RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS,
DDNS, and PPPoE
．Triple-window video for motion detection
．One D/I and one D/O for external sensor and alarm
．Event notification using HTTP, SMTP, or FTP
．Local recording of MP4 files
．Multi-level user access with password protection
．IP address filtering
．HTTPS encrypted data transmission
．Wireless: WEP, WPA-PSK, WPA2 (PZ7112/PZ7122)
．Camera live viewing for up to 10 clients
．Ø 105 mm x 120 mm
．Net: 391 g (PZ7111/PZ7121)
．Net: 408 g (PZ7112/PZ7122)
．System power and status indicator
．System activity and network link indicator
．12V DC
．Power consumption: Max. 12 W
(PZ7111/7121)
．Power consumption: Max. 13 W
(PZ7112/7122)
．802.3af compliant Power-over-Ethernet
(PZ7111/PZ7121)
．Temperature: 0 ~ 50 °C (32 ~ 122 °F)
．Humidity: 20% ~ 80% RH
．Compression:
GSM-AMR speech encoding, bit rate:
4.75 kbps to 12.2 kbps
MPEG-4 AAC audio encoding, bit rate:
16 kbps to 128 kbps
．Interface:
Built-in microphone
External microphone input
Audio output
External/Internal microphone switch
．Supports two-way audio via SIP protocol
．Supports audio mute
．Compression: MJPEG & MPEG-4
．Streaming:
Simultaneous dual-streaming
MPEG-4 streaming over UDP, TCP, HTTP or HTTPS
MPEG-4 multicast streaming
MJPEG streaming over HTTP or HTTPS
．Supports 3GPP mobile surveillance
．Frame rates:
MPEG-4: Up to 30/25 fps 704x480/704x576
MJPEG: Up to 30/25 fps 704x480/704x57
．Adjustable image size, quality, and bit rate
．Time stamp and text caption overlay
．Flip & mirror
．Configurable brightness, contrast, saturation,
sharpness and white balance
．ATW, AWB, AES, ALC
．Backlight compensation (BLC)
．OS: Microsoft Windows 2000/XP/Vista
．Browser: Internet Explorer 6.x or above
．Cell phone: 3GPP player
．Real Player: 10.5 or above
．Quick Time: 6.5 or above
．SDK available for application development
and system integration
Warranty ．24 months
．Installation Wizard 2
．16-CH recording software
．Supports firmware upgrade
Pan/Tilt Range
All specications are subject to change without notice. Copyright 2009 VIVOTEK INC. All rights reserved.
c
P/N: 011001601 Ver 1.0
Pan:300°
。
150 150
。
Tilt:135°
90
。
45
。
Power Cord
Socket
Ethernet 10/100
RJ45 Socket
MIC In General I/O
Terminal Block
AV Out
External/Internal
MIC Switch
Antenna
(PZ7112/7122 only)
PoE InjectorMounting KitEnclosure
