Vizualogic SDM107 User manual

SDM107
1
 Before operating the unit, please read these instructions carefully.
 Retain the manual for future reference.
 You are advised to follow the instructions carefully when operating the unit.
 Do not use any chemical solvent, clean agent or corrosive detergent to clean away dirt of the surface of the screen. By doing so,
you may cause irreversible damage to the surface of the TFT screen. To clean off dirt or fingerprints, we recommend the use of a
soft damp lens cleaning cloth.
 Using spare parts from another manufacturer may cause permanent damage to the unit.
 When operating the display unit, avoid touching or pressing the LCD glass panel. Excessive force may cause irreparable damage to
the LCD screen.
 It is unlawful in most jurisdictions for a person to drive a motor vehicle which is equipped with a screen that is located in the motor
vehicle at any point forward of the back of the driver’s seat, or that is visible, directly or indirectly, to the driver while operating the
vehicle. In the interesting of safety, this monitor should never be installed where it will be visible, directly or indirectly, by the operator
of the motor vehicle.
 Lock the LCD screen in the fully closed position when not in use.
 Remember to leave the dome light switch in the off or auto positions when the vehicle is unattended, as the dome
lights can drain the vehicle’s battery.
IMPORTANT NOTICE

SDM107
2
 FLIP DOWN 10.2” 16:9 WIDE SCREEN TFT-LCD MONITOR
 BUILT IN 1/4 DIN Full Function DVD Player
 BULIT IN USB 1.1 PORT
 BUILT IN WIRELESS HEADPHONE IR TRANSMITTER
 1 AUDIO/VIDEO INPUT
 1 AUDIO/VIDEO OUTPUT
 FULL FUNCTION WIRELESS REMOTE CONTROL
 (OSD) ON SCREEN DISPLAY FOR CONTROL OF PICTURE QUALITY AND FUNCTIONS
 DOME LIGHTS
MAIN SPECIFICATIONS
SDM185
DISPLAY: 10.2” wide screen TFT LCD active matrix 8.5” wide screen TFT LCD active matrix
RESOLUTION: 800RGB(W) X 480(H)
PIXEL PITCH(mm): 0.0925(W) X 0.2775(H)
VIEWING ANGLE: Left/Right 130°, Up/Down 45°/65°
BRIGHTNESS: 250 NITS
CONTRAST RATIO: 300:1
POWER SOURCE: DC 12V ( NEGATIVE GROUND)
POWER CONSUMPTION: 20W ( Max.)
OPERATING TEMPERATURE:
0℃~60℃ (32℉~140℉)
STORAGE TEMPERATURE:
-20℃~70℃(-4℉~158℉)
DIMENSIONS (W x D x H): 335x280x45 mm
NET WEIGHT: 3Kgs. (6.6lbs)
MAIN FEATURES

SDM107
3
DVD PLAYER
 Supports DVD, SVCD, VCD, AUDIO CD, and MP3 format.
MEDIA PLAYER
 Support USB 1.1 Drive.
 Equipped with USB Socket.
 Plays MP3 music.
 Applies to NTSC or PAL system.
STANDARD ACCESSORIES PACKAGE CONTENTS
 Remote control (CR2025 x 1 Lithium Battery)
 Operating manual
 Power connection cable

SDM107
4
DVD player
Dome lights
IR transmitter
 POWER button: Press to turn the monitor on/off.
 MENU button: Press menu button to active OSD feature and select OSD features.
 UP/DOWN buttons: Adjustment buttons.
 IR Sensor: IR sensor for remote control.
 Dome lights: Provide additional interior illumination.
 Dome lights switch: Press to loop OFF / ON / DOOR.
 USB port: Plays USB 1.1 Drive.
 IR transmitter: Transmit audio to wireless headphones.
 DVD player: Plays DVD, SVCD, VCD, AUDIO CD and MP3 format.
 A/V input jack: Connecting to your Game port or any A/V device.
CONTROLS & CONNECTORS
Dome lights switch
USB port
A/V input jack
Buttons
Panel lock
Eject Key

SDM107
5
MONITOR FUNCTION DESCRIPTIONS
1. MUTE button
Press to mute the audio, press the button again to restore
sound to the previous audio level.
2. MENU button
Press this button to active the OSD menu screen.
3. MENU Adjust Up button
4. MENU Adjust Down button
Use this button to change the value of the menu option.
5. VOLUME UP button
6. VOLUME DOWN button
Use this button to raise the volume level of the audio output.
7. SOURCE button
Press to enter the GAME input mode.
8. POWER button
Press this button to turn on the monitor, press again to turn off the monitor.
9. DVD button
Press DVD button to play DVD or change to USB Mode.
1
2
3
8
9
7
5
6
4

SDM107
6
DVD FUNCTION DESCRIPTONS
10. NUMBER buttons
Allows the user to enter the numbers 0 to 10 for selection of CD track,
DVD chapters, and password setting.
11. PBC button
Allows the user to select the subtitle when playing the VCD 2.0 version only.
12. TITLE button
Some DVDs come with title selection. For such case, allows the user to
select desired title.
13. SUBTITLE button
Allows the user to select a subtitle display in various languages.
14. BWD button
Allows the user to search in a backward direction.
15. UP button
16. FWD button
Allows the user to search in a forward direction.
17. LEFT button
18. PLAY button
Press this button to active the play mode while a disc is loaded into the disc compartment.
19. RIGHT button
20. PREVIOUS button
Allows the user to return to the previous chapter or track.
21. DOWN button
22. NEXT button
Allows the user to skip to the next chapter or track.
10
11 12 13
14 15 16
17 18 19
20 21 22

SDM107
7
23. STOP button
DVD disc play will be stopped.
24. PAUSE button
Allows the user to pause the playback.
25. ENTER button
Press this button to confirm selection.
26. EJECT button
Press this button to eject the DVD disc.
27. A-B button
Allows the user to repeat play of a DVD or CD from point A to point B.
Press button once to set point A once again to set point B.
28. REPEAT button
Allows the user to repeat play various positions of a DVD, CD or MP3.
(Track/Chapter/All).
29. SET UP button
Allows the user to select the DVD player’s options (Display, OSD language,
Defaults, Parental Control, Password, Exit Setup)
30. DISPLAY button
Press to display DVD disc current information.
31. ZOOM button`
Allows the user to zoom in or zoom out the image, press the
“LEFT/RIGHT/UP/DOWN” buttons to move the zoomed image to move
in the direction of the remaining portion of the image.
23 24 25
27
28
29
30
31
26

SDM107
8
USB 1.1 DRIVE FUNCTIONS DESCRIPTIONS
32. REPEAT button
Allows the user to repeat play.
33. SETUP button
Press to enter the SETUP MENU MAIN PAGE.
34. DISPLAY button
Press to display the Media Card current information.
35. ZOOM button
Allows the user to zoom in or zoom out the image, press the “LEFT/RIGHT
UP/DOWN” buttons to move the zoomed imaged to move in the direction of the
remaining portion of the image.
36. UP button
37. LEFT button
38. PLAY button
Press this button to start the play mode of the USB drive.
39. RIGHT button
40. DOWN button
41. STOP button
USB media file play will be stopped.
42. PAUSE button
Allows the user to pause the play of “MUSIC” or “VIDEO” file.
43. ENTER button
Press this button to confirm selection.
36~40
32
33
34
35
41 42 43

SDM107
9
MONITOR OPERATION
Slide the screen release lock forward will unlock the LCD screen and the LCD screen will drop down slightly. Pivot the screen downward
until a comfortable viewing angle is reached.
 Press the POWER button on the unit or remote to turn on the monitor.
 Press the SOURCE button to select viewing source.
 Press the MENU button to active the OSD menu shown on the LCD screen.
 Press the MENU button again to select the adjustment item, press the “▲” or “▼” button to enter the sub menu and adjust
function/value.
 “FM PRESET”: press the “▲” button to select M1 ~ M6; press “▼” button 1 sec. to change present FM channel or press “▼” button
more than 2 sec. to cover and save a new FM channel.

SDM107
10
OVERHEAD DOME LIGHTS
The lights are controlled by a bush button switch. Push the button to change “ON”  “DOOR”  “OFF” function by loop. The “ON”
function will turn the lights on. The “OFF” position will prevent the lights from turning on at all times, and the “DOOR” or “AUTO” position
will allow the lights to turn on and off with the vehicle’s interior lighting. Do not leave the vehicle unattended with the dome light switch in
the “ON” position, as this could result in a discharged battery.
DVD OPERATING
The DVD player has the ability to play DVD, VCD, Audio CD and MP3 audio. Make sure you read this section completely before using
the DVD section.
REGIONAL CODING
Both the DVD player and DVD disc are coded by region. These regional codes must match in order for the disc to play. If the codes don’t
match, the disc won’t play. This DVD player will only region 1 DVD disc.
TO PLAY A DVD OR VCD
 Press the DVD button on the remote control.
 Insert DVD or VCD disc (Label Up), the disc will automatically load.
 Press the “PLAY” button on the remote to play selected title.
NOTE: The On Screen Display will show “INVALID DISC” if the disc region code does not correspond with the unit setting.
 Press the “PAUSE” button to pause, press the “PLAY’ button to resume play.
 Press the “STOP” button to stop play.

SDM107
11
DVD SETTING AND ADJUSTMENT
This chapter describes how to set and how to adjust using the on-screen SETUP menu.
Using the Setup Menu:
 Press the SETUP button to display the “SETUP” menu on the display screen.
 Select the main item you want using the cursor (
▲ ▼
) button, and then press the ▼ button.
 To exit setup menu, press SETUP button on the remote again.
OSD (ON-SCREEN DISPLAY) LANGUAGE MENU
The OSD Language Menu allows the user to select the language for the on-screen display. Press SETUP and then use the (
▲ ▼
▼
▲) button to select the desired language.
ADJUST DVD SETUP MENU

SDM107
12

SDM107
13
AUDIO SET UP
Press the SETUP button and select AUDIO. The AUDIO SETUP allows you to change the speaker setup and HDCD. Press (
▲ ▼
▼
▲) button to select.

SDM107
14

SDM107
15
VIDEO SET UP
Press the SETUP button and select VIDEO. The VIDEO SETUP allows you to change the quality. Press (
▲ ▼
▼ ▲ ) button to select.

SDM107
16

SDM107
17
PREFERENCE SET UP
THIS SETTING HAVE TO STOP PLAYING DISC. Press the SETUP button and select Preference. The Preference SETUP allows you
to change the quality. Press (
▲ ▼
▼ ▲ ) button to select.

SDM107
18

SDM107
19

SDM107
20
NEW PASSWORD SET UP (PARENTAL CONTROL PASSWORD)
Press the SETUP button and select PASSWORD. The PASSWORD SETUP allows you to change the parental control password. Press
▼
and then press number and then Enter to implement it.
