Vizualogic VL8000 Series User manual

99-9018-003 1/04
1493 Bentley Drive • Corona, CA 92879 • 909-272-1996 • 800-624-7960 • Fax [phone]
www.vizualogic.com
Copyright © 2003 TMI Products, Inc.
All Rights Reserved
Corona, CA U.S.A.
060300
VL8000 Series
Hummer H2
VISOR MONITOR SYSTEM
Installation Manual
Visor Installation
1. Disconnect the vehicle’s negative battery terminal. (Black wire)
2. Please see Visor Removal Instructions to remove the passenger side visor.
3. Remove the ‘A’ pillar trim and kick panel on the passenger side and route the Video
Cable and Ground Wire around the front edge of the headliner and across to the ‘A’.
4. Install the visor monitor and mounting brackets to the headliner by reversing the Visor
Removal Instructions.
5. Route the Video Cable and Ground Wire down the ‘A’ pillar. Use a wire fish to pull the
cable straight down past the edge of the vehicle’s dash to the kick panel.
6. From behind the kick panel, route the Ground Wire, under the front edge of the carpet,
across the vehicle to the Parking Brake. Use the supplied connector to attach the Ground
Wire to the vehicle wire for the Parking Brake Switch.
7. Continue routing the Video Cable under the door sill and carpet and
connect the video control box.
Vizualogic®Visor System Diagram
- See diagram insert or go to www.vizualogic.com.
Winter 2004
Advantage™Series

(2) Batteries, AAA
(1) VL8000 Installation Manual
(1) VL8000 Owner’s Manual
VL8000 Kit contents:
(1) Visor with Monitor and Cable
(1) A/V Module
(1) 12V Harness for A/V Module
(1) Remote Control
12V Power Installation
We recommend the installation of a main power switch for the entire headrest system.
The circuit should be marked to assist the consumer in locating the correct vehicle fuse
for the video system in the case of a system failure.
A V Module Installation
1. Place A/V module in a well protected area under a seat or behind a panel.
2. Connect the 12V harness to the same 12V+ and 12V Ground as the Video Source Unit(s).
3. Insert 12V harness connector into A/V module.
4. Insert video cable from Source.
5. Insert video output cable connecting the Headrest.
6. Install I/R extender cable from source unit to A/V module.
System Operation
Please see CONTROLS on page 4, 5 and 6 of the VL8000 Owner’s Manual for system
operation instructions.
Specifications
ELECTRICAL SPECIFICATIONS – 7.0”
Display Type: LCD
Screen size: 7.0” (Diagonal)
Resolution: 1,440 (W) x 234 (H)
Number of Pixels: 336,960
Brightness: 400 nit
Horizontal view angle: ±65°
Vertical view angle: +40°, -65°
Power requirement: (Monitor) DC 12.0V ±1.5
Power consumption: (Monitor) DC <1A
Note: Designs and specifications are subject to change without notice and without
legal obligation.
Visor Removal Instructions
1. Use a small blade screwdriver
to insert in access slot to
depress the retaining tab.
2. With the screwdriver in the
slot, push the elbow of the
visor up, towards the roof.
3. Pushing up on the visor will
release it form the roof header.
4. Locked Position (installed) 5. Service Position (ready to un-install)
Lock Position Service Position
6. With the visor now in service
position, pull the visor bracket
down. This will remove the
visor completely from the
roof header and headliner.
7. Disconnect lighted
mirror wires.
8. Remove shipping ring by
disengaging all 3 locking tabs
and do not re-install.
A-PillAr Trim removAl tip
1. Remove the upper retaining clip from
passenger-side A-pillar assist handle
2. Remove the lower retaining clip from
passenger-side A-pillar assist handle
3. Remove passenger-side A-pillar assist
handle by pulling straight away from the
A-pillar. Remove passenger-side A-pillar
trim by pulling at edge of panel.
Advantage™Series Advantage™Series
