Eclipse Square 3 Function Slide Shower
Chrome
VECL041
Voda Plumbingware Limited | Freephone: 0508 367 366 | 5 Hewlett Street, Port Whangarei 0110 | vodaplumbingware.co.nz
Congratulations on your purchase of this high quality product from Voda Plumbingware.
Please read the following before installation and retain (along with your receipt).
TECHNICAL SPECIFICATIONS
Suitable for Mains Pressure only
Minimum Pressure = 150kPa
Maximum operating Pressure = 500kPa
Maximum operating Temperature = 65 deg. Celsius
For domestic use only.
CONFIGURATION
Mains Pressure systems Install as supplied.
Unequal Low systems This product is not suitable for this type of water pressure.
Equal Low systems This product is not suitable for this type of water pressure.
CONTENTS
• Rail with adjuster/holder
• Wall brackets
• Fixing kit
• 1.5m shower hose with flow restrictor disc fitted
• Supply elbow
• Shower handpiece
INSTALLATION
See steps on the next page, then attach the supply elbow to the supply connection on the wall.

4
2
1
3
4
5
6
WARRANTY
Please refer to our website for warranty information: www.vodaplumbingware.co.nz/warranty
In the unlikely event that this product fails during its warranty period, phone our Customer Service team
immediately on 0508 367 366 – as unauthorised removal of the product may void the warranty.
CARE AND MAINTENANCE
When cleaning your Voda product (including chrome, stainless steel, coloured or any other surface coating) you
must not use any type of astringent, abrasive or citric cleaners.
We recommend using only a so, damp cloth and on occasion a mild soap solution. Try to avoid excessive
scrubbing as this could cause damage and void your warranty.
ATTACH PROOF OF PURCHASE HERE
Voda Plumbingware Limited | Freephone: 0508 367 366 | 5 Hewlett Street, Port Whangarei 0110 | vodaplumbingware.co.nz
1. Decide where you would like your Shower rail positioned in relation to your elbow (water supply) then measure and mark
hole positions (at points A and B) with a pencil at exactly 700mm apart.
2. Drill two holes where you have marked.
3. Fit the wall fixing parts into the drilled holes.
4. Push the rail bracket onto the wall fixings, then tighten the grub screws.
5. Fix the elbow to the water inlet.
6. Attach hose to elbow and handpiece then insert the shower handpiece into holder on the rail.
850mm 700mm
