Vogt HE S Series Installation manual

5/2/2011
HE S Series
TUBE-ICE
MACHINE
INSTALLATION
&
START-UP
INSTRUCTIONS
Part Number: 12A4171S0702

Installation & Start-up – HES Series
2
Blank Page

Installation & Start-up – HES Series
3
Revision Date: April 2011
Table of Contents
Bin Installation ----------------------------------------------------------- 5
Setting the Ice Machine on the Bin ----------------------------------- 5
Figure-1 Ice Bin to Machine Layout ------------------------------- 5
Figure-2 Forklift-&-Blocks Method -------------------------------- 6
Figure-3 Forklift-&-Rope or Lifting Straps Method ------------- 7
Sealing Instructions-Ice Machine to Bin Top ----------------------- 8
Figure-4 Machine to Bin Top Installation ------------------------- 8
Connecting Electrical, Water & Drains ----------------------------- 9
Figure-5 Rear Utility Connection Layout -------------------------- 9
Wiring & Electrical Connection -------------------------------------- 10
Figure-6 Terminal Block Connections ----------------------------- 10
Table-1 Electrical Specifications ------------------------------------ 10
Piping & Drain Connections ------------------------------------------- 11
Table-2 Water Supply & Drains ------------------------------------ 11
Figure-7 Water Connections ----------------------------------------- 11
Figure-8 Typical Space Diagram ----------------------------------- 12
Air-Cooled Installation Instructions --------------------------------- 13
Table-3 Pounds R-404A to Add vs Liquid Line Length ---------- 14
Table-4 Air-Cooled Condenser Data -------------------------------- 15
Table-4A Cold Weather Kit Parts ----------------------------------- 16
Figure-9 Condenser Dimensions ------------------------------------- 16
Figure-9A Condenser Field Piping, 50/25/25 Split --------------- 17
Figure-9B Condenser Field Piping, 50/50 Split ------------------- 18
Condenser Equivalent Line Size Worksheet ----------------------- 19
Table-5 Fitting factors ------------------------------------------------ 19
Figure-10 Minimum Traps for Discharge Lines ------------------ 19
Air-Cooled Condenser Wiring----------------------------------------- 20
Figure-11 Condenser Wiring to Ice Machine ---------------------- 20
Figure-12 Wiring for Single Fan, 50/50 Split --------------- 20
Figure-12A Wiring for Single Fan, 50/25/25 Split --------- 21
Figure-12B Wiring for Dual Fan, 50/50 Split --------------- 22
Refrigerant Connections to Air-Cooled Condenser --------------- 23
Figure-13 Field Attachment for Refrigerant Tubing ------------- 23
Table-6 Torque Ratings for Rotalock Connectors ---------------- 23
Ice Bin Thermostat Sensor Installation ------------------------------ 24
Figure-14 Location of Thermostat Sensors ------------------------ 24
Programming the Electronic Bin Thermostat ---------------------- 25
Figure-15 Electronic Thermostat ------------------------------------ 25

Installation & Start-up – HES Series
4
Table of Contents (Cont.)
Initial Start-Up & Installation Procedure --------------------------- 26
Figure-16 Piping Schematic, Air-Cooled -------------------------- 26
Figure-17 Piping Schematic, Water-Cooled ----------------------- 27
Figure-18 Switch Plate ------------------------------------------------ 28
Figure-19 Control Circuit Breakers --------------------------------- 29
General Machine Information ----------------------------------------- 31
Refrigerant Charge ----------------------------------------------------- 31
Total Pump down Mode----------------------------------------------- 31
Adding Refrigerant ---------------------------------------------------- 31
Adjustable Blowdown ------------------------------------------------- 32
Automatic Blowdown ------------------------------------------------- 32
Figure-20 Automatic Blowdown / Petcock ------------------------- 32
Troubleshooting -------------------------------------------------------- 33
Table-7 PLC Inputs, Outputs & Fault Codes ----------------------- 33
Figure-21 Fault Indicator / Selector switch Location ------------- 33
Figure-22 Copeland Performance Alert Wiring ------------------- 34
Figure-23A Control Panel Layout ----------------------------------- 35
Figure-23B Control Panel Layout (Hoffman Enclosure) --------- 35
Table-9 Control Panel Parts List ------------------------------------- 36
Figure-24 HES Wiring Schematic, Single Ice --------------------- 37
Figure-25 HES Wiring Schematic, Dual Ice ----------------------- 38
Figure-26 HES Wiring Schematic, Single Ice (Dual Voltage)--- 39
Figure-27 HES Wiring Schematic, Single Ice (400/460V) ------ 40
Figure-28 Casing Installation ---------------------------------------- 41
Convert from Cylinder Ice to Crushed Ice ------------------------- 42
Table-10 Recommended Freezer Pressure Settings --------------- 42
Table-11 Recommended Ice Weights per cycle ------------------- 42
Review Checklist --------------------------------------------------- 43
Warranty Registration / Start-up Form ---------------------- 44

Installation & Start-up – HES Series
5
Installing Your Tube-Ice Machine
! WARNING !
Only service personnel experienced and certified in refrigeration and qualified to work
with high voltage electrical equipment should be allowed to install or work
on this Tube-Ice
®
machine.
! WARNING !
Important Notice.
The Warranty Registration / Start-Up Form must be completed and returned
to Vogt Tube-Ice
®
to initiate and assure a full warranty. A postage paid
envelope is provided or you may fax the report to 800-770-8648.
Bin Installation. Set the bin on solid, level footing. Inside the bin you will find the four
legs. Screw these legs to the bottom of the bin. You can make MINOR leveling adjustments by
using these legs as leveling screws, as outlined in the manufacturer’s instructions.
Setting the ice machine on the ice bin. Once the ice storage bin is level, the Tube-Ice
®
machine can be elevated and placed on the bin top. Using the dimensions in FIGURE-1 below,
mark the machine footprint on the bin top by measuring over from the ice chute opening.
Note: Above machine footprint shown with stainless casings
Machine footprint with no casings: 40” X 26”
Machine footprint with plastic casings: 41” X 27 1/2”
FIGURE - 1
Ice Bin to Machine Layout

Installation & Start-up – HES Series
6
FIGURES 2 and 3 illustrate two methods of lifting & setting Tube-Ice
®
machine on a ice storage bin.
! CAUTION !
The approximate weight of the machine is 1360 pounds.
Always use equipment with adequate load-carrying capacity.
! CAUTION !
FIGURE - 2
Forklift-&-Blocks Method
You need: + forklift truck with adequate load and height capacities
+ (8) 2X4 wood blocks 8 in. long
+ (2) wooden 2X4’s measuring 3-ft. long
+ pry bar
Step 1. Position Tube-Ice
®
machine on forks.
! CAUTION !
The Tube-Ice
®
machine may be somewhat top heavy on the rear.
! CAUTION !
Step 2. Stack wood blocks in each corner of the drip pan on top of the ice storage bin.
Step 3. Lift and set Tube-Ice
®
machine on wood blocks.
Step 4. Remove forklift.
Step 5. Stack 3-ft. long 2X4’s beside drip pan, overlapping front and back of bin.
Step 6. Using a pry bar with fulcrum on 2X4’s, raise side of machine enough to remove TOP
wood blocks.
! CAUTION !
Do not remove top AND bottom blocks at the same time.
! CAUTION !
Step 7. Repeat steps 5 and 6 on other side.
Step 8. With machine sitting on one (1) block under each corner, repeat steps 5, 6, and 7 remove
remaining blocks. Drip pan flanges may bend slightly.
Step 9. Straighten bent drip pan flanges.
Step 10. Check alignment of ice chute to bin opening.

Installation & Start-up – HES Series
7
FIGURE - 3
Forklift-&-Rope or Lifting Straps Method
You need: + extra headroom
+ Forklift with adequate load and height capacities
+ 1/2” rope or four lifting straps to bind forks to top angles
Step 1. Remove front, rear, and top access panels.
Step 2. Position fork truck so that forks are resting flat on top angles of Tube-Ice
®
machine.
Step 3. Use the rope or straps to securely bind forks to the top angles.
! CAUTION !
Be sure the bin is level and is set in its proper location.
See the space diagram, FIGURE 6.
! CAUTION !
Step 4. Lift Tube-Ice
®
machine and set into drip pan of bin.
Step 5. Remove rope or straps and fork truck.
Step 6. Check alignment of ice chute to bin opening.

Installation & Start-up – HES Series
8
Sealing Ice Machine to Bin Top.
For machines installed on bins that do not have a drip pan, the perimeter of the ice machine
must be sealed with silicone. A tube of silicone sealant, and instructions are shipped inside the
ice machine for this purpose. (See FIGURE-4 and the instructions below)
1. Set machine on bin making sure that ice discharge chute is centered over bin
top opening.
2. Apply approximately 1/8” fillet bead of silicone to all sides of frame where it
meets bin top as shown in Detail “A”. NOTE: make sure that silicone bead on
frame does not interfere with proper casing fitup.
FIGURE – 4
Machine to Bin Top Installation

Installation & Start-up – HES Series
9
Connecting Electrical, Water & Drains
! WARNING !
The scroll compressor is phase sensitive. The compressor rotation must be checked before
the unit is operated. Failure to do so may affect compressor warranty.
! WARNING !
All electrical, water, drains, and air-cooled condenser connections are made at the rear of the ice
machine. See FIGURE-5 below for location information of all connecting points.
FIGURE – 5
Rear Utility Connection Layout

Installation & Start-up – HES Series
10
Wiring And Electrical Connection.
! WARNING !
Only service personnel experienced in refrigeration and qualified to work with high
voltage electrical equipment should be allowed to install or work on the Tube-Ice
®
machine.
! WARNING !
Refer to TABLE-1 below to properly size wiring connections. A fused disconnect must be
provided near the Tube-Ice
®
machine. Connect 3-phase power to terminals L1, L2, L3 for
operation of the Tube-Ice
®
machine and its controls. (See FIGURE-6) If one leg of the 3 phase
power is higher or lower (“Wild”), then it should be connected to terminal #L2. Connect the
“Ground” wire to the “Ground” terminal provided. On dual voltage, 50 Hz machines, the 220V
single phase should be connected to terminals L4 and L5.
Note: When initially starting the machine, the scroll compressor must be phased properly. If
the compressor is run backwards for an extended period of time, the compressor may be
damaged.
208/230V Air-cooled condenser should be wired to terminals 20,21,22 and 23. (see FIG. 11 &
12). 460V air cooled condensers should be wired to terminals B1, B2, B3, 22 & 23.
FIGURE – 6
Terminal Block Connections
Standard Voltages: Water Cooled Air Cooled
Model Voltage F.L.A. Min. Ampacity Max. Fuse F.L.A. Min. Ampacity Max. Fuse
208/230, 3p, 60 hz 18.0 20.9 30 21.4 24.3 35
460, 3p, 60 hz 9.0 10.4 15 10.3 11.7 20
220, 3p, 50 hz 19 21.0 35 22.4 25.3 35
HES20
400, 3p, 50 hz 9.5 10.9 15 10.8 12.2 15
208/230, 3p, 60 hz 21.6 25.4 40 25.5 29.3 40
460, 3p, 60 hz 10.7 12.6 15 12.0 13.9 20
220, 3p, 50 hz 22.6 26.4 40 26.5 30.3 45
HES30
400, 3p, 50 hz 11.2 13.1 20 12.5 14.4 20
208/230, 3p, 60 hz 27.3 32.5 50 35.1 40.3 60
460, 3p, 60 hz 13.3 15.8 30 17.3 19.8 30
220, 3p, 50 hz 28.3 33.5 50 36.1 41.3 60
HES40
400, 3p, 50 hz 15.3 18.2 25 17.9 20.8 30
TABLE – 1
Electrical Specifications

Installation & Start-up – HES Series
11
Piping and Drain Connections.
All connections are located at the rear of the machine. Water-cooled machines will have five
water connections (air cooled will have three water connections) on the freezing unit. See
FIGURE-7 to locate connections.
! CAUTION !
Exterior shut-off valves must be provided in the water inlet lines.
The minimum inlet water pressure for satisfactory operation of the machine is 30 psig.
The maximum allowable pressure is 100 psig.
! CAUTION !
Model 20 30 40
Make Up Water In
3/8” FPT
3/8” FPT
3/8” FPT
Water Tank Drain
3/4” FPT
3/4” FPT
3/4” FPT
Drip Pan Drain
3/4” FPT
3/4” FPT
3/4” FPT
Condenser Water In
3/4” FPT
3/4” FPT
1” FPT
Condenser Water Out
3/4” FPT 3/4” FPT 1” FPT
TABLE - 2
Water Supply and Drains
The condenser water outlet, water tank drain, drip drain and ice storage bin drain connections
must be extended to an open drain or sump and arranged for visible discharge. See FIGURE-7
for water and drain connections on machine. See FIGURE-8 of typical space diagram drawing
for ice storage bin drain connection.
! CAUTION !
These lines must NOT be connected into a pressure tight common header
due to the possibility that warm condenser water
may back up into the water pan, drip pan or the ice storage bin. The
condenser water outlet MUST be piped separately to the drain.
! CAUTION !
Note: Above drawing shown with plastic side casings (1/2” thick)
FIGURE –7
Water Connections

Installation & Start-up – HES Series
12
FIGURE - 8
Typical Space Diagram

Installation & Start-up – HES Series
13
Air-Cooled Condenser Installation Instructions
! WARNING !
These installation guidelines must be followed to obtain reliable operation
from air-cooled ice machines. If these guidelines are not followed, the
compressor warranty will not be honored.
! WARNING !
1. Use only Vogt approved condensers. Any exceptions to this policy must be obtained in
writing prior to installation and operation of the ice machine.
2. Outdoor condensers must be installed with vertical airflow. Indoor condensers used for
heat recovery may be installed with either horizontal or vertical airflow.
3. The condenser must be mounted above the ice machine, with liquid refrigerant from the
condenser outlet draining freely (1/4” per foot slope) in the direction of normal operating
flow (back to the ice machine) with no traps in the liquid line.
4. Flooding head pressure controls such as Alco Headmaster are not to be used, since they cause
excessive subcooling of the returned liquid refrigerant and interfere with reliable ice harvest.
5. The discharge and liquid lines must be insulated with 1/2” thick Armaflex insulation or equal.
6. Horizontal runs in the discharge line should slope 1/4” per foot in the normal direction
of flow (away from the ice machine).
7. Traps must be installed in discharge lines at the base of all vertical risers. There should be
no intentional traps in liquid lines. Trap volume should be kept to a minimum. Typical
details are shown in FIGURE-10. Long vertical runs should have traps every 20 feet.
8. Use only ACR grade copper pipe, Type L. Recommended line sizes are shown in TABLE-3.
9. Distance between ice machine and condenser must not exceed 150 equivalent feet. Refer
to Condenser Equivalent Line Size worksheet. (See TABLE-5)
10. Condensers must be provided with a cold weather valve kit per FIGURE-9A. These valves
allow one-half of the condenser to be disabled in cold weather. Running the ice machine
with one half the condenser in cold weather makes it easier to maintain minimum necessary
condensing pressure, particularly in windy conditions. The coil thermostat should be set to
close at 35°F. for multiple fan condensers or 50°F for single fan condensers.
11. Condensers with multiple fans must be provided with a thermostat to turn off unneeded
fans in cold weather. Turning off unneeded fans reduces on-off cycling of the fan(s) and
allows for a steadier condensing pressure. The fan thermostat should be set at 50°F.
12. When extreme cold conditions are expected or encountered (temperatures below 0°F and
wind greater than 15 MPH), it may be necessary to install a protective enclosure around
the condenser. Other apparatuses such as louvers may be used. Contact the factory for
suggestions.

Installation & Start-up – HES Series
14
13. After installation, the field-installed lines are to be evacuated to a vacuum of 500 microns
or less and held for at least one hour. Use ¼” access connection located on compressor
discharge line and liquid return line (32). After the vacuum pump is removed, vacuum
should hold at 500 microns or less for at least 5 minutes and the lines pressurized with R-
22 to 25-psig minimum.
14. The volume of refrigerant supplied with the machine is sufficient to fill the condenser and
condenser lines when length of pipe (one way) is 75 feet or less. When the length of lines
is longer than 75 feet, additional refrigerant must be added as noted below. Instructions
for adding refrigerant are included further in these instructions.
Liquid Line Size 75 ft. 100 ft. 125 ft. 150 ft.
1/2” none None None 2
5/8” none 2 4 6
7/8” none 4 8 12
1-1/8” none 6 12 18
TABLE - 3
Pounds R-404A to Add Vs. Liquid Line Length
15. All piping must be done in accordance with applicable local and national codes. Such
codes may include “The Safety Code for Mechanical Refrigeration (ANSI B9.1), and “The
Code for Refrigerant Piping” (ANSI B31.5).
16. The following installation guidelines are strongly suggested. While they do not affect the
machine warranty, they may be required for safe operation, and to comply with all
applicable electrical and mechanical codes.
17. Local electrical code must be checked for wiring method.
18. The installer must provide a lockable disconnect switch(s) adjacent to the condenser. The
power is fused at the machine by a 15 amp breaker.
19. Electrical connections between the condenser and the Tube-Ice
®
machine require
minimum 12 ga. wire. See FIGURE-11 &12.
20. All electrical fittings and components exposed to the weather must be suitable for outdoor
installation.
The design total heat rejection for each Tube-Ice
®
machine, the recommended air-cooled
condenser, and condenser physical and electrical data are shown in TABLE-4. Only the
condensers shown are UL listed with the ice machines. Other condensers may be individually
UL listed, but are not UL listed with the Tube-Ice
®
machines, and cannot be recommended by
Vogt Tube-Ice. Catalog energy efficiency ratings of the ice machines are based on use of the
recommended condenser.
Condensers supplied by Vogt must be utilized. The use of non-Vogt condensers will void the
compressor warranty. For continuous operation at ambient above 95°F, consult the factory
about using a larger condenser.

Installation & Start-up – HES Series
15
Ice Machine Model HE20 HE30 HE40
Recommended Condenser DVT005 (DVT008) DVT008 (DVT012) DVT012 (DVT016)
Note: For continuous operation at ambient above 105 °F, use larger condenser shown in parenthesis
Total Heat Rejection:
BTU/hr at 60 Hz. (15°F TD)
BTU/hr at 50 Hz.
35,700
32,800
58,800
54,100
117,500
108,100
Fans:
Number
HP, Each
Total, CFM
1
1/3 (1/2)
5,050 (6,450)
1 (2)
1/2
6,450 (12,400)
2
1/2
12,400 (12,900)
Full Load Amps:
1 ph., 208/230V, 60 Hz
3 ph., 208/230V, 60 Hz
3 ph., 460V, 60 Hz
1 ph., 200/220V, 50 Hz
3 ph., 200/220V, 50 Hz
3 ph., 400V, 50 Hz
3.4 (3.9)
N/A
1.3 (1.3)
3.4 (3.9)
N/A
1.3 (1.3)
3.9 (7.8)
N/A
1.3 (2.6)
3.9 (7.8)
N/A
1.3 (2.6)
7.8 (7.8)
N/A
2.6 (2.6)
7.8 (7.8)
N/A
2.6 (2.6)
Weight, lbs.:
Net
Shipping
Operating (maximum flooded)
180 (260)
320 (390)
195 (285)
260 (470)
390 (520)
285 (500)
470 (530)
520 (680)
500 (560)
Condenser dimensions, inches:
A (Width)
B (Length)
C (Height)
D (Leg centerline)
E (Leg centerline)
F (Clearance below)
43”
39.75” (49.75”)
30” (40”)
17”-3
30” (40”)
24.5”
43”
49.75” (69.75”)
40” (60”)
17” - 3
40” (60”)
24.5”
43”
69.75”
60”
17” - 3
60”
24.5”
Recommended Line Sizes, OD:
Liquid (All lengths and orientations)
Discharge Gas
Vertical Up, All lengths
Horizontal Or Down, < 75 ft.
Horizontal Or Down, > 75 ft.
1/2”
5/8”
5/8”
7/8”
5/8”
7/8”
7/8”
1-1/8”
7/8”
1-1/8”
1-1/8”
1-3/8”
Connections at Condenser:
Liquid (ODC)
Discharge Gas (ODC)
Connections at Machine
Liquid & Discharge Gas (ODC)
5/8” (7/8”)
7/8” (1 1/8”)
1-1/8”
7/8”
1 1/8”
1-1/8”
7/8”
1-1/8” (1-3/8”)
1-1/8”
TABLE - 4
Bohn Air-Cooled Condenser Data

Installation & Start-up – HES Series
16
Solenoid Valve Thermostats
Condenser Description Valve Valve Rebuild Kit Replacement Coil Fan Solenoid
DVT005 5/8” N.O. 12A4200A0503 12A4199V42 12A2105C04
DVT008 7/8” N.O. 12A4200A0704 12A4199V44 12A2105C04
DVT012
DVT016
1 1/8” N.O. 12A4200A0902
12A4200A09021
12A4199V45
12A4199V55
12A2105C04
12A2105C25
Penn
A19
Penn
A319
Note: Sporlan Solenoid Valves
Sporlan Solenoid valve OE34S290 (12A4200A0902) discontinued in Aug 2006
TABLE – 4A
Cold Weather Kit Replacement Parts
FIGURE - 9
Condenser Dimensions (Condenser pictured: DVT012 or DVT016)
Machine Bohn Part # Vogt Part # Coil Split
HE20 DVT005 12A2115B03 50/50
HE30 & HE20 (High Ambient) DVT008 12A2115B04 50/25/25
HE40 & HE30 (High Ambient) DVT012 12A2115B05 50/50
HE40 (High Ambient) DVT016 12A2115B06 50/50
P112 BNHS02A011 12A2115B07 50/50
P112 (High Ambient) BNHS02A011(12) 12A2115B08 50/50
P118 BNHS02A015(8) 12A2115B09 50/25/25
P118 (High Ambient) BNHS02A015(12) 12A2115B10 50/25/25
P18XT BNHS04A029 12A2115B11 50/50

Installation & Start-up – HES Series
17
Note: Check Valves in the return line (labeled “Output Liquid Return Line”) is supplied with
the condenser.
FIGURE – 9A
Condenser Field Piping / 50-25-25 Coil Split

Installation & Start-up – HES Series
18
Note: Check Valve in the return line (labeled “Output Liquid Return Line”) is supplied with the
condenser.
FIGURE – 9B
Condenser Field Piping / 50-50 Coil Split

Installation & Start-up – HES Series
19
CONDENSER EQUIVALENT
LINE SIZE WORKSHEET
Discharge Gas Line O.D. _____________
Fitting Type Number Used Factor Total
Globe Valve (open)
Angle Valve (open)
45°Elbow
90°Elbow
Feet of Straight Copper Used
Total Fitting Factor
Total Equivalent Feet
Fitting Factors
Copper Tube O.D. Type “L” 1/2” 5/8” 7/8” 1 1/8”
Globe Valve (open) 14 16 22 28
Angle Valve (open) 7 9 12 15
45°Elbow
.5 1 1 1.5
90° Elbow 1 2 2 3
TABLE - 5
FIGURE - 10
Minimum Traps for Discharge Lines

Installation & Start-up – HES Series
20
Wiring Connections to Air-Cooled Condenser.
HE Air-cooled condenser should be wired to terminals 20, 21, 22 and 23 (see FIGURE - 12).
NOTE: All four wires must be run from the ice machine to the remote air-cooled condenser.
FIGURE - 11
FIGURE - 12
Wiring For BOHN DVT005 with Cold Weather Valve and Single Fan,
50/50 Condenser Split
Main Power Connections
Condenser Connections
Main
Power
Fan
Motor (s)
Cold
Weather
Package
(Hot)
