Vogue RH.VG.600T User manual

ＲＨ．ＶＧ．６００Ｔ

1.Warnings
zThis appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without
supervision. If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
zThere shall be adequate ventilation of the room when the
range hood is used at the same time as appliances burning gas
or other fuels.
zThe filter mesh is med of high density aluminum. Please do
not use corrosive detergent for cleaning. The proper function
of the unit is conditioned by the regularity of the maintenance.
zTo protect the main body from corrosive of the long time
accumulation of dirt, the cooker hood should be cleaned with
hot water with non-corrosive detergent every two months.
zThere is a fire risk if cleaning is not carried out in accordance
with the instructions; do not flame under the range hood.
zThe air must not be discharged into a flue that is used for
exhausting fumes from appliances burning gas or other fuels.
zThe minimum distance between the supporting surface for the
cooking vessels on the hob and the lowest part of the range
hood is 65cm. Regulations concerning the discharge of air
have to be fulfilled.
zThe appliance uses 4 hob elements at most.
2

zThe appliance is not intended for use by young children or
infirm persons without supervisions.
zYoung children should be supervised to ensure they do not
play with the appliance.
zPlug the power cord to socket outlet with earthing continuity
terminal.
zThe cooker hood is for home use only, not suitable for
barbecue, roast shop and other commercial purposes.
zThe cooker hood and its filter mesh should be cleaned
regularly according to the instruction.
zDo not use open flame, or allow oil to go beneath tile
appliance.
zIf there is any fault occurred with the appliance, please call
after sale.
zservice department.
zPlease keep the kitchen room ventilated.
zPrior to any maintenance, cleaning operation, ensure the
power is cut off.
zlf the supply cord is damaged, it must be replaced by the
manufacturer, service agent or similarly qualified person in
order to avoid a hazard. The replaced power cord should be
provided by manufacturer or seller.
zlf the plug or cord is damaged, please call after- sales service
department.
zThere is a fire risk if cleaning is not carried out in accordance
with the instruction; regulations.
zIn case of damaged connecting wire, please refer to the
manufacturer, after-sale service personnel or other qualified
technicians.
zUse the unit according to the instructions to avoid any fire
hazard.
3

zThe exhaust air must not be introduced into a smoke flue or
chimney that is used for exhausting fumes from appliances
burning gas.
zFollow tile local laws applicable for external air evacuation.
zCAUTION: Accessible parts may become hot when
zused with cooking appliances.
4

Warnings
5

2.
Adjustable decorating trim
Frame groupware
Junction box
Grease filter
Lamp
Top plate
groupware
Control box cover
U-shaped section
-cover hang board
Power cord groupware
Decorate
Switch circuit board
Switch box
Fan
Ssmoke box
Volute stents
Front plate
racket
BSwitch
B ody groupware
6

Overlap the weatherstrip on the guide plate,
cut off the extra weatherstrip(
Then, fortify the glass top plate with four
screws
)by scissors.
L
7

Speed adjustment. See Fig.7
● Press Stop button, the motor will stop running.
● Press the Low (speed) button, the motor runs at low speed.
● Press the Mid (speed) button, the motor runs at mid speed.
● Press the High (speed) button, the motor runs at high speed.
● Press the Light button, the two lighting lamps will come on.
Press it again and the lamps will be turned off.
Fig.7
8

9

10

Voltage 220-240V～50Hz
Rated Power
Lighting Power
Motor Power 125W
Motor Single Motor
Inner diameter of air tube 150mm
Air output
Noise ≤61dB
1 W
０0m³/h
W
11
4
1.5 x2
28
