Void Cirrus 4.1 User manual

Cirrus 4.1/6.1
User Guide V1.0

©2020 Void Acoustics Research Ltd.
Version 1.0
This user guide is subject to change without notice.
For the latest online version, visit: www.voidacoustics.com
Void Acoustics and the Void logo are registered trademarks of Void
Acoustics Research Ltd. in the United Kingdom, USA and other
countries; all other Void trademarks are the property of Void Acoustics
Research Ltd.

Cirrus 4.1/6.1 User Guide V1.0 Page 3
Contents
1 Safety and regulations 4
1.1 Important safety instructions 4
1.2 Limitations 4
1.3 EC declaration of conformity 4
1.4 WEEE directive 4
2 Limited warranty 5
3 Unpacking and Checking 6
4About 7
4.1 Welcome 7
4.2 Cirrus series overview 7
5 Specifications and dimension 8
5.1 Cirrus 4.1 8
5.1.1 Key features 8
5.1.2 Cirrus 4.1 specifications 8
5.1.3 Cirrus 4.1 dimensions 9
5.2 Cirrus 6.1 10
5.2.1 Key features 10
5.2.2 Cirrus 6.1 specifications 10
5.2.3 Cirrus 6.1 dimensions 11
6 Voltage and power settings 12
7 Mounting 13
7.1 Installation safety 13
7.2 Mounting instruction 14
8 Service 17

Cirrus 4.1/6.1 User Guide V1.0 Page 4
1.1 Important safety instructions
The lightning flash with an arrowhead symbol
within an equilateral triangle is intended to alert the
user to the presence of uninsulated “dangerous
voltage” within the product’s enclosure that may
be of sucient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an equilateral triangle
is intended to alert the user of the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
appliance.
Safety instructions - read this first
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
8. Do not install near any heat source such as radiators, heat
registers, stoves, or other such apparatus that produce heat.
9. Do not defeat the safety purpose of the grounding-type
plug. A grounding type plug has two blades and a third
grounding prong. The third prong is provided for your safety.
If the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
10. Protect power cords from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit the apparatus.
11. Onlyuseattachmentsandaccessoriesspecifiedby Void
Acoustics.
12. Only use with the cart, stand, tripod, bracket, or table specified
by the manufacturer, or sold with the apparatus. When a
cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplugtheapparatusduringlightningstormsorwhenunused
forlongperiodsoftime.
14. Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in
any way, such as when the power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into
the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
15. Since the mains power supply cord attachment plug is used
to disconnect the device, the plug should always be easily
accessible.
16. Void loudspeakers can produce sound levels capable
of causing permanent hearing damage from prolonged
exposure. The higher the sound level, the less exposure
needed to cause such damage. Avoid prolonged exposure to
the high sound levels from the loudspeaker.
1.2 Limitations
This guide is provided to help familiarise the user with the
loudspeaker system and its accessories. It is not intended to provide
comprehensive electrical, fire, mechanical and noise training and is
not a substitute for industry-approved training. Nor does this guide
absolve the user of their obligation to comply with all relevant
safety legislation and codes of practice.
While every care has been taken in creating this guide, safety is
user-dependent and Void Acoustics Research Ltd cannot guarantee
complete safety whenever the system is rigged and operated.
1.3 EC declaration of conformity
Manufacturer:
Void Acoustics Research Ltd,
Unit 15 Dawkins Road Ind Est,
Poole, Dorset,
BH15 4JY,
United Kingdom.
We declare that under our sole responsibility the following product
models: Cirrus 4.1/6.1
are intended to be used as loudspeakers and are in conformity with
the following EC Directives, including all amendments, and with
national legislation implementing these directives:
• BS EN 60065:2002
• BS EN 55103-1/-2
March 2016
Alex Skan
Technical Director
1.4 WEEE directive
If the time arises to throw away your product, please recycle all the
components possible.
This symbol indicates that when the end-user
wishes to discard this product, it must be sent
to separate collection facilities for recovery
and recycling. By separating this product from
other household-type waste, the volume of
waste sent to incinerators or land-fills will be
reduced and natural resources will thus be
conserved.
The Waste Electrical and Electronic Equipment Directive (WEEE
Directive) aims to minimise the impact of electrical and electronic
goods on the environment. Void Acoustics Research Ltd complies
with the Directive 2002/96/EC and 2003/108/EC of the European
Parliament on waste electrical finance the cost of treatment and
recovery of electronic equipment (WEEE) in order to reduce the
amount of WEEE that is being disposed of in land-fill sites. All of
our products are marked with the WEEE symbol; this indicates that
this product must NOT be disposed of with other waste. Instead
it is the user’s responsibility to dispose of their waste electrical
and electronic equipment by handing it over to an approved
reprocessor, or by returning it to Void Acoustics Research Ltd for
reprocessing. For more information about where you can send
your waste equipment for recycling, please contact Void Acoustics
Research Ltd or one of your local distributors.
1 Safety and regulations

Cirrus 4.1/6.1 User Guide V1.0 Page 5
Limited warranty
The warranty
For a period of three (3) years from the date of
delivery to the original purchaser (as shown on the
original invoice or sales receipt; a copy of this may be
required as proof of warranty dates), Void Acoustics
Research Ltd (hereinafter “Void”) warrants to the
Original Owner (person or company who originally
purchased the product brand new from either Void
or a Void Authorised Dealer/Distributor) of each new
Cirrus Series product (provided it was purchased at
an Authorised Void Dealer) that it is free of defects
in materials and workmanship and that each
product will meet or exceed all factory published
specifications for each respective model. Void agrees
to repair or replace (at its discretion) all defective parts
at no charge for labour or materials; subject to the
following provisions:
Warranty violations
Void shall take no responsibility for repair or
replacement as specified under this warranty, if
the damaged product has been subject to misuse,
accident, neglect or failure to comply with normal
maintenance procedures; or if the serial number
has been defaced, altered or removed. Nor will Void
accept responsibility for, or resulting from, improper
alterations or unauthorised parts or repairs. This
warranty does not cover any damage to speakers
or any other consequential damage resulting from
breach of any written or implied warranty.
Void warranty provisions
Void will remedy any defect, regardless of the
reason for failure (except as excluded) by repair, or
replacement. Void will remedy the defect and ship
the product within a reasonable time after receipt of
the defective product at a Void Authorised Service
Centre.
To obtain warranty service
If a Void product requires service, the Owner must
contact Void or an Authorised Void Service Centre to
receive an R.A.N. (Return Authorisation Number) and
instructions on how to return the product to the Void
Authorised Service Centre, or to Void.
Void (or its Authorised Service Centre) will initiate
corrective repairs upon receipt of the returned
product. Please save the original carton and all the
packing materials in case shipping is required. All
products being returned to the factory or service
centre for repairs must be shipped prepaid.
If the repairs made by Void or the Void Authorised
Service Centre are not satisfactory, the Owner
is instructed to give written notice to Void. If the
defect or malfunction remains after a reasonable
number of attempts by Void to remedy the defect
or malfunction, the Original Owner shall then have
the option to elect either a refund or replacement of
said Void product free of charge. The refund shall be
an amount equal to but not greater than the actual
purchase price, not including any taxes, interest,
insurance, closing costs and other finance charges
(minus reasonable depreciation on the product).
If a refund is necessary, the Original Owner must
make the defective or malfunctioning product
available to Void free and clear of all liens or other
restrictions.
Equipment modifications
Technical and design specifications are subject to
change without notice.
Void reserves the right to modify or change
equipment (in whole or part) at any time prior to
delivery thereof, in order to include therein electrical
or mechanical improvements deemed appropriate
by Void, but without incurring any liability to modify
or change any equipment previously delivered, or
to supply new equipment in accordance with any
earlier specifications.
Disclaimer of consequential and incidental
damages
You, the Original Owner, are not entitled to recover
from Void any incidental damages resulting from any
defect in the Void product.
This includes any damage to another product or
products resulting from such a defect.
Warranty alterations
No person has the authority to enlarge, amend, or
modify this Warranty. This Warranty is not extended
by the length of time which the Original Owner
is deprived of the use of product. Repairs and
replacement parts provided pursuant to the Warranty
shall carry only the non-expired portion of the
Warranty.
This Statement of Warranty supersedes all
others contained in this user guide.
2 Limited warranty

Cirrus 4.1/6.1 User Guide V1.0 Page 6
All Void Acoustics products are carefully manufactured and thoroughly tested before being
despatched. Your dealer will ensure that your Void products are in pristine condition before
being forwarded to you but mistakes and accidents can happen.
Before signing for your delivery:
• Inspect your shipment for any signs of contamination, abuse or transit damage as soon as
you receive it
• Check your Void Acoustics delivery fully against your order
• If your shipment is incomplete or any of its contents are found to be damaged; inform the
shipping company and inform your dealer.
See section 2 for warranty conditions and see section 8 if your product needs service.
3 Unpacking and checking

Cirrus 4.1/6.1 User Guide V1.0 Page 7
4.1 Welcome
Many thanks for purchasing this Void Acoustics Cirrus 4.1/6.1. We truly appreciate your
support. At Void, we design, manufacture and distribute advanced professional audio systems
for the installed and live sound market sectors. Like all Void products, our highly skilled and
experienced engineers have successfully combined pioneering technologies with ground-
breaking design aesthetics, to bring you superior sound quality and visual innovation. In buying
this product, you are now part of the Void family and we hope using it brings you years of
satisfaction. This guide will help you both use this product safely and ensure it performs to its
full capability.
4.2 Cirrus series overview
Cirrus ceiling loudspeakers bring Void’s quality and attention to detail to the commercial install
sector. Designed for quick and easy installation, Cirrus delivers fidelity levels worthy of the
Void badge. With an understated, discreet appearance, the 70V/100V line integration, multiple
wattage taps and low impedance setting allow for seamless audio matching.
4 About

Cirrus 4.1/6.1 User Guide V1.0 Page 8
5.1 Cirrus 4.1
5.1.1 Key features:
• Passive 4” two-way full range ceiling loudspeaker
• Internal 100V/70V line transformer
• Selectable voltage taps and low impedance setting
• Wide 120° dispersion pattern
• Paintable white ABS enclosure
• 4” low frequency driver
• 0.75” coaxially mounted high frequency driver
• Quick and easy ceiling mount fixings
5.1.2 Cirrus 4.1 specifications
Frequency Response 149 Hz ~ 20 kHz (-3dB) / 98Hz ~ 20KHz (-10dB)
Eciency187 dB 1W/1m
Crossover Points 3 kHz passive
Nominal Impedance 8 Ω
Power Handling260 W AES
Voltage Taps 100 V - 25 W, 12.5 W, 6.3 W
70 V - 25 W, 12.5 W, 6.3 W and 3.2 W
Maximum Output3101 dB cont, 104 dB peak
Driver Configuration 1 x 4” LF, 1 x 0.75” HF
Dispersion 120°
Connectors Removable locking connector with screw-down terminals.
Two input terminals and two loop-thru output terminals.
Max. wire 12 AWG (2.5 mm2)
Weight 2.6 kg (5.7 lbs)
Enclosure ABS bae
Mounting Backing plate and tiles rails (included)
Colour White
Construction Note Mounting hole 178 mm (7”) diameter
1Measured in half space 2AES2 - 1984 compliant 3Calculated
5 Specifications and dimensions

Cirrus 4.1/6.1 User Guide V1.0 Page 9
5.1.3 Cirrus 4.1 dimensions
173 (6.8”) 150 (5.9”)
ø202 (8”)
Figure 5.1: Cirrus 4.1 dimensions
5 Specifications and dimensions

Cirrus 4.1/6.1 User Guide V1.0 Page 10
5 Specifications and dimensions
5.2 Cirrus 6.1
5.2.1 Key features
• Internal 100V/70V line transformer
• Selectable voltage taps and low impedance setting
• Wide 110° dispersion pattern
• Paintable white ABS enclosure
• 6.5” low frequency driver
• 0.75” coaxially mounted high frequency driver
• Quick and easy ceiling mount fixings
5.2.2 Cirrus 6.1 specifications
Frequency Response 96Hz ~ 18KHz (-3dB) / 62Hz ~ 20KHz (-10dB)
Eciency190 dB 1W/1m
Crossover Points 3.3 kHz passive
Nominal Impedance 8 Ω
Power Handling2100 W AES
Voltage Taps 100 V - 30 W, 15 W, 7.5 W
70 V - 30 W, 15 W, 7.5 W and 3.8 W
Maximum Output3107 dB cont, 110 dB peak
Driver Configuration 1 x 6.5” LF, 1 x 0.75” HF
Dispersion 110°
Connectors Removable locking connector with screw-down terminals.
Two input terminals and two loop-thru output terminals.
Max. wire 12 AWG (2.5 mm2)
Weight 3.5 kg (7.7 lbs)
Enclosure ABS bae
Mounting Backing plate and tiles rails (included)
Colour White
Construction Note Mounting hole 224 mm (8.8”) diameter
1Measured in half space 2AES2 - 1984 compliant 3Calculated

Cirrus 4.1/6.1 User Guide V1.0 Page 11
5 Specifications and dimensions
5.2.3 Cirrus 4.1 dimensions
204 (8”)
194 (7.6”)
ø251 (9.9”)
Figure 5.2: Cirrus 6.1 dimensions

Cirrus 4.1/6.1 User Guide V1.0 Page 12
6 Voltage and power setting
The Cirrus 4.1 and Cirrus 6.1 operate at 8 Ohms directly or at 100 V or 70 V operation through
line transformers from the switch on the bae.
Model 8 Ohm 100 V 70 V
Cirrus 4.1 60 W 25 W, 12.5 W, 6.3 W 25 W, 12.5 W, 6.3 W and 3.2 W
Cirrus 6.1 100 W 30 W, 15 W, 7.5 W 30 W, 15 W, 7.5 W and 3.8 W
Figure 6.1: Bae switch location

Cirrus 4.1/6.1 User Guide V1.0 Page 13
7 Mounting
Tools required
Cross head screw driver
7.1 Installation safety
To avoid mechanical hazards, please note the following:
• Safety regulations vary in dierent regions. Full compliance with those
regulations must be your priority
• Rigging must only be undertaken by fully-qualified and experienced riggers who
understand local regulations
• This may include consulting a structural engineer before installation of wall brackets
• Remember that all personnel have a duty of care to themselves, to their assistants, to the
venue sta and to the public
• Before lifting any part of the system above head height, check the whole rig for loose tools
or other items that may fall and cause injury
• Do not use a telephone (even if hands-free) while rigging. Always concentrate fully on the
rigging operation
• Do not rig equipment that is worn, damaged, corroded, mishandled or over-stressed in any way
• Use only Void-approved mounting equipment and accessories.
• Secondary safeties should be provided in all instances where cabinets are flying or fixing
overhead and should conform to local regulations

Cirrus 4.1/6.1 User Guide V1.0 Page 14
7.2 Mounting instructions
Step 1:
Cut the hole in the ceiling using the following dimensions or the cut out provided with the
Cirrus series loudspeaker:
Cirrus 4.1 178 mm (7”)
Cirrus 6.1 224 mm (8.8”)
7 Mounting
Step 3:
Attach the C-bracket to the rail with the screws
provided
Step 2:
Lay the tile rail either side of the hole and put
the C-bracket over the vertical edges of the
rails as shown in the image below.
Figure 7.1: C-bracket and rails
Figure 7.2: Attaching C-bracket to rail

Cirrus 4.1/6.1 User Guide V1.0 Page 15
7 Mounting
Step 4:
Insert the Cirrus series loudspeaker through the
ceiling hole and the C-bracket ensuring that
the swivel tabs do not align with the gap in the
bracket.
Step 5:
Tighten all four screws in the bae plate to
engage the swivel tabs and lock onto the
C-bracket.
Step 6:
Connect the amplifier cable to the
loudspeaker. The Cirrus series loudspeakers
have a 4 pin terminal that allows for + (2) and -
(3) for input and + (1) and - (4) link out.
Figure 7.3: Loudspeaker positioning
Figure 7.4: Engaging the swivel tabs
Figure 7.5: Terminal layout

Cirrus 4.1/6.1 User Guide V1.0 Page 16
7 Mounting
Step 7:
Reattach the steel fire proof cover to the
loudspeaker enclosure and attach the clamp to
the cable to ensure fire protection.
Step 8:
Attach a steel safety wire, rated to local
regulations, to the safety tag.
Step 9:
Push the grille into position.
Figure 7.6: Fire proof cover placement
Figure 7.7: Safety tag
Figure 7.8: Grille positioning

Cirrus 4.1/6.1 User Guide V1.0 Page 17
Void Cirrus loudspeakers should only be serviced by a fully-trained technician.
No user serviceable parts inside. Refer servicing to your dealer.
8.1 Return authorisation
Before returning your faulty product for repair, please remember to get an R.A.N. (Return
Authorisation Number) from the Void dealer who supplied the system to you. Your dealer will
handle the necessary paperwork and repair. Failure to go through this return authorisation
procedure could delay the repair of your product.
Note that your dealer will need to see a copy of your sales receipt as proof of purchase so
please have this to hand when applying for return authorisation.
8.2 Shipping and packing considerations
• When sending a Void Cirrus loudspeaker to an authorised service centre, please write a
detailed description of the fault and list any other equipment used in conjunction with the
faulty product.
• Accessories will not be required. Do not send the instruction manual, cables or any other
hardware unless your dealer asks you to.
• Pack your unit in the original factory packaging if possible. Include a note of the fault
description with the product. Do not send it separately.
• Ensure safe transportation of your unit to the authorised service centre.
8 Service

Page intentionally left blank

Page intentionally left blank

www.voidacoustics.com
Head Oce
Void Acoustics Research Ltd
Unit 15 Dawkins Road Industrial Estate
Poole
Dorset
BH15 4JY
England
[phone]
[e-mail]
Registered in England & Wales No. 07533536
North America
Void Acoustics North America
503-854-7134
[email protected]
