DB9 Male DB9 MaleDB9 Female DB9 Female
2 RD
3 TD
4 DTR
DSR, DCD
7 RTS
8 CTS
5 GND
9 RI
Straight Cable Wiring
IRF-631 RS-232
Device
DB9 Signal
RD
TD
DTR
DSR,DCD
RTS
CTS
GND
RI
2
3
4
6,1
7
8
5
9
DB9 Signal
6,1
See below for the pin assignment for crossover cable.
IRF-631 RS-232
Device
DB9 Male DB9 MaleDB9 Female DB9 Female
2 RD
3 TD
4 DTR
6,1 DSR, DCD
7 RTS
8 CTS
5 GND
9 RI
Cross Cable Wiring
DB9 Signal
2 TD
3 RD
6,1 DSR,DCD
4 DTR
7 CTS
8 RTS
5 GND
9 RI
DB9 Signal
1. Overview
The IRF-629 & IRF-631 Converters are used to connect
legacy serial device to ber based Ethernet
IRF-629 – RS-422/485 to Fiber Converter
IRF-631 – RS-232 to Fiber Converter
2. Package Checklist
Before installing IRF-6xx series, verify that the package
contains the following items:
 IRF-629/IRF-631 Converters
 Din Rail kit
 Power adapter (Check for area type)
 IRF-6xx series Quick Installation Guide
Push
Button Power
Input
DCE
DTE
PWR
9~32VDC
800mA
LNK
RCV
RS-232
Port
Fiber
Port
TX RX
DIP
Switches Power
Input
PWR
9~32VDC
800mA
OFF
ON
1 2 3 4
DIP SW
1NA
2NA
3
ON:485 2W
OFF:422/485 4W
4TMR
LNK
RCV
RS-422/485
Port
Fiber
Port
TX RX
Wallmount
screw hole
Wallmount
screw hole
3. Hardware Installation Procedure
STEP 1:
Remove the IRF-629/IRF-631 from packing. Connect
the 9-32V DC power adapter to the power input on
rear panel.
STEP 2:
Connect the Fiber port to the networking device. See
the LNK/ACT LED to confirm if the connection is
established.
STEP 3:
Connect the serial port to the serial devices.
STEP 4:
See the DIP switch on rear panel to enable/disable the
required features for appropriate usage.
NOTE: Please use the same hardware version for pair
connection. The version information is shown on
the label, i.e Rev.A.
4. Location
The IRF-629/ IRF-631 can be placed on a desktop or
horizontal surface, wall mounted and Din Rail mounted.
Quick Installation Guide
IRF-629/IRF-631
-1- -2- -3-
IRF-629 IRF-631
5. Terminal Block (RS-422/485) Wiring - IRF-629
IRF-629 offers 5-pin terminal block port. See the figure
below for the pin assignment.
Data+
Data-
GND
Rx+
Rx-
B
A
RS-485(2W)
RS-422(4W)
RS-485(4W)
RS-422/485
GND
TX+
TX-
(A)Rx+
(B)Rx-
Din RailWall Mount
IRF-631 oers 9-pin male console port. See gure be
low for the pin assignment for straight cable. This pin
assignment can also be used for IRF-633/634 as well if
using RS-232 conguration for serial port.
6. DB9 Male Pin Assignment (RS-232)
– IRF-631
Tx+
Tx-
GND
Rx+
Rx-
Operating Temperature
0˚C~50˚C
Storage Temperature
-20˚C~80˚C
Ambient relative humidity
10 to 80% (non-condensing)
7. Environmental limits
6400-000130
-4-
Limited Warranty
VOLKTEK Corporation warrants this product against defect in materials
and workmanship for a period of TWO(2) YEARS to the original purchaser.
If you discover a defect, VOLKTEK will, at its sole option, repair or
replace the product at no additional charge, provided that you contact
VOLKTEK technical support to obtain a Return Merchandise Authoriza-
tion Number (RMA) and instruction on how and where repairs can be
made. This warranty does not apply if the product has been damaged
by accident, abuse, misuse, misapplication, neglect, re, water,
lightning or other acts of nature, failure to follow supplied instructions,
installation or removal, have been repaired or have undergone
attempted repair by unauthorized personnel without written consent
from VOLKTEK, modied, defaced, or has its serial numbers removed.
VOLKTEK reserves the right to use remanufactured, refurbished, or
used parts and components in making warranty repairs.
All expressed or implied warranties for this product, including the
implied warranties of merchantability and tness for a particular
purpose are limited in duration to the warranty period. No warranties
expressed or implied will applied after this period. VOLKTEK shall not
be liable for lost prots, damage to other property caused by any
defects of this product, or damages based upon inconvenience, loss of
product use, loss of time, commercial use, incidental and/or
consequential damages for the breach of any expressed or implied
warranty, including damages to property, and to the extent permitted
by law, damages for personal injury, even if VOLKTEK has been advised
of the responsibilities of such damages.
If you have any further questions, please contact Customer Support:
Address of the manufacturer.
VOLKTEK CORPORATION
4F, 192 Liancheng Rd, Zhonghe, New Taipei 23553, Taiwan
Email: [email protected]
Tel: +886-2-8242-1000
Fax: +886-2-8242-3333
