PRODUCT MANUAL
PURE SINE WAVE INVERTER/UPS
WARRANTY CARD
FILL IN IF NEEDEED
(*) Cross incorrect
I agree to pay the cost of inverter repair due to:
* expiration of the warranty period / * warranty void
Before proceeding with the repair, service will inform by phone about the exact costs of the repair.
Please attach a copy of the purchase document (receipt or invoice) to the complaint.
The full regulations of service repairs can be found on our website www.voltpolska.pl
VOLT POLSKA Sp. z o.o.
ul. Swiemirowska 3
81-877 Sopot
www.voltpolska.pl
Proper disposal of the product
(waste electrical and electronic equipment)
The marking placed on the product or in the texts related to it indicates that it should not be disposed of with other household waste at the
end of its useful life. To avoid harmful effects to the environment and human health from uncontrolled disposal, please separate this product
from other types of waste and recycle responsibly to promote the reuse of material resources as a continuing practice. For
information on where and how to recycle this product in an environmentally safe manner, residential users should
contact the retailer where they purchased the product, or their local government authority. Business users should
contact their supplier and check the terms and conditions of their purchase contract. The product should not be
disposed of with other commercial waste.
DATE OF PURCHASE
SHIPPING ADDRESS
SIGNATURE / STAMP
DAMAGE DESCRIPTION
SERVICE COMMENTS
[email protected] [email protected] | [email protected] [email protected] |
wersja 1.2022.12.23
sinusPRO W

PREFACE SAFETY PRECAUTIONS
Welcome to use the inverter sinusPRO W. Please read carefully this manual
before operation.
Product features:
źWith inverter, UPS, AVR and charger function.
źToroidal transformer design, high efficiency low static loss, much more energy-
saving than old square transformer type design.
ź32-bit high speed CPU controlled, swift response speed, more accurate
detection.
źLED colorful humanistic and friendly operation interface, displays clearly
device’s working status (input&output voltage, loading status, battery status.
źPure sine wave output, suitable for almost all of appliance.
źHigh charging current.
źShort switchover time, guarantees the connected appliances uninterruptible
usage.
źVantilation fan intelligent controlled, fan working based on the setting
temperature and working status.
The manual is the integral part of the sinusPRO W series devices. Do not throw it out, store it
an easily accessible place and read the content before using device.
źAvoid overloading, don’t use the device beyond its maximum power capacity.
źIt will be a danger of high voltage in the device even all the switches are turned off, any
operation to move or open the device should be performed by authorized professional staff.
źIn case of fire, use the dry powder type fire extinguisher, don’t use liqiud type fire
extinguisher.
źIf the device works unusually, please switch off both power sources of battery and city power
immediately, any power source exist in such case will cause danger; and please report to the
distributor for professional advices.
źIMPORTANT! Don’t input voltage from poor quality generators that don’t produce sinusoidal
voltage, because the device will not work.
źIMPORTANT! We recommend using dedicated AGM/GEL lead-acid batteries that are
suitable for buffer/cyclic work and deep discharge. Connecting to the converter car batteries
that are not adapted for such work may result in damage to the converter/battery. Also, do not
connect LiFePO4 batteries, due to different charging/discharging characteristics than those
offered by the Sinus PRO E, W, S. To work with LiFePO4 batteries, we recommend using the
Sinus PRO ULTRA series by VOLT Polska.
[email protected] [email protected] | [email protected] [email protected] |

/
/
/
/
/
/
/
/
/
/
/
ac charger (mains charger on / off switch in the power supply)
the button is used to turn on / off the battery charger built into the power supply
DISPLAY, CONTROLL AND WARNING DETAILS OPERATIONAL DESCRIPTION
[email protected] [email protected] | [email protected] [email protected] |

TECHNICAL PARAMETERS
BUZZER WORKING STATUS
[email protected] [email protected] | [email protected] [email protected] |
Working status
źwhen city power abnormal swithover to battery mode - beeping one time
źbattery working low voltge or output overload - beeping every second
źprotection or outuput abnormal - beeping hurrily
Installation
źIf you find any damage upon package openning, please contact distribution
immediately.
źDon’t install the device up-side-down; not expose to direct sunlight or heat
source; away from children, away from water, moisture, oil or grease and any
flammable substance.
źFor better ventilation, fan outles and device ventilation should have at least 10cm
distance from the wall or other adjacent not heat producing equipment.
źMake sure the city power voltage and frequencey matches the device rated.
źThe device should be placed in the well grounded condititon to ensure the safety.
źBattery connection: connect the red cable to battery „+” pole and connect the
black cable to battery „-” pole, device cannot work under wrong connection.
500 W 800 W 1000 W 2000 W 2500 W 5000 W
500VA 800VA 1000VA 2000 VA 2500 VA 5000 VA
300W 500W 700W 1400W 1800W 3500W
voltage
frequency
voltage
frequency
voltage waveform
distortions
48VDC
10A
312x310x167 540x330x130
4,2 4,7 6,8 9,5 12 22
weight (kg)
311x232x140
MODEL
max power
max power current
input
output
< 3%
yes
overload, temperature, over and under voltage,battery discharge, short circuit,
overcharging
button battery mode/mains mode
protection
170VDC-270VDC
45 ~ 65 Hz
230 VAC ± 1% in battery mode; 230 VAC ± 8% in mains mode with AVR
50 Hz ± 0.5 Hz
pure sine wave
dimensions (mm)
≤ 4ms
time of switching between battery
mode/mains mode
battery voltage
12VDC
24VDC
charging current
10A
20A
253x241x102
