BALANSER AKU PROTECT 24V
Equalizer/Balanser
for
Gel/Flood/AGM Lead
Acid Batteries

[email protected] (58) 341-05-06 | [email protected] (58) 341-38-80 | [email protected] (22) 100-42-99
BALANSERA AKU PROTECT 24V is used for the 12V lead-acid batterie which
are connected in series to keep battery voltage balance (Gel/Flood/AGM lead
acid batteries all are ok.)
W h e n t w o o r m o r e i n - s e r i e s c o n n e c t e d b a t t e r i e s a r e i n
charging/discharging/free status. The battery voltages maybe become
different. One battery voltage is high and one is low.
The battery equalizer BALANSER AKU PROTECT 24V will equalize/balance
the battery voltage when it detect there are 20mV between two batteries. It will
shunt current from one battery (the higher voltage one) to the other battery (the
lower voltage one). Until their battery voltage almost becomes same. This will
improve battery's performance and extent battery's life time.
Battery equalizer can be used for 24V, 36V, 48V and any other N*12V battery
system.
ź1 piece for 24V system
ź2 pieces for 36V system
ź3 pieces for 48V system
Technical data:
Battery nominal voltage 2*12V
Optimizing current 0-5A
Quiescent current <3mA
Dimensions 70*70*27 mm
Protection Reverse polarity protection
Low Voltage Disconnect 10V

[email protected] (58) 341-05-06 | [email protected] (58) 341-38-80 | [email protected] (22) 100-42-99
LED Indicator:
Installation:
Please connect the battery equalizer to battery as follows: (Please check the pictures)
1. Red cable: Battery B positive/+ pole
2. Black cable: Battery A negative/- pole
3. White cable: Battery B negative pole or Battery A positive pole. (The pole which
connected Battery A and Battery B in series)
A B
A B A B A B A B A B
A B
+-
B A
+-
B A
+-
B A
+-
B A
+-
B A
+-
B A
+-
B A
+-
B A
+-
B A
+-
B A
+-
B A
+-
B A
+-
B A
Balanser AKU
PROTECT
Balanser AKU
PROTECT
Balanser AKU
PROTECT
Balanser AKU
PROTECT
Balanser AKU
PROTECT
Balanser AKU
PROTECT
Balanser AKU
PROTECT
A B
Red Black
White
A B A B A B A B A B
A B
+-
B A
+-
B A
+-
B A
+-
B A
+-
B A
+-
B A
+-
B A
+-
B A
+-
B A
+-
B A
+-
B A
+-
B A
+-
B A
Figure 2: 24V battery bank of 4 batteries
Balanser AKU
PROTECT
LED A LED B
U(A)=U(B) Off Off
Off
Off
Off
Off
U(A)>U(B)
U(A)<U(B)
U(A)<10V
U(B)<10V
U(A/B)<10V
Flash
Flash
On
On
On On
Figure 1: 24V battery bank of 2
Figure 4: 48V battery
Figure 3: 36V battery
Balanser AKU
PROTECT
Balanser AKU
PROTECT
Balanser AKU
PROTECT
Balanser AKU
PROTECT
Balanser AKU
PROTECT
Balanser AKU
PROTECT
