VOLTCRAFT 1893207 User manual

Operating Instructions
Automatic charger 6V/12V 1A/4.5A
Item No. 1893207 Page 2 - 15
Notice d’emploi
Chargeur automatique de 6V/12V
1A/4,5A
N° de commande 1893207 Page 16 - 29
Gebruiksaanwijzing
Automatischelader6V/12V1A/4,5A
Bestelnr. 1893207 Pagina 30 - 43

2
Table of contents
Page
1. Introduction..........................................................................................................................................................3
2. Explanation of symbols........................................................................................................................................3
3. Intended use........................................................................................................................................................4
4. Package contents ................................................................................................................................................4
5. Features and functions ........................................................................................................................................5
6. Safety information................................................................................................................................................5
a) General information.......................................................................................................................................5
b) Connected devices........................................................................................................................................6
c) Electrical safety .............................................................................................................................................6
d) Persons and product .....................................................................................................................................7
e) Rechargeable batteries .................................................................................................................................7
7. Operating elements .............................................................................................................................................8
a) Meaning of LED indicators ............................................................................................................................9
8. Installation and mounting.....................................................................................................................................9
9. Setup .................................................................................................................................................................10
a) Charging a battery.......................................................................................................................................10
b) Charging modes and functions....................................................................................................................12
c) Charging time ..............................................................................................................................................13
d) Built-in protection features...........................................................................................................................13
10. Care and cleaning..............................................................................................................................................14
11. Changing the fuse..............................................................................................................................................14
12. Disposal.............................................................................................................................................................14
a) Product ........................................................................................................................................................14
b) Rechargeable batteries ...............................................................................................................................14
13. Technical data....................................................................................................................................................15

3
1. Introduction
Dear customer,
Thank you for purchasing this product.
This product complies with statutory national and European regulations.
To ensure that the product remains in this state and to guarantee safe use, always follow the instructions in this
manual.
These operating instructions are part of this product. They contain important information on setting up and
using the product. Do not give this product to a third party without the operating instructions. Keep these
operating instructions in a safe place for future reference.
If there are any technical questions, please contact:
International: www.conrad.com/contact
United Kingdom: www.conrad-electronic.co.uk/contact
2. Explanation of symbols
The symbol with the lightning in a triangle indicates that there is a risk to your health, e.g. due to an electric
shock.
The symbol with an exclamation mark in a triangle is used to highlight important information in these oper-
ating instructions. Always read this information carefully.
The arrow symbol indicates special information and tips on how to use the product.
This symbol indicates that this product is built according to protection class II. It is equipped with reinforced
or dual insulation between the mains circuit and the output voltage.
The product must only be installed and used in dry, indoor locations. It must not become damp or wet, as
this may cause a fatal electric shock!
This symbol reminds you to read the operating instructions included with the product.
This symbol indicates the protection class. The product is sealed and protected against dust ingress and
spray water from all directions

4
3. Intended use
This compact charger automatically charges lead-acid, calcium and lithium batteries with a 6 V or 12 V terminal volt-
age and a capacity of 1.2 Ah to 120 Ah (for 12 V batteries) or 1.2 Ah to 24 Ah (for 6 V lead-acid batteries). Compatible
battery types include lead-eece (AGM) wet or gel batteries and lithium batteries. The charger can be used to charge
batteries mounted in vehicles. The charger can be used to charge batteries mounted in vehicles. It automatically
detects drained batteries and reactivates them by delivering an increased charging voltage. A trickle charge function
keeps the battery voltage at an optimal level. The charger features an operating button. LED indicators indicate the
operating status. The charger is protected against reverse polarity and short circuits. It can also detect faulty batteries.
The clamps initially deliver a voltage of 0.6-0.8 V when the charger detects that a battery is connected. This prevents
sparks from being produced if the clamps are touched unintentionally. The connection is indicated with colour-coded
clamps (red +, black -) for universal contact, or eyelets for permanent contact. It is also possible to connect the
charger to an in-vehicle cigarette lighter with a connector plug (for charging/power supply). The charging connections
can be reversed with a reverse-polarity protected socket system. The charger must not be used to connect or charge
primary batteries (e.g. zinc-carbon or alkaline batteries) or other batteries that are not specied in these instructions
(see "Technical data").
The charger must be connected to a standard household AC voltage and must only be used in well ventilated indoor
areas. The charger is powered by a 100–240 V/AC mains voltage.
This product is intended for indoor use only. Do not use it outdoors. Contact with moisture (e.g. in a bathroom) must
be avoided under all circumstances.
For safety and approval purposes, do not rebuild and/or modify this product. Using the product for purposes other than
those described above may damage the product. In addition, improper use can cause hazards such as a short circuit,
re or electric shock. Read the instructions carefully and store them in a safe place. Only make this product available
to third parties together with its operating instructions.
All company and product names are trademarks of their respective owners. All rights reserved.
4. Package contents
• Charger
• 1x ring eyelet connection (black = negative terminal, red = positive terminal).
• 1x red and black terminal (black = negative terminal, red = positive terminal).
• 1x car plug
• Operating instructions
1Up-to-date operating instructions
To download the latest operating instructions, visit www.conrad.com/downloads or scan the QR
code on this page. Follow the instructions on the website.

5
5. Features and functions
• Charges a range of batteries such as lead-acid (wet), gel, lead-eece (AGM) and lithium (LiFePO4) batteries
• Automatically selects the previous charging mode when switched on
• Can be used to power on-board devices when connected to the battery
• Charging mode for AGM and low temperatures
• Detects faulty batteries
• Compact and lightweight design
• Trickle charge function
6. Safety information
Read the operating instructions and safety information carefully. If you do not follow the safety
instructions and information on proper handling in these operating instructions, we assume no
liability for any resulting personal injury or damage to property. Such cases will invalidate the
warranty/guarantee.
a) General information
• The product is not a toy. Keep it out of the reach of children and pets.
• Do not leave packaging material lying around carelessly. It may become a dangerous toy for children.
• Protect the product from extreme temperatures, direct sunlight, strong jolts, high humidity, moisture,
ammable gases, vapours and solvents.
• Do not place the product under any mechanical stress.
• If it is no longer possible to operate the product safely, stop using it and prevent unauthorised use. Safe
operation can no longer be guaranteed if the product:
- is visibly damaged,
- is no longer working properly,
- has been stored for extended periods in poor ambient conditions or
- has been subjected to any serious transport-related stress.
• Handle the product carefully. Jolts, impacts or a fall even from a low height may damage the product.
• Consult a technician if you are not sure how to use or connect the product, or if you have concerns
about safety.
• Maintenance, modications and repairs must be done by a technician or a specialist repair centre.
• If you have any questions which are not answered in these operating instructions, contact our technical
support service or other technical personnel.

6
b) Connected devices
• Always observe the safety instructions and operating instructions of other devices (vehicle, batteries)
which are connected to the product.
c) Electrical safety
• Before connecting the product to the mains, check that your local A/C mains voltage matches the speci-
cations on the nameplate.
• The product is constructed according to protection class II. Only connect the charger to a standard mains
socket (230 V/AC, 50 Hz) connected to the public grid.
• Never pour liquids over electrical devices or place objects lled with liquid next to the device. If liquid
or an object does enter the interior of the device, power down the respective socket (e.g. switch off the
circuit breaker) and remove the mains plug from the mains socket. Discontinue use and take the product
to a specialist repair centre.
• Never use the product immediately after it has been brought from a cold room into a warm one. The
condensation that forms may destroy the product. The mains adapter may also cause a fatal electric
shock! Allow the product to reach room temperature before connecting it and putting it to use. This may
take several hours.
• The mains outlet must be located near to the device and be easily accessible.
• Never unplug the mains plug by pulling on the cable. Always use the grips on the plug.
• Unplug the mains plug from the mains socket if you do not plan to use the appliance for an extended
period of time.
• For safety reasons, disconnect the mains plug from the mains socket during thunderstorms.
• Make sure that the mains cable is not squeezed, bent, damaged by sharp edges or subjected to me-
chanical stress. Avoid excessive thermal stress on the mains cable from extreme heat or cold. Do not
modify the mains cable, as this may damage the components inside the cable. Damaged mains cables
can cause a fatal electric shock.
• Do not touch the mains cable if there are any signs of damage. Power down the respective mains socket
(e.g. via the respective circuit breaker), and then carefully unplug the mains plug from the mains socket.
Never use the product if the mains cable is damaged.
• Damaged mains cables must be replaced by the manufacturer, an authorised repair centre or a qualied
electrician.
• Never insert or unplug the mains plug when your hands are wet.

7
d) Persons and product
• Always comply with the accident prevention regulations for electrical equipment when using the product
in commercial facilities.
• In schools, educational facilities, computer and DIY workshops, the product must be used under the
supervision of qualied personnel.
• The device must not be used in explosion-prone areas.
• Observe the safety information in each section.
• Observe the labels on the product.
- Warning! Avoid explosive gases, naked ames and sparks.
- Disconnect the mains plug before connecting/disconnecting the battery.
- Read the operating instructions before charging.
- Use only the product in well ventilated areas.
• Do not use the charger inside vehicles.
• Never cover the charger or the connected battery!
• Do not smoke when using the charger or handling rechargeable batteries.
• Do not use the charger when the ambient temperature is higher than +40 ºC.
• Do not use the charger in the vicinity of ammable substances or gases.
e) Rechargeable batteries
• Ensure that you insert the battery in the correct polarity.
• Keep batteries out of the reach of children. Do not leave batteries lying around, as they constitute a
choking hazard for children and pets.
• Rechargeable batteries must not be dismantled, short-circuited or thrown into open ames. Never at-
tempt to charge non-rechargeable batteries, as this may cause an explosion!

8
7. Operating elements
56 4 3 2 1
7 8 9 10 11
1 MODE button
2 FULL charging status LED
3 MID charging status LED
4 LOW charging status LED
5 Defective faulty battery indicator
6 Reversed polarity indicator
7 AGM mode LED indicator
8 Flooded mode LED indicator
9 6 V mode LED indicator
10 12 V mode LED indicator
11 POWER LED indicator
13
1716 15
12 13
141516
12 Mains cable with mains plug
13 Charging cable connector with connection coupling
14 Red and black terminal (black = negative terminal, red = positive terminal).
15 Eyelet connector (black = negative terminal, red = positive terminal).
16 Vehicle connector

9
a) Meaning of LED indicators
LED Meaning
FULL Charging indicator (ashes when battery is more than 75 % charged, constant when battery
is fully charged)
MID Charging indicator (battery is less than 75 % charged)
LOW Charging indicator (battery is less than 50 % charged)
The indicator turns on if the connected battery is faulty.
The indicator turns on if the cable is connected in reverse polarity. Check that the charg-
ing contacts are connected in the correct polarity and diagnose the cause of the problem.
AGM This mode (winter mode) (14.7 V/4.5 A for lead-acid batteries) is designed for low ambient
temperatures. This mode is also recommended for AGM batteries.
LITHIUM This mode is designed to charge 12 V lithium rechargeable batteries (the AGM and Flood-
ed LEDs turn on).
Flooded This mode (summer mode) is designed to charge lead-acid batteries (14.4 V/4.5 A) at
normal temperatures.
6V 1A The 6 V motorcycle mode is designed to charge lead-acid batteries with a voltage of up to
7.2 V and a capacity of up to 24 Ah.
12V 1A The 12V motorcycle mode is designed to charge lead-acid batteries with a voltage of up to
14.4 V and a capacity of up to 120 Ah.
POWER The power LED indicates that the charger is connected to a power supply and in standby
mode.
8. Installation and mounting
You can place the charger on an even surface or screw it to a suitable surface (e.g. wall or workbench) via the mount-
ing brackets on the housing. Mount the charger on a stable surface using the mounting brackets and suitable screws
(not included).
Ensure that no existing cables or pipes (including water pipes) are damaged when drilling mounting holes
or securing screws.
• Remove all connected devices and the battery before mounting the charger.
Ensure that the mains socket for connecting the charger is close to the mounting location.
Follow the steps below to screw the charger in place:
• Place the charger in the desired mounting position. If necessary, use a spirit level to ensure that the charger is
aligned.

10
• Mark the position of the two screws through the holes in the mounting brackets. Drill the holes. Depending on the
surface, suitable screws and/or dowels may be required. Screws for wood and dowels in walls are not included
and must be purchased separately.
• After securing the charger to the surface, adjust it to the exact position and tighten the screws (do not overtighten
the screws). Use a suitable screwdriver to tighten the screws.
9. Setup
The charger heats up during use. Ensure that there is sufcient ventilation. Do not cover the housing!
Never charge lead batteries in a closed container.
Ensure there is sufcient ventilation during the charging process and avoid naked ames!
Explosive gases may be generated during the charging process. Keep the charger out of the reach of
children!
Before charging batteries with liquid acid, open the sealing plugs on each cell.
Leave the battery casing to ventilate for approx. 2 minutes to allow explosive gases to evaporate!
Check the liquid level and top up if necessary.
Check the liquid level on a regular basis during longer charging periods (overwintering). Wear safety
goggles when inspecting the batteries!
Do not turn lead-acid batteries upside down. Avoid any contact with the battery liquid, as it may cause
severe chemical burns.
Rinse the contact points (skin, clothes, etc.) immediately with water to dilute the battery acid.
Contact a doctor immediately in case of contact with skin.
In case of prolonged storage, charge lead-acid batteries every 3 months to prevent them from draining.
Never short-circuit the battery contacts.
When connecting batteries, ensure that they are connected in the correct polarity and observe the charg-
ing instructions provided by the battery manufacturer.
a) Charging a battery
• Ensure that your battery is compatible with the charger. The battery must be a 6 V/12 V lead-acid, lead-eece or
gel battery or a 12 V lithium battery. Refer to the specications in the "Technical data" section.
Do not use the charger to charge batteries with other operating voltages!
• Connect the appropriate adapter cable (15 or 16) to the charging cable. The plugs can only be connected in the
correct polarity. Check that the cables are connected properly. The locking mechanism should click into place.

11
You can also connect the charger to an in-vehicle cigarette lighter socket via the adapter cable and vehicle
connector (16). Switch off the ignition and other connected devices before connecting the charger. Refer
to the information in your vehicle owner's manual. The ground connection (negative terminal) is on the
outside of the vehicle connector. The positive terminal is located on the inside of the tip. This adapter only
functions when the cigarette lighter socket is connected to a continuously positive terminal (i.e. the socket
must function when the ignition is switched off).
• To unplug the adapter cable from the charging cable, press gently on the latch and pull the cables apart. Do not
force the cables apart if the locking mechanism has not been released.
• Insert the mains plug (13) into a mains socket (100-240 V/AC, 50/60 Hz). The charger will switch on and check
each charging function. The LED indicators will turn on briey.
The charger has an automatic memory function, i.e. it automatically selects the previous charging mode
when it is connected to the mains.
• Use the MODE button (1) to select a charging mode. Press the button until the LED/LEDs indicate the desired
function. For details on individual charging modes, refer to the next section ("b) Charging modes and functions").
Connect the adapter cable to the battery. Never connect the cable directly to other devices!
• Connect the charger to the battery. Ensure that the battery is connected in the correct polarity. The red adapter
cable must be connected to the positive terminal, and the black adapter cable must be connected to the negative
terminal. Connect the cables on the red and black clamps to the battery terminals. Screw the eyelet connector
to the terminal contacts (red and black terminal and eyelet connector: black = negative terminal, red = positive
terminal). Insert the vehicle connector into the cigarette lighter socket in your vehicle.
For built-in batteries connected to an on-board system, connect the positive terminal and then connect the
black terminal to an earth potential (chassis) that is positioned at a slight distance from the battery and the
fuel pipe. Check that the clamps are connected properly.
• Disconnect all devices from the battery. If the battery is mounted inside a vehicle, switch off the ignition.
For more information on charging vehicle batteries, follow the instructions and safety information in the
owner's manual. Modern vehicles are equipped with sensitive electronic components and sensors which
may be damaged if you do not exercise caution.
• The Reversed LED (6) will turn on if the polarity is incorrect. Check the polarity and connect the terminals in the
correct polarity.
• If the charging circuit is short-circuited, the Defective LED (5) will turn on.
• The charger can automatically detect defective batteries. If the battery is defective, the selected charging program
will not be started and the Defective LED (5) will turn on. Ask a technician to inspect the battery, or purchase a
replacement.
• Disconnect the battery and the charger from the power supply after the battery has nished charging. Disconnect
the mains plug (12) from the mains socket. Remove the black and then the red clamp from the battery.

12
b) Charging modes and functions
11. AGM mode (14.7 V ±0.25 V)
• This mode is designed to charge lead-acid, gel and lead-eece batteries with a capacity of over 25 Ah at low
ambient temperatures.
• To select this mode, press the MODE button (1) until the AGM indicator (7) turns on. The charging process will
start automatically (4.5 A ±10 %).
• The FULL indicator (2) will turn on when the battery is fully charged (14.7 V ±0.25 V). The device automatically
switches to trickle charge mode.
You can use this mode for batteries that are designed for higher nal charge voltages. Follow the charging
instructions provided by the battery manufacturer.
22. Wet/summer mode (14.4 V ±0.25 V, max. 4.5 A)
• This mode is designed to charge lead-acid, gel and lead-eece batteries with a capacity of over 25 Ah at normal
ambient temperatures.
• To select this mode, press the MODE button (1) until the Flooded indicator (8) turns on. The charging process
will start automatically (4.5 A ±10 %).
• The FULL indicator (2) will turn on when the battery is fully charged (14.4 V ±0.25 V). The device automatically
switches to trickle charge mode.
33. 6 V motorcycle mode (7.2 V ±0.25 V)
• This mode is designed to charge 6 V batteries with a capacity of less than 24 Ah at normal ambient temperatures.
• To select this mode, press the MODE button (1) until the 6 V LED indicator (9) turns on. The charging process
starts automatically. The maximum charging current is 1 A ±10 %.
• The FULL indicator (2) will turn on when the battery is fully charged (7.2 V ±0.25 V). The device automatically
switches to trickle charge mode.
44. 12V motorcycle mode (14.4 V ±0.25 V)
• This mode is designed to charge 12V batteries with a capacity of less than 120Ah at normal ambient temperatures.
• To select this mode, press the MODE button (1) until the 12 V LED indicator (10) turns on. The charging process
starts automatically. The maximum charging current is 1 A ±10 %.
• The FULL indicator (2) will turn on when the battery is fully charged (14.4 V ±0.25 V). The device automatically
switches to trickle charge mode.
55. Lithium mode (14.4 V ±0.25 V, max. 4.5 A)
• Lithium mode is designed to charge 12 V lithium rechargeable batteries (LiFePO 4 batteries). Follow the charging
instructions provided by the battery manufacturer.
• Press the MODE button (1) until the AGM (7) and Flooded (8) LED indicators start to ash. After approx. 2 sec-
onds, the LEDs will stay constant and the battery will start to charge. The charging process starts automatically.
The maximum charging current is 4.5 A ±10 %.
• The FULL indicator (2) will turn on when the battery is fully charged (14.4 V ±0.25 V). The device automatically
switches to trickle charge mode.

13
6Restore function
• This function is designed to restore overdischarged batteries. It cannot be selected manually. Restore mode starts
automatically when an overdischarged battery is connected to the charger. A low charging current is used to re-
store the battery to a normal voltage. When the battery reaches its normal voltage, the charger continues to charge
the battery using the normal charging process.
c) Charging time
• The time it takes for the battery to reach its nal charging voltage depends on several parameters, such as:
- The capacity (Ah) (batteries with higher capacities take longer to charge)
- The type of battery
- The charging status (full, half-full or empty)
- The ambient temperature (ideally between 20 - 25 °C) and
- The general condition (age) of the battery.
The charging time depends on the above parameters and can be roughly estimated using the following formula:
Charging time (in hours) = Battery capacity (in Ah) x 1.2 / Charging current (in A)
1Example: 20 Ah lead-gel battery, empty
Approx. charging time 5 hrs = 20 Ah x 1.2 / 5 A
d) Built-in protection features
1Spark-resistant short-circuit and reverse polarity protection
• These functions protect the charger from damage when the battery cables are connected in reverse polarity.
2Overvoltage protection
• This function protects sensitive electronic components in the charger against damage caused by high voltages.
3Charging current regulator
• This function prevents the charger from overheating and damage caused by short or excessive loads.
4Automatic overtemperature protection
• The overtemperature protection feature prevents damage to the charger caused by abnormal ambient tempera-
tures or faulty components.
The built-in overheat protection feature constantly monitors the temperature of the electronic components.
If the temperature exceeds the preset limit, the current is reduced to prevent the charger from overheating.
This reduces the output current until the temperature has dropped to a safe level.

14
10. Care and cleaning
Never use aggressive detergents, rubbing alcohol or other chemical solutions, as these may damage the
casing or stop the product from functioning properly.
• Before cleaning, disconnect the product from the mains and remove any connected batteries.
• Use a dry, lint-free cloth to clean the product.
11. Changing the fuse
• If the fuse of the device has burned out (there is no voltage at the charging output when a battery is connected),
send the charger to our technical support team or a qualied technician for repair/replacement fuse. Do not attempt
to replace the fuse by yourself!
12. Disposal
a) Product
Electronic devices are recyclable waste and must not be placed in household waste. At the end of its
service life, dispose of the product according to the relevant statutory regulations. Remove any connected
batteries and dispose of them separately from the product.
b) Rechargeable batteries
You are required by law to return all used batteries. They must not be placed in household waste.
Rechargeable batteries that contain hazardous substances are labelled with this symbol to indicate that
disposal in household waste is forbidden. The abbreviations for heavy metals in batteries are: Cd = Cad-
mium, Hg = Mercury, Pb = Lead (indicated on the battery, e.g. below the waste bin icon on the left).
Used batteries can be returned to local collection points, our stores or battery retailers.
You thus full your statutory obligations and contribute to environmental protection.

15
13. Technical data
Input voltage.....................................................100–240 V/AC, 50/60 Hz
Power consumption..........................................Max. 75 W
Output voltage/current......................................12 V/DC, 1 A / 4.5 A, 6 V/DC, 1 A
Rechargeable batteries ....................................1.2 – 120 Ah (12 V lead-acid/lithium)
1.2 – 24 Ah (6 V lead-acid)
Charging modes with voltages ......................... 14.4 V ±0.25 V, 4.5 A ± 10 % (wet mode)
14.7 V ±0.25 V, 4.5 A ± 10 % (AGM mode)
14.4 V ±0.25 V, 4.5 A ± 10 % (Lithium (ooded + AGM) mode)
14.4 V ±0.25 V, 1 A ±10 % (12 V, 1 A)
7.2 V ±0.25 V, 1 A ±10 % (6 V, 1 A)
Protection rating (housing) ...............................IP65
Fuse..................................................................T3.15A
Operating conditions.........................................0 to +40 ºC
Storage conditions............................................-30 to +70 ºC
Dimensions (L x W x H)....................................203 x 67 x 48 mm (device)
Weight ..............................................................650 g (with accessories)

16
Table des matières
Page
1. Introduction........................................................................................................................................................17
2. Explication des symboles ..................................................................................................................................17
3. Utilisation prévue ...............................................................................................................................................18
4. Contenu .............................................................................................................................................................18
5. Caractéristiques et fonctions .............................................................................................................................19
6. Consignes de sécurité .......................................................................................................................................19
a) Généralités ..................................................................................................................................................19
b) Appareils raccordés.....................................................................................................................................20
c) Sécurité électrique.......................................................................................................................................20
d) Personnes et produit ...................................................................................................................................21
e) Accumulateurs.............................................................................................................................................21
7. Éléments de fonctionnement .............................................................................................................................22
a) SignicationdesvoyantsLED.....................................................................................................................23
8. Montageetxation ............................................................................................................................................23
9. Mise en service..................................................................................................................................................24
a) Recharge d’une batterie ..............................................................................................................................24
b) Modes de charge et fonctions .....................................................................................................................26
c) Duréederecharge.......................................................................................................................................27
d) Fonctions de protection du chargeur...........................................................................................................27
10. Entretien et nettoyage........................................................................................................................................28
11. Remplacement du fusible ..................................................................................................................................28
12. Élimination des déchets.....................................................................................................................................28
a) Produit .........................................................................................................................................................28
b) Accumulateurs.............................................................................................................................................29
13. Donnéestechniques..........................................................................................................................................29

17
1. Introduction
Chers clients,
Nous vous remercions d’avoir choisi ce produit.
Ce produit est conforme aux exigences des normes européennes et nationales en vigueur.
Andemaintenirl’appareilenbonétatetd’enassurerunfonctionnementsansdanger,l’utilisateurdoitimpérative-
ment respecter ce mode d’emploi !
Ce mode d’emploi fait partie intégrante du produit. Il contient des consignes importantes pour la mise en
service et la manipulation du produit. Tenez compte de ces remarques, même en cas de cession de ce
produitàuntiers.Conservezcemoded’emploiandepouvoirleconsulteràtoutmoment!
Pour toute question technique, veuillez vous adresser à:
France (email) : [email protected]
Suisse : www.conrad.ch
www.biz-conrad.ch
2. Explication des symboles
 Lesymboledel’éclairdansuntriangleindiqueunrisquepourvotresanté,parex.suiteàunchocélec-
trique.
 Lesymboledupointd’exclamationdansuntriangleattirel’attentionsurlesconsignesimportantesdumode
d’emploi à respecter impérativement.
 Lesymboledelaècheprécèdelesconseilsetremarquesspéciquesàl’utilisation.
 CesymboleindiquequecetappareilestconformeàlaclassedeprotectionII.Ilpossèdeuneisolation
double ou renforcée entre le réseau d’alimentation et la tension de sortie.
 Leproduitdoitêtreinstalléetutiliséuniquementàl'intérieurdelocauxsecsetclos.L’appareilnedoitni
prendre l’humidité, ni être mouillé ! Il y aurait alors danger de mort par électrocution !
 Cesymbolevousrappellequevousdevezlirelemoded'emploidel'appareil.
Cesymboleindiquel'indicedeprotectionduproduit.Leproduitestprotégécontrelapoussièreetlesjets
d’eau provenant de toutes les directions.

18
3. Utilisation prévue
Lechargeurcompactsertàrechargerautomatiquementdesbatteriesauplomb-acide,calciumetlithiumayantune
tension aux bornes de 6 V ou 12 V et une capacité de 1,2 Ah à 120 Ah (pour les accus 12 V) ou de 1,2 Ah à 24 Ah
(uniquementpourlesaccusauplombde6V).Lestypesd'accusrechargeablessontlesaccusplomb-feutre(AGM),
lesaccusàélectrolyteliquideougéliéainsiquelesaccusaulithium.Lacharged'accusintégrésdansdesvéhicules
estpossible.Lacharged'accusintégrésdansdesvéhiculesestpossible.Cechargeurintelligentreconnaîtdesaccus
en décharge profonde et permet de les réactiver par une tension de charge augmentée. Une fonction de maintien
dechargemaintientlatensiondel'accutoujoursàunniveauoptimal.Unetouchepermetlacommandeduchargeur.
L'indicationdefonctionnementetd'étatestassurépardesvoyantsLED.Lechargeurestprotégécontrel'inversionde
polarité et les courts-circuits. Il détecte automatiquement les accus défectueux.
Lesbornesconduisentunetensionsupérieureà0,6-0,8Vuniquementlorsqu'unaccuestdétecté.Celaempêchela
formationd'étincellesencasdecontactinvolontaireaveclescontactsduchargeur.Leraccordementsefaitpardes
bornes codées couleur (rouge +, noir -) pour un contact universel, ou avec des œillets pour un contact permanent.
Leraccordementpourlachargeetl'alimentationélectriqueestégalementpossibleparbranchementsurlaprise
allume-cigared'unvéhiculeaumoyend'unecheallume-cigare.Lesbornesdechargepeuventêtreremplacéespar
unsystèmed'enchageprotégécontrel'inversiondespôles.Ilestinterditderaccorderetderechargerdesbatteries
primaires(auzinc-carbone,alcalinesetc.)oudestypesd'accusautresqueceuxindiquésprécédemment(voirle
chapitre « Caractéristiques techniques »).
Lechargeurnedoitêtreraccordéetutiliséquedansdeslocauxbienaérésetnedoitfonctionnerqu'avecunetension
alternativeusuellepourlesappareilsdomestiques.L'alimentationélectriques'effectueavecunetensionsecteurde
100 - 240 V/AC.
L’utilisationestuniquementautoriséeenintérieur,dansdeslocauxfermés;l’utilisationenpleinairestinterdite.Évitez
impérativement tout contact avec l’humidité, par ex. dans la salle de bains, etc.
Pourdesraisonsdesécuritéetd’homologation,toutetransformationet/oumodicationduproduitestinterdite.Sivous
utilisezleproduitàd’autresnsquecellesdécritesprécédemment,vousrisquezdel’endommager.Parailleurs,une
utilisationincorrectepeutêtresourcededangerstelsquelescourts-circuits,lesincendies,l'électrocution.Lisezatten-
tivementlemoded'emploietconservez-le.Netransmettezleproduitàuntiersqu’accompagnédesonmoded’emploi.
Tous les noms d’entreprises et appellations de produits contenus dans ce mode d’emploi sont des marques déposées
de leurs propriétaires respectifs. Tous droits réservés.
4. Contenu
• Chargeur
• 1Raccordàœillet(noir=pôlenégatif,rouge=pôlepositif)
• 1Bornerougeetnoire(noir=pôlenégatif,rouge=pôlepositif)
• 1 Connecteur de type automobile
• Moded'emploi
1Modes d'emploi actuels
Téléchargez les modes d’emploi actualisés via le lien www.conrad.com/downloads ou scannez le
Code QR illustré. Suivez les instructions disponibles sur le site Internet.

19
5. Caractéristiques et fonctions
• Pourlerechargementdedifférentstypesd'accustelsquedesbatteriesauplomb-acide(électrolyteliquide),au
gel,auplomb-feutre(AGM)etaulithium(LiFePO4).
• Réglageautomatiqueduderniermodedechargesélectionnéaprèsremiseenservice
• Alimentationdeconsommateursparconnexionàl'accupossible
• Sélection du mode de charge pour les batteries AGM et les températures basses
• Détectiond'accusdéfectueux
• Taille compacte et faible poids
• Fonction de maintien de la charge
6. Consignes de sécurité
Lisez attentivement le mode d’emploi dans son intégralité, en étant particulièrement attentif aux
consignes de sécurité. Nous déclinons toute responsabilité en cas de dommage corporel ou maté-
riel résultant du non-respect des consignes de sécurité et des instructions d’utilisation de ce mode
d’emploi. En outre, la garantie est annulée dans de tels cas.
a) Généralités
• Ceproduitn’estpasunjouet.Gardez-lehorsdeportéedesenfantsetdesanimauxdomestiques.
• Nelaissezpastraînerlematérield’emballage.Celapourraitdevenirunjouettrèsdangereuxpourles
enfants.
• Gardezleproduitàl'abridetempératuresextrêmes,delalumièredirectedusoleil,desecoussesin-
tenses,d'humiditéélevée,d'eau,degazinammables,devapeursetdesolvants.
• N’exposez pas le produit à des contraintes mécaniques.
• Si une utilisation en toute sécurité n’est plus possible, cessez d’utiliser le produit et protégez-le contre
une utilisation accidentelle. Une utilisation en toute sécurité n’est plus garantie si le produit :
- présente des traces de dommages visibles,
- ne fonctionne plus comme il devrait,
- a été rangé dans des conditions inadéquates sur une longue durée, ou
- aététransportédansdesconditionstrèsrudes.
• Manipulezleproduitavecprécaution.Leschocs,lescoupsetleschutes,mêmed’unefaiblehauteur,
sufsentpourendommagerl’appareil.
• En cas de doutes concernant le mode de fonctionnement, la sécurité ou le raccordement de l’appareil,
adressez-vous à un technicien spécialisé.
• Toute opération d’entretien, de réglage ou de réparation doit être effectuée par un spécialiste ou un
atelier spécialisé.

20
• Si vous avez encore des questions auxquelles ce mode d’emploi n’a pas su répondre, veuillez vous
adresser à notre service technique ou à un expert.
b) Appareils raccordés
• Respectez également les consignes de sécurité et le mode d’emploi des autres appareils (véhicule,
accu(s)) raccordés au produit.
c) Sécurité électrique
• Avant de brancher l'appareil, assurez-vous que les spécications de la plaque signalétique corres-
pondent à celles des prises de courant de votre domicile.
• LeproduitestfabriquéselonlaclassedeprotectionII.Cetappareildoitimpérativementêtrebranchésur
une prise de courant standard (230 V/AC, 50 Hz) du réseau d’alimentation public.
• Neversezjamaisdeliquidessurlesappareilsélectriquesetneposezpasd’objetscontenantdesli-
quidesàcôtédel’appareil.Siduliquideouunobjetdevaittoutefoispénétreràl’intérieurdel’appareil,
mettez d’abord la prise de courant correspondante hors tension (déconnectez par ex. le coupe-circuit
automatique)etdébranchezensuitelachedelaprisedecourant.N’utilisezensuiteplusleproduitet
conez-leàunatelierspécialisé.
• N’allumezjamaisl’appareilimmédiatementaprèssonpassaged’unepiècefroideàunepiècechaude.
L’eaudecondensationquienrésultepourraitéventuellementdétruirel’appareil.Ilyaenplusdangerde
mortparélectrocutionauniveaudublocd’alimentation!Laissezl’appareils’acclimateràlatempérature
ambiante avant de le brancher et de le mettre en marche. Selon les cas, cela peut prendre plusieurs
heures.
• Lapriseélectriquedoitsetrouveràproximitédel'appareiletêtrefacilementaccessible.
• Netirezjamaissurlecâblepourdébrancherlached’alimentationdelaprisedecourant;retireztou-
jourslacheenlasaisissantparlessurfacesdepréhensionprévuesàceteffet.
• Lorsquel’appareiln’estpasutilisédurantunepériodeprolongée,débranchez-le.
• Pour des raisons de sécurité, débranchez l’appareil en cas d’orage.
• Veillezàcequelecâbled’alimentationnesoitpasécrasé,plié,endommagépardesbordstranchants,ni
exposéàd’autrescontraintesmécaniques.Évitezdesoumettrelecâbled’alimentationauxcontraintes
thermiquesexcessivesduesàlachaleurouaufroidextrême.Nemodiezpaslecâbled’alimentation.
Danslecascontraire,vousrisquezdel’endommager.Uncâbled’alimentationendommagépeutocca-
sionner une électrocution mortelle.
• Silecâbled’alimentationestendommagé,neletouchezpas.Metteztoutd’abordlaprisedecourant
correspondante hors tension (par ex. au moyen du coupe-circuit automatique correspondant) puis re-
tirezavecprécaution la che delaprise. N’utilisez en aucuncasle produit avec uncâblesecteur
endommagé.
• Uncâbled’alimentationdoitêtreremplacéuniquementparlefabricant,parunatelieragrééouparune
autrepersonnequaliéeand’évitertoutdanger.
• Nebranchezninedébranchezjamaislachesecteuraveclesmainsmouillées.
