Volvo XC70 - ANNEXE 808 User manual

CONTENTS
THE VOLVO XC70
Supportive Technology 2
Performance 6
Driver’s environment 10
Passenger comfort 12
In-car entertainment 14
Versatility 16
Personal security 20
Safety & Environment 22
YOUR VOLVO XC70
Engines & Equipment 28
Style guide 30
Exterior design 32
Interior design 36
Inscription 42
Features, Options & Accessories 44
www.volvocars.com
There’s more to life than a Volvo. There’s the great outdoors. There’s
the daily routine. There’s rain, snow, sleet, sun, dust and dirt.
There’s you, your family, your friends and a thousand reasons to
get to any place you need to with power, refinement, versatility
and style. Then there’s your car. Life isn’t about limitations. It’s
about living. That’s why you should drive an XC70.

2
The car that lives
your way(s).
In the space of a few hours, pristine ski slopes
could be replaced by downtown traffic. Some
cars might find such a journey traumatic. Not the
XC70. Advanced technology such as Adaptive
Cruise Control (ACC) ensures that wherever life
might take you, your XC70 won’t utter a single
word of complaint.

4
Safe by nature – human nature.
Try to imagine a car that can see. A car that can think. A car that can intuitively react. Sounds
like science fiction, right? Not in the case of the XC70. Its brain consists of some of the most
powerful micro processing technology in the automotive world. Its eyes are advanced radar and
digital camera technology. And its intuition? How about Collision Warning with Auto Brake (CWAB),
Driver Alert Control (DAC) and Lane Departure Warning (LDW). Of course, we realise that no
safety equipment can compensate for a fully alert and responsive driver, but with the support of
these, and many other outstanding features, everyone lucky enough to travel in an XC70 enjoys
world class driving safety. Naturally.

6
Power liberates.
Consider where the XC70 can take you and you won’t be surprised
to learn about its engine program. For maximum performance, we
recommend you consider the new T6. This six-cylinder, 304 hp twin-
scroll turbocharged petrol engine delivers immediate response at all
revs. Or how about the new, impressively efficient D5? Its five-cylinder,
2.4 litre direct-injection turbodiesel engine develops 205 hp and 420 Nm
of max torque. The XC70 is even available as a DRIVe alternative.
Without compromising on performance, the DRIVe model satisfies
itself with a mere 5.8 litres of fuel per 100 km and emits a modest
154 g CO2/km. Add transmissions that include the six-speed Geartronic
automatic or a six-speed manual and, of course, Haldex®AWD all-wheel
drive and enjoy liberating power wherever you find yourself.

8
Going downhill was never
this uplifting.
Hill Descent Control is one of the Volvo XC70’s outstanding features. By simply
pushing a button, it offers smooth, controlled and safe descents on steep,
rough roads. The system controls braking on each wheel, allowing you to
concentrate fully on steering. Away from the wilderness, Hill Descent Control
also makes it easier to move off when towing a heavy trailer.

10
From here,
anything is possible.

12
Come alive.
No matter how much it changes, this is one view you’ll never grow tired of. Inside the Volvo XC70,
intuitive design and facilitating features take you to a place where complexity is simplified and
ergonomics and comfort live in harmony. Step inside and come alive.

14
Believing is hearing.
What’s the most attractive feature of the XC70’s Premium Sound System? Is it the refined power delivered by a state of the art
twelve-speaker system? Perhaps it’s the Dolby®Pro Logic®II surround sound. Or how about the 5x130 W digital class D amplifier?
Maybe it’s something simpler. Like the fact that wherever you sit in the XC70, music sounds just exactly the way it should. Your way.

16
Life engineering.
Versatility. A word you hear quite often in the
context of cars but one that takes on a whole
new meaning in the case of the Volvo XC70.
Especially when considering loading. Take the
Volvo XC70’s 40/20/40 split rear seats for
example. The flexibility they deliver in terms of
combining cargo and passengers let’s you load
up without compromising comfort or safety.
They also leave a lot of room for something
equally important – life. Or perhaps we should
say ‘lives’.

18

20
Now and again we like to
reduce pulse rates.
When you leave your XC70, you might find that you
pause for a moment. More out of reflection than
concern, might we add. Consider the fact that features
such as a remote alarm, Personal Car Communicator,
Home Safe Lighting and 360° laminated windows
place this car in a security class of its own – whether
you’re inside the car or a hundred miles away.
The alarm has been
triggered.
Your car is
unlocked.
Press here to
see the actual
status of your car
(within a range of
60–100 m) or the
car’s status when
you left it (outside
the range).
Your car is locked.
Remove mini-key
to lock storage
separately.

23
There’s more to life than a volvo. That’s why we design our
cars to support you in any situation on the road. That’s why
our safety technology has pushed automotive development for
more than eighty years. That’s why we aim for a future where
cars don’t crash. That’s why we lead the way to zero emissions,
and offer one of the premium segments strongest ranges of
low CO2 alternatives. And there are all the reasons in the world
to move the boundaries for what’s possible and what’s not.
That’s why we innovate for life.

24
Eyes in the back.
Park Assist and Park Assist Camera let you know what’s going on
behind your car when reversing.
All-road stability.
Volvo’s All-Wheel Drive (AWD) with Instant Traction™ enhances driving
stability and traction in all weathers, all seasons and on all roads.
Innovated for your enjoyment,
the Volvo safety technologies
will protect more than the fun
of driving.
Across the world, Volvo equals safety. And that comes with good reason, because few carmakers
can match our record of safety innovations and the commitment for safety that has guided us
for more than 80 years. Of course, this makes us extremely proud. But we’re not satisfied.
Because we know what we want to achieve: zero accidents. This huge task calls for innovative
thinking and a brand new approach to the way we design cars. Good news is we’ve already
come a long way. For starters, our cars are more fun and engaging to drive than ever (because
a bored driver will never be a safe driver). Neither is the technology needed any figment of the
imagination – some is already available in your Volvo. This means driving a Volvo today is like
having a first peek at a very exciting automotive future – a future where passionate engineering
and design do more to help you get the most out of life.
After all, there’s more to life than a Volvo.
Stay on track.
Volvo’s anti-skid system Dynamic Stability and Traction Control
(DSTC) improves handling and safety in a wide range of
challenging situations.
24/7 peace of mind.
Stay cool. Volvo On Call is Volvo’s integrated emergency and
roadside assistance technology.
Position control.
Lane Departure Warning (LDW ) warns you if you begin to
drift between the lanes.
Personal gatekeeping.
Inspired by fighter aircraft technology, the Intelligent Driver
Information System (IDIS) can help reduce your workload in
stressful situations.
Smooth cruising.
Adaptive Cruise Control (ACC) automatically maintains your set
speed and distance to the vehicle ahead of you.
Keeping a safe distance.
Collision Warning with Auto Brake (CWAB) warns if you’re too
close to a vehicle in front and helps brake the car automatically
if a collision is imminent.
An eye on the blind spot.
The Blind Spot Information System (BLIS) helps you detect
vehicles entering your blind spot.
Staying alert.
Driver Alert Control (DAC) aler ts you if you begin to lose
concentration and need a break.
On-road enlightenment.
Active Bending Lights (ABL) with Dual Xenon technology expands
your vision range when driving in the dark and provides considerably
improved illumination around bends.

26
Brake for energy.
Every time you brake, the batter y is fed with extra power.
Smart and fuel-saving.
154 g CO2 per km.
Our latest eco-progress, the front wheel drive Volvo XC70
DRIVe, satisfies itself with only 5. 8 litres fuel per 100 km
– for minimum emissions and maximum st yle.
Designed to catch the light
brilliantly, this car also reflects
a promise.
Thankfully, the automotive industry is moving away from fantasyland to the real world. Our
journey towards a better environment started already in the early 70’s. Then we were among
the first carmakers to acknowledge the environmental downside of cars and to do something
about it. Since then we are constantly innovating to reduce the environmental impact of the
cars and how we make them.
Today’s biggest challenge is, of course, to reduce the carbon dioxide emissions that cause
climate change. Today we offer one of the premium segments strongest ranges of low CO2
alternatives: the Volvo DRIVe variants. Utilising innovative powertrain technology together
with advanced aerodynamics, low friction technology and lightweight materials, the DRIVe
range is an important step towards zero emissions.
In near future we will introduce new technology such as plug-in hybrid vehicles that will further
reduce CO2emissions and can be charged from a standard wall socket. And we’re heavily
engaged in the development of electrical vehicles – a technology that will dramatically reduce
the environmental footprint of our cars and make them even more fun to drive.
Good for you, and for the world we share.
Cleaner exhaust.
Fast responding after a cold star t, Volvo’s advanced emission
control eliminates between 95 and 99% of carbon monoxide,
hydrocarbons and nitrogen oxides from petrol engine exhaust
gases. The Volvo turbodiesels feature a particulat e filter
that removes about 95% of the particl es from the diesel
exhaust gases. Most engines comply with stringent Euro 5
emission requirements.
Fresh cabin air.
Continuously monitoring incoming air and shutting out
carbon monoxide, ground-level ozone and nitrogen dioxide,
Volvo’s Interior Air Quality System helps ensure that the air
you breathe in the car is cleaner than that outside when
driving in heavy city traffic.
Fuel-saving design.
To reduce energy-losses from wind and roll resist ance, we
utilise advanced aerodynamic design, light-weight materials
and low friction technology. Together with state-of-the-art
engine technology, this lowers your CO2e missions and
helps you travel fur ther on less fuel.
Allergy-approved interior.
Clean Zone Interior Package (CZIP) provides cabin air that
is so clean it is recommended by the Swedish Asthma and
Allergy Association.
Maximised fuel efficiency with diesel.
Volvo’s advanced common rail turbodiesel technology
ensures superior fuel economy and low CO2emissions
– from the new CO2optimised front-wheel drive DRIVe
variant to the all-wheel drive D5 AWD.
85% recyclable.
To help minimise its total environmental impact, every Volvo
is designed to facilitate recovery and recycling at the end
of its useful life.
Allergy-tested interior materials.
All our upholsteries and interior textiles are tested for certain
allergy -inducing or harmful substances and comply with
Oeko-Tex Standard 100. And several interior metal details
are tested with regard to contact allergies. Good for you,
and for anyone who shares your ride.

28
THE CREATION OF YOUR VOLVO STARTS UNDER THE HOOD. A major part of the experience ahead of you is
defined by the engine you choose. Is it maximum performance and a sporty engine character that make your heart tick? Or do
you prefer relaxed cruising and the highest possible fuel mileage? Whichever engine satisfies your requirements, you will enjoy
instant power and smooth running while state-of-the-art fuel management systems make the most of every micro-drop of fuel.
Pick your engine, and enjoy the drive.
STANDARD
40/20/40 split rear seat
Aluminium decor inlays
Aluminium wheels 16"
AUX input
All-wheel drive (AWD)
Belt reminder, all positions
Cargo compartment load rails including four sliding hooks
Cup holders, tunnel console
Driver and passenger side airbags
Dynamic Stability and Traction Control (DSTC)
Electronic air heater
Electronic parking brake
Four aluminium attachments in cargo side panel
Frontal airbags
Front and rear skidplate
Hill Descent Control
Illuminated vanity mirror, passenger side
Inflatable Curtains (IC)
ISOFIX child safety seat attachments, rear
Load cover
Load protection net, steel
Lockable load space under load floor
Performance audio package
Remote control central locking
Roof rails XC
Side Impact Protection System (SIPS)
Temperature gauge, outer
Textile floor mats
Textile/Vinyl upholstery
Trip computer
Whiplash Protection System (WHIPS)
EQUIP YOUR OWN VOLVO XC70. As you define your own style
and specify your needs, choose one of Volvo’s equipment levels – Kinetic,
Momentum or Summum. These ample packages add luxury and comfort
beyond the impressive standard equipment level and reflect our core belief
that functionality and beauty go everywhere together. For more information
about the different equipment levels, please contact your Volvo dealer or
visit www.volvocars.com
DIESEL ENGINES
T6 AWD
auto
244 CO2g/km
10. 5 l/100 km
304 hp
440 Nm
3.2 AWD
auto
239 CO2g/km
10. 2 l/100 km
238 hp
320 Nm
PETROL ENGINE
D5 AWD
ma n/au to
182 /189 CO2g/km
6. 9 /7. 2 l/100 km
205 hp
420 Nm
D3 AWD
man/au to
182 /189 CO2g/km
6. 9 /7. 2 l/100 km
163 hp
420 Nm
D3
auto
179 CO2g/km
6.8 l/100 km
163 hp
400 Nm
DRIVe
man
154 CO2g/km
5.8 l/100 km
163 hp
400 Nm
Technical data may be subject to change. Please talk to your Volvo dealer for the latest information. All technical data is preliminary.
29
KIN E T I C
includes Standard equipment level plus the following:
Interior Air Quality System (IAQS)
Audio controls in steering wheel
Cruise control
Electronic Climate Control (ECC)
Fog lights, front spoiler
Illuminated vanity mirrors, driver
Leather-clad gear knob
Leather-clad steering wheel
MO M E N TUM
includes Standard and Kinetic equipment level plus
the following:
Automatically dimmed inner rear-view mirror
Bright window trim
Grocery bag holder
Heated front seats
Leather upholstery
Power tailgate
Rain sensor
Rear armrest with cup holder
Retractable outer rear-view mirrors
SU M M U M
includes Momentum equipment level plus the following:
Aluminium wheels 17"
Dual Xenon headlights
Compass
Park assist, rear
Power seat, driver with memory
Wood decor inlay
N.B. The contents in the equipment levels may vary from country to countr y.
Please ask your Volvo dealer for further information.

WANT A DYNAMIC TOUCH? If stylish and sporty looks get your
pulse racing, this may be the Volvo XC70 for you: Perforated Leather
Offblack upholstery in Anthracite Black interior with Crossed aluminium
centre stack and door panel inserts, leather-clad steering wheel,
Charcoal and leather-clad gear knob, Charcoal. Exterior colour Ice
White with colour-matched roof spoiler, side-scuff plates and Erakir 19"
Diamond cut/Anthracite matt aluminium wheels.
OR MODERN LUXURY? Some people prefer sophisticated,
timeless elegance. If that sounds like you, your new Volvo XC70 can
look like this: Leather Soft Beige upholstery in Sandstone Beige interior
with Classic wood centre stack and door panel inserts plus illuminated
instep plats. Leather/Classic wood steering wheel, Soft Beige and
Leather/Classic wood gear knob, Soft Beige. Exterior colour Flamenco
Red metallic and Sargas 17"Silver Bright aluminium wheels.

32
498 Caspian Blue metallic
493 Caper Green metallic
COLOUR YOUR VOLVO. When it comes to the appearance of your Volvo,
the choice of exterior colour and wheels are probably your most important
design decisions. For more exterior styling options and to build your new Volvo
online, please visit www.volvocars.com
472 Oyster Grey metallic
477 Electric Silver metallic
Inscription is our exclusive design programme for a truly distinguished look.
33
702 Flamenco Red metallic
426 Silver metallic
614 Ice White
019 Black Stone452 Black Sapphire metallic
484 Seashell metallic
Please n ote: It ’s not possible to reproduce exact original shades in printed matter. Please ask
your dealer to show you samples.
Clean colours
To reduce usage of environmentally hazardous solvents, all Volvo exterior colours are
water-based. What’s more, our painting facilities are among the cleanest in the world.

35
EXTERIOR DESIGN. The XC70’s muscular yet
lean design characteristics can both seduce and
deceive. Its seductive nature is obvious. Horizontal
lines give the car a wide, low look while the vertical
design qualities have been emphasised to create a
tough, rugged and stable impression. As for deceptive,
we were referring to load capacity. And in the case
of the XC70, this is anything but lean. The XC70 is
also a blank page on which you can write your own
personal signature by adding side scuff plates,
aluminium crossbars, a roof spoiler or any one of
many other eye-catching touches.
Erakir 8x19"
Black Chrome
Erakir 8x19"
Diamond cut/Silver Stone
Erakir 8x19"
Diamond cut/Anthracite matt
Agena 7x16 "
Silver Stone
Side scuff plate
The matt aluminium finish side scuff plates add an extra touch of
attitude to the Volvo XC70 – perfectly matching the design of the
sill and other XC70 exterior styling details.
Aluminium crossbars
An aerodynamic design element that complements the roof rails
and the design of your Volvo. These aluminium crossbars also
allow you to exploit the roof’s load-carrying capacity to the full.
Roof spoiler
The stylish roof spoiler enhances the sporty lines of your Volvo
estate and is colour-coordinated with the body.
EXTERIOR DESIGN Aluminium wheels
Merac 7.5x18"
Silver Bright
Sargas 7.5x17"
Silver Bright
Cecino 7x16"
Silver Stone
ACCESSORY Aluminium wheels

37
Perforated leather
Designed for use with ventilated seats, this qualit y is made with
buf fed leather. Central seat panels are perforated, efficiently
managing body moisture while adding an aesthetic quality.
Duved textile/vinyl
This rugged looking upholstery combines two materials. The
contemporar y textile upholstery is trimmed with durable vinyl
hide that has a leather look and feel.
Leather
This is a hide quality that’s comfortable, durable and has a coarse grain
pattern. Like all Volvo leather, it’s organically tanned and ages beautifully.
IMAGINE YOUR NEW INTERIOR. Crafted according to your requirements, the interior of your Volvo can take
on any number of personalities. Choose between two interior colours – Anthracite Black and Sandstone Beige – and
different upholstery variants. Pick the interior that suits you and add the finishing touch with the interior trim, steering
wheel, gear knob and floor mat of your choice. After all, you’re probably going to spend a lot of time here.
Ergonomic design Developed in co-operation with ergonomic
specialists to provide generous support for the body during hours
of driving, the seats in the Volvo XC70 are among the most
comfor t abl e in the au tomot ive wor ld. M ultip le adju stment
possibilities and adjustable lumbar support make it easy to find
the perfect driving position.
