Vonsch RU CONTROL Series Quick guide

15. apríla 2019 Page 1 from 97
Configuration and diagnostics
for RU CONTROL, FOTO CONTROL, GSE CONTROL,
UNIKOMPENZATOR and QUATROFREM (grid side) inverters

RU , GSE, FOTO CONTROL, QUATROFREM v.2.53x
15. apríla 2019 Page 2 from 97

RU , GSE, FOTO CONTROL, QUATROFREM v.2.53x
15. apríla 2019 Page 3 from 97
1 Contents
2Structure and types of parameters in the document....................................................................6
2.1 Defining the meaning and type of parameters in part DIAGNOSTICS ................................6
2.2 Defining the meaning and type of parameters in part SETTINGS .......................................7
2.3 Type of parameters defining in the part SAVE / RESTORE ..............................................12
3Range of parameters by product type........................................................................................13
3.1 Voltages...............................................................................................................................13
3.2 Temperatures ......................................................................................................................13
3.3 Currents...............................................................................................................................14
4DIAGNOSTICS ...........................................................................................................................15
4.1 Fotocontrol / PGE................................................................................................................15
4.1.1 String measurement.....................................................................................................15
4.1.2 Energy of strings ..........................................................................................................16
4.2 Power and energy ...............................................................................................................17
4.2.1 Production stats ...........................................................................................................17
4.2.2 Energy meter................................................................................................................17
4.3 Command ............................................................................................................................18
4.4 Control .................................................................................................................................18
4.4.1 Symmetry of INV currents............................................................................................19
4.4.2 I Harmonics ..................................................................................................................19
4.4.3 V harmonics .................................................................................................................20
4.4.4 DC curr. controller........................................................................................................21
4.4.5 Additional quantities.....................................................................................................21
4.5 Inputs and outputs...............................................................................................................21
4.5.1 BIN................................................................................................................................21
4.5.2 AIN................................................................................................................................22
4.5.3 RELAYS .......................................................................................................................22
4.5.4 AOUT ...........................................................................................................................22
4.6 Functions .............................................................................................................................23
4.6.1 PLC function.................................................................................................................23
4.6.2 Process controller ........................................................................................................23
4.6.3 Optimization .................................................................................................................24
4.6.4 Ext. thermal protection .................................................................................................24
4.6.5 S0 measurement..........................................................................................................25
4.7 Inverter state........................................................................................................................25
4.8 Thermal protections.............................................................................................................26
4.9 Communication....................................................................................................................26
4.9.1 MODBUS......................................................................................................................26
4.9.2 PROFIBUS...................................................................................................................27
4.9.3 RS LINKS.....................................................................................................................28
4.10 SW and HW version............................................................................................................28
4.11 Date and Time.....................................................................................................................28
5WARNINGS ................................................................................................................................29
6ERRORS.....................................................................................................................................32
7SETTINGS ..................................................................................................................................35
7.1 FOTOCONTROL / PEG ......................................................................................................35
7.1.1 STRING CHECK..........................................................................................................36
7.1.2 EFFICIENCY CHECK ..................................................................................................36
7.2 INVERTER PARAMETERS ................................................................................................37
7.2.1 ENERGY CONS. SETTING.........................................................................................38
7.3 COMMANDS .......................................................................................................................38
7.3.1 START RESET ............................................................................................................38
7.3.2 ON / OFF......................................................................................................................40
7.3.3 DC VOLTAGE REFERENCE ......................................................................................41
7.3.4 AC VOLTAGE REF......................................................................................................41

RU , GSE, FOTO CONTROL, QUATROFREM v.2.53x
15. apríla 2019 Page 4 from 97
7.3.5 POWER FACTOR REF. ..............................................................................................41
7.3.6 AC POWER REFERENCE ..........................................................................................41
7.3.7 REACTIVE POWER REF. ...........................................................................................42
7.3.8 DISCRETE SETPOINTS .............................................................................................42
7.4 CONTROL AND REGULATION .........................................................................................44
7.4.1 POWER RESTRICTION..............................................................................................45
7.4.2 VOLTAGE RAMPS ......................................................................................................46
7.4.3 CONTROLLERS ..........................................................................................................46
7.4.4 DROOP CONTROL .....................................................................................................47
7.4.5 DC CURR. CONTROLLER..........................................................................................48
7.5 INPUTS AND OUTPUTS ....................................................................................................48
7.5.1 BINARY INPUTS..........................................................................................................48
7.5.2 ANALOG INPUTS........................................................................................................49
7.5.3 RELAY OUTPUTS .......................................................................................................53
7.5.4 ANALOG OUTPUTS....................................................................................................55
7.6 FUNCTIONS........................................................................................................................57
7.6.1 PLC FUNCTIONS ........................................................................................................57
7.6.2 PROCESS CONTROLLER..........................................................................................66
7.6.3 OPTIMIZATION............................................................................................................69
7.6.4 EXTERNAL THERMAL PROTECTION (ETP) ............................................................71
7.6.5 S0 measure..................................................................................................................72
7.7 FAULTS AND WARNINGS.................................................................................................72
7.7.1 OPTIONAL FAULTS ....................................................................................................72
7.7.2 GRID TEST ..................................................................................................................73
7.7.3 HARMONICS CHECK .................................................................................................75
7.7.4 I SYMMETRY CHECK.................................................................................................76
7.7.5 FAULT ACKNOWLEDGEMENT..................................................................................77
7.7.6 QUANTITIES TO LOG.................................................................................................78
7.7.7 WARNINGS .................................................................................................................78
7.8 DISPLAY..............................................................................................................................79
7.8.1 DISP. QUANT. SETTINGS..........................................................................................79
7.8.2 MONITOR SETTING ...................................................................................................79
7.9 COMMUNICATION .............................................................................................................80
7.9.1 MODBUS......................................................................................................................80
7.9.2 PROFIBUS...................................................................................................................83
7.10 PAR. SETS..........................................................................................................................84
7.10.1 SET SWITCH...............................................................................................................84
8Control panel –Unipanel user manual.......................................................................................86
8.1 Buttons.................................................................................................................................86
8.2 Panel start ...........................................................................................................................87
8.3 Display .................................................................................................................................87
8.4 Converter status ..................................................................................................................87
8.5 Main menu F1......................................................................................................................87
8.6 Monitor, monitor detail.........................................................................................................90
8.7 Parameters setting ..............................................................................................................91
8.8 Graph...................................................................................................................................94
8.9 Parameter search................................................................................................................96
8.10 Device selection for control panel.......................................................................................97

RU , GSE, FOTO CONTROL, QUATROFREM v.2.53x
15. apríla 2019 Page 5 from 97
WARNING
This manual dedicates to the configuration and diagnostics options of VONSCH RU CONTROL,
FOTO CONTROL, GSE CONTROL, UNIKOMPENSATOR and QUATROFREM (grid side)
inverters.

RU , GSE, FOTO CONTROL, QUATROFREM v.2.53x
15. apríla 2019 Page 6 from 97
2 Structure and types of parameters in the document
2.1 Defining the meaning and type of parameters in part DIAGNOSTICS
Diagnostic parameter that displays the value of signal in physical units or in relative units or
discrete number of sequences, steps, received data etc.
EXAMPLE:
Value –the value
MENU \ DIAGNOSTICS \ Converter state \
Value –discrete number
MENU \ DIAGNOSTICS \ Functions \ Lifting functions\
Example for value diagnostics –the value display
Example of diagnostic value representing the number
of illegal control drive sequences
Individual word bits status diagnostics. Each bit represents the status of one flag of a specific
function or converter mode.
MENU PARAMETERS
ID –unique identification number
SETTINGS
DIAGNOSTICS
SAVE/RESTORE
-Value–the value,
number
-Word (array of bits)
-Constant
-Date time
-The value
-Calculated parameters
-Selection (1 option selection)
-Multiple selection (multiple options
selection - mask)
-Command (execution of a single action)
-Signal (source of signal and functions
inputs)
-Dynamic value (linked parameter)
-Password
-Path (position in the
structure of
parameters)
-parameters types as
in the part
SETTINGS
Parameter type: VALUE
Name [ID]
Unit
Description
AIN1 Rel.
[41]
%
Value of the signal connected to the analog input terminals + X1:11 and -
X1:12.Parameters of the analog input can be configured in the parameter group
P[147] AIN1.
MENU \ DIAGNOSTICS \ Inputs / outputs \ AIN \
Value unit
Values ID and name
The basic diagnostics information about the importance of value
Position of the parameter in a tree hierarchical parameters structure
Parameter type: WORD

RU , GSE, FOTO CONTROL, QUATROFREM v.2.53x
15. apríla 2019 Page 7 from 97
EXAMPLE:
MENU \ DIAGNOSTICS \ Command \
MENU \ DIAGNOSTICS \ Inputs / outputs \ Relay
Converter control signals diagnostics
Output relays status diagnostics
Diagnostic information, which takes a fixed value.
EXAMPLE:
Constant
Diagnostic value of the date or time format.
MENU \ DIAGNOSTICS \
MENU \ DIAGNOSTICS \
2.2 Defining the meaning and type of parameters in part SETTINGS
Possibility of parameter value setting in absolute or relative units.
Name [ID]
Unit
Description
OPS status [856]
Indicates the status of the OPS switch block.
Reset
RESET signal of the OPS is active.
Detection
Autodetection of the overload limits is running.
Overload
Overload occurred. Operation in the positive direction (up) is blocked.
Tipping
Too many forbidden tipping control commands.
Settling
Drive operates in static mode.
Dynamics
Drive operates in dynamic mode.
MENU \ DIAGNOSTICS \ Functions \ Lifting functions\
The basic diagnostic information about the importance of word
Additional diagnostic information about word bits view, status of
word bits view, respectively meaning of word bits
Individual word bits
description
Parameter type: CONSTANT
Name [ID]
Unit
Description
SW Version [379]
Converter SW version
MENU \ DIAGNOSTICS \ SW and HW version \
Constant description
Parameter type: DATE TIME
Parameter type: THE VALUE

RU , GSE, FOTO CONTROL, QUATROFREM v.2.53x
15. apríla 2019 Page 8 from 97
EXAMPLE:
MENU \ SETTINGS \ MOTOR \
Motor current value setting
Nominal motor voltage value setting
Parameter, that is derived by calculation based on the values of other parameters.
EXAMPLE:
MENU \ SETTINGS \ MOTOR \ SPECIAL PARAMETERS \
Example of the calculated parameter
Name [ID]
Description
Def.
Nom. Current
[151]
Nominal motor current, read from the nameplate or catalog data.
2.80 A
0.01 A ÷ 1000.00 A
This parameter determines the value of permanent motor current for motor
overload protection P[27] Motor overloading.
MENU \ SETTINGS \ MOTOR \
Basic information about the importance of the parameter
Range of the value, that
parameter can take Min ÷ Max
Additional information
about the importance of the
parameter
The default value of the parameter –
The value that is set at factory settings
restoration
Parameter type: CALCULATED PARAMETER
Name [ID]
Description
Def.
Nr of motor poles [1049]
Number of motor poles calculated from the nominal rpms and the motor
frequency.
2 ÷ 1000
MENU \ SETTINGS \ MOTOR \ SPECIAL PARAMETERS \
Additional information about derivation of parameter calculation

RU , GSE, FOTO CONTROL, QUATROFREM v.2.53x
15. apríla 2019 Page 9 from 97
Type of parameter with option to select only one setting option (alternative).
EXAMPLE:
MENU \ SETTINGS \ COMMANDS \ FREQUENCY SETPOINT \
... \ SETTINGS \ FUNCTIONS \ LOGICAL BLOCKS\ LB1 (Fast) \
One setting option selection of selection type parameter examples
Parameter type with a option to select multiple possible value elections, modes, respectively active
bit of parameter.
Parameter type: SELECTION
Name [ID]
Description
Def.
Start source
[194]
Setting the converter start source. The START command generates the desired voltage and frequency
on the U,V,W outputs (or U,V for a single phase load).
BIN1
Control panel
Pressing the green START button on the control panel causes the converter to start. The start is canceled by
pressing the red STOP button.
Permanent
start
The converter starts immediately after the switch on.
BIN1
The converter start after the activation of the 1st binary input.
BIN5
The converter starts after the activation of the 5th binary input.
BIN6
The converter starts after the activation of the 6th binary input.
MODBUS
The converter start is controlled over the serial communication. See the MODBUS serial communication
protocol.
PROFIBUS
The converter start is controlled over the serial communication. See the PROFIBUS serial communication
protocol.
Special
The converter start is controlled by a special preset signal and switching thresholds, see P[987] SPECIAL
START.
MENU \ SETTINGS \ COMMANDS \ START STOP RESET \
Basic information about type of parameter - selection
The name of specific (alternative)
selection of parameter value
Additional information about the meaning
of a specific parameter selection
Parameter type: MULTIPLE SELECTION (MASK)
Name [ID]
Description
Def.
V/f Type [347]
V/f Curve type. Selecting the features of the V/f control method operation.
□ IR compensation
Turns on the stator resistance loss compensation P[973] Compensation of IR
(CIR). Requires correct value of the motor parameters and the stator resistance
P[345] Stator resistance.
□ ST controller
Turns on the starting torque controller P[29] ST Controller (STC) to boost starting
torque.
* When the square is black ■ - the default setting is set
MENU \ SETTINGS \ CONTROL AND REGULATION \ V/f CONTROL \ V/f CURVE \
Basic information about the
parameter type - multiple selection
Names of parameter
value elections (modes)
Additional information about the meaning of
individual parameter elections (modes)

RU , GSE, FOTO CONTROL, QUATROFREM v.2.53x
15. apríla 2019 Page 10 from 97
EXAMPLE:
Example: V/f curve operation mode selection
Command to execute a single action or operation on the converter. It is required to confirm the
command before execution in the confirmation window.
EXAMPLE:
This command resets consumed energy counters
Parameter for dynamic ties and any parameter connection, that becomes a value source for a
given function or for input of this function.
EXAMPLE:
MENU \ SETTINGS \ INPUTS AND OUTPUTS \ ANALOG OUTPUTS \ AO1 \
Selection of the signal that will linearly recalculate the analog output AO1
Parameter type: COMMAND
Name [ID]
Description
Def.
Reset the consumption [897]
This command resets the counters of consumed energy.
MENU \ SETTINGS \ CONVERTER PARAMETERS \ Energy consumption \
Function, description and importance of the
command
Name and command ID
Parameter type: SIGNAL
Name [ID]
Description
Def.
AIN1 Signal [251]
Selection of the signal that will be linearly recalculated according to the
analog input.
[ - ]
MENU \ SETTINGS \ INPUTS AND OUTPUTS \ ANALOG INPUTS \ AIN1 \ SPECIAL SETTING \
Type of signal selection from the diagnostics
Signal name

RU , GSE, FOTO CONTROL, QUATROFREM v.2.53x
15. apríla 2019 Page 11 from 97
Parameter is dynamically set to the value that is inherited from another parameter (usually from the
signal type parameter).
EXAMPLE:
The condition for RELAY switching „R1 switch on [301]“ – If any parameter (e.g. Cooler
temperature [74]) is selected as „R1 Signal [189]“:
MENU \ SETTINGS \ INPUTS AND OUTPUTS \ RELAY
OUTPUTS \ Relay 1 \
MENU \ SETTINGS \ INPUTS AND OUTPUTS \ RELAY
OUTPUTS \ Relay 1 \ SPECIAL SETTING R1 \
Special source of Relay R1 switch setting
Relay R1 switches on when heatsink temperature
exceeds the set level
The condition for RELAY switching „R1 switch on [301]“ –If status word is selected as „R1 Signal
[189]“:
MENU \ SETTINGS \ INPUTS AND OUTPUTS \ RELAY OUTPUTS \ Relay 1 \ SPECIAL SETTING R1 \
Relay R1 switches on at active bite (Failure) of converter status word
Parameter to enter a password to allow access to the specific levels of converter setting
respectively to unlock some of the modes.
The password characters can be {0..9, A..Z}.
EXAMPLE:
Example of password entry
Parameter type: DYNAMIC VALUE (Linked parameter)
Name [ID]
Description
Def.
R1 switch on [301]
Conditions for R1 switch on.
Run |
MENU \ SETTINGS \ INPUTS AND OUTPUTS \ RELAY OUTPUTS \ Relay 1 \ SPECIAL SETTING \
Name and ID of the dynamic parameter
Default value of the dynamic value parameter
Parameter type: PASSWORD
Name [ID]
Description
Def.
Password
[548]
Setting the user password for access to the device settings. Password
needs to be entered when entering the converter settings.
0 *
0 * ÷ 0 *
Protects the converter settings against reconfiguration by unauthorized persons.
MENU \ SETTINGS \ CONVERTER PARAMETERS \
Basic information about the importance of the parameter

RU , GSE, FOTO CONTROL, QUATROFREM v.2.53x
15. apríla 2019 Page 12 from 97
UNIPANEL –PASSWORD SETTING
Set the required password character:
Cursor position change:
After setting the password, press ENTER to confirm.
2.3 Type of parameters defining in the part SAVE / RESTORE
Parameter of root parameters directory choice defining.
EXAMPLE:
INPUTS AND OUTPUTS root directory selection for the transfer of parameters from set 1 to set 3
Parameter type: PATH
Name [ID]
Description
Def.
Directory [ - ]
The choice of which part of the parameters will be restored. If nothing
is selected, all will be restored.
INPUTS AND
OUTPUTS
0 * ÷ 0 *
MENU \ SAVE / RESTORE \ Parameters backup \ Parameter transfer \
Basic information about the importance of the parameter
The selected path in the tree hierarchy

RU , GSE, FOTO CONTROL, QUATROFREM v.2.53x
15. apríla 2019 Page 13 from 97
3 Range of parameters by product type
3.1 Voltages
Undervolt.[V]
Overvolt. [V]
Grid [V]
Vacmax[V]
Vdcmax [V]
Fotocontrol
230 012, 290 125
420
850
290
374,9
865
Fotocontrol 400
011
380
730
400
480,0
740
Fotocontrol 400
012.5, 013.5 033
040
400
850
400
518,5
880
Fotocontrol 400
020
400
800
400
551
880
Fotocontrol 400
037
275
790
400
518,5
800
GSE 400 010
420
850
400
518,5
880
MVE 400
005, 012, 030
380
730
400
480,0
740
MVE 400
011, 090
360
730
400
518,5
740
QUATROFREM
400 011
380
730
400
518,5
740
QUATROFREM
400 110
380
730
400
480,0
740
3.2 Temperatures
Warning line CB
temperature
[°C]
Error line CB
temperature
[°C]
Warning line
cooler
temperature
[°C]
Error line
cooler
temperature
[°C]
Fotocontrol
230 012, 290 125
40
60
110
125
Fotocontrol 400
011
40
55
75
90
Fotocontrol 400
012.5, 013.5 020
033 037
40
45
75
90
Fotocontrol 400
040
40
50
75
90
GSE 400 010
40
50
75
90
MVE 400
005
40
55
80
90
MVE 400
011
40
45
75
90
MVE 400
012, 030
40
45
75
109
MVE 400
090
40
70
110
125
QUATROFREM
400 011, 400 110
40
45
75
90

RU , GSE, FOTO CONTROL, QUATROFREM v.2.53x
15. apríla 2019 Page 14 from 97
3.3 Currents
Imax [A]
Over. Ac
Nr. Of strings
Fotocontrol 230 012
500,0
1,1
32
Fotocontrol 290 125
500,0
1,1
32
Fotocontrol 400 011
48,0
1,1
4
Fotocontrol 400 012.5
56,0
1,1
4
Fotocontrol 400 013.5
52,0
1,1
4
Fotocontrol 400 020
80,0
1,1
4
Fotocontrol 400 033
144,0
1,1
4
Fotocontrol 400 037
214,0
1,1
1
Fotocontrol 400 040
160,0
1,2
32
GSE 400 010
160,0
1,2
32
MVE 400 005
16,0
1,5
-
MVE 400 011
32,0
1,5
-
MVE 400 012
48,0
1,1
-
MVE 400 030
94,0
1,1
-
MVE 400 090
290,0
1,186
-
QUATROFREM 400 011
36,2
1,5
-
QUATROFREM 400 110
152
1,1
-

RU , GSE, FOTO CONTROL, QUATROFREM v.2.53x
15. apríla 2019 Page 15 from 97
4 DIAGNOSTICS
Group of parameters number [2]
Diagnostic information (quantities and states).
4.1 Fotocontrol / PGE
Group of parameters number [744]
Quantities relevant to the control of PV power plant or peak energy generator (PEG).
MENU \ DIAGNOSTICS \ FOTOCONTROL / PGE
Name [ID]
Description
Dim.
Sum DC
currents
[634]
Sum of DC currents flowing from all PV or battery strings. For FOTO CONTROL inverter
which do not have the extension module for DC current measurement this value is
calculated as a sum of all DC strings. The check of sum strings can be turned on by
String check [747] (page 36).
A
Voltage per
cell [477]
The voltage of single photovoltaic (PV) panel or one cell of battery. It is calculated as the
quotient of the DC link voltage and the parameter Number of panels/cells [507] (page
35).
V
DC input
power [632]
Instantaneous input power (power of solar panels). It is calculated as a product of DC
Voltage [46] (page 19) and Sum DC currents [634] (page 15).
W
Inv.
efficiency
[859]
Inverter efficiency calculated from the ratio of Active grid power [70] (page 17) and DC
input power [632] (page 15) in percent. When the power is lower than 10% of the Max.
gen. power [808] (page 45) , this value is not calculated, but set to 99.9%. Permament
decrease of the efficiency can be caused by malfunction of inverter components or
incorrect configuration. The efficiency can be guarded by the optional fault set by [864]
(page 36).
%
String
unbalance
[928]
Determines the percentage error of string currents. This unbalance is calculated as the
difference between the lowest and highest value of the currents. Short-term unbalance
may arise due to uneven lighting of PV panels in cloudy weather. Long-lasting unbalance
may be caused by uneven number of PV panels installed in the strings, permanent
damage or by partial shielding of the panels. This test can be turned on/off in String
check [747] (page 36).
%
PEG BAT
SOC [1166]
PEG battery state of charge in percents of PEG Nom. Ah [1164] (page 35).
%
4.1.1 String measurement
Group of parameters number [735]
DC currents of individual PV strings. The number of displayed strings is determined by the parameter Nr.
paral. strings [701] (page 35).
MENU \ DIAGNOSTICS \ FOTOCONTROL / PGE \ STRING MEASUREMENT
Name [ID]
Description
Dim.
String1 [703]
Current flowing from the 1st PV string.
A
String2 [704]
Current flowing from the 2nd PV string.
A
String3 [705]
Current flowing from the 3rd PV string.
A
String4 [706]
Current flowing from the 4th PV string.
A
String5 [707]
Current flowing from the 5th PV string.
A
String6 [708]
Current flowing from the 6th PV string.
A
String7 [709]
Current flowing from the 7th PV string.
A
String8 [710]
Current flowing from the 8th PV string.
A
String9 [711]
Current flowing from the 9th PV string.
A
String10 [712]
Current flowing from the 10th PV string.
A
String11 [713]
Current flowing from the 11th PV string.
A
String12 [714]
Current flowing from the 12th PV string.
A
String13 [715]
Current flowing from the 13th PV string.
A

RU , GSE, FOTO CONTROL, QUATROFREM v.2.53x
15. apríla 2019 Page 16 from 97
Name [ID]
Description
Dim.
String14 [716]
Current flowing from the 14th PV string.
A
String15 [717]
Current flowing from the 15th PV string.
A
String16 [718]
Current flowing from the 16th PV string.
A
String17 [719]
Current flowing from the 17th PV string.
A
String18 [720]
Current flowing from the 18th PV string.
A
String19 [721]
Current flowing from the 19th PV string.
A
String20 [722]
Current flowing from the 20th PV string.
A
String21 [723]
Current flowing from the 21st PV string.
A
String22 [724]
Current flowing from the 22nd PV string.
A
String23 [725]
Current flowing from the 23rd PV string.
A
String24 [726]
Current flowing from the 24th PV string.
A
String25 [727]
Current flowing from the 25th PV string.
A
String26 [728]
Current flowing from the 26th PV string.
A
String27 [729]
Current flowing from the 27th PV string.
A
String28 [730]
Current flowing from the 28th PV string.
A
String29 [731]
Current flowing from the 29th PV string.
A
String30 [732]
Current flowing from the 30th PV string.
A
String31 [733]
Current flowing from the 31st PV string.
A
String32 [734]
Current flowing from the 32nd PV string.
A
4.1.2 Energy of strings
Group of parameters number [1066]
The energy supplied by the individual strings for today. Just as many strings as there are set in parameter
Nr. paral. strings [701] (page 35) are displayed.
MENU \ DIAGNOSTICS \ FOTOCONTROL / PGE \ ENERGY OF STRINGS
Name [ID]
Description
Dim.
String1 [1071]
Energy supplied by the photovoltaic string today.
kWh
String2 [1072]
Energy supplied by the photovoltaic string today.
kWh
String3 [1073]
Energy supplied by the photovoltaic string today.
kWh
String4 [1074]
Energy supplied by the photovoltaic string today.
kWh
String5 [1075]
Energy supplied by the photovoltaic string today.
kWh
String6 [1076]
Energy supplied by the photovoltaic string today.
kWh
String7 [1077]
Energy supplied by the photovoltaic string today.
kWh
String8 [1078]
Energy supplied by the photovoltaic string today.
kWh
String9 [1079]
Energy supplied by the photovoltaic string today.
kWh
String10 [1080]
Energy supplied by the photovoltaic string today.
kWh
String11 [1081]
Energy supplied by the photovoltaic string today.
kWh
String12 [1082]
Energy supplied by the photovoltaic string today.
kWh
String13 [1083]
Energy supplied by the photovoltaic string today.
kWh
String14 [1084]
Energy supplied by the photovoltaic string today.
kWh
String15 [1085]
Energy supplied by the photovoltaic string today.
kWh
String16 [1086]
Energy supplied by the photovoltaic string today.
kWh
String17 [1087]
Energy supplied by the photovoltaic string today.
kWh
String18 [1088]
Energy supplied by the photovoltaic string today.
kWh
String19 [1089]
Energy supplied by the photovoltaic string today.
kWh
String20 [1090]
Energy supplied by the photovoltaic string today.
kWh
String21 [1091]
Energy supplied by the photovoltaic string today.
kWh
String22 [1092]
Energy supplied by the photovoltaic string today.
kWh
String23 [1093]
Energy supplied by the photovoltaic string today.
kWh
String24 [1094]
Energy supplied by the photovoltaic string today.
kWh
String25 [1095]
Energy supplied by the photovoltaic string today.
kWh

RU , GSE, FOTO CONTROL, QUATROFREM v.2.53x
15. apríla 2019 Page 17 from 97
Name [ID]
Description
Dim.
String26 [1096]
Energy supplied by the photovoltaic string today.
kWh
String27 [1097]
Energy supplied by the photovoltaic string today.
kWh
String28 [1098]
Energy supplied by the photovoltaic string today.
kWh
String29 [1099]
Energy supplied by the photovoltaic string today.
kWh
String30 [1100]
Energy supplied by the photovoltaic string today.
kWh
String31 [1101]
Energy supplied by the photovoltaic string today.
kWh
String32 [1102]
Energy supplied by the photovoltaic string today.
kWh
4.2 Power and energy
Group of parameters number [511]
Quantities for evaluation the power and energy consumed or produced. These quantities do not replace
official electricity meters, but they offer an insight and check of produced and consumed energy by the
device.
MENU \ DIAGNOSTICS \ POWER AND ENERGY
Name [ID]
Description
Dim.
Inst. consumption
[592]
Instantaneous value of consumed power (from the grid to the inverter).
W
Inst. production
[593]
Instantaneous value of produced power (from the inverter to the grid).
W
Active grid power
[70]
Instantaneous active power transfered to L1,L2,L3 phases of the grid. Positive
values represent energy consumption, negative represent energy production.
W
Reactive grid
power [1196]
Instantaneous reactive power of the inverter on the Grid side of LCL filter. Positive
values represent the capacitive nature, negative values represent the inductive
nature of power.
VAr
Active inv. power
[66]
Active power of the inverter measured on IGBT elements. Positive values
represent energy consumption, negative represent energy production.
W
Reactive inv.
power [222]
Instantaneous reactive power of the inverter on the inverter side of LCL filter.
Positive values represent the capacitive nature, negative values represent the
inductive nature of power.
VAr
4.2.1 Production stats
Group of parameters number [640]
Overview of daily, weekly, monthly and annual production of energy.
MENU \ DIAGNOSTICS \ POWER AND ENERGY \ PRODUCTION STATS
Name [ID]
Description
Dim.
Today [594]
Produced energy for present day.
kWh
Yesterday [595]
Produced energy for yesterday.
kWh
2cdays ago [596]
Produced energy for the day before yesterday.
kWh
This week [597]
Produced energy for this week.
kWh
Last week [598]
Produced energy for the last week.
kWh
This month [599]
Produced energy for this month.
kWh
Last month [600]
Produced energy for the last month.
kWh
This year [601]
Produced energy for this year.
kWh
Last year [602]
Produced energy for the last year.
kWh
Total [677]
Total produced energy since the last reset.
kWh
Last reset [678]
Date of last reset of produced energy counters.
4.2.2 Energy meter
Group of parameters number [567]
Information about consumed and produced energy.
MENU \ DIAGNOSTICS \ POWER AND ENERGY \ ENERGY METER

RU , GSE, FOTO CONTROL, QUATROFREM v.2.53x
15. apríla 2019 Page 18 from 97
Name [ID]
Description
Dim.
Production kWh [259]
Produced energy (kWh) counter. This counter can be preset or reset by
[414] (page 38).
kWh
Production MWh [260]
Produced energy (MWh) counter. This counter can be preset or reset by
[414] (page 38).
MWh
kWh Consumption [257]
Consumed energy (kWh) counter. This counter can be preset or reset by
[414] (page 38).
kWh
MWh Consumption
[258]
Consumed energy (MWh) counter. This counter can be preset or reset by
[414] (page 38).
MWh
Production today [1067]
Only produced energy for present day.
kWh
Consumption today
[1068]
Only consuption energy for present day.
kWh
4.3 Command
Group of parameters number [737]
Quantities affecting the inverter control, inputs and outputs.
MENU \ DIAGNOSTICS \ COMMAND
Name [ID]
Description
Dim.
Panel setpoint [161]
Setpoint value from the panel, entered in the monitor window.
DC voltage reference
[220]
DC voltage reference, its source is set by parameter DC voltage reference [293]
(page 41).
V
AC voltage ref. [875]
Value of AC voltage reference, which source is selected by AC voltage ref. [873]
(page 41).
V
Phi angle ref. [356]
Phase difference reference between voltage and current. Positive value
represents the capacitive nature and negative value the inductive nature of
generated current.
°
Grid power ref. [883]
Active grid-side power reference, when the "active power control" is set by
Control strategy [878] (page 44).
W
Reactive power ref.
[975]
Reactive power reference. Reactive power control is possible only for PF
CORRECTOR device type.
VAr
Discrete setpoint
[574]
Discrete setpoint value [559] (page 42).
Control word [77]
Control signals of the inverter.
□ START
Control command for the motor operation mode (1 - starts the inverter).
□ Bit 1
Reserved
□ RESET PWM
Control command for the immediate voltage cut-off on the inverter output (active -
turns off PWM).
□ FAULT ACK.
Command for fault acknowledgement.
□ ERR_MASTER
Master fault
□ COMPENSATION
DT
Turn on the dead time compensation mode
□ Bit 6
Reserved
□ UNF BOARD TYPE
0 - UNF 400, 1 - UNF 230/400 M.
ON / OFF time [686]
Represents the time in AUTO OFF mode to the next automatic start or stop of
the inverter.
Random time [807]
Value of random time according to the parameter Random time [806] (page 40).
s
4.4 Control
Group of parameters number [738]
Quantities affecting the inverter control, values of important control and operating quantities.
MENU \ DIAGNOSTICS \ CONTROL
Name [ID]
Description
Dim.
V ramp ref.
Output of the AC or DC voltage reference ramp according to the chosen mode of
V

RU , GSE, FOTO CONTROL, QUATROFREM v.2.53x
15. apríla 2019 Page 19 from 97
Name [ID]
Description
Dim.
[361]
control. When off-grid operation is present, AC voltage is controlled.
DC Voltage
[46]
Voltage of the DC bus. After START command this voltage is continuously increased
up to the value of DC voltage reference [293] (page 41) and this voltage is then
maintained by voltage controller.
V
AC voltage
[221]
RMS value of phase-to-phase voltage of supply grid (terminals L1,L2,L3).
V
Grid current
[313]
RMS value of the grid-side current.
It is calculated in the mathematical model of LCL filter from the values Current INV
[515] (page 19) and AC voltage [221] (page 19).
A
Current INV
[515]
RMS value of the inverter current (current flowing through the power elements of the
inverter).
A
Modulation
index [750]
PWM duty cycle of the switching power elements.
%
INV voltage
[1194]
RMS value of phase-to-phase voltage on IGBT tranzistors - on inverter terminals.
V
Grid frequency
[47]
Grid frequency. Excessive fluctuations of this frequency can mean an instability in the
control loop of Phase Locked Loop ( Bandwidth w0f [301] (page 47), Damping bf [302]
(page 47)).
Hz
Cos(phi) ref.
[106]
Power factor cos(phi) reference on the grid-side. Positive value represents the
capacitive nature and negative value the inductive nature of generated current. It is
calculated from Phi angle ref. [356] (page 18).
Cos(Phi) grid-
side [530]
Power factor on the grid side.
Cos(Phi) inv.
[312]
Power factor on the inverter side.
Power
restriction
[809]
Coefficient of power restriction from external effects.
At maximal allowed power or current the value 1 is acquired and when power
restriction is in effect, this value is decreased to 0. Individual conditions of the power
restriction can be selected in Power restriction (PR) [700] (page 45).
4.4.1 Symmetry of INV currents
Group of parameters number [855]
Quantities which can be used for symmetry evaluation of inverter currents.
MENU \ DIAGNOSTICS \ CONTROL \ SYMMETRY OF INV CURRENTS
Name [ID]
Description
Dim.
Curr. IGBT L1
[856]
RMS value of the current flowing through the IGBT module in L1 phase.
It is used for symmetry evaluation of inverter currents.
A
Curr. IGBT L2
[857]
RMS value of the current flowing through the IGBT module in L2 phase.
It is used for symmetry evaluation of inverter currents.
A
Curr. IGBT L3
[858]
RMS value of the current flowing through the IGBT module in L3 phase.
It is used for symmetry evaluation of inverter currents.
A
I-AC
asymmetry
[868]
Maximum permissible difference between any phase RMS values of the output currents.
High current asymmetry can be caused by unbalance of input voltages or faulty current
sensors. When the asymmetry of AC currents is high, sustained oscillations in controller
quantities or instability of control may occur. Asymmetry check can be turned on/off in
[860] (page 76).
A
4.4.2 I Harmonics
Group of parameters number [223]
Values of harmonics of inverter current.
High harmonic currents check can be turned on in [191] (page 75).
MENU \ DIAGNOSTICS \ CONTROL \ I HARMONICS
Name [ID]
Description
Dim.
THD current [532]
Total harmonic distortion of grid current measured in the phase corresponding to
the parameter Measured curr. phase [225] (page 20).
%

RU , GSE, FOTO CONTROL, QUATROFREM v.2.53x
15. apríla 2019 Page 20 from 97
Name [ID]
Description
Dim.
Measured curr.
phase [225]
Displays the number of input phase, which is used for THD and harmonic currents
calculation. Phases are changed in 60 seconds intervals.
I-2nd harmonic
[226]
2nd current harmonic.
%
I-3rd harmonic
[227]
3rd current harmonic.
%
I-4th harmonic
[228]
4th current harmonic.
%
I-5th harmonic
[229]
5th current harmonic.
%
I-6th harmonic
[230]
6th current harmonic.
%
I-7th harmonic
[231]
7th current harmonic.
%
I-8th (9th) harm.
[232]
8th (9th for FOTO CONTROL) current harmonic.
%
I-9th (11th) harm.
[233]
9th (11th for FOTO CONTROL) current harmonic.
%
I-11th (15th) harm.
[234]
11th (15th for FOTO CONTROL) current harmonic.
%
I-13th (19th) harm.
[235]
13th (19th for FOTO CONTROL) current harmonic.
%
I-15th (27th) harm.
[236]
15th (21st for FOTO CONTROL) current harmonic.
%
I-17th (22nd) harm.
[237]
17th (22nd for FOTO CONTROL) current harmonic.
%
I-19th (23rd) harm.
[238]
19th (23rd for FOTO CONTROL) current harmonic.
%
I-21st (24th) harm.
[239]
21th (24th for FOTO CONTROL) current harmonic.
%
4.4.3 V harmonics
Group of parameters number [240]
Values of grid voltage harmonics.
High harmonic voltages check can be turned on in [191] (page 75).
MENU \ DIAGNOSTICS \ CONTROL \ V HARMONICS
Name [ID]
Description
Dim.
THD voltage [533]
Total harmonic distortion of grid voltage measured in the phase corresponding to
the parameter Measured curr. phase [225] (page 20).
%
Meas. voltage
phase [241]
Displays the number of input phase, which is used for THD and harmonic voltages
calculation. Phases are changed in 60 seconds intervals.
V-2nd harmonic
[242]
2nd voltage harmonic.
%
V-3rd harmonic
[243]
3rd current harmonic.
%
V-4th harmonic
[244]
4th current harmonic.
%
V-5th harmonic
[245]
5th current harmonic.
%
V-6th harmonic
[246]
6 current harmonic.
%
V-7th harmonic
[247]
7th current harmonic.
%
V-8th (9th) harm.
[248]
8th (9th for FOTO CONTROL) voltage harmonic.
%
