1 Introduction
Thank you for purchasing the Xantrex 500 Inverter. The
500 Inverter is part of a family of advanced, high-
performance power inverters from Xantrex, the leader in the
field of high-frequency inverter design.
Connected directly to a 12 volt battery, the 500 Inverter
efficiently and reliably powers a wide variety of household
AC products, such as TVs and VCRs, laptop computers,
camcorder and cell phone chargers, compact fluorescent
lights, soldering irons, and small power tools.
The 500 Inverter uses reliable solid state power electronics
for years of safe, trouble-free operation and includes
automatic safety monitoring circuitry to protect it from
inadvertent overload conditions.
Read this guide before connecting or using the 500 Inverter,
and save it for future reference. The main topics in the guide
are:
• Safety information (page 2)
• 500 Inverter features (page 5)
• Instructions for connecting the inverter (page 9)
• Operating guidelines (page 16)
• Troubleshooting information (page 20)
• Warranty and service information (page 23)
• Specifications (page 27)

2
2 Important Safety Information
If the 500 Inverter is connected or used incorrectly,
hazardous conditions may be created. Read and save this
safety information, and pay special attention to all Caution
and Warning statements in the guide and on the inverter
itself. Warnings and Cautions are indicated by this symbol:
•Warning statements identify conditions that could
result in personal injury or loss of life.
•Caution statements identify conditions or practices that
could result in damage to the 500 Inverter or other
equipment.
Warnings and Cautions
Warning! Shock hazard.
The 500 Inverter generates the same potentially
lethal AC power as a household wall outlet. Do not
insert foreign objects in the inverter’s AC outlet or
any other openings in the inverter. Do not open the
inverter. Have a qualified individual complete any
service work.
Warning! Shock hazard.
Do not expose the 500 Inverter to water, rain,
snow, or spray.

3
Warning! Risk of fire or explosion.
The 500 Inverter contains components that tend to
produce arcs or sparks. To prevent fire or
explosion, do not install the inverter in
compartments containing batteries or flammable
materials or in locations that require ignition-
protected equipment.
Warning! Fire hazard.
To reduce the risk of fire, do not cover or obstruct
the ventilation openings. Do not install the
500 Inverter in a zero-clearance compartment.
Overheating may result.
Warning! Shock and fire hazard.
During installation route all cable/wiring away
from sharp edges and hot surfaces of the engine
compartment or vehicle.
Caution! Risk of damage to equipment.
The 500 Inverter is designed to be directly
connected to standard electrical and electronic
equipment in the manner described in this guide.
Do not connect it to household or RV AC
distribution wiring. Do not connect it to any AC
load circuit in which the neutral conductor is
connected to ground (earth) or to the negative of
the DC (battery) source.

4
Caution! Risk of damage to the 500 Inverter.
Reverse battery polarity (negative connected to
positive; positive connected to negative) will
damage the 500 Inverter, and it will require
servicing. Damage caused by reverse polarity is
not covered by your warranty.
Caution! Risk of damage to rechargeable
appliances.
The output of the 500 Inverter is non-sinusoidal.
Certain battery chargers can be damaged if they are
connected to the 500 Inverter. Two particular types
of equipment are prone to this problem:
• Small battery-operated appliances such as
rechargeable flashlights, shavers, and night
lights that can be plugged directly into an AC
receptacle to recharge.
• Certain battery chargers for battery packs used
in hand power tools. These chargers have a
warning label stating that dangerous voltages
are present at the charger battery terminals.
Do not use the 500 Inverter with the type of
appliances just described.
Caution! Risk of damage due to high
temperatures.
Do not use the 500 Inverter in temperatures over
40° C (105° F). Overheating may result.

5
3 Xantrex 500 Inverter Features
This section describes the main features of the 500 Inverter.
Figure 1 shows the inverter’s AC panel.
Figure 1 AC Panel on the 500 Inverter (European AC Outlet)
➀ AC Outlet An AC outlet is located on one end of the
inverter. It allows you to plug in a 230 volt AC product with
a power consumption of 500 watts or less when the inverter
is connected to a 12 volt battery.
The AC outlet on your inverter may be different from the
one shown here. For all available outlets, see Figure 2,
Figure 3, and Figure 4, on page 7.
➁ On/Standby Switch The two positions on the On/Standby
switch are: = Standby and = On.
①②③④
➄

6
When the inverter is connected to a DC power source and
the On/Standby switch is on, AC power is available at the
outlet.
➂ Power Light The green PWR light is on all the time when
the On/Standby switch is on.
➃ Fault Light The red light indicates that the
inverter has shut down because of low or high battery
voltage, AC overload, or excessively high temperatures.
➄ Mounting Flanges Mounting flanges on the AC and DC
ends allow you to mount the inverter permanently. For
additional information, see “Fastening the Inverter to a
Mounting Surface” on page 8.
Audible Alarm An audible alarm warns you of a high
temperature shutdown or of an impending low voltage
shutdown.
Fan The fan (see Figure 5) turns on when an AC load of 100
watts or higher is plugged in.

7
AC Outlets
Depending on your geographic location, your 500 Inverter
will have one of the following AC outlets.
Figure 2 European AC
Outlet Figure 3 British AC
Outlet
Figure 4 Australian and
New Zealand AC Outlet

8
4 Connecting the 500 Inverter
This section explains how to connect the 500 Inverter.
Choosing a Location
For the best performance, choose a location that is:
•Dry Do not expose the inverter to water drip or spray.
•Cool Operate the inverter in ambient temperatures
between 0° C and 40° C (32° F and 100° F). Keep it
away from heating vents and direct sunlight.
•Well ventilated For proper cooling, allow at least 5 cm
(2 in.) of clearance around the inverter.
•Clean and free of dust and dirt Choose a location
that is free of any debris that could get into the inverter.
•Protected from battery gases Do not mount the
inverter where it will be exposed to battery gases. These
are very corrosive and will damage the inverter.
Fastening the Inverter to a Mounting Surface
For temporary or portable use, place the inverter on a flat
surface like a table or the floor of your vehicle.
For a permanent installation, use four screws to attach the
inverter’s mounting flanges to an appropriate surface.
Note: Local and national electrical codes that apply to your
installation may require that you permanently mount the
inverter if you make permanent electrical connections and
may disallow permanent mounting if you make a temporary
electrical connection.

9
Connecting the 500 Inverter to DC Power
Warning! Corrosive materials and energy
hazard.
To reduce the risk of irritation and burns, wear
protective eyewear and clothing when you work
with batteries.
Take special care to ensure that metal tools or
personal objects like rings or watches do not
contact the battery terminals.
Caution! Risk of damage to the 500 Inverter.
The 500 Inverter must only be operated with a
nominal 12 volt battery. The inverter will not
operate with a lower voltage battery. A higher
voltage battery will damage the inverter.
Caution! Damage to the 500 Inverter.
Reversing the positive and negative battery cables
will damage the inverter and will void your
warranty.
When you connect the inverter to the battery,
double check the connections. The red wire must
be connected to the red (+) terminal on the inverter
and the positive (+) terminal on the battery. The
black wire must be connected to the black (–)
terminal on the inverter and the negative (–)
terminal on the battery.

10
You can make a temporary or a permanent connection
between the inverter and the 12 volt DC power source.
• Use the battery clip wire assembly to make a temporary
connection (page 11).
• Hardwire the inverter to the battery to make a
permanent connection (page 13).
Refer to Figure 5 and Figure 6 when you connect the
inverter.
Figure 5 DC Panel on the 500 Inverter
① Fan ② Red (positive +) terminal ③ Black (negative –
) terminal
①②
③

11
Using the Battery Clip Wire Assembly
Warning! Corrosive materials and energy
hazard.
To reduce the risk of irritation and burns, wear
protective eyewear and clothing when you work
with batteries.
Take special care to ensure that metal tools or
personal objects like rings or watches do not contact
the battery terminals.
Caution! Risk of damage to the 500 Inverter.
Reversing the positive and negative battery cables
will damage the inverter and void your warranty.
When you connect the inverter to the battery,
double check the connections. The red wire must be
connected to the red (+) terminal on the inverter and
the positive (+) terminal on the battery. The black
wire must be connected to the black (–) terminal on
the inverter and the negative (–) terminal on the
battery.
Caution! Fire hazard.
The wires in most 12 volt sockets or power outlets
are not large enough for loads greater than 150
watts: they will overheat and present a fire hazard.
For loads greater than 150 watts, connect the
inverter directly to the battery and use
appropriately sized wires like those in the battery
clip wire assembly provided with the inverter.

12
To connect the inverter to a 12 volt battery using the battery
clip wire assembly:
1. Remove the nuts from the DC terminals on the inverter.
2. Place the red ring connector on the red (positive +) DC
terminal, and then screw the red nut on until it is snug.
Do not over tighten.
3. Attach the red clip to the red (positive +) battery
terminal.
4. Attach the black clip to the black (negative –) battery
terminal.
5. Place the black ring connector on the black (negative –)
DC terminal, and then screw the black nut on until it is
snug. Do not over tighten.
Note: A spark may occur when you make this
connection. This is normal.
6. Check that both clips are securely connected to the
battery terminals. A loose connection will cause
excessive voltage drop and may cause the cables to
overheat. This could result in equipment damage or fire.
7. Turn on the On/Standby switch. The green PWR light
comes on, and AC power is available at the outlet.

13
Hardwiring the Inverter to the Battery
A hardwired installation is illustrated in Figure 6.
Figure 6 Hardwiring the 500 Inverter to a 12 Volt Battery
To hardwire the inverter to a 12 volt battery:
1. Cut the clips off the cable clip wire assembly.
Warning! Shock and fire hazard.
Use a qualified installer to perform a hardwired
installation.
➂②
①
④
➄
–
+
① 500 Inverter ②8.4mm2(8 AWG) red wire from the
positive inverter terminal to the positive battery terminal (via
the fuse and switch) ➂80 amp automotive fuse ④12 volt,
80 amp disconnect switch ➄12 volt battery 8.4mm2
(8 AWG) black wire from the negative inverter terminal to
the negative battery terminal.

14
2. Using 8.4mm2(8 AWG) wire or heavier, extend the
power cord if you need to, to a maximum total length of
2 meters (6.5 feet) including the existing 500 Inverter
power cord length. Solder all connections and make
sure they are properly insulated by using electrical tape
or heat shrinkable tubing.
3. Install an 80 amp automotive fuse and a switch rated at
80 amps in the positive (red) wire, close to the end that
will attach to the battery. See Figure 6. The switch lets
you disconnect the DC power if you need to replace the
in-line fuse. Solder and insulate the connections as
detailed in Step 2 above.
4. Turn off the in-line switch.
5. Solder or crimp heavy-duty terminals to the battery end
of the positive and negative wires. Use terminals that
mate properly with the battery terminals or existing
battery cable clamps.
Warning! Damage to the 500 Inverter.
Reversing the positive and negative battery
cables will damage the inverter and will void
your warranty.
Before connecting the inverter to the battery,
double check the connections: the red wire must
be connected to the red terminal on the inverter
and the positive (+) terminal on the battery; the
black wire must be connected to the black
terminal on the inverter and the negative (–)
terminal on the battery.

15
6. Remove the nuts from the DC terminals on the inverter.
7. Place the red ring connector on the red (positive +) DC
terminal on the inverter, and then screw the red nut on
