Voxx Electronics VOXX DEI DS3+ User manual

933.TL11
v1.16.198.12
2008 Toyota FJ Cruiser
THTON10 Compatible
(Sold Separately)
Functions compatible with the 2008 Toyota FJ Cruiser
*Telematics features: The telematics features listed below (with an asterisk) ONLY apply when using SmartStart Pro.
* Odometer
Accessory Activation
Arm Factory Security
Disarm Factory Security
Door Lock Control
Door Unlock
DS4+/DS3+/VSM3 Only
Entry Monitoring ALL Door Pins
Entry Monitoring Hood Pin
Entry Monitoring Trunk/Hatch Pin
Fuel level/EV battery level
Ignition Activation
Immobilizer Bypass-Data No Key Req'd
Parking Lights Control
Remote Start Takeover
SmartStart
Start (Crank) Activation
Tach / RPM Output
Trunk / Hatch Release

Introduction 3
Pre-installation and application warnings 4
Installation 5
Wiring diagram with T-Harness (THTON10)
5
Wiring diagram 6
Locating components in the vehicle 7
Vehicle connections 8
Module programming 11
(For security-only programming, see next section.) 11
Module programming for security-only installations 12
Pairing remotes 13
Connecting the module 13
8556T Temperature Sensor 13
8504D Combo Sensor 13
RF Systems 13
When used in conjunction with SmartStart 14
D2D port configuration 14
Manual transmission 15
LED diagnostics and troubleshooting 16
Soft reset 18
Hard reset 18
Tach learning procedure (not needed with Virtual Tach) 19
Initializing Virtual Tach (not needed with hardwired or data tach applications) 19
Limited lifetime consumer warranty 20
Quick reference guide 21
Contents

3933.TL11 1.16.198.12 2008 Toyota FJ Cruiser
©2023 Directed. All rights
Introduction
This guide provides information on the installation of the DS3/DS3+ and DS4/DS4+ modules as a digital solution. Using these modules in a
digital configuration requires the module to be flashed with vehicle-specific firmware. Refer to our website (www.directechs.com) and click
on the DIRECTLINK text in the header for additional information.
DS3/DS3+ and DS4/DS4+ modules provide an all-in-one solution for most modern vehicles, and include remote start, keyless entry, security,
and immobilizer bypass capabilities. T-harnesses may also be used in many applications for easy installation.
The following methods are available to configure modules:
• Web: www.directechs.com (DS3/DS3+ and DS4/DS4+)
• Desktop application: Directlink DT (DS3/DS3+ and DS4/DS4+)
• Mobile device: Directlink App (DS4/DS4+ only)
When flashing via Directlink DT (desktop app) or via the Web, an XKloader2 will be required.
To configure via Web or DirectLink DT (desktop app):
1. Disconnect the main module from any (+) 12V power source.
2. Connect the module to your computer using the XKLoader2.
3. Follow the steps in the pop-up window that will be displayed when the module is detected.
Notes:
•Flashing via web is only possible using Internet Explorer on Windows 8, 8.1, and 10.
•This method is not compatible with any other browser (Edge, Chrome, Firefox, etc.).
•When using Windows 11 or newer, Directlink DT is mandatory.
The DS4/DS4+ module is designed to be configured using the DirectLink application through mobile devices.
To download the DirectLink mobile application, visit the Google Play or Apple store. They can also be
configured via Web and DirectLink DT. The DS4/DS4+ features are built in Bluetooth® 4.0, allowing you to
configure and control your system. The DS3/DS3+ module is not equipped with Bluetooth®, therefore is not
compatible with the DirectLink app for mobile devices.
To configure via DirectLink mobile app (Android/iOS):
1. Follow and complete the wiring diagram(s) related to your installation through the app.
2. When installation is complete, select Configure DS4/DS4+.
3. Follow the on-screen instructions.
FLASH REQUIRED!
FLASH REQUIRED!
4 White

4933.TL11 1.16.198.12 2008 Toyota FJ Cruiser
©2023 Directed. All rights
Pre-installation and application warnings
START HERE This section highlights important information for this specific firmware and will assist in pricing accordingly, as
well as bringing awareness to any operational or vehicle limitations.
Compatibilities and Requirements
T-Harness
compatible THTON10 Keys required for
programming 1Keys required for operation 0
Vehicle Takeover Refer to the Quick Reference Guide section for more details.
Firmware notes
CAN/IMMO wires: This firmware requires either CAN or IMMO connections. An analog firmware is recommended if CAN
connections are not used and the vehicle does not have a transponder. This installation guide can be used for wire and connection
details.
DS4+ module: A DS4+ module is required for this installation, as the Relay harness (H2), 10-pin white connector is used.
T-Harness THTON10 notes:
•All T-Harness wires not listed in the diagram are not required for the installation.
•The OBDII Diagnostic Connector features will remain the same even when the T-Harness is installed.
•The optional Plug & Play T-Harness is sold separately
Unless specified otherwise, all connectors are displayed from the wire side, with the exception of the OBDII diagnostic connector.
Fuses: It is important to check that the fuses are positioned correctly in the module. Proper fuse positioning is displayed on each wiring
diagram.
Refer to the "Vehicle connections" following the installation diagram.
Encryption types
Some Toyota 2010+ models have different encryption types. See the markings on your key blade.
•A dot "." means the vehicle is compatible.
•A letter "G" or "H" indicates the vehicle is not compatible with this firmware.
Note: some replacement keys may not have any markings on the key.
For vehicles with H-stamped key,
see the TL10 firmware.
For vehicles with G-stamped key,
see the TL5 firmware.
For vehicles with dot-stamped key,
see the TL11 firmware.
G-stam ped keys H-stam ped keys
H
Standard Key
G-stam ped keys H-stam ped keys
H
Standard Key
For vehicles with dot-stamped key,
see the TL11 firmware.
For vehicles with G-stamped key,
see the TL5 or TL7 firmware.
For vehicles with H-stamped key,
see the TL10 firmware.
Footnotes
[1] Hood pin: The installation of an aftermarket hood pin is only required on vehicles that are not equipped with a factory hood pin or if
not supported in data.
[2] Siren: The siren is only required when enabling the security features during module flashing.
[3] Starter Disable/Antigrind: The Green wire is only required for starter disable and antigrind applications.
[4] Door trigger input: Connection required when enabling the security features during module flashing or when installing in manual
transmission vehicles.
[5] Trunk Release: Connection may be required in some vehicles.

5933.TL11 1.16.198.12 2008 Toyota FJ Cruiser
©2023 Directed. All rights
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).
Wiring diagram with T-Harness (THTON10)
Siren
Hood Pin (-) Hood Input: Gray
(+) Siren Output: Brown/Red
Security Only
Mandatory Connections
Remote Start Only
Legend:
Remote Start + Security
8-pin White Connector
22-pin White Connector
12-pin Black Connector
(-) Parking Lights Output: Lt.Green/Black
(-) Lock Output: Green/Black
(-) Trunk Release Output: Red/White
(+) Brake Input: Brown
(-) Unlock Output: Dk.Blue/Black
(-) Door Trigger Input: Green
10-pin White Connector
Transponder Key Amplifier
(black conn. around ignition)
Ignition Connector
Diagnostic Connector OBDII
THTON10
(optional T-Harness)
Refer to ‘Vehicle
Connections ’ for more
information on
vehicle-specific wiring
connections.
NOT USED
Cut the
Yellow/Black loop
labelled SIL.
Cut the TACH loop for Data
Tach ONLY.
Refer to the “Tach Learning
procedure” section for
more information. IMPORTANT:
Position the
fuses correctly!
Slide to open
MAIN (5A) (+)
(-) RLY3 PK LIGHT (15A) (+)
(-) ACC & START (30A) (+)
(-) FLEX RLY (20A) (+)
IGN (20A) (+)
5
30
20
20
15
Cut the Tan and
Tan/Black loops.

6933.TL11 1.16.198.12 2008 Toyota FJ Cruiser
©2023 Directed. All rights
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).
Wiring diagram
(-) Ground: Black: 10
(+) 12V Input: Blue/Red: 2
(-) Parking Lights Output: Lt.Green/Black: 1
(-) Lock Output: Green/Black: 3
(AC) Tach Input: Violet/White: 22
(-) Trunk Release Output: Red/White: 4
(+) Brake Input: Brown: 14
(-) Unlock Output: Dk.Blue/Black: 9
Data RX: Orange/Black 7
Data TX: Yellow/Black: 8
Hood Pin
(+) 12V Input: Red: 6 &12
(+) Ignition Input/Ouput: Pink: 10
(+) 12V Input: Red: 5
(+) Ignition 2 Output: Pink/White: 4
(+) Accessory Output: Orange: 8
(+) 12V Input: Red/White: 9
(+) 12V Input: Red/Black: 2
(-) Hood Input: Gray: 21
Siren
(+) Siren Output: Brown/Red: 11
(AC) Tach: Pin 9
16
8
9
1
Diagnostic Connector
at OBDII
16
8
9
1
Refer to Vehicle Connections
for wire and connector details.
Ignition Switch
(-) Door Trigger Input: Green: 20
(+) Starter 2 Output: Blue: 3
Refer to Vehicle Connections
for wire and connector details.
Transponder Key Amplifier
(black conn. around ignition)
(+) Starter Output (veh. side): Violet: 7
Starter Input (conn. side): Green: 6
CUT
Security Only
Mandatory Connections
Remote Start Only
Legend:
Remote Start + Security
Refer to ‘Vehicle
Connections ’ for more
information on
vehicle-specific wiring
connections.
IMPORTANT:
Position the
fuses correctly!
Slide to open
MAIN (5A) (+)
(-) RLY3 PK LIGHT (15A) (+)
(-) ACC & START (30A) (+)
(-) FLEX RLY (20A) (+)
IGN (20A) (+)
5
30
20
20

7933.TL11 1.16.198.12 2008 Toyota FJ Cruiser
©2023 Directed. All rights
Locating components in the vehicle

8933.TL11 1.16.198.12 2008 Toyota FJ Cruiser
©2023 Directed. All rights
Vehicle connections
The connection information listed below is specific to the 2008 Toyota FJ Cruiser. Refer to “Pre-installation and application warnings” for a list of important notes.
Data harness, 8-pin white connector (H1)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H1/1 Tan No Connection No Connection
H1/2 Tan/Black No Connection No Connection
H1/3 Orange/Brown No Connection No Connection
H1/4 Orange/Green No Connection No Connection
H1/5 Lt. Green No Connection No Connection
H1/6 Violet/Brown No Connection No Connection
H1/7 Orange/Black (Data) Immo Data RX Transponder Key Amplifier on ignition switch, black 7 pin plug, pin 4 data pink/green Remote Start
Only
H1/8 Yellow/Black (Data) Immo Data TX Transponder Key Amplifier on ignition switch, black 7 pin plug, pin 5 data lt. green/red Remote Start
Only
Analog input/output harness, 22-pin white connector (H2)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H2/1 Lt. Green/Black (-) Pk Light Output headlight switch, black 17 pin plug, pin 14 or Body ECU, top white 26
pin plug, pin 8
- green Mandatory
H2/2 Blue/White (-) Keysense Output No Connection
H2/3 Dk. Green/Black (-) Lock Output driver kick, white 18 pin plug, pin 6 - blue (driver door key lock) Mandatory
H2/4 Red/White (-) Trunk Release Output [5] Back Door ECU in tailgate, white 25 pin plug, pin 13 5 wire blue/yellow (glass hatch)
H2/5 Brown/Black No Connection No Connection
H2/6 Brown/White No Connection No Connection
H2/7 White (+) No Connection No Connection
H2/8 Violet/Black No Connection No Connection
H2/9 Dk. Blue/Black (-) Unlock Output driver kick, white 18 pin plug, pin 8 doubl
e -
pink (driver door key unlock) Mandatory
H2/10 Lt. Blue/Black No Connection No Connection
H2/11 Brown/Red (+) Siren Output [2] The siren is only required when enabling the security features during
module flashing.
Security Only
H2/12 Pink No Connection No Connection
H2/13 Violet (+) Door Input No Connection
H2/14 Brown (+) Brake Input brake switch or dash fuse box, white 16 pin plug (1F), pin 16 + green/yellow Remote Start
Only
H2/15 White/Blue No Connection No Connection
H2/16 Red/Blue No Connection No Connection
H2/17 Black/White (-) E-Brake Input No Connection
H2/18 Orange/Black No Connection No Connection

9933.TL11 1.16.198.12 2008 Toyota FJ Cruiser
©2023 Directed. All rights
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H2/19 Blue (-) Trunk Input No Connection
H2/20 Green (-) Door Input [4] dash fuse box, white 20 pin plug (1A), pin 8 - white Security Only
H2/21 Gray (-) Hood Switch Input [1] Not Applicable
The installation of an aftermarket hood pin is only required on vehicles
that are not equipped with a factory hood pin or if not supported in
data.
H2/22 Violet/White (AC) Tach Input data link connector, white 16 pin plug, pin 9 ac black/white Remote Start
Only
Main harness, 12-pin black connector (H3)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H3/1 Blue/White Relay N.C. No Connection No Connection
H3/2 Blue/Red Relay N.O. (+) 12 Volt Input ignition switch, white 8 pin plug, pin 7 + blue/black (30A) Remote Start
Only
H3/3 Blue Relay COM. (+) Starter 2 Output ignition switch, white 8 pin plug, pin 1 + black/white Remote Start
Only
H3/4 White/Brown Relay N.C. No Connection No Connection
H3/5 White Relay COM. No Connection No Connection
H3/6 Red (+) 12 Volt Input ignition switch, white 8 pin plug, pin 7 + blue/black (30A) Mandatory
H3/7 Lt. Green/Red Relay N.O. No Connection No Connection
H3/8 Lt. Green Relay COM. No Connection No Connection
H3/9 Lt. Green/White Relay N.C. No Connection No Connection
H3/10 Black (-) Ground (chassis ground) Mandatory
H3/11 White Relay COM. No Connection No Connection
H3/12 Red (+) 12 Volt Input ignition switch, white 8 pin plug, pin 7 + blue/black (30A) Mandatory
Relay harness, 10-pin white connector (H4)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H4/1 N/A No Connection No Connection
H4/2 Red/Black (+) 12 Volt Input ignition switch, white 8 pin plug, pin 7 + blue/black (30A) Remote Start
Only
H4/3 Pink/Black No Connection No Connection
H4/4 Pink/White (+) Ignition 2 Output ignition switch, white 8 pin plug, pin 4 + blue/yellow Remote Start
Only
H4/5 Red (+) 12 Volt Input ignition switch, white 8 pin plug, pin 7 + blue/black (30A) Remote Start
Only
H4/6 Green Starter Input (conn. side) [3] ignition switch, white 8 pin plug, pin 8
Connection required for Starter Disable Only.
+ green/black Mandatory
H4/7 Violet (+) Starter Output (vehicle side) ignition switch, white 8 pin plug, pin 8 + green/black Mandatory

10 933.TL11 1.16.198.12 2008 Toyota FJ Cruiser
©2023 Directed. All rights
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H4/8 Orange (+) Accessory Output ignition switch, white 8 pin plug, pin 3 + white/green Remote Start
Only
H4/9 Red/White (+) 12 Volt Input ignition switch, white 8 pin plug, pin 7 + blue/black (30A) Remote Start
Only
H4/10 Pink (+) Ignition Input/Output ignition switch, white 8 pin plug, pin 6 + black/red Mandatory
RF Port harness, 2-pin white connector (H5)
Module
Conn./Pin Color Description
H5/1 N/A
H5/2 N/A
D2D harness, 4-pin white (1) and black (2) connectors (H6)
Module
Conn./Pin Color Description
H6/1 Blue
H6/2 Black
H6/3 Green
H6/4 Red
Temperature sensor harness, 2-pin black connector (H7)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Connection
H7/1 Black Temperature Sensor
H7/2 Black Temperature Sensor
