Voyager Dock Homecrest Chair User manual

Homecrest Chair
PAGE 1
undercarriage shaft
ushing (old style)
be
Diagram D
Diagram E
Diagram F

PARTS LIST DESCRIPTIONPART NUMBERQTYITEM CHAIR UNDERCARRIAGE SHAFTVM-07911 3-8X1SSCARHD-0005962 3/8 BRASS FLANGE NUTHD-0005663 WASHERWASHER14
3/8X1S.S.CARRIAGEBOLT (6REQ'D) 3/8 FLANGE NUT (6 REQ'D)
PAGE 2
23
RACEWAY
Diagram A
WASHER (1 REQ'D) NYLON BUSHING NEW STYLE (1 REQ'D)
4
51
VM-123-02 BUSHING
5

To insure your safety while assembling your Voyager product:
Fully read and understand the assembly instructions
Do not assemble this product if items are missing or damaged
Wear protective gloves, clothing and eye wear when assembling this product
Check tightness of all hardware each year to avoid injury.
Installation procedure
The following tools will be needed: 9/16” wrench, pliers
1. Insert head of carriage bolt into raceway on the underside of dock rail and slide to
desired location on dock. Per diagram A.
2. Slide bracket into dock rail, put carriage bolts into bracket and attach flange nuts, finger
tight at this time. Per diagram B.
3. Install carriage bolts into keyhole slots on chair mount bracket, slide into place and
attach flange nuts. Per diagram C.
4. Take 9/16” wrench and tighten all 4 flange nuts. Check tightness annually to ensure
safety.
5. You have 2 options for installing nylon bushing in the base tube.** It may be necessary
to lightly tap bushing in with hammer, make sure to keep bushing as straight as possible
while tapping in so not to damage . Per diagram D.
6. Slide the washer onto the basket undercarriage shaft. Per diagram E.
7. Place basket undercarriage shaft into nylon bushing. Per diagram F.
8. Press basket undercarriage into the base tube until it clicks.
**OPTION 1)If you wish to easily remove your Homecrest chair from base use following
procedure: A)remove tabs on bushing prior to installation into base B)take pliers and bend
each of the 2 tabs back and forth until they snap off. C) Place bushing into base mount with
tab end down. D) Proceed with step 5.
OPTION 2) For permanent mount of basket carriage use, proceed with step 5
.
PAGE 3

PAGE 4
Keyholes
Raceway
3
3
2
2
2
Diagram B
1
Diagram C
