Voyager Dock VM-052 User manual

A2
3
1
Standing Dock Leg
PAGE 1

3/8X1S.S.CARRIDGEBOLT (4REQ'D) 3/8 FLANGE NUT (4 REQ'D)
1/2X11/4SQ.HEADBOLT(8REQ'D)
1/2 SQ. NUT BRASS (10 REQ'D)
PAGE 2
4
5
6
7
5PRONGKNOB(2REQ'D) LEG CAPS (2 REQ'D)

To insure your safety while assembling your Voyager product:
Fully read and understand the assembly instructions
Do not assemble this product if items are missing or damaged
Wear protective gloves, clothing and eye wear when assembling this product
Note: You may need assistancewhen turning dock over and also when installing dock
into the water.
Installation procedure
The following tools will be needed: 1/2” wrench, 9/16” wrench, tape measure, cut off saw,
level.
1. For ease of installation set dock frame upside down on a flat surface.
2. Insert head of 2- carriage bolts into raceway on the underside of dock rail, one on side
rail and one on end rail.Per diagram A.
3. Put square nuts into bracket and start bolts in nut to keep in place. Per diagram B.
4. Take foot pad and slide square nut into place and start bolt to keep in place. Per
diagram C.
5. Slide bracket into corner post of dock, slide carriage bolts into bracket slots and attach
flange nuts.Per diagram D.
6. Take 9/16” wrench and tighten flange nuts.
7. Slide dock leg into dock bracket*(you will need to do following to figure out dock leg
length: determine if dock legs are mounted below deck or sticking above deck and with
how much above, measure water depths using the lengths of docks being installed and
leg location if docks go side by side or off to the side and height of dock frame to be out
of the water).
8. Put foot pad onto leg and tighten set bolt with ½” wrench.Per diagram E.
9. Put leg to desired height using tape measure and tighten set bolts firmly to keep leg in
place for dock installation using a ½” wrench.
10. Repeat steps 2-9 for second bracket.
11. If connecting multiple dock frames go to step 12. If last frame skip to step 14.
12. Take connector brackets** slide square nuts into it and start set bo lts in one nut and 5
prong knob in other nut (screw in enough to keep nuts in place). Per diagram F.
PAGE 3

13) Put bracket on dock frame in desired location and tighten set bolt with ½” wrench and
leave 5 prong knob as is until next dock is put in place per dock instruction manual. Per
diagram F.
14) Dock can now be tipped over to upright position.
15) Install dock frame into water, check dock height and level. When height and level are set
tighten set bolts with ½” wrench.
16) Check to make sure all hardware is in and tight.
17) Dock panels can now beinstalled. Some panels may need to be notched for dock legs
depending on dock leg position.
18) If dock legs are installed above deck install caps to top of legs. ***
*dock leg not supplied in kit, sold separate.
** Connector brackets are used for hooking another dock frame together with this one
otherwise won’t be used
.
***if dock legs are mounted under deck caps won’t be use
PAGE 4

PARTS LIST DESCRIPTIONPART NUMBERQTYITEM LEG SOCKET ASM, [NS]VM-00721 DETACHABLE FOOTPADVOY001-FOOTPAD22 1/2 SQ_NUT BRASSHD-000581033/8 FLANGE BRASS NUTHD-0005644 1/2 X 1 1/4 SQ BOLT S/S
HD-0006085 3/8 X 1 CAR S/SHD-0005946 5PRONGKNOBHD-0015927 DOCK BRACKETVM-11228
Raceway
PAGE 5
Diagram A

5
3
3
5
6
6
44
2
3
5
Flat side to bolts
Diagram B
Diagram C
And
Diagram E
PAGE 6

8
7
PAGE 7
Diagram D
Diagram F
VM-112 DOCK BRACKET
NOTE:
ONLY USED IF HOOKING
UP MULTPLE DOCKS.
