VRG Controls VGP Series User manual

VGP-BV Valve Gas Posioner
Instrucon Manual
VRG CONTROLS LLC. 1 of 38 DECEMBER 2020
VRG Controls LLC. 1 of 37 JANUARY 2019
VGP-BV Valve Gas Posioner
Instrucon Manual
Applicable Models:
This instrucon Manual applies to the following VRG-Valve Gas Posioner. To conrm suitability
for addional models and/or components, please contact VRG Controls or view us online at
www.vrgcontrols.com.
VGP-100-DA-BV
VGP-100-SA-BV
VGP-100-DA-BV-SPL
VGP-100-SA-BV-SPL
ADDRESS: VRG Controls, LLC.
1199-B Flex Court
Lake Zurich, IL 60047, USA
TOLL FREE: (800) 844-FLOW-VRG
FAX: [phone]
E-MAIL: [e-mail]
WEBSITE: vrgcontrols.com
STAY IN TOUCH!
Scan the QR Code at right
for company informaon
and product updates.
PATENT NO.:
US 9,400,060 B2
PATENT NO.:
US 9,400,060 B2
US 10,234,047 B2

VGP-BV Valve Gas Posioner
Instrucon Manual
VRG CONTROLS LLC. 2 of 38 DECEMBER 2020
VGP-BV Valve Gas Posioner
Instrucon Manual
VRG Controls LLC. 2 of 37 JANUARY 2019
SECTION DESCRIPTION PAGE
1Scope of Manual 3
2Technical Specicaons 4
3 Model Number Explanaon 5
4 Flow Calculaons 6
5VGP Valve Gas Posioners Bias and Spring Range Conguraons 7
6 Principles of Operaon for Single Acng Posioners 8
7 Principles of Operaon for Double Acng Posioners 9
9Assembly Guide For:
• VGP-100-SA-BV (CI) [Part Number: PA-0150]
• VGP-100-DA-BV SPL (CI) [Part Number: PA-0151]
10
10 Assembly Guide For:
• VGP-100-SA-BV (OI) [Part Number: PA-0155]
• VGP-100-SA-BV-SPL (OI) [Part Number: PA-0152]
11
11 Assembly Guide For:
• VGP-100-DA-BV (CI) [Part Number: PA-0160]
• VGP-100-DA-BV SPL (CI) [Part Number: PA-0161]
12
12 Assembly Guide For:
• VGP-100-DA-BV (OI) [Part Number: PA-0165]
• VGP-100-DA-BV SPL (OI) [Part Number: PA-0166]
13
13 Changing the Acon of the VGP-SA-BV 14-18
14 Adjustment Procedures 19-21
15 Piping Diagrams 22-34
16 Repair Kit 35
17 Factory Quality Checklist 36
18 Annual Maintenance Checklist 37

VGP-BV Valve Gas Posioner
Instrucon Manual
VRG CONTROLS LLC. 3 of 38 DECEMBER 2020
VGP-BV Valve Gas Posioner
Instrucon Manual
VRG Controls LLC. 3 of 37 JANUARY 2019
SECTION DESCRIPTION PAGE
1Scope of Manual 3
2Technical Specicaons 4
3 Model Number Explanaon 5
4 Flow Calculaons 6
5VGP Valve Gas Posioners Bias and Spring Range Conguraons 7
6 Principles of Operaon for Single Acng Posioners 8
7 Principles of Operaon for Double Acng Posioners 9
9Assembly Guide For:
• VGP-100-SA-BV (CI) [Part Number: PA-0150]
• VGP-100-DA-BV SPL (CI) [Part Number: PA-0151]
10
10 Assembly Guide For:
• VGP-100-SA-BV (OI) [Part Number: PA-0155]
• VGP-100-SA-BV-SPL (OI) [Part Number: PA-0152]
11
11 Assembly Guide For:
• VGP-100-DA-BV (CI) [Part Number: PA-0160]
• VGP-100-DA-BV SPL (CI) [Part Number: PA-0161]
12
12 Assembly Guide For:
• VGP-100-DA-BV (OI) [Part Number: PA-0165]
• VGP-100-DA-BV SPL (OI) [Part Number: PA-0166]
13
13 Changing the Acon of the VGP-SA-BV 14-18
14 Adjustment Procedures 19-21
15 Piping Diagrams 22-34
16 Repair Kit 35
17 Factory Quality Checklist 36
18 Annual Maintenance Checklist 37
SCOPE OF THIS MANUAL
This Instrucon Manual provides instrucon
for installaon, maintenance, adjustment and
troubleshoong of VRG Controls VGP - Valve
Gas Posioner. This product is typically ulized
in conjuncon with control valves, pneumac
actuators and a variety of other axillary devices
and accessories. For informaon on products
other than those manufactured by VRG Controls,
please consult the appropriate manufacturer.
WARNING:
Only those qualied through training or experience
should install, operate, or maintain VRG Controls
posioners. If there are any quesons concerning
these instrucons, contact your VRG Controls sales
representave, sales oce, or manufacturer before
proceeding.
DESCRIPTION:
The VGP Valve Gas Posioner represents a
breakthrough in Valve Control technology. The VGP
provides a modular, plug & play control system for
use in conjuncon with pneumacally actuated
control valves. The VGP features a simplied 5-in-1
conguraon that provides compability with double
acng and single acng (spring return) control valves
ulizing a single plaorm. The VGP may be easily
recongured in the eld to provide compability
with almost any pneumac control valve on the
market. The highly accurate performance and ZERO
emissions capabilies of the VGP provide the desired
features to meet natural gas industry needs. The VGP
was designed by the inventor of the original “Valve
Gas Posioner” and features patent US 9, 400, 060
B 2 technological advances that provide reliability,
convenience, and performance above and beyond
previous technologies. VGP- Valve Gas Posioners
represent the future of control valve control
technology and are backed up by the industries’ most
experienced team.
TECHNICAL ASSISTANCE
For technical assistance with VRG products, please con-
tact your local VRG Controls sales representave or VRG
Controls direct. In order to facilitate technical assistance,
we strongly recommend that obtain the MODEL NUMBER
and SERIAL NUMBER of the product for which you require
assistance prior to contact us. MODEL NUMBER and
SERIAL NUMBER may be found on the PRODUCT ID LABEL
located on the front of the VGP product on the center face
of lower poron of the power assembly.
APPLICABLE MODELS:
This instrucon Manual applies to the following VRG-Valve
Ga Posioners. To conrm suitability for addional models
and/or components, please contact VRG Controls or view
us online at www.vrgcontrols.com.
• VGP-100-DA-BV
• VGP-100-SA-BV
• VGP-100-DA-BV-SPL
• VGP-100-SA-BV-SPL
NOTES ON TABLE 1.0:
• ZERO Steady State emissions achieved when
VPC properly adjusted to exhibit factory advised
deadband seng.
• Consumpon is approximate and based upon 100
psig Supply Gas. Atmosphere emissions may be
completely eliminated with Discharge to Pressure
System incorporated.
• Double acng VPC’s require addion of No-Vent
Device to achieve ZERO emissions at full open
and full closed.
SCOPE OF THIS MANUAL
This Instruction Manual provides instruction for instal-
lation, maintenance, adjustment and troubleshooting of
VRG Controls VGP - Valve Gas Positioner. This prod-
uct is typically utilized in conjunction with control valves,
pneumatic actuators and a variety of other axillary de-
vices and accessories. For information on products oth-
er than those manufactured by VRG Controls, please
consult the appropriate manufacturer.
WARNING:
Only those qualied through training or experience
should install, operate, or maintain VRG Controls posi-
tioners. If there are any questions concerning these in-
structions, contact your VRG Controls sales represen-
tative, sales o󰀩ce, or manufacturer before proceeding.
DESCRIPTION:
The VGP Valve Gas Positioner represents a break-
through in Valve Control technology. The VGP provides
a modular, plug & play control system for use in con-
junction with pneumatically actuated control valves.
The VGP features a simplied 5-in-1 conguration that
provides compatibility with double acting and single
acting (spring return) control valves utilizing a single
platform. The VGP may be easily recongured in the
eld to provide compatibility with almost any pneumatic
control valve on the market. The highly accurate per-
formance and ZERO emissions capabilities of the VGP
provide the desired features to meet natural gas indus-
try needs. The VGP was designed by the inventor of
the original “Valve Gas Positioner” and features patent
US 9, 400, 060 B 2 technological advances that pro-
vide reliability, convenience, and performance above
and beyond previous technologies. VGP- Valve Gas
Positioners represent the future of control valve control
technology and are backed up by the industries’ most
experienced team.
TECHNICAL ASSISTANCE
For technical assistance with VRG products, please
contact your local VRG Controls sales representative or
VRG Controls direct. In order to facilitate technical as-
sistance, we strongly recommend that obtain the MOD-
EL NUMBER and SERIAL NUMBER of the product for
which you require assistance prior to contact us. MOD-
EL NUMBER and SERIAL NUMBER may be found on
the PRODUCT ID LABEL located on the front of the
VGP product on the center face of lower portion of the
power assembly.
APPLICABLE MODELS:
This instruction Manual applies to the following VRG-
Valve Ga Positioners. To conrm suitability for addi-
tional models and/or components, please contact VRG
Controls or view us online at www.vrgcontrols.com.
• VGP-100-DA-BV
• VGP-100-SA-BV
• VGP-100-DA-BV-SPL
• VGP-100-SA-BV-SPL
NOTES ON TABLE 1.0:
• ZERO Steady State emissions achieved when
VPC properly adjusted to exhibit factory advised
deadband setting.
• Consumption is approximate and based upon
100 psig Supply Gas. Atmosphere emissions may
be completely eliminated with Discharge to Pres-
sure System incorporated.
• Double acting VPC’s require addition of No-Vent
Device to achieve ZERO emissions at full open
and full closed.

VGP-BV Valve Gas Posioner
Instrucon Manual
VRG CONTROLS LLC. 4 of 38 DECEMBER 2020
VRG Controls LLC. 4 of 37 JULY 2017
TABLE 1.0
TECHNICAL
SPECIFICATIONS
VGP MODEL
Type
Outputs
Internal Valve Logic
Command Signal Range
Posioning Logic
Temperature Range
Linearity and Hysterisis
CONSUMPTION
Steady State Control
Full Open/Closed
ZERO Emissions
EPA Specicaons
PNEUMATIC
Command Signal
Supply Gas Quality
Max Supply Gas Pressure
Min Supply Gas Pressure
Max Discharge DeltaP
Min Discharge DeltaP
Connecons
CONSTRUCTION
External Parts
Internal Parts
Diaphragms
O-Rings
Control Springs
Gauges
Weight
Approximate Dimensions
COMPATIBLE ACTUATORS
LD Linear Diaphragm
VGP-100-SA-BV VGP-100-DA-BV VGP-100-DA-SN
ZERO^2 <10 SCFH^3 ~100 SCFH ^3
Single Acng Double Acng
NC Balanced Value No Seat + Nozzel^1
3-15 psig 6-30 psig, Split Range
Available (Close on Increasing) OR (Open on Increasing) Command Signal
-20*F to +160*F(-29*C to +71*C)
Proporonal Posioning Device
ZERO (Note 1) ZERO^4
0 Atmospheric Emissions May Be Achieved When “Vent to Pressure System” Feature Ulized
Exceeds EPA Ruling, EPA-HQ-OAR-2010-0505, requiring <6 SCFH bleed rate by Oct. 2013
Max Pressure 100 psig
Dry, Filtered @ 10u Natural Gas or Air
400 psig (2758 kPa)
20 psig
150 psig (1034 kPa)
20 psig (138 kPa)
All Ports 1/4 FNPT
VRG Military grade Alloy w/[Stealth System] Corroston Protecon (304SS Oponal)
316 SS
Nylon Reinforced Buna-N (Viton-Oponal)
Buna-N (Viton-Oponal)
Painted Alloy Steel
2.5 In. Liquid-Filled SS Case & Body
20 lbs. (9.0 kg)
22In x 12 In x 7 In (559 mm x 305 mm x 178 mm)
LD-Linear Diaphragm
< 1%

VGP-BV Valve Gas Posioner
Instrucon Manual
VRG CONTROLS LLC. 5 of 38 DECEMBER 2020
VGP-BV Valve Gas Posioner
Instrucon Manual
VRG Controls LLC. 5 of 37 JANUARY 2019
Item Tag Model Number Serial Number
1
2
3
4
5
6
7
8
Example Run 1 Monitor
Regulator
VGP-100-DA-BV 0912123V
TABLE 3.0 INSTALLED PRODUCT IDENTIFICATION LOG
We recommend that you record the MODEL NUMBER and SERIAL NUMBER of all VRG Products installed at each
applicaon locaon in the table below for future reference.
PRODUCT ID LABEL
SCAN QR CODE
T O R EGI ST ER
S/N 0317005 DP
RCV100 1
SCAN QR CODE
T O R EGI ST ER
S/N 0317005 DP
RCV100 1
SCAN QR CODE
T O R EGI ST ER
S/N 0317005 DP
RCV100 1
SCAN QR CODE
T O R EGI ST ER
S/N 0317005 DP
RCV100 1
SCAN QR CODE
T O R EGI ST ER
S/N 0317005 DP
RCV100 1
SCAN QR CODE
T O R EGI ST ER
S/N 0317005 DP
RCV100 1
SCAN QR CODE
T O R EGI ST ER
S/N 0317005 DP
RCV100 1
SCAN QR CODE
T O R EGI ST ER
INV 17-1106
Base Model Acon Output Type Integral Valve Logic
VGP-100-DA-BV Double Acng 3-15 PSI
6-30 PSI
BV Balance Valves
VGP-100-DA-BV-SPL Double Acng Split Control
See Table 5.0
BV Balance Valves
VGP-100-SA-BV Single Acng 3-15 PSI
6-30 PSI
BV Balance Valves
VGP-100-SA-BV-SPL single Acng Split Control
See Table 5.0
BV Balance Valves
TABLE 2.0 MODEL NUMBER EXPLANATION
We recommend that you record the MODEL NUMBER and SERIAL NUMBER of all VRG Products installed at each
applicaon locaon in the table below for future reference.
Example: Model VGP-100-SA-BV-SPL
VPG MODEL NUMBER IDENTIFICATION LABEL

VGP-BV Valve Gas Posioner
Instrucon Manual
VRG CONTROLS LLC. 6 of 38 DECEMBER 2020
VGP-BV Valve Gas Posioner
Instrucon Manual
VRG Controls LLC. 6 of 37 JANUARY 2019
FLOW CALCULATIONS
Variable Descripon Unit
  
1 
  
G 
T 
Variable Descripon Unit
t 
  in.
  in.
  
G 
T 
TABLE 4.0 
1 1


TABLE 5.0 

Installed Orice 0125 
Standard  0.009 0.018    0.111 
Medium (M)    0.089   0.211 
Large (L)        
Adjustable Orice Seng
Notes:
1. 

2. 

 

TABLE 6.0 

 G



2

VGP-BV Valve Gas Posioner
Instrucon Manual
VRG Controls LLC. 7 of 37 JANUARY 2019
Applicaon Recommended
VGP Model
Ball Value Globe
Value
Actuator
Volume
DA
Actuator
CLOSE
Orrice
OPEN
Orrice
Cylinder
Output
Pressure
Notes
TABLE 7.0 VGP VALVE GAS POSITIONERS BIAS AND SPRING RANGE CONFIGURATIONS
RANGE ES-0015 ES-0025 ES-0035 ES-0045
BIAS
RANGE ES-0018 ES-0028 ES-0038 ES-0048
BIAS
RANGE ES-0010 ES-0020 ES-0030 ES-0040
BIAS
RANGE ES-0010 ES-0020 ES-0030 ES-0040
BIAS
RANGE ES-0016 ES-0026 ES-0036 ES-0046
BIAS
RANGE ES-0015 ES-0025 ES-0035 ES-0045
BIAS
N/A
N/A
CS-0100 (BLACK)
CS-0110 (BROWN)
CS-0100 (BLACK)
CS-0110 (BROWN)
SIGNAL
RANGE
3-15 psig
6-30 psig
3-9 psig
9-15 psig
6-24 psig
18-30 psig
2-4 in 4-6 in 6-8 in 10-12 in
ACTUATOR STROKE LENGTHSPRING
TABLE 8.0 APPICATION BASED FINE TUNING SETTING GUIDELINES - VGP DOUBLE ACTING
Downstream Piping
and > 1.0 Mile
VGP-100-DA-BV < 80in 3 3 “98%” of
power gas
VGP-100-DA-BV >80in < 400in 4 4 “98%”
VGP-100-DA-BV >400in < 1350in 5 5 “98%”
VGP-100-DA-BV >1350in NR NR NR 1
3
3 3
3 3
3
NOTE: For Actuator Volume greater than 1350 in ulize VGP-100-DA-SN with Volume Busters. Contact VRG for addional details.
3

VGP-BV Valve Gas Posioner
Instrucon Manual
VRG CONTROLS LLC. 7 of 38 DECEMBER 2020
VGP-BV Valve Gas Posioner
Instrucon Manual
VRG Controls LLC. 7 of 37 JANUARY 2019
Applicaon Recommended
VGP Model
Ball Value Globe
Value
Actuator
Volume
DA
Actuator
CLOSE
Orrice
OPEN
Orrice
Cylinder
Output
Pressure
Notes
TABLE 7.0 VGP VALVE GAS POSITIONERS BIAS AND SPRING RANGE CONFIGURATIONS
RANGE ES-0015 ES-0025 ES-0035 ES-0045
BIAS
RANGE ES-0018 ES-0028 ES-0038 ES-0048
BIAS
RANGE ES-0010 ES-0020 ES-0030 ES-0040
BIAS
RANGE ES-0010 ES-0020 ES-0030 ES-0040
BIAS
RANGE ES-0016 ES-0026 ES-0036 ES-0046
BIAS
RANGE ES-0015 ES-0025 ES-0035 ES-0045
BIAS
N/A
N/A
CS-0100 (BLACK)
CS-0110 (BROWN)
CS-0100 (BLACK)
CS-0110 (BROWN)
SIGNAL
RANGE
3-15 psig
6-30 psig
3-9 psig
9-15 psig
6-24 psig
18-30 psig
2-4 in 4-6 in 6-8 in 10-12 in
ACTUATOR STROKE LENGTHSPRING
TABLE 8.0 APPICATION BASED FINE TUNING SETTING GUIDELINES - VGP DOUBLE ACTING
Downstream Piping
and > 1.0 Mile
VGP-100-DA-BV < 80in 3 3 “98%” of
power gas
VGP-100-DA-BV >80in < 400in 4 4 “98%”
VGP-100-DA-BV >400in < 1350in 5 5 “98%”
VGP-100-DA-BV >1350in NR NR NR 1
3
3 3
3 3
3
NOTE: For Actuator Volume greater than 1350 in ulize VGP-100-DA-SN with Volume Busters. Contact VRG for addional details.
3
CS-0100 (BLACK) .50 psi/turn
CS-0110 (BROWN) 1.86 psi/turn
CS-0100 (BLACK) .50 psi/turn
CS-0100 (BLACK) .50 psi/turn
CS-0110 (BROWN) 1.86 psi/turn

VGP-BV Valve Gas Posioner
Instrucon Manual
VRG CONTROLS LLC. 8 of 38 DECEMBER 2020
VGP-BV Valve Gas Posioner
Instrucon Manual
VRG Controls LLC. 8 of 37 JANUARY 2019

The VGP-SA-BV posioner is a force balanced
instrument that provides a control valve posion
proporonal to a pneumac input signal. In this
case the control valve is set to open on loss of
input signal. The energy to operate the control
valve comes from the dierenal force created
by the pneumac loading on one side of the
cylinder and the opposing actuator spring force.
In steady-state, the force imposed on the balance
beam by the input signal diaphragm and range
spring are equal. When these forces are equal
the balance valves in the top and boom bodies
of the posioner are closed. The posioner will
not feed gas to the actuator cylinder or exhaust
loading pressures from the cylinder. When the
spring force and cylinder force are equal, the
control valve remains in a staonary posion.
An increase in the input signal pressure results in
the opening of the lower balanced valve due to an
imbalance in the beam forces. This increases the
pressure in the cylinder, further closing the valve
and compressing the actuator spring. The actuator
feedback rod stretches the range spring, increasing
its tension. The force from the spring, which opposes
the force on the balance beam created from the
increased input signal, connues to increase unl
the balance beam forces are in equilibrium. At this
point the valve is in the correct posion for the
applied input signal. The sensivity adjustment of
the posioner changes the posioner’s dead band
(the change in input signal necessary to create
a certain amount of change in output signal.
O
In this case the control valve is set to close on loss
of input signal. The energy to operate the control
valve comes from the dierenal force created by the
pneumac loading on one side of the cylinder and
the opposing actuator spring force. In steady-state,
the force imposed on the balance beam by the input
signal diaphragm and range spring are equal. When
these forces are equal the balance valves in the top
and boom bodies of the posioner are closed. The
posioner will not feed gas to the actuator cylinder or
exhaust loading pressures from the cylinder. When the
spring force and cylinder force are equal, the control
valve remains in a staonary posion. An increase
in the input signal pressure results in the opening
of the upper balanced valve due to an imbalance in
the beam forces. This increases the pressure in the
cylinder, further opening the valve and compressing
the actuator spring. The actuator feedback rod
stretches the range spring, increasing its tension. The
force from the spring, which opposes the force on the
balance beam created from the increased input signal,
connues to increase unl the balance beam forces are
in equilibrium. At this point the valve is in the correct
posion for the applied input signal when the actuator
spring and cylinder forces again balance. The sensivity
adjustment of the posioner changes the posioner’s
dead band (the change in input signal necessary to
create a certain amount of change in output signal.
P2
P1
FLOW
SIGNAL




CLOSE
EX
P1
S
FLOW
P1
OPEN



EX
SIGNAL

C O

Close
Close
Close on Increasing Signal- Actuator Fails Open
The VGP-SA-BV positioner is a force balanced instru-
ment that provides a control valve position proportion-
al to a pneumatic input signal. In this case the control
valve is set to open on loss of input signal. The energy
to operate the control valve comes from the di󰀨erential
force created by the pneumatic loading on one side of
the cylinder and the opposing actuator spring force. In
steady-state, the force imposed on the balance beam by
the input signal diaphragm and range spring are equal.
When these forces are equal the balance valves in the
top and bottom bodies of the positioner are closed. The
positioner will not feed gas to the actuator cylinder or
exhaust loading pressures from the cylinder. When the
spring force and cylinder force are equal, the control
valve remains in a stationary position. An increase in
the input signal pressure results in the opening of the
lower balanced valve due to an imbalance in the beam
forces. This increases the pressure in the cylinder, fur-
ther closing the valve and compressing the actuator
spring. The actuator feedback rod stretches the range
spring, increasing its tension. The force from the spring,
which opposes the force on the balance beam created
from the increased input signal, continues to increase
until the balance beam forces are in equilibrium. At this
point the valve is in the correct position for the applied
input signal. The sensitivity adjustment of the position-
er changes the positioner’s dead band (the change in
input signal necessary to create a certain amount of
change in output signal.
Open on Increasing Signal - Actuator Fails Closed
In this case the control valve is set to close on loss of
input signal. The energy to operate the control valve
comes from the di󰀨erential force created by the pneu-
matic loading on one side of the cylinder and the op-
posing actuator spring force. In steady-state, the force
imposed on the balance beam by the input signal dia-
phragm and range spring are equal. When these forc-
es are equal the balance valves in the top and bottom
bodies of the positioner are closed. The positioner will
not feed gas to the actuator cylinder or exhaust loading
pressures from the cylinder. When the spring force and
cylinder force are equal, the control valve remains in a
stationary position. An increase in the input signal pres-
sure results in the opening of the upper balanced valve
due to an imbalance in the beam forces. This increases
the pressure in the cylinder, further opening the valve
and compressing the actuator spring. The actuator
feedback rod stretches the range spring, increasing its
tension. The force from the spring, which opposes the
force on the balance beam created from the increased
input signal, continues to increase until the balance
beam forces are in equilibrium. At this point the valve is
in the correct position for the applied input signal when
the actuator spring and cylinder forces again balance.
The sensitivity adjustment of the positioner changes the
positioner’s dead band (the change in input signal nec-
essary to create a certain amount of change in output
signal.

VGP-BV Valve Gas Posioner
Instrucon Manual
VRG CONTROLS LLC. 9 of 38 DECEMBER 2020
VGP-BV Valve Gas Posioner
Instrucon Manual
VRG Controls LLC. 9 of 37 JANUARY 2019

The posioner is a force-balanced instrument that
provides a control valve posion proporonal to
the pneumac input signal. The control valve will
open on loss of input signal. The energy to operate
the control valve is obtained from the dierenal
between the supply and discharge pressures. In
steady state, the forces imposed on the balance
beam by the input signal diaphragm and the range
spring are equal; therefore, the top and boom
balance valves in the posioner are at or near their
closed posions. The cylinder top and boom
pressures are both equal to power gas pressure,
and the control valve is staonary. An increase in
the input signal pressure results in the opening of
the lower balanced valve due to an imbalance in the
beam forces. This decreases the pressure in the
cylinder top., while the pressure in cylinder boom
remains at power gas. The control valve begins to
close. The actuator rod stretches the range spring,
increasing its tension. This force, which opposes the
force on the balanced beam caused by the increasing
input signal, connues to increase unl the balance
beam forces are in equilibrium. At this point the
valve is in the correct posion for the applied input
signal. The posioner has a sensivity adjustment
which permits a balance between greater accuracy
(from a smaller deadband) and minimal bleed gas.
O
The posioner is a force-balanced instrument that
provides a control valve posion proporonal to the
pneumac input signal. The control valve will close on
loss of input signal. The energy to operate the control
valve is obtained from the dierenal between the
supply and discharge pressures. In steady state, the
forces imposed on the balance beam by the input
signal diaphragm and the range spring are equal;
therefore, the top and boom balance valves of the
posioner are at or near their closed posions. The
cylinder top and boom pressures are both equal
to power gas, and the control valve is staonary. An
increase in the input signal pressure results in the
the opening of the upper balance valve due to an
imbalance in the beam forces. This decreases the
pressure in the cylinder boom, while the pressure
in the cylinder top remains at power gas pressure.
The control valve begins to open. The actuator rod
stretches the range spring, increasing its tension.
This force, which opposes the force on the balanced
beam caused by the increasing input signal, connues
to increase unl the balance beam forces are in
equilibrium. At this point the valve is in the correct
posion for the applied input signal. The posioner
has a sensivity adjustment which permits a balance
between greater accuracy (from a smaller deadband)
and minimal bleed gas.
OPEN
CLOSE
P2 P1
FLOW
SIGNAL



OPEN
SIGNAL


P2 P1
OPEN
OPEN
SIGNAL
CLOSE
SUPPLY
OUT 2
OUT 1
S
OPEN
FLOW
CLOSE
P2 P1

OPEN ON INCREASING SIGNAL
C O

Close on Increasing Signal
The positioner is a force-balanced instrument that pro-
vides a control valve position proportional to the pneu-
matic input signal. The control valve will open on loss
of input signal. The energy to operate the control valve
is obtained from the di󰀨erential between the supply
and discharge pressures. In steady state, the forces
imposed on the balance beam by the input signal dia-
phragm and the range spring are equal; therefore, the
top and bottom balance valves in the positioner are at
or near their closed positions. The cylinder top and bot-
tom pressures are both equal to power gas pressure,
and the control valve is stationary. An increase in the
input signal pressure results in the opening of the lower
balanced valve due to an imbalance in the beam forces.
This decreases the pressure in the cylinder top., while
the pressure in cylinder bottom remains at power gas.
The control valve begins to close. The actuator rod
stretches the range spring, increasing its tension. This
force, which opposes the force on the balanced beam
caused by the increasing input signal, continues to in-
crease until the balance beam forces are in equilibrium.
At this point the valve is in the correct position for the
applied input signal. The positioner has a sensitivity
adjustment which permits a balance between greater
accuracy (from a smaller deadband) and minimal bleed
gas.
Open on Increasing Signal - Actuator Fails Closed
The positioner is a force-balanced instrument that pro-
vides a control valve position proportional to the pneu-
matic input signal. The control valve will close on loss
of input signal. The energy to operate the control valve
is obtained from the di󰀨erential between the supply
and discharge pressures. In steady state, the forces
imposed on the balance beam by the input signal di-
aphragm and the range spring are equal; therefore,
the top and bottom balance valves of the positioner
are at or near their closed positions. The cylinder top
and bottom pressures are both equal to power gas, and
the control valve is stationary. An increase in the in-
put signal pressure results in the the opening of the
upper balance valve due to an imbalance in the beam
forces. This decreases the pressure in the cylinder bot-
tom, while the pressure in the cylinder top remains at
power gas pressure. The control valve begins to open.
The actuator rod stretches the range spring, increasing
its tension. This force, which opposes the force on the
balanced beam caused by the increasing input signal,
continues to increase until the balance beam forces are
in equilibrium. At this point the valve is in the correct
position for the applied input signal. The positioner has
a sensitivity adjustment which permits a balance be-
tween greater accuracy (from a smaller deadband) and
minimal bleed gas.

VGP-BV Valve Gas Posioner
Instrucon Manual
VRG CONTROLS LLC. 10 of 38 DECEMBER 2020
VGP-BV Valve Gas Posioner
Instrucon Manual
VRG Controls LLC. 10 of 37 JANUARY 2019
VGP-100-SA-BV (CI) Assembly Guide
Part Number: PA-0150
VGP-100-DA-SA SPL (CI) Assembly Guide
Part Number: PA-0151
EX EX
Note: Acon open/close on increasing depends on direcon of the feedback mechanism.
The table refers to “down to open” mechanisms. If mechanism is “down to close” the acon
will reverse.
Note: Action open/close on increasing depends on direction of the feedback mechanism. The
table refers to “down to open” mechanisms. If mechanism is “down to close” the action will re-
verse.

VGP-BV Valve Gas Posioner
Instrucon Manual
VRG CONTROLS LLC. 11 of 38 DECEMBER 2020
VGP-BV Valve Gas Posioner
Instrucon Manual
VRG Controls LLC. 11 of 37 JANUARY 2019
VGP-100-SA-BV (OI)
Part Number: PA-0155
VGP-100-SA-BV-SPL (OI) Assembly Guide
Part Number: PA-0152
EX
EX
Note: Acon open/close on increasing depends on direcon of the feedback mechanism.
The table refers to “down to open” mechanisms. If mechanism is “down to close” the acon
will reverse.
Note: Action open/close on increasing depends on direction of the feedback mechanism. The
table refers to “down to open” mechanisms. If mechanism is “down to close” the action will re-
verse.

VGP-BV Valve Gas Posioner
Instrucon Manual
VRG CONTROLS LLC. 12 of 38 DECEMBER 2020
VGP-BV Valve Gas Posioner
Instrucon Manual
VRG Controls LLC. 12 of 37 JANUARY 2019
VGP-100-DA-BV (CI) Assembly Guide
Part Number: PA-0160
VGP-100-DA-BV SPL (CI) Assembly Guide
Part Number: PA-0161
EX EX
Note: Acon open/close on increasing depends on direcon of the feedback mechanism.
The table refers to “down to open” mechanisms. If mechanism is “down to close” the acon
will reverse.
Note: Action open/close on increasing depends on direction of the feedback mechanism. The
table refers to “down to open” mechanisms. If mechanism is “down to close” the action will re-
verse.

VGP-BV Valve Gas Posioner
Instrucon Manual
VRG CONTROLS LLC. 13 of 38 DECEMBER 2020
VGP-BV Valve Gas Posioner
Instrucon Manual
VRG Controls LLC. 13 of 37 JANUARY 2019
VGP-100-DA-BV (OI) Assembly Guide
Part Number: PA-0165
VGP-100-DA-BV SPL (OI) Assembly Guide
Part Number: PA-0166
EXEX
Note: Acon open/close on increasing depends on direcon of the feedback mechanism.
The table refers to “down to open” mechanisms. If mechanism is “down to close” the acon
will reverse.
Note: Action open/close on increasing depends on direction of the feedback mechanism. The
table refers to “down to open” mechanisms. If mechanism is “down to close” the action will re-
verse.

VGP-BV Valve Gas Posioner
Instrucon Manual
VRG CONTROLS LLC. 14 of 38 DECEMBER 2020
VGP-BV Valve Gas Posioner
Instrucon Manual
VRG Controls LLC. 14 of 37 JANUARY 2019

The following procedure is the same for SA-BV
and DA-BV, but SA-BV is shown as an example.
In some situaons the VGP-SA-BV posioner
may need to be congured from an open
on increasing signal posioner, to a close on
increasing signal posioner, or vice versa.


Order parts per table 9.0.
Figure 1. Close on Increasing VGP-SA-BV Front View
 Remove the (2) 
from the  Remove the TOP
BOX from the 
 Remove the
 that fasten the to the VGP

Figure 2. Top Box Removal
A
B
C
D
E

 Disconnect all supply lines, instrument lines
and output line from the posioner.
   
PD-5065 ALL VGP TR-CI Beam Curved Extension (I) 1
FB-0035 4, 6, 8 8” Stoke Range Spring TR Extension (L) 1
FB-0037 12 12” Stroke Range Spring TR Extension
(L)
1
FN-0255 ALL 7/16-20 Hex Jam Nut SS (J) 2
TABLE 9.0 Bill of Materials for Conversion Kit to CI from OI
The following procedure is the same for SA-
BV and DA-BV, but SA-BV is shown as an
example.
In some situations the VGP-SA-BV positioner
may need to be congured from an open on
increasing signal positioner, to a close on in-
creasing signal positioner, or vice versa.
To Change from Open on Increasing to Close
on Increasing
Order parts per table 9.0.
Disconnect all supply lines, instrument
lines and output line from the positioner.
Step 1: Remove the (2) 1/4-20 x 1-1/4” SHCS 316
SS (A) from the TOP BOX COVER (B). Re-
move the TOP BOX COVER (B) from the
TOP BOX (C).
Remove the 1/4-20 x 1-3/4” SHCS 316 SS
BOLT (D) that fasten the TOP BOX (C) to the
VGP BOTTOM BOX (E).
Step 2:
Step 3:

VGP-BV Valve Gas Posioner
Instrucon Manual
VRG CONTROLS LLC. 15 of 38 DECEMBER 2020
VGP-BV Valve Gas Posioner
Instrucon Manual
VRG Controls LLC. 15 of 37 JANUARY 2019
Figure 3. Unlocking Range Spring
Step 4: Unlock and remove the RANGE EXTENSION SPRING
(F) from the RANGE SPRING RETAINER (G).
Step 5: Remove the VGP RANGE SPRING SCREW 1-5/8”
LONG (H) and RANGE EXTENSION SPRING (F)
from the VGP-TR-CI BEAM CURVED EXTENSION
(I).
Step 6: Remove the (2) 7/16-20 JAM NUTS RH 316 SS
(J) and SPRING RETAINER (G) from the BIAS
ADJUSTMENTING STUD (K).
Figure 4. Range spring and Retainer Removal
Step 7: Unscrew and remove the VGP ADJUSTING STUD
(K) from the VGP STROKE RANGE SPRING TR
EXTENSION (L).
Step 8: Unscrew and remove the VGP STROKE RANGE
SPRING TR EXTENSION (L) from the Actuator Rod,
along with the VGP TR INDICATOR WASHER (N)
and VGP TR SPACER (O).
Figure 5. Removing the Extension from the Rod
Step 9:
Figure 6. Preparing to Remove the Posioner
FG
K
L
M
N
P
Q
P
O
H
J
G
I
J
F
K
J
Unscrew and remove (3), 8-22 X 1/2 SCREW
316 SS (P) FROM BEAM (I). Remove BEAM
(I). Remove Posioner MNGT Bolts (4) I-18x1
hues (not shown).
I
Part No. Stroke Descripon Qt.
PD-5065 ALL VGP TR-CI Beam Curved Extension (I) 1
FB-0035 4, 6, 8 8” Stoke Range Spring TR Extension (L) 1
FB-0037 12 12” Stroke Range Spring TR Extension
(L)
1
FN-0255 ALL 7/16-20 Hex Jam Nut SS (J) 2
Unlock and remove the RANGE EXTENSION
SPRING (F) from the RANGE SPRING RETAIN-
ER (G).
Step 4:
Remove the VGP RANGE SPRING SCREW
1-5/8” LONG (H) and RANGE EXTENSION
SPRING (F) from the VGP-TR-CI BEAM
CURVED EXTENSION (I).
Remove the (2) 7/16-20 JAM NUTS RH 316
SS (J) and SPRING RETAINER (G) from the
BIAS ADJUSTMENTING STUD (K).
Step 5:
Step 6:
Unscrew and remove the VGP ADJUSTING
STUD (K) from the VGP STROKE RANGE
SPRING TR EXTENSION (L).
Unscrew and remove the VGP STROKE RANGE
SPRING TR EXTENSION (L) from the Actuator
Rod, along with the VGP TR INDICATOR WASH-
ER (N) and VGP TR SPACER (O).
Step 7:
Step 8:
Unscrew and remove (3), 8-22 X 1/2 SCREW
316 SS (P) FROM BEAM (I). Remove BEAM (I).
Remove Positioner MNGT Bolts (4) I-18x1 hues
(not shown).
Step 9:

VGP-BV Valve Gas Posioner
Instrucon Manual
VRG CONTROLS LLC. 16 of 38 DECEMBER 2020
VGP-BV Valve Gas Posioner
Instrucon Manual
VRG Controls LLC. 16 of 37 JANUARY 2019
Figure 7. Remove Posioner and VGP Beam Cover
Step 10: Pull the VGP-SA-BV from the VGP TR BOTTOM
BOX (E).
Step 11: Unscrew and remove (2) 1/4”-20 x 1/2” SHCS SS
(S). Separate the VGP BEAM COVER (R) from the
VGP TR BOTTOM BOX (E).
Step 12: Assemble parts VGP TR SPACER (Q) , VGP-TR-
INDICATOR WASHER (N), VGP-TR-OI OFFSET BAR
(M), SPRING HOLDER EXTENSION (U) on Cylinder
Tailroad or Actuator Rod. Tighten the Parts with
7/16-20 X 1-3/4” HHCS 18-8 SS (T). Insert VGP
ADJUSTING STUD (K) into SPRING HOLDER
EXTENSION (U). Tighten 7/16-20 JAM NUT RH
316 SS (J).
Figure 8. Re-insert the VGP Bias Adjusng Stud Upside Down
E
RS
Figure 9. Re-connecng the Range Extension Spring.
Step 13: Insert the VGP-RANGE SPRING SCREW (H) into
the RANGE EXTENSION SPRING (F), and thread it
into the BIAS ADJUSTING STUD (K).
Figure 10. Re-aaching the Top Box.
Step 14: Install VGP TOP BOX (C) onto the VGP BOTTOM
BOX (E). Fasten the assembly together using (2)
1/4-20 x 1-3/4” SHCS 316 SS (D).
C
D
E
F
K
F
H
Pull the VGP-SA-BV from the VGP TR BOTTOM
BOX (E).
Unscrew and remove (2) 1/4”-20 x 1/2” SHCS SS
(S). Separate the VGP BEAM COVER (R) from
the VGP TR BOTTOM BOX (E).
Step 10:
Step 11:
Assemble parts VGP TR SPACER (Q) ,
VGP-TRINDICATOR WASHER (N), VGP-TR-OI
OFFSET BAR (M), SPRING HOLDER EXTEN-
SION (U) on Cylinder Tailroad or Actuator Rod.
Tighten the Parts with 7/16-20 X 1-3/4” HHCS
18-8 SS (T). Insert VGP ADJUSTING STUD (K)
into SPRING HOLDER EXTENSION (U). Tighten
7/16-20 JAM NUT RH 316 SS (J).
Step 12:
Insert the VGP-RANGE SPRING SCREW (H)
into the RANGE EXTENSION SPRING (F), and
thread it into the BIAS ADJUSTING STUD (K).
Step 13:
Install VGP TOP BOX (C) onto the VGP BOT-
TOM BOX (E). Fasten the assembly together us-
ing (2) 1/4-20 x 1-3/4” SHCS 316 SS (D).
Step 14:

VGP-BV Valve Gas Posioner
Instrucon Manual
VRG CONTROLS LLC. 17 of 38 DECEMBER 2020
VGP-BV Valve Gas Posioner
Instrucon Manual
VRG Controls LLC. 17 of 37 JANUARY 2019
Figure 11. Moving the VGP Box Side Cover to the VGP
Boom Box
 Insert the  into the VGP
on the 

 Install  using 

Figure 12. Removing the Access Cover from the Top Box
E
V
W
Figure 13. Fastening the Spring Retainer
Figure 14. Aaching the VGP
 Insert the POSITIONER into the 
onto the Fasten the
assembly using (4)
C
R
P

R S
X
G
AA
Y
Z
Convert VGP-SA-BV-CI to VGP-SA-BV-OI. Use diagram
on page 12. Fasten the to the
using 
Install and 
using .
Insert the 1/4-20 Hex Nut 316 SS (V) into the
VGP BOX SIDE COVER (W) on the VGP BOT-
TOM BOX (E).
Step 15:
Install VGP BEAM COVER (R) using 1/4-20 x
1/2” SHCS (S).
Step 16:
Convert VGP-SA-BV-CI to VGP-SA-BV-OI. Use di-
agram on page 12. Fasten the SPRING RETAIN-
ER (G) to the PIVOTED BEAM (AA) using (2) 8-32
x 1/2” SHCS (X). Install VGP RANGE SPRING
LOCK (Y) and 1/4” ID LOCK WASHER (Z) using
8-32 x 1/2” SHCS (X).
Step 17:
Insert the POSITIONER into the VGP BEAM
COVER (R) onto the TOP BOX (C). Fasten the
assembly using (4) 5/16-18x 1HHCS 316 SS (P).
Step 18:

VGP-BV Valve Gas Posioner
Instrucon Manual
VRG CONTROLS LLC. 18 of 38 DECEMBER 2020
VGP-BV Valve Gas Posioner
Instrucon Manual
VRG Controls LLC. 18 of 37 JANUARY 2019
Figure 15. Connecng the Range Spring and Locking it onto
the Spring Retainer
Step 19: Pull the RANGE SPRING (F) up over the RANGE
SPRING RETAINER (G) and wind approximately 3
coils before locking.
G
FFigure 16. Finalizing the Topworks Assembly
Step 20: Adjust posioner per procedures on PG. 20-23.
Put BOX TOP COVER (B) on TOP BOX (C) using (2)
1/4-20 x 1-1/4” SCHS 316 SS (A).
Step 21: Install ngs, gages and tubing using the piping
schemac drawings on Pg. 28-35 for SA only.
A
B
C
Figure 17. Posioner Fings and Tubing in the Final
Posion
Pull the RANGE SPRING (F) up over the
RANGE SPRING RETAINER (G) and wind ap-
proximately 3 coils before locking.
Step 19: Adjust positioner per procedures on PG. 20-23.
Put BOX TOP COVER (B) on TOP BOX (C) us-
ing (2) 1/4-20 x 1-1/4” SCHS 316 SS (A).
Step 20:
Install ttings, gages and tubing using the piping
schematic drawings on Pg. 28-35 for SA only.
Step 21:

VGP-BV Valve Gas Posioner
Instrucon Manual
VRG CONTROLS LLC. 19 of 38 DECEMBER 2020
VGP-BV Valve Gas Posioner
Instrucon Manual
VRG Controls LLC. 19 of 37 JANUARY 2019
CLOSE ON INCREASING ADJUSTMENT PROCEDURE
The VGP-SA-BV posioner comes factory adjusted for
your parcular applicaon. The use of the following
adjustment procedure will only be necessary when
a RUBBER GOODS replacement kit is installed or
any other me the posioner is disassembled.
The VGP-SA-BV posioner has 3 adjustment secons:
1. The ADJUSTMENT DRUM adjusts the dead band.
2. The ADJUSTMENT SCREW adjusts the bias
3. The RANGE SPRING adjusts the span.
Adjustment Drum Sengs
The ADJUSTMENT DRUM seng or “dead band”
seng ne tunes the sensivity of the VGP balance
valves.
Figure 28. VGP-SA-BV Adjustment Drum
Figure 29. Range Spring and Spring Retainer Adjustment
Figure 30. Set Instrument Signal to Midpoint
BB
G
F
Step 1: Turn the dead band ADJUSTMENT DRUM (BB) in
the direcon of decreasing numbers unl it can
no longer turn, then turn the drum 2-3/4 turn in
the opposite direcon (use the numbers on the
drum as a guide).
Step 2: If not already aached, wind 3 to 4 coils of the
RANGE SPRING (F) onto the RANGE SPRING
RETAINER (G).
Step 3: If not already adjusted, set the RANGE SPRING
RETAINER (G) so that it is in the middle of the
stud.
Step 4: Set the instrument signal pressure at the
midpoint of its range. For example, set it at 9
psig if the range is 3-15 psig, or 18 psig if the
range is 6-30 psig. Stroke the actuator to an
intermediate posion.
The VGP-SA-BV positioner comes factory adjusted
for your particular application. The use of the following
adjustment procedure will only be necessary when a
RUBBER GOODS replacement kit is installed or any
other time the positioner is disassembled.
The VGP-SA-BV positioner has 3 adjustment sections:
1. The ADJUSTMENT DRUM adjusts the dead
band.
2. The ADJUSTMENT SCREW adjusts the bias
3. The RANGE SPRING adjusts the span.
Adjustment Drum Settings
The ADJUSTMENT DRUM setting or “dead band”
setting ne tunes the sensitivity of the VGP balance
valves.
Turn the dead band ADJUSTMENT DRUM (BB)
in the direction of decreasing numbers until it
can no longer turn, then turn the drum 2-3/4 turn
in the opposite direction (use the numbers on
the drum as a guide).
If not already attached, wind 3 to 4 coils of the
RANGE SPRING (F) onto the RANGE SPRING
RETAINER (G).
If not already adjusted, set the RANGE SPRING
RETAINER (G) so that it is in the middle of the
stud.
Step 1:
Step 2:
Step 3:
Set the instrument signal pressure at the mid-
point of its range. For example, set it at 9 psig
if the range is 3-15 psig, or 18 psig if the range
is 6-30 psig. Stroke the actuator to an interme-
diate position.
Step 4:

VGP-BV Valve Gas Posioner
Instrucon Manual
VRG CONTROLS LLC. 20 of 38 DECEMBER 2020
VGP-BV Valve Gas Posioner
Instrucon Manual
VRG Controls LLC. 20 of 37 JANUARY 2019
Step 5A:If the actuator is equipped with a MCV-3 Manual
Control Valve, place the le MCV-3 handle in the
manual posion.
Note: When increasing or decreasing the
instrument signal, the output pressure should
swing up and down respecvely. When changing
direcon of the false instrument signal, the output
pressure should immediately reverse direcon.
Any “bump” or inial reacon of the gauge in
the wrong direcon indicates fricon within the
components of the posioner. In the case where
fricon is a problem the posioner must be
disassembled and rebuilt to eliminate it.
Note: Step 6 should only be used if the posioner
is being used in a bleed to pressure system.
Step 6: Turn the adjustment drum one division (1/4-
1/2 of a number, NOT one full number) in the
direcon of decreasing numbers. Re-aach
exhaust port to pressure system.
Figure 31. Le handle moved to manual posion.
Step 5B: If the actuator is not equipped with VMO-150,
use the 1/4” ball block valve installed between
the posioner output and the actuator. Once the
actuator has reached its desired posion (based
on the mid-signal applied to the instrument port
in step d), place the block valve in the closed
posion.
a) Observe the output pressures. Set output
pressure per table 8.0 using the i.0. Turning
the drum in the direcon of increasing
numbers will reduce the output pressure.
Note: Raising the output pressure will reduce
sensivity and bleed gas at steady state.
b) At this point the unit is properly adjusted if
an increase or decrease in the input signal of
0.25 psig causes the output gauge to swing in
either direcon.
If the actuator is equipped with a MCV-3 Manual
Control Valve, place the left MCV-3 handle in
the manual position.
Step 5A:
If the actuator is not equipped with VMO-150,
use the 1/4” ball block valve installed between
the positioner output and the actuator. Once the
actuator has reached its desired position (based
on the mid-signal applied to the instrument port
in step d), place the block valve in the closed
position.
a) Observe the output pressures. Set out-
put pressure per table 8.0 using the i.0.
Turning the drum in the direction of in-
creasing numbers will reduce the output
pressure.
Note: Raising the output pressure will re-
duce sensitivity and bleed gas at steady
state.
b) At this point the unit is properly adjusted
if an increase or decrease in the input sig-
nal of 0.25 psig causes the output gauge
to swing in either direction.
Step 5B: Turn the adjustment drum one division (1/4- 1/2
of a number, NOT one full number) in the direc-
tion of decreasing numbers. Re-attach exhaust
port to pressure system.
Step 6:
