VTOMAN JUMP1000 User manual

JUMP1000/JUMP1500X/JUMP1800/JUMP2200
Portable Power Station
User Manual
Model:PB21/PB22X/PB29

English
日本語
Français
Deutsch
Italiano
Русский
Українська
Español
CONTENTS
1~12
13~27
28~41
42~56
57~70
71~85
86~100
101~115

Thank you for purchasing VTOMAN JUMP1000/JUMP1500X/
JUMP1800 portable power station. To make sure
your personal safety, property security and user experience,
please read this manual carefully before operating, and retain
it for the future reference.
Preface
WWW.VTOMAN.COM
Scan to get more information about VTOMAN products
1

1.Specification
2
Model
Capacity
DC Input
DC Output
AC Output
USB Output
Type-C Output
Weight
Dimensions
Battery
JUMP1000
1408Wh
JUMP1500X
828Wh
JUMP1800
1548Wh
Extra Battery
1548Wh
12V-30V(200W MAX）
2 DC output+ 1* Car output: Total 120W
AC Wave 110V/60Hz
Continuous1000W
Peak2000W
AC Wave 110V/60Hz
Continuous1500W
Peak3000W
AC Wave 110V/60Hz
Continuous1800W
Peak3600W
5V/2.4A*3; Quick Charge 3.0*1
PD(5V3A/9V3A/12V3A/15V3A/20V3A/20V5A)
N.W : 37.04lbs N.W : 30.86lbs N.W : 38.58lbs N.W : 32.41lbs
12+12 Months
FCC/CE/PSE/RoHS/UL
14.2x10.6x11.0 inch
LiFePO4
Pure Sine Wave
12W LED
Temperature Protection
Over Charge Protection
Short Circuit Protection
Over-Current Protection
Over Discharge Protection
Lifecycles
LED Flashlight
Warranty
Certifications
Management
System
14°F~113°F
Operating
Temperature
Recharging
Temperature
Output Waveform
32°F~113°F
3100+ Cycles
/
/
/
/
/
/

2.Package List
3
Model JUMP1000 JUMP1500X JUMP1800 Extra Battery
Power Station 1000W Portable
Power Station
1500W Portable
Power Station
1800W Portable
Power Station Extra Battery
Car Charger 1 1 1 /
Wall Charger 1 1 1 /
USB to Type-C
Cable 1 1 1 /
Type-C to
Type-C Cable 1 1 1 /
Extra Battery
Connect Cable / / / 1
User Manual 1 1 1 1
Please kindly check all accessories are complete. If any parts
missing, please feel free to contact us at [email protected].

3.2 LCD Screen Introduction
3.Product Overview
Remaining Charge/Discharge Time
Remaining Battery Percentage
AC Output
TYPE-C Output
12V DC Output USB-A Output
Input/Output
Power
3.1 Product Detail
4
CP3500 cable Power Click Button
Indicator
Light
USB-A 5V2.4A Output
USB-A 5V2.4A Output
USB-A 5V2.4A Output
USB Quick Charge 3.0 Output
LCD
12V Jump start
AC 110V/60hz 1000W/
1500W/1800W Output
Back-up
battery port
USB-C Output
DC12V~30V
Input
DC12V10A
Output
I nput
DC12V~30V ttuuppttuuOO CC--BBSSUU
DC 12V ttuuppttuuOO
5V2.4A
Quick Charge 3.0 PURE SINE WAVE 110V/60Hz 1000W
Input
DC12V~30V ttuuppttuuOO CC--BBSSUU
DC 12V ttuuppttuuOO
5V2.4A
Quick Charge 3.0 PURE SINE WAVE 110V/60Hz 1000W

4. Product Operating Instructions
4.1 Power & Function On/Off
1.Power On: Short press any button to power on the product and
enter the standby state, the LCD Screen will light up and the battery
level indicator icon will display.
2.Power Off: Turn off all outputs manually, then the product enters
the standby state and will shut down after 30 minutes.
3.AC Output On/Off: Short press the AC Button to use the AC
output; Short press the AC Button again to turn if off.
4.DC Output On/Off: Short press the DC Button to use the 12V DC
output; Short press the DC Button again to turn if off.
5.USB-A & Type-C On/Off: Short press the USB Button to use the
USB-A & Type-C output; Short press the USB Button again to turn if
off.
4.2 Recharge Methods & Recharge Time
Recharge Methods
Wall Charging
1.Wall Charger
2.DC5521 Connector
1.Not Included
Solar Panel Charging
5

4.3Jump Start Your Vehicle
UMP1000/JUMP1500X/JUMP1800 are designed for jump starting 12V
vehicle batteries，Start current: 500A Peak current: 2000A.
Step 1: Fully plug the blue connector of the clamp cable into the jump
starter socket, and make sure the Indicator on the clamp cable is off.
Step 2: Connect Red Clamp to the negative(+) battery terminal and
Black Clamp to the negative(-) battery terminal.
Car Charging
1.Cigarette Lighter Plug
2.Car Charger
Recharge Time
6
JUMP1000 JUMP1500X JUMP1800 Extra Battery
Wall Charger 7-8 Hours 4-5 Hours 8-9 Hours 8-9 Hours
Car Charger 8-9 Hours 5-6 Hours 9-10 Hours 9-10 Hours

Step 3: Operate according to the Indicator on the clamp cable:
GREEN LIGHT on: Telling the connection is correct and the circuit is
working,you can turn on the engine to jump startdirectly.
5.Troubleshooting
to
ell.
r
se.
P
l
ll.
Problem Cause Solution
No output pow er
Your device is not
connected to the
pow er station w ell.
Connect your device
the pow er station w
Output switch is not
turned on.
Turn on the output
switch manually.
Battery is low . Recharge the pow e
station fully before u
Output breaks dow n
during use
Your device’s operating
pow er is too low ,
causing the product
turns off automatically.
Please turn on the
power again.
roduct cannot charge
Charger is not w ell
connected to the
pow er station or w all
outlet .
Please make sure al
connections are w e
Connection is w ell, but
the charger indicator is
off. Charger is broken.
Please contact w ith
Vtom an custom er
service.
7

6.FAQs
1.What is V-surging Technology?
V-surging Technology refers to the technology exclusive to VTOMAN
which enables power staiton to keep supplying power even when the
connected appliances add up to a higher rated power than max
output. (In V-surging status, the output power of power station is
stable at the max output.)
2.Does VTOMAN power station pass-through charging？
Yes, all Vtoman power stations support pass-through charging. You
can recharge your power stations and use them to charge other devic-
es and appliances simultaneously.
3.How can I connect an extra battery to VTOMAN power station?
First, you need to disconnect your power station from the supported
devices or apliances. Then you connect the extra battery to your
power station and you can use power station to power other devices
and apliances again.
4.Is VTOMAN power station water-resistant? Can I use it in ourdoors
when it's raining?
VTOMAN power station is not water-resistant. It is not recommended
to expose it to rain. When your VTOMAN power station gets wet, if is
is not inputing or outpputing, you can continue to use after drying it.
5.How long can I use my power station to power my devices?
The conversiona rate of VTOMAN power station is greater than 90%,
so you can estimate a rough period of time with 90% (at least) conver-
sion rate. When the connected product power is lower than rated
power of your power station, the length of power supply = remained
capacity of you power station * 0.9 / product input power; when the
connected product is beyond rated power of your power station, the
length of power supply = remained capacity of you power station * 0.9
/ rated power of your power station. Please note that in the later case,
although the product can be used, the effect may not be as good as
that of its fully operating. In addition, refrigerators, microwave ovens,
washing machines and other heavy-duty appliances may be more sen-
sitive to the temperature, and their conversion energy loss does up
when the temperature is higher. Neither such cases nor appliances
with additional power output are subject to the formula mentioned
above. 8

7.Safety Instructions
6.How often should I recharge my VTOMAN power station?
After receiving your VTOMAN power station, it is recommended that
you first open the AC output port to see if the internal fan rotates
normally, and then charge the power station for 2~3 hours. It is also
recommended that you recharge your power station every 6 months
when not frequently using it.
7.How can I jump start my car with VTOMAN power station? Is there
a munimum capacity needed for a jump-start?
You can connect it with your car engine via the jump cable and start
your car in seconds. For most of the time, any Vtoman power station
with more than 5% of its battery can jump start a car. However, it is
reconmmended you keep more than 10% of the battery to jump start
your car with VTOMAN power stations.
8.What will be displayed on the LCD screen when an extra battery is
connected VTOMAN power station?
When connected to an extra battery, VTOMAN power station will
display the average capacity of power station and the connected
extra battery on its LCD screen.
7.1Danger
Noncompliance may very likely lead to serious injury or death.DO NOT
disassemble, repair or modify the unit or the battery.
DO NOT expose the product to fire or excessive temperatures. It will
explode if thetemperature is over 266°F. Keep out of direct sunlight.
DO NOT charge, use or store the unit in a bathroom or in an area
exposed to rainor moisture.
Only use the output socket to power external devices. Never connect
the output tomains power under any condition.
DO NOT touch the unit or the plug-in points if your hands are wet.
DO NOT connect any metallic objects to the AC input or output.
DO NOT rub your eyes if fluid from inside the unit should get in your
eyes.
DO NOT dispose the unit together with household waste.
DO NOT use any inappropriate power cords.
9

DO NOT operate the unit above the specified input voltage.
DO NOT use the unit if it is not functioning correctly.
DO NOT drop the unit if it is recharging or in use.
7.2Warning
Noncompliance may lead to serious injury or death
Use and store the unit only in a clean and dry environment. DO NOT
use and storein dusty and wet environment.
DO NOT use the unit if it is damaged or broken.Check the unit prior to
every use.DO NOT use the unit if the power cord is damaged or
broken.
Keep the unit away from children. DO NOT let children use the power
supply unit.Keep this product away from pets.
DO NOT use or store the unit in an area or environment with high tem-
perature.
Should fluid from inside of the unit come in contact with your skin or
clothing, washthe affected areas with tap water.
In a storm, unplug the power cord from the socket.
DO NOT charge the unit via power supply systems that operate
outside of 100-240V.DO NOT place the unit on its side or upside down
while in use or storage.
DO NOT use accessories for other usage.
7.3Caution
Noncompliance may lead to injuries and/or property damage.
If peculiar odors, overheating or other abnormal circumstances are
observed, stopusing the unit immediately and contact our customer
service
The unit complies with all legal requirements for transport of danger-
ous goods.Make sure that the unit is properly secured when transport-
ing it in a motor vehicle.Only charge, use and store the unit within an
ambient temperature of 0 to 45°C(32-113℉).
Switch the unit off immediately if it has accidentally fallen, was
dropped or wasexposed to vibrations.
Carefully read the instructions for the electric devices that you intend
to connect toyour power supply unit.
10

8.Warranty
Warranty Period
The warranty period is 12+12 months. In each case, the warranty period
is measured starting on the date of purchase by the original purchaser.
The sales receipt from the first consumer purchase, or other reason-
able documentary proof, is required in order to establish the start date
of the warranty period.
11
Please remove power plug when the product is not in use.
7.4Disclaimer
· Our company cannot be held liable for damages caused by fire,
earthquake, use by a third party, other accidents, intentional miscon-
duct on the part of the customer, abuse or other abnormal conditions.
· Do not repair any damage to the AC plug or power supply on your
own.
. The warranty covers all terms and conditions of the warranty. Con-
tents that are not specified in the warranty terms and conditions are
beyond our responsibility.
· Our company assumes no liability for damages caused by incorrect
use or non-compliance with this instruction manual.
Intended Use: Our product is not suitable to be used with equipment
that relates to one's own personal safety and relies heavily on electrici-
ty such as large medical devices, equipment for nuclear faclities,the
manufacture of air and spacecraft, etc. We therefore assume no liabili-
ty for accidents involving personal safety, fires, or machine failures,
caused by using our product with the aforementioned devices.

9.Customer Service
華佳商事 株式会社
MADE IN CHINA
12+12 Months Limited Warranty Service
Lifetime Technical Service
Feel Free to Contact Us
For FAQ and More Information
www.vtoman.com
[email protected] (recommend)
Facebook : @Vtoman2022
Youtube : @Vtoman
Twitter : @Vtoman
Instagram : vtomanofficial
12

JUMP1000/JUMP1500X/JUMP1800
ポータブル電源
取扱説明書
型番: PB21/PB22X/PB29
13

このたびは、VTOMAN JUMP1000/JUMP1500X/JUMP1800ポータ
ブル電源をお買い上げいただき、誠にありがとうございます。お
客様の身の安全、財産の安全を確保し、快適にお使いいただくた
めに、ご使用になる前に、必ずこの取扱説明書をよくお読みにな
り、正しくお使いください。
前書き
WWW.VTOMAN.JP
QRコードをスキャンして、詳しい情報をご覧ください。
14

1.仕様
15
型番
容量
DC 入力
DC 出力
AC 出力
USB 出力
Type-C 出力
重量
サイズ
バッテリー
JUMP1000
1408Wh
JUMP1500X
828Wh
JUMP1800
1548Wh
拡張バッテリー
1548Wh
12V-30V(最大200W ）
2* DC 出力+ 1* シガーソケット出力
AC 100V/60Hz,
定格出力1000W，
瞬間最大出力2000W
AC 100V/60Hz,
定格出力1500W，
瞬間最大出力3000W
AC 100V/60Hz,
定格出力1800W，
瞬間最大出力3600W
5V/2.4A*3; Quick Charge 3.0*1
PD(5V3A/9V3A/12V3A/15V3A/20V3A/20V5A)
N.W : 16.8Kg N.W : 14Kg N.W : 17.5Kg N.W : 14.7Kg
12+12 ヶ月
FCC/CE/PSE/RoHS/UL
360X270X280mm
LiFePO4
純正弦波
12W LED
過熱/低温保護
過充電保護
短絡保護
過電圧保護
過負荷保護
サイクル回数
LEDライト
保証期間
認証
管理システム
-20℃~55℃
動作温度
充電温度
出力波形
0℃~55℃
3100+ サイクル
/
/
/
/
/
/
過電流保護
逆充電保護
AIソフトウェア保護
逆極性保護
火花防止保護

2.パッケージリスト
16
型番 JUMP1000 JUMP1500X JUMP1800 拡張バッテリー
ポータブル電源 1000W ポータ
ブル電源
1500W ポータ
ブル電源
1800W ポータ
ブル電源 拡張バッテリー
シガーソケッ
トケーブル
1 1 1 /
AC
アダプター 1 1 1 /
USB to Type-C
ケーブル
1 1 1 /
Type-C to
Type-C ケー
ブル
1 1 1 /
拡張バッテリー
ケーブル / / / 1
取扱説明書 1 1 1 1
ご使用いただく前に、次の同梱物がすべてそろっていることをご
確認ください。何かご問題があれば、[email protected]に
てご連絡ください。

入力/出力総電力
バッテリー残量の割合
AC 出力
TYPE-C 出力
12V DC 出力 USB-A す出力
入力/出力
総電力
3.2 LCD ディスプレイ 説明
3.製品の概要
3.1 各部の機能の説明
17
CP3500 ケーブル 電源ボタン
電源表示
ライト
USB-A 5V2.4A 出力
USB-A 5V2.4A 出力
USB-A 5V2.4A 出力
USB-A Quick Charge 3.0 出力
LCD ディスプレイ
12V カージャンプスタ
ーターソケット
拡張バッテリー接続
ポート
USB-C 出力
DC 12V-30V
入力
DC 12V/10A
出力
AC 100V/60hz 1000W/
1500W/1800W 出力
Input
DC12V~30V UUSSBB--CC OO uuttppuutt
5V/2.4A
12V/10A Quick Charge 3.0 PURE SINE WAVE 100V/60Hz 1800W
Input
DC12V~30V UUSSBB--CC OOuuttppuutt
5V/2.4A
12V/10A QuickCharge 3.0 PURESINE WAVE 100V/60Hz 1800W
