Vulcan-Hart VC4GD ML-126611 User manual

INSTALLATION &
OPERATION MANUAL
VC SERIES
GAS CONVECTION OVENS
MODELS
VC4GD ML-126611
VC4GC ML-136494
VC6GD ML-126613
VC6GC ML-136495
STACKED MODELS
VC44GD ML-126611
VC44GC ML-136494
VC66GD ML-126613
VC66GC ML-136495
MODEL VC4GD
VULCAN-HART
DIVISION OF ITW FOOD EQUIPMENT GROUP, LLC
WWW.VULCANHART.COM
P.O. BOX 696
LOUISVILLE, KY 40201-0696
FORM 31123 Rev. K (Mar. 2009)
For additional information on Vulcan-Hart or to locate an authorized parts
and service provider in your area, visit our website at www.vulcanhart.com

– 2 –
IMPORTANT FOR YOUR SAFETY
THIS MANUAL HAS BEEN PREPARED FOR PERSONNEL QUALIFIED TO INSTALL GAS
EQUIPMENT, WHO SHOULD PERFORM THE INITIAL FIELD START-UP AND
ADJUSTMENTS OF THE EQUIPMENT COVERED BY THIS MANUAL.
POST IN A PROMINENT LOCATION THE INSTRUCTIONS TO BE FOLLOWED IN THE
EVENT THE SMELL OF GAS IS DETECTED. THIS INFORMATION CAN BE OBTAINED
FROM THE LOCAL GAS SUPPLIER.
IMPORTANT
IN THE EVENT A GAS ODOR IS DETECTED, SHUT DOWN
UNITS AT MAIN SHUTOFF VALVE AND CONTACT THE
LOCAL GAS COMPANY OR GAS SUPPLIER FOR
SERVICE.
FOR YOUR SAFETY
DO NOT STORE OR USE GASOLINE OR OTHER
FLAMMABLE VAPORS OR LIQUIDS IN THE VICINITY OF
THIS OR ANY OTHER APPLIANCE.
Improper installation, adjustment,
alteration, service or maintenance can cause property
damage,injuryordeath.Readtheinstallation,operating
and maintenance instructions thoroughly before
installing or servicing this equipment.
INTHEEVENTOFAPOWERFAILURE,DONOTATTEMPT
TO OPERATE THIS DEVICE.
© VULCAN-HART, 2009

– 3 –
Installation, Operation and Care of
VC SERIES
GAS CONVECTION OVENS
KEEP THIS MANUAL FOR FUTURE REFERENCE
GENERAL
Models VC4GD and VC6GD feature a solid state temperature control. Models VC4GC and VC6GC
feature a programmable oven controller. One hour dial timer is standard; five hour timer is optional.
Two-speed 1/2HP (0.37 kw) electric motor is standard equipment. Each oven is furnished with 5 racks;
additional oven racks are available. The burner input rating for each oven is 44,000 BTU/hr.
Porcelain interior is standard on all models.
Model VC6GD and VC6GC has a 4 inches (102 mm) deeper oven cavity.
Standard ovens are 120 V, 60 Hz, 1 PH and include cord and plug. Optional electrical specifications
of 208/240 V are available and require hard wire connection.
Independently opening doors are standard; simultaneous door opening is optional.
Other options include: an open stand with lower storage rack, roast and hold, and a stacking kit for
mounting one oven on top of another.
Vulcan VC Series Gas Convection Ovens are produced with quality workmanship and material. Proper
installation, usage and maintenance of your oven will result in many years of satisfactory performance.
It is suggested that you thoroughly read this entire manual and carefully follow all of the instructions
provided.
Model Thermostat Timer Oven Roast & Legs Standwith Voltage
Lights Hold Storage Rack
VC4GD Solid State 1 Hr. 5 Hr. Std. Opt. 253/4Opt. 120/60/1 Std.
VC6GD Std. Opt. (654 mm) 208/60/1 Opt.
VC4GC Programmable N/A N/A Std. Std. 253/4Opt. 240/60/1 Opt.
VC6GC (654 mm) 240/50/1 Opt.
220/380 (3W)/50/3 Opt.
Stacked 8" 220/380 (4W)/50/3 Opt.
Ovens (203 mm) 240/415 (4W)/50/3 Opt.
FEATURES AND OPTIONS

– 4 –
INSTALLATION
Before installing, verify that the electrical service and type of gas supply (natural or L.P.) agree with
the specifications on the rating plate, located behind the top trim panel on the front of the oven. If the
supply and equipment requirements do not agree, do not proceed with the installation. Contact your
dealer or Vulcan-Hart Company immediately.
UNPACKING
This oven was inspected before leaving the factory. The transportation company assumes full
responsibility for safe delivery upon acceptance of the shipment. Immediately after unpacking, check
for possible shipping damage. If the oven is found to be damaged, save the packaging material and
contact the carrier within 15 days of delivery.
Carefully unpack the oven and place it in a work-accessible area near to its final installed position.
Do not use the doors or their handles to lift the oven.
LOCATION
The equipment area must be kept free and clear of combustible substances.
When installed, minimum clearance from combustible construction must be 1 inch (25 mm) at the left
side, 4 inches (102 mm) at the right side and 2 inches (51 mm) at the rear. Minimum clearance from
noncombustible construction must be 0 inch (0 mm) at the left side, 4 inches (102 mm) at the right side
and 2 inches (51 mm) at the rear. The oven may be installed on combustible floors.
The installation location must allow adequate clearances for servicing and proper operation. For solid
state and digital control models, there must be 18 inches (457 mm) of clearance on the right side of
the oven from any open flame.
The oven must be installed so that the flow of combustion and ventilation air will not be obstructed.
Adequate clearance for air openings into the combustion chamber must be provided. Make sure there
is an adequate supply of air in the room to allow for combustion of gas at the oven burners.
Donotpermitfanstoblowdirectlyattheoven.Whereverpossible,avoidopenwindowsnexttotheoven.
Avoid wall-type fans which create air cross currents within the room.
INSTALLATION CODES AND STANDARDS
In the United States of America:
1. State and local codes.
2. National FuelGasCode,ANSI/Z223.1/NFPA#54(latestedition).CopiesmaybeobtainedfromThe
American Gas Association, Inc., Accredited Standards Committee Z223 @ 400 N. Capital St. NW,
Washington, DC 20001 or the Secretary Standards Council, NFPA, 1 Batterymarch Park, Quincy,
MA 02169-7471.
NOTE: In the Commonwealth of Massachusetts,
All gas appliances vented through a ventilation hood or exhaust system equipped with a damper or
with a power means of exhaust shall comply with 248 CMR.

– 5 –
3. Vapor Removal From Cooking Equipment , NFPA-96 (latest edition). Copies may be obtained from
The National Fire Protection Association, Batterymarch Park, Quincy, MA 02169-7471.
4. National Electrical Code, ANSI/NFPA-70 (latest edition). Copies may be obtained from The
National Fire Protection Association, Batterymarch Park, Quincy, MA 02169-7471.
In Canada:
1. Local codes.
2. CSA B149.1 Natural Gas and Propane Installation Code.
3. CSA C22.1 Canadian Electric Code (latest edition).
The above are available from the Canadian Standard Association, 5060 Spectrum Way, Suite 100,
Mississauga, Ontario, Canada L4W 5N6.
INSTALLING BASIC OVEN
The basic oven must be installed on legs or be mounted on a
modularstand.Installationsonconcretebasesorothersupports
restricting air circulation underneath the oven is not advisable
and may void the warranty.
Ovens Mounted on Casters
Ovens mounted on casters must use a flexible connector (not
supplied by Vulcan) that complies with the Standard for
Connectors for Movable Gas Appliances, ANSI Z21.69 • CSA
6.16 and a quick-disconnect device that complies with the
Standard for Quick-Disconnect Devices for Use With Gas
Fuel, ANSI-Z21.41 • CSA 6.9. In addition, adequate means
must be provided to limit movement of the appliance without
depending on the connector and the quick-disconnect device
or its associated piping to limit appliance movement. Attach the
restraining device at the rear of the oven as shown in Fig. 1.
Remove two screws from the rear of the oven and install the tie-down strap shipped with the casters
using these screws (Fig. 1). Attach the gas line strain relief to the tie-down strap at the rear of the oven
(Fig. 1).
If disconnection of the restraint is necessary, turn off the gas supply before disconnection. Reconnect
this restraint prior to turning the gas supply on and returning the oven to its installation position.
Separate instructions for installing casters to the oven are included with the casters.
Note: If the oven is installed on casters and is moved for any reason, it is recommended that the oven
be releveled front to back and side to side.
Fig. 1
CONNECT
GAS LINE
STRAIN RELIEF
HERE PL-53563

– 6 –
ASSEMBLING STACKED OVENS
Unpack the ovens and stack kit. Position the oven to be used as
the bottom oven on its back for access to the oven bottom, taking
carenottoscratchordamageit.Thegaspipeprotrudesbeyondthe
back; provide for this when the oven is tipped back by resting it on
suitable spacers (2 x 4" [51 x 102 mm], etc.). Attach the four leg
assemblies with the 24 bolts and lockwashers (six per leg).
Placetheloweroven(withlegs)onthefloorandremovetwo7/16 inch
(11mm)diameterknockoutsoneachsideofthetopcover.Remove
vent guard and discard it.
Move the oven with legs to the installed position and place upper
oven on top of lower oven using the locating studs.
Install the stacking flue (Fig. 3) with the four screws provided.
Connect the piping between the top oven and bottom oven. For all
gas supply connections, pipe joint compound must be resistant to
the action of propane gases.
LEVELING
Make sure that the oven racks are level in the final installed position. If the oven is installed on legs,
turn the adjustable feet in or out to level the oven front-to-back and side-to-side. If the oven is installed
oncasters, loosenset screws andturn casters inor out tolevel the ovenfront-to-back and side-to-side.
Retighten set screws after leveling.
Assembling the Legs to the Oven
Thelegsmustbeinstalledonthebottomoftheoven.Gentlypositionthe
oven on its side, taking care not to scratch or damage it.
Attacheachofthefourlegassembliestothebottomoftheovenwiththe
24 bolts and lockwashers (six per leg). Carefully raise the oven to its
normal position.
ASSEMBLING THE STAND TO THE OVEN
Attacheachofthefourlegassembliestothebottomoftheovenwiththe
24 bolts and lockwashers (six per leg). Carefully raise the oven to its
normal position.
Attach the undershelf to the legs with eight bolts and lockwashers
(two per leg).
Install the rack guides into the undershelf at desired locations (for pan
or flat rack), then attach the rack supports to the top end of the rack
guides. Attach rack supports to the leg assembly by removing one
middle bolt and reattaching back through the end holes in the rack
support (Fig. 2). Fig. 2
Fig. 3
STACKING FLUE
PL-53564
BACK
FRONT
RACK SUPPORT
RACK GUIDE
PL-56178

– 7 –
GAS CONNECTION
Gassupply connections and anypipe joint compound mustbe resistant to the actionof propane gases.
Location of the gas inlet is at the rear of the oven. Codes require that a gas shutoff valve must be
installed in the gas line ahead of the oven.
Connect gas supply after leveling the oven. The gas supply line must be at least the equivalent of
3/4inch (19 mm) iron pipe. Make sure the pipes are clean and free of obstructions, dirt or pipe joint
compound.
The ovens are equipped with fixed burner orifices which coincide with installation elevation.
Standardovenwith electronicignition isprovided witha regulatorintegral tothe gassolenoid valveand
requires no external regulator.
Ovens with standing pilot must use external regulator provided with unit, set to pressures as indicated
in above gas data chart.
The gas pressure regulator provided with this appliance must be used. This regulator is set
for an outlet pressure of 3.5” W.C. (0.9 kPa) natural gas and 10” W.C. (2.5 kPa) propane gas.
Prior to lighting, check all joints in the gas supply for leaks. Use soap and
water solution. Do not use an open flame.
A. Check all joints prior to the gas valve (solenoid) before lighting unit.
B. Check all joints beyond gas valve (solenoid) after unit is lit.
After piping has been checked for leaks, all piping receiving gas should be fully purged to remove air.
TESTING THE GAS SUPPLY SYSTEM
When gas supply pressure exceeds 1/2psig (3.45 kPa), the oven and its individual shutoff valve must
be disconnected from the gas supply piping system.
Whengassupplypressure is1/2psig(3.45 kPa)orless, theovenshould beisolatedfrom thegassupply
system by closing its individual manual shutoff valve.
BURNER AIR ADJUSTMENT
Although main burner air is adjusted before shipment, it should be checked at the time of installation.
Excessive air will cause flames to lift off a burner when cold or may cause flash-back during normal
cycling of oven, particularly when propane gas is used.
INPUT RATING MANIFOLD PRESSURE
44,000 BTU/hr 44,000 BTU/hr 3.5"W.C. (0.9 kPa) 10"W.C. (2.5 kPa)
44,000 BTU/hr 44,000 BTU/hr 3.7" W.C. (0.93 kPa) 10"W.C. (2.5 kPa)
L.P. GASES L.P. GASES
Natural (Propane) Natural (Propane)
VC4GD
VC6GD
VC4GC
VC6GC
VC4GD-SEF
(With Standing Pilot)
MODEL
GAS DATA

– 8 –
VENT SYSTEM
DO NOT obstruct theflow of flue gases fromthe flue located onthe rear of theoven. It is recommended
that the flue gases be ventilated to the outside of the building through a ventilation system installed by
qualified personnel.
Ovens may use an optional down-draft diverter flue method. This optional down-draft diverter must be
purchased from the oven manufacturer and vented to the outside; otherwise, the installation of any
such device will void all oven certifications and warranties. This oven is suitable for connection to
Type B Gas Vent when used with the draft hood provided.
From the termination of the flue to the filters of the hood venting system, a minimum clearance of
18 inches (457 mm) must be maintained.
Information on the construction and installation of ventilating hoods may be obtained from
Vapor
Removal from Cooking Equipment
, NFPA Standard No. 96 (latest edition), available from the National
Fire Protection Association, Batterymarch Park, Quincy, MA 02269.
ELECTRICAL CONNECTIONS
Electrical and grounding connections must comply with the applicable
portions of the National Electrical Code and/or other local electrical codes.
Appliances equipped with a flexible electric supply cord are provided with
a three-prong grounding plug. It is imperative that this plug be connected into a properly
grounded three-prong receptacle. If the receptacle is not the proper grounding type,
contact an electrician. Do not remove the grounding prong from this plug.
VC series ovens with 120 V/60 Hz/1 PH electrical specification are equipped with a cord and plug as
standard equipment.
A wiring diagram is located on the inside of the control housing.
ATADLACIRTCELE
sledoMHP/zH/V yticapmAtiucriCmuminiM eciveDevitcetorPmumixaM SPMA
DG4CV DG6CV
1/06/021 1/06/802 1/06/042 1/05/042 3/05/)W3(083/022 3/05/)W4(083/022 3/05/)W4(514/042 51515151515
151
.)noitidetsetal(07-APFN,edoClacirtcelElanoitaNehthtiwecnadroccanidelipmoC
Insufficient air will cause flames to burn with a yellow tip and result in carbon accumulation in the flame
chamber and heat exchanger tubes.
Contact your local Vulcan-Hart servicer if required.
VC4GD
VC6GD
VC4GC
VC6GC

– 9 –
OPERATION
The oven and its parts are hot. Use care when operating, cleaning or
servicing the oven.
CONTROLS (Models VC4GD and VC6GD Without Roast & Hold)
THERMOSTAT
HI
LO
MASTER SWITCH
OFF
HEAT
ON
IGNITION
OVEN COOL
ON
TIMER
OFF
ON
OFF
LIGHTS
FAN SPEED
LO
150
150
225
250
275
300
325 350 375 200
400
425
450
250
475
500
F
100 C
PL-53547
1
2
3
4
5
0
LIGHTING INSTRUCTIONS
SHUTDOWN INSTRUCTIONS
TURN GAS AND MASTER SWITCH "OFF"
TURN GAS "ON"
PUSH MASTER SWITCH "ON"
IF BURNER FAILS TO LIGHT
TURN GAS "OFF"
WAIT 5 MINUTES FOR RETRIAL
OFF
45
50
55
60
40 35 30
25
20
15
10
5
0
PL-53562
HI
LO
TIMER
ON
OFF
LIGHTS
FAN SPEED
LO
THERMOSTAT
MASTER SWITCH
OFF
HEAT
ON
IGNITION
OVEN COOL
ON
150
150
225
250
275
300
325 350 375 200
400
425
450
250
475
500
F
100 C
LIGHTING INSTRUCTIONS
SHUTDOWN INSTRUCTIONS
TURN GAS AND MASTER SWITCH "OFF"
TURN GAS "ON"
PUSH MASTER SWITCH "ON"
IF BURNER FAILS TO LIGHT
TURN GAS "OFF"
WAIT 5 MINUTES FOR RETRIAL
Master Switch ON — Turns oven control circuits on.
OFF — Turns oven control circuits off.
OVEN COOL — Allows the fan motor to run with the doors ajar to speed ovencooling.
On Light (Amber) — Lit when Master Switch is ON.
Heat Light (White) — Comes on and goes off when the burner cycles on and off.
Ignition Light (Red) — Comes on if burner fails to ignite. When lighting the oven, the IGNITION
light flashes.
Thermostat — Controls oven temperature during cooking operation.
Timer (1 Hr. or 5 Hr.) — Sets the bake time. Buzzer sounds continuously after timer counts down
to0. Ovendoesnotturnoff.TurnTimertoOFFtostopbuzzer.Whenoven
is not in use, keep Timer at OFF position.
Fan Speed Switch — Allows you to select HI or LO Fan Speed.
Lights Switch — Turns the lights in the oven ON or OFF.

– 10 –
CONTROLS (Models VC4GD and VC6GD With Roast & Hold)
OFF
150
150
225
250
275
300
325 350 375 200
400
425
450
250
475
500
F
100 C
THERMOSTAT
1
2
3
4
5
0
PL-53551
ON
OFF
LIGHTS
NORMAL
R & H
FUNCTION
MASTER SWITCH
OFF
HEAT
ON
IGNITION
OVEN COOL
ON
TIMER
OFF
45
50
55
60
40 35 30
25
20
15
10
5
0
R & H TIMER
1
2
3
4
5
OFF
0
PL-53550
ON
OFF
LIGHTS
R & H
FUNCTION
1
2
3
4
5
0
NORMAL
OFF
TIMER
150
150
225
250
275
300
325 350 375 200
400
425
450
250
475
500
F
100 C
THERMOSTAT
MASTER SWITCH
OFF
HEAT
ON
IGNITION
OVEN COOL
ON
R & H TIMER
Master Switch ON — Turns oven control circuits on.
OFF — Turns oven control circuits off.
OVEN COOL — Allows the fan motor to run with the doors ajar to speed ovencooling.
On Light (Amber) — Lit when Master Switch is ON.
Heat Light (White) — Comes on and goes off when the burner cycles on and off.
Ignition Light (Red) — Comes on if burner fails to ignite. When lighting the oven, the IGNITION
light flashes.
Thermostat — ControlsoventemperaturewhenFunctionswitchison NORMALorduring
the first stage of Roast & Hold.
R & H Timer — Sets the first stage cooking time in Roast & Hold.
Timer (1 Hr. or 5 Hr.) — Sets the bake time when Function switch is on NORMAL. Buzzer sounds
continuously after timer counts down to 0. Oven does not turn off at end
of cycle. Turn Timer to OFF to stop buzzer. When oven is not in use, keep
timer at OFF position.
Function Switch — Allows you to select Normal or Roast & Hold (R & H).
Normal: Uses the regular timer and high fan speed.
R & H: Uses the R & H Timer for the first stage of roasting at the
thermostat setting, selects a hold temperature of 160°F (71°C) during
second stage roasting. Uses low fan speed when burners are on.
Lights Switch — Turns the lights in the oven ON or OFF.

– 11 –
ON — Turns oven control circuits on.
OFF — Turns oven control circuits off.
SHABBOS — Puts oveninSabbathmodeallowingoven tooperatewhendoors areopen.
On Light (Amber) — Lit when Master Switch is ON or in Shabbos mode.
Heat Light (White) — Lit when thermostat calls for more heat.
Thermostat — Controls oven temperature during cooking operation.
Timer (1 Hour) — Sets the bake time. Buzzer sounds continuously after timer counts down
to0. Ovendoesnotturnoff. TurnTimertoOFFtostopbuzzer.Whenoven
is not in use, keep timer in OFF position.
Fan Speed — Allows you to select HI or LOW Fan Speed.
Lights Switch — Turns the oven lights ON or OFF.
CONTROLS (Model VC4GD-SEF)
(With Standing Pilot)
Master Switch

– 12 –
BEFORE FIRST USE
Beforeusingtheoven forthefirst time,itmust be"burnedin" toreleaseany odorsthatmight resultfrom
heating the new surfaces in the chamber.
1. Using a clean, damp cloth, wipe the inside of the oven including the racks.
2. Close the oven doors.
3. Push the Master Switch to ON.
4. Turn the Thermostat to 300°F (149°C) and allow the oven to cycle for 2 hours or until no odor is
detected before pushing the Master Switch to OFF.
LIGHTING MODEL VC4GD AND VC6GD OVENS
1. Turn the main gas supply ON.
2. Push the Master Switch to ON.
3. If the burner fails to light, push Master Switch OFF. Wait 5 minutes for retrial.
If the oven does not light after three trials, turn off the main gas valve and call a qualified servicer.
SHUTDOWN INSTRUCTIONS
1. Turn Master Switch to OFF.
EXTENDED SHUTDOWN
1. Push Power Switch to OFF.
2. Turn gas and electrical power supplies OFF.
USING MODEL VC4GD AND VC6GD OVENS
Preheating
1. Selecttheproperrackarrangementfortheproducttobecooked.RefertoRACKARRANGEMENTS,
page 18.
2. Make sure the doors are closed.
3. Push Master Switch to ON. The amber ON light will come on, indicating that power to the oven
is on.
4. Set the two-speed FAN SWITCH to the desired setting (without Roast & Hold models).
5. Set thermostat as desired. The HEAT light will come on and remain on until the oven reaches set
temperature (approximately 10 to 15 minutes for settings from 300 to 400°F (149 to 204°C)).
RefertoSUGGESTEDCOOKINGGUIDELINESfortemperaturesandtimesforvariousproducts.
If the burner fails to light, the red IGNITION light will come on and remain on.
6. Prepare product and place in suitable pans. When the white HEAT light goes off, the oven has
reached the desired preheat temperature.

– 13 –
LIGHTING OVEN (Model VC4GD-SEF)
(With standing pilot)
The oven fan continues to run when the oven door is opened. The oven
contains hot air and steam. Stay clear while opening the door.
1. Turn on main gas supply.
2. With Master Switch in OFF position, lift access door in lower trim, light pilot while holding red
button on control panel.
3. Keep holding button for 30 seconds after pilot ignites.
4. Once steady pilot flame in achieved, close access door.
5. Set to desired temperature and fan speed.
6. Turn Master Switch to ON for weekly operation or SHABBOS for Sabbath Mode operation.
SHUTDOWN INSTRUCTIONS
1. Turn Master Switch to OFF position.
EXTENDED SHUTDOWN
1. Turn Master Switch to OFF position.
2. Turn main gas and electrical power supplies off.

– 14 –
Cooking
1. Opendoorsandloadtheproductintotheoven.Placepansinthecenteroftheracks.Closedoors.
2. Set the Timer. After the preset time lapses, turn Timer to OFF position to stop alarm.
3. When product is done, open doors and carefully remove cooked product from the oven. Care
should be taken when wiping up spills, as oven is still hot.
Roast & Hold (When Equipped)
1. Turn the oven ON.
2. Set the Thermostat to the desired setting.
3. Position the Function switch to R & H.
4. Set the R & H TIMER to the desired roasting time.
• The oven will roast the product for the chosen set time and temperature. The oven controller
will automatically switch from the roasting thermostat to the holding thermostat at the end of
thepresetroastingtime.Inholdingmodethe ovenwillmaintainatemperatureof160°F(71°C)
until the oven is turned off. The blower fan will run while the burner is on and the unit is
operating in R & H.
5. To turn Cook & Hold off, flip the Function switch to the NORMAL position. The oven temperature
will return to the thermostat setting.
End of Day
1. Turn Thermostat to OFF setting.
2. Push Master Switch to OVEN COOL. Leave door ajar while the fan is on to cool the oven.
3. When oven has cooled sufficiently, flip Master Switch to OFF.
4. Turn gas valve to OFF and clean oven.
Extended Shutdown
Repeat Steps 1 through 3 of End of Day. Unplug oven and shut off manual gas valve.
CONSERVING ENERGY— ALL MODELS
• Turn off unused equipment.
• Adjust menu patterns and cooking/baking schedules for optimum equipment use.
• Reduce thermostat settings in slack periods since gas equipment heats up and recovers quickly.
• Preheat only to required cooking temperature for specific food — not higher.
• Do not open the oven door unless absolutely necessary.
• Keep area around the oven door clean and free of food particles.
• Anyobstructionthatpreventsthedoorfromclosingcompletelywilladverselyaffectovenefficiency.

– 15 –
ROAST & HOLD OPERATION — (When Equipped)
Roast & Hold cooks the product in two stages. During first-stage cooking, the oven temperature is
regulatedbythetemperaturesetpointandtheR&HTimersetting. Afterthetimecountsdownto00:00,
second-stage cooking begins. During second-stage cooking, the heat is off as the temperature in the
oven declines to the hold temperature. The doors should remain closed during second-stage cooking.
Whentheholdtemperatureisreached,theoventemperaturewillbemaintainedattheholdtemperature
until the oven is turned off.
400ºF
300ºF
200ºF
100ºF
ROAST AND HOLD DIAGRAM - Time vs. Temperature
SHORT BEEP.
TIMER DISPLAYS "HOLD."
ROAST THERMOSTAT OFF.
HEATERS OFF UNTIL HOLD
TEMPERATURE IS REACHED.
HEATERS MAINTAIN
HOLD TEMPERATURE.
TIMER DISPLAY FLASHES
"HOLD."
OVEN TEMPERATURE
TIMER DISPLAY COUNTS DOWN.
COOKING FROM
STORED HEAT
LOAD PRODUCT
INTO OVEN
PRODUCT TEMPERATURE
TEMP.
TIME
PREHEAT FIRST-STAGE COOKING SECOND-STAGE
COOKING
(DO NOT OPEN
DOORS)
HOLDING
PL-56291
PROPER UTENSILS
The use of proper utensils can enhance oven operation. Medium and light weight pans allow the
product to warm faster. Roast meats in shallow pans deep enough to hold all juices yet allow free air
circulation.
OPERATING HINTS
When using the convection oven for the first time with a particular food, check the degree of doneness
periodicallybefore the suggested time has elapsed.Thiswill ensure the desired doneness isachieved.
Record your temperature and time settings for various products. The convection oven can provide
consistent and repeatable results.
The convection oven is faster than conventional deck-type ovens; temperature settings are lower and
cook times are shorter. Since recipes and foods are subject to many variations and tastes, the
guidelines regarding times and temperatures in this manual are SUGGESTIONS ONLY. Experiment
withyourfood productsto determinethecooking temperaturesand timesthat giveyouthe bestresults.
204°C
149°C
93°C
38°C

– 16 –
PROGRAMMABLE CONTROLS (Models VC4GC AND VC6GC)
Always displays [HR:Min] when setting the time.
Displays [HR:Min] if the countdown time is more than 1 hour.
Displays [Min:Sec] if the countdown time is less than 1 hour.
Displays temperature in °F.
R & H
MODE
Indicates the oven is in the Roast & Hold Mode.
OVEN
READY
Indicates the oven is preheated and ready for cooking.
OVEN
HEATING
Indicates the oven is preheating or burners have cycled on to
maintain temperature setting.
PRIMARY
Primary indicates menu items 1, 3 or 5.
SECONDARY
Secondary indicates menu items 2, 4 or 6.
Up arrow increases and Down arrow decreases a displayed
time or temperature value (if arrow keys are lit).
TEMPERATURE: Use with SET to set the oven temperature.
SET
SET: Use with time or temperature.
TIME: Use with SET to manually set the cooking time.
ROAST
&
HOLD
Selects Roast & Hold mode; also selects low fan speed.
START
STOP
Press once to start; press a second time to stop.
1/2
3/4
5/6
Select Menu Cook Times. Press once for primary (1, 3 or 5).
Press a second time for secondary (2, 4 or 6). See next page.
1
2
3
4
5
Rack Buttons select individual Menu/Rack Number Cook
Times — once programmed.

– 17 –
MANUALLY SETTING THE TEMPERATURE AND COOK TIME
To Set the Temperature
1. Press the SET button. Press the TEMPERATURE button; StPt displays to indicate Setpoint.
2. Use the Up and Down arrow keys to increase or decrease the displayed temperature value.
3. Press the SET button again to save the temperature setpoint in the computer.
To Set the Cook Time
1. Press the SET button. Press the TIME button. Tine displays to indicate time.
2. Use the Up and Down arrow keys to increase or decrease the displayed cook time (HR:Min).
3. Press the SET button again to save the time setting in the computer.
To Start Cooking
1. Press the START/STOP button.
2. The manual Cook Time counts down to 00:00. Displays [HR:Min] above 1 hour; [Min:Sec] below.
3. The buzzer will sound. To silence the buzzer, press the START/STOP button again.
4. The control retains the manual settings for temperature and time.
TO PROGRAM MENU ITEM AND RACK NUMBER COOK TIMES
Factory-Preset and Programmable Cook Times are shown in the table, below:
UNEM NOITCELES UNEM METI
TESERP-YROTCAF METIUNEM EMITKOOC
SEULAVELBAMMARGORP
METIUNEM EMITKOOC 1KCAR EMITKOOC 2KC
AR EMITKOOC 3KCAR EMITKOOC 4KCAR EMITKOOC 5KCAR EMITKOOC
yramirP2/11.nim01
yradnoceS2/12.nim51
yramirP4/33.nim02
yradn
oceS4/34.nim52
yramirP6/55.nim03
yradnoceS6/56.nim53
The PRIMARY indicator light with MENU 1/2 selects Menu Item 1 (Factory-Preset Cook
Time = 10 minutes).TheSECONDARYindicatorlightwithMenu1/2selectsmenuitem2(Factory-Preset
Cook Time = 15 minutes). This is similar for MENU Buttons 3/4 or 5/6. Any menu item cook time can
be changed using the procedure below. Rack number cook times may be programmed if desired but
are not required.
To Change the Time Setting for any Menu Item (1 – 6)
1. To enter program mode, press and hold the Up and Down arrow buttons until PrOG displays.
2. Select the menu item to be programmed (1 – 6). Tine displays to indicate time. Use the Up and
Down arrow buttons to increase or decrease the Menu Item's COOK TIME. Repeat this step for
any other menu items.
3. Press the START/STOP button; LOC displays. Press the START/STOP button a second time
to save the Menu Item(s)' COOK TIME(s).
4. Press the START/STOP button once to begin cooking (with the Menu Item's Cook Time). To exit,
press the START/STOP button a second time.
To Program Individual Rack Number Cook Times for a Menu Item
1. To enter program mode, press and hold the Up and Down arrow buttons until PrOG displays.
2. Select the Menu Item to be programmed (1 – 6); Tine displays to indicate time.
3. Then select the rack number (1 – 5). [t 1] indicates rack 1; [t 2] indicates rack 2 and so on. Use
the Up and Down arrows to increase or decrease the cook time for any rack number.
NOTE: All rack times can be preprogrammed before pressing the START/STOP button to lock.
4. Press the START/STOP button; LOC displays. Press the START/STOP button a second time to
save the Menu/Rack Number's COOK TIME(s).
5. To exit program mode, press START/STOP twice.

– 18 –
Always Set the Temperature Before Setting the Time
1. Open the door; door will display.
2. Place the desired product on any of the five racks.
3. Close the door. The display should return to the set temperature or the GROWING BAR.
4. Press the MENU key once for primary or twice for secondary to select a menu item cook time.
5. Press the START/STOP button. Pressing the START/STOP button after making a menu
selection will time all racks for the selected menu time.
6. The timer will count down the time remaining for the Menu Item Cook Time.
7. When the time has counted down to 00:00, the buzzer will sound and all Rack Buttons will flash.
8. To silence the buzzer, press the START/STOP button.
Starting a Timed Cycle Using Programmed Individual Menu/Rack Number Cook Time(s)
1. After the set temperature is reached, open the door; door displays. Place product(s) in oven.
2. Close the door. The display returns to the set temperature or the GROWING BAR.
3. Select the menu item (once for primary or twice for secondary) and the Rack Number to select
the Menu/Rack Number Cook Time. If using simultaneous cook times, select the other Menu/
Rack Numbers.
4. The timer selects the rack number with the shortest cook time and counts down to 00:00.
5. The buzzer sounds and the rack number flashes. To silence the buzzer, press the flashing Rack
Number.
6. Open the door; door displays. Remove the finished product and close the door.
7. The next shortest cook time displays, its rack number flashes and the time counts down to 00:00.
8. Thebuzzer sounds.Press the flashingRack Number. Openthe door;door displays. Removethe
product and close the door.
9. Repeat steps 7 and 8 until all rack numbers are done.
To Display the Actual Oven Temperature
1. Press and hold the TEMPERATURE button for 3 seconds to display actual oven temp until
released.
To End a Cooking Cycle
Attheendofacookingcycle,thebuzzerwillsound. Tosilencethebuzzerandendamenuitemcooking
cycle, press START/STOP. To silence the buzzer and end a rack number cooking cycle, press the
Rack Number.
To cancel a cooking cycle which might have been started in error, press and hold the Rack Number
button to be terminated and press START/STOP at the same time.
Door and Timing
Openingthedoorwhileloadingadditionalproductwillinterruptalltimingfunctionsuntilthedoorisclosed
and the timer resumes. For example, if a product time had diminished to 1 minute and the door was
opened for 30 seconds and then closed, the timer would still show 1 minute.

– 19 –
RACK ARRANGEMENTS
All models are supplied with five racks and have a maximum operating capacity of six racks per oven.
The 11-position rack supports provide for maximum flexibility and proper rack spacing.
Thefollowingarrangementsarerecommended.Theposition
numbers are in numerical sequence starting at the bottom
(Fig. 4).
Arrangement #1 — Five racks in positions #2, #4, #6, #8
and #10 for cookies or reconstitution of frozen lunches at
maximumcapacity.Alsorecommendedpositionforgeneral
baking in sheet pans with products not over 21/2inches
(64 mm) high.
Arrangement #2 — Four racks in positions #1, #4, #7 and
#10 for general baking in sheet pans, muffin pans, pie or
cake tins and pudding pans 31/2inches (89 mm) high with
productsnotover4inches(102mm)high.Thisarrangement
can also be used for casseroles or meat dishes in #200
seriesfood servicepans 12 x20 x21/2"(305x 508 x64 mm).
Arrangement #3 — Three racks in positions #1, #5 and #9 for baking breads or cakes in loaf or tube
pans and high meringue pies. This arrangement can also be used for casseroles, meat dishes or
roasting in pans up to 51/2inches (140 mm) deep with products up to 6 inches (152 mm) high.
Arrangement#4—Tworacksinpositions#1 and#6forroastingturkeysandotherroastsupto7inches
(178 mm) high.
With the rack in position #1, there is limited space for a water pan (see cooking chart in this manual).
When mixed loads or partial loading is regular practice, some users have developed other rack
arrangements to suit their particular needs.
Fig.4
PL-52806
#1
RACK POSITION
#2
#3
#4
#5
#6
#7
#8
#9
#10
#11
SETTING THE OVEN FOR ROAST & HOLD
1. Press the ROAST & HOLD button to select roast & hold.
2. Set the first stage temperature and the cook time as described in MANUALLY SETTING THE
TEMPERATURE AND COOK TIME. Press START/STOP to begin cooking.
3.
The roast temperature is preset by the computer control at 150°F (66°C).
4. The low fan speed is present during Roast & Hold. Use Roast & Hold to select low fan speed.
ROAST & HOLD OPERATION — (When Equipped)
Roast & Hold roasts the product in two stages. During first-stage cooking, the oven temperature is
regulated by the temperature setpoint and the time setting. After the time counts down to 00:00,
second-stage cooking begins. During second-stage cooking, the heat is off as the temperature in the
oven declines to the hold temperature. The doors should remain closed during second-stage cooking.
WhentheHoldtemperatureisreached,thedisplayflashesHOLD(onovensequippedwithProgrammable
Controls only). Temperature in the oven will be maintained at the hold temperature until the oven is
turned off.

– 20 –
SPECIAL PROCEDURES FOR BAKING
When baking yeast breads, cooking starts immediately in the convection oven. Yeast breads do not
usually rise as much in a convection oven as in a conventional oven. Therefore it is usually necessary
to allow fuller proof, 21/2to 3 times increase in volume, for best results.
When baking pies in your convection oven, three or four pies should be put on an 18 x 26" (457 x 660 mm)
sheet or bun pan. This procedure helps the bottom crust to bake, makes handling easier and reduces
the possibility of boilover spoiling the appearance of the pies on the lower racks.
HIGH LIMIT SWITCH
All ovens are equipped with a high limit switch, which senses the temperature of the oven to prevent
overheating. The high limit switch operates independently and will automatically shut the oven down
should the primary control fail. If this situation occurs, DO NOT attempt to bypass the high limit. Shut
the oven down and contact your local Vulcan authorized service agency.
