SPECIFICATIONS:
65 - 70 lb. capacity free standing gas fryer, Vulcan-Hart Model
No. (1G6BD) Solid State knob controls located behind the door.
200°F to 390°F. Maintains +/- 2° F yields quick recovery. Both
Fahrenheit and Celsius scales. Electronic ignition standard.
Stainless steel Cabinet. Set of four 6" adjustable casters (2
locking). Stainless steel fry tank with four heat exchanger
tubes and a "V" shaped large cold zone. Twin fry baskets with
plastic coated handles. 150,000 BTU/hr. input. Built in flue
deflector. Drain extension and holder mounted on inside of door.
Tank brush, stainless steel crumb scoop and clean-out rod.
Overall dimensions: 21"w x 301/4"d x 471/8"h. Working
height 361/4".
CSA design certified. NSF listed.
SPECIFY TYPE OF GAS WHEN ORDERING.
Natural Gas
Propane Gas
SPECIFY ALTITUDE WHEN:
MODEL: 1G6BD SERIES FREE STANDING GAS FRYER
1G6BD SERIES
FREE STANDING GAS FRYER
Model 164BD
1G6BD: Solid state temperature control behind the door.
Knob set temperature from 200° to 390°F. Two melt
cycles. Electronic ignition.
STANDARD FEATURES
Stainless steel fry tank, 65 - 70 lb. capacity.
Solid State knob controls located behind the door. 200°F to
390°F. Maintains +/- 2° F yields quick recovery.
Both Fahrenheit and Celsius scales.
Electronic Ignition.
Two melt modes - liquid and solid.
Stainless steel cabinet.
Large cold zone area.
Set of four 6" adjustable casters (2 locking).
Twin fry baskets with plastic coated handles.
150,000 BTU/hr. input.
Built in flue deflector.
Drain extension and holder mounted on inside of door.
Hi-limit shut-off.
Combination gas shut-off valve.
Tank brush, stainless steel crumb scoop and clean-out rod.
1 year limited parts and labor warranty. 12 year full replace-
ment tank warranty.
ACCESSORIES
FRYMATE VX21 add-on frymate.
Stainless steel tank cover.
Grease protector strips.
11/4" Rear Gas Manifold Pipe with Shutoff Valves to connect
single fryers in the field - up to four
Single large basket - 183/4"w x 131/4"d x 51/2"h.
Set of twin baskets - 91/4"w x 131/4"d x 6"h.
Set of tri-baskets - 51/2"w x 11"d x 41/2"h.
3/4" Flexible gas hose with quick disconnect.
OPTIONS
Second year extended limited parts and labor warranty.
Natural Gas for above 2000 ft
Propane Gas for above 3500 ft.
FILTRATION
Available with our KleenScreen PLUS® filtration system with
multiple fryers and/or Frymate™ dump station..

Printed On Recycled Pap
er
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. [phone]
502-778-2791 QUOTE & ORDER FAX: [phone]
NOTE: In line with its policy to continually improve its products, Vulcan-Hart Company reserves the right to change materials and
specifications without notice.
F-32936 (4-08)
1G6BD SERIES
FREE STANDING GAS FRYER
IMPORTANT
1. A combination valve with pressure regulator is provided with
this unit.
Natural Gas 4.0" (102 mm) W.C.
Propane Gas 10.0" (254 mm) W.C.
2. An adequate ventilation system is required for Commercial
Cooking Equipment. Information may be obtained by writing
to the National Fire Protection Association, Batterymarch
Park, Quincy, MA 02269. When writing refer to NFPA No. 96.
3. All models require a 6" (152 mm) clearance at both sides and
rear adjacent to combustible construction.
OVERALL WORKING TANK FRY COMP. APPROX.
MODEL WIDTH DEPTH HEIGHT HEIGHT SIZE BTU/HR. CAPACITY SHP.WT.
1G6BD 21 30
1
/ 4 "47
1
/ 8 "36
1
/ 4 "19
1
/ 2 " x 14" 150,000 65 - 70 lbs. 275 lbs.
4. All models require a 16" (407 mm) minimum clearance to
adjacent open top burner units.
5. This appliance is manufactured for commercial installation
only and is not intended for home use.
SERVICE CONNECTIONS:
P1 1/2" (13 mm) rear gas connection (single units).
E1 115 volt cord & 5-15P NEMA plug supplied with fryers.
