Vulcan-Hart GHF91G User manual




 
A2780
ISO9001
Vulcan-Hart Co.

:
45 lb. capacity heavy duty gas range match fryer, Vulcan-Hart
Model No. GHF91G with millivolt control system. Temperature
adjusts from 200° to 400°F. Stainless steel front top ledge. 6"
adjustable nickel plated, noncorrosive legs. 11/4" diameter front
gas manifold. Stainless steel fry tank with 1" full port drain valve.
Four 30,000 BTU/hr. cast burners with pilot ignition system,
120,000 BTU/hr. total input. Four heat exchanger tubes posi-
tioned for easy cleaning. Hi-limit shut-off. Twin fry baskets with
plastic coated handles.
Exterior dimensions: 17"w x 391/8"d x 36" working height on
6" legs.
CSA design certified. NSF listed.






�Stainless steel front top ledge.
�6" adjustable stainless steel legs.
�11/4" diameter front gas manifold.
�Stainless steel fry tank, 45 lb. capacity.
�1" full port ball type drain valve.
�Four 30,000 BTU/hr. cast burners with pilot ignition system,
120,000 BTU/hr. total input.
�Four heat exchanger tubes positioned for easy cleaning.
�Millivolt control system. Thermostat adjusts from 200° to
400°F.
�Hi-limit shut-off.
�Twin fry baskets with plastic coated handles.
�One year limited parts and labor warranty.

�Cap and cover manifold end(s).
�15/8" stainless steel toe base - 315/8" working height.
�1/2" or 3/4" rear gas connection.
�Second year extended limited parts and labor warranty.

�17" high stainless steel backguard. (Common backguards
available up to 102" wide.)
�Extra set of twin baskets. (61/2"w x 131/4"l x 51/2"d.)
�Large single basket. (13"w x 131/4"l x 51/2"d.)
�Gas pressure regulator (specify size and type of gas).
�Flexible gas hose with quick disconnect and restraining
device. Consult price book for available sizes.
o
o
o
o
o
o
o
o
o

Printed On Recycled Paper

 
 In line with its policy to continually improve its products, Vulcan-Hart Company reserves the right to change materials and
specifications without notice.


1. A gas pressure regulator suitable for battery or single
unit application must be furnished and installed. Natural
gas 4.0" W.C., propane gas 10.0" W.C.
2. An adequate ventilation system is required for commercial
cooking equipment. Information may be obtained by
writing to the National Fire Protection Association,
Batterymarch Park, Quincy, MA 02269. When writing refer
to NFPA No. 96.
3. These units are manufactured for installation in
accordance with ANSZ223.1a (latest edition), National
Fuel Gas Code. Copies may be obtained from the
American Gas Association, 1515 Wilson Blvd., Arlington,
VA 22209.


   
      
       
17" 391/8" 36" 14" 14" 45 lbs. 120,000 225/102
4. All models require a 6" clearance at both sides and rear
adjacent to combustible construction.
5. For proper flueing, a backguard must be installed with
each unit.
6. This appliance is manufactured for commercial installation
only and is not intended for home use.
