Vytronix JETW1800 User manual

1
Important safety instructions
x WARNING: High pressure jets can be dangerous if subject to misuse. The jet
must not be directed at any person or animal, live electrical equipment, or
the appliance itself.
x It is forbidden in the UK to clean surfaces containing asbestos with high
pressure equipment.
x The appliance is designed solely for outdoor domestic use and NOT for
commercial use.
x The recommended distance between the nozzle and surface to be cleaned is
at least 30cm.
x It is your responsibility to check the suitability of surface to be cleaned,
Vytronix cannot be held responsible for any damage caused by use.
x Please keep the appliance away from open fires and heat sources, do not
leave exposed for prolonged periods of time to direct sunlight and avoid
exposure to rain, snow or frost.
x Do not leave the appliance plugged in while unattended or not in use.
x Use only as described in this manual and use only the included attachments.
x Do not use if the cord or plug are damaged. If the appliance is not working as
it should, has been dropped, damaged, left exposed to or submersed in water,
please contact Vytronix.
x Do not pull or carry by the cord, use the cord as a handle, close doors on the
cord, or pull the cord around sharp edges or corners.
x Do not unplug by pulling on the cord. To unplug, grasp by the plug.
x Do not handle the plug with wet hands.
x Do not put any foreign object into openings.
x Keep hair, loose clothing, fingers and all parts of body away from openings to
avoid risk of injury.
x Turn all controls off before unplugging.

2
x If the power cord is damaged, it must be replaced only by Vytronix to
comply with warranty terms and conditions.
x Do not let children or people who have not been trained in the use of a
pressure washer nor read the instruction manual operate the machine
unless properly supervised by a responsible adult.
x Before starting up your machine please check it carefully for any defects.
If you find any, do not start up your machine and contact Vytronix
immediately.
x Hold the pressure gun and lance firmly with both hands.
x The operator and anyone in the immediate vicinity of the site of
cleaning should take action to protect them from being struck by debris
dislodged during operation.
x Wear goggles or other eye protection during operation.
x Take special care when pointing at tyres and/or tyre valves as they
may be damaged by the high-pressure jet, causing them to burst.
x This pressure washer must not be used at temperatures below 0°C.
ELECTRICAL CONNECTION
If an extension cable is used, the plug and the socket must be waterproof and
comply with the below mentioned requirements for length and cable dimensions.
x 1.0 mm² max. 12.5 m
x 1.5 mm² max. 20 m
WATER CONNECTION
x Connection to the public mains water supply according to local regulations.
x Inlet connection can be connected to mains water supply with a max pressure
of 10 bars.
IMPORTANT!
Only use water without any impurities. If there is a risk of sand particles in the
inlet water (i.e. from your own well), an additional filter should be mounted.

Gun and accesories assembly

Max.Flow 8.0l/min

6
Push the lance into the trigger gun
When inserted turn it. Caution: Make sure
the lance is properly fixed to the gun
Attach the nozzles. Caution: When
attaching the nozzle the button (A) on the
nozzle should come out again. Check
before activating the trigger that the
nozzle is properly fixed.
Use a reinforced hose (not supplied) with a
standard connection (ext. diameter:
16mm/int. 12mm, maximum length: 25m).
IMPORTANT! Only use water without
any impurities. If there is a risk of sand
particles in the inlet water an additional
filter should be mounted.
Let the water run through the water hose
before connecting it to the machine to
prevent sand and dirt from penetrating the
machine. Note: Check that the filter is
fitted in the water inlet pipe and that it is
not clogged up.
Connect the water hose to the water supply
by means of the quick connector (inlet
water, max. pressure: 10 bar, max.
temperature: 60°C).
Turn on the water.
The trigger gun (1) and lance is affected by
a thrust during operation - therefore always
hold it firmly with both hands.
IMPORTANT: Point the nozzle at the
ground.
Check that the machine is in upright
position. NOTE: Do not place the appliance
on uneven ground.
Release the trigger lock.
Activate the trigger of the trigger gun (1)
and let the water run until all air has
escaped from the water hose.
Press the Start/stop switch (5).
Activate the trigger of the trigger gun (1).
Always adjust the distance and thus the
pressure of the nozzle to the surface, which
is to be cleaned.
Do not cover the machine during operation
or use it in a room without adequate
ventilation.
NOTE: If the machine is left or not used
for 5 minutes, it must be switched off on
the start/stop switch (5) "O":
Press the start/stop switch (5) "O".
Disconnect the electrical plug (9) from
the socket.
Shut off the water supply and activate
the trigger of the trigger gun (1) to
relieve the machine of pressure.
Lock the trigger gun (1)
When releasing the trigger of the trigger
gun (1), the machine automatically stops.
The machine will start again when you re-
activate the trigger gun (1)
Mounting of lance and nozzle
Water connection
Start/stop
1
2
A
3

7
The pressure on the multi-nozzle can be
adjusted by tuning it. WARNING: Do not
do this under operation to avoid injury.
The machine should be stored in a frost-free
room.
Pump, hose, and accessories should always
be emptied of water prior to storing as
follows:
Stop the machine (press the start/stop
switch “O”and detach water hose, high
pressure hose and nozzle
Restart the machine and activate the trigger
of the trigger gun. Let the machine run until
no more water runs through the trigger gun
Stop the machine, unplug, and wind up hose
and cable.
Place trigger gun, lance, nozzles, and other
accessories in the holders of the machine.
The hook can be used for storage of the
hose and cord. All accessories can be stored
on the washer after using.
WARNING: Never start up a frozen
machine.
WARNING! Always disconnect the
electrical plug from the socket prior to
maintenance or cleaning.
To prolong the life of your appliance please
ensure regular maintenance is carried out as
below:
Wash out water hose, high pressure hose,
spray lance and accessories before
mounting.
Clean the connectors of dust and sand.
Rinse the detergent spraying attachment
after use.
Clean the nozzles.
If the appliance is not working, please
follow the troubleshooting steps below.
Please contact Vytronix Ltd for any
maintenance advise.
Clean the water inlet filter regularly once a
month or more frequently according to use.
Carefully loosen the filter with a
screwdriver and clean it. Check that it is
intact before re-mounting it.
The inlet filter must always be fitted inside
the water inlet pipe to filter out sand,
limestone, and other impurities, as they will
damage the pump valves.
CAUTION: Failure to fit the filter can
cause damage to this appliance.
The appliance should be kept clean so as to
let cooling air pass freely through the
machine vents. These can be wiped with a
dry cloth.
To ensure an easy connection and that O-
rings do not dry up; the couplings should be
greased regularly.
Multi Nozzle
After using the appliance
Maintenance & cleaning
Cleaning of inlet filter
Greasing of couplings
Cleaning of air vents

8
Symptom
Cause
Recommended action
The machine will not
start
The machine is not plugged-in
Plug the machine in
The fuse has blown
Replace the fuse Unplug other appliances
Faulty extension cable
Try without the extension cable
Fluctuating pressure
The pump is drawing in air
Check that hoses and connections are airtight.
Valves dirty, worn or sticking
Contact Vytronix Ltd
The water supply is not
sufficient
Increase water pressure, check for blockages
and / or change the large pipe.
Pump seals worn
Contact Vytronix Ltd
The machine stops
The fuse has blown
Replace the fuse
Incorrect mains voltage
Unplug other appliances
Check that the mains voltage corresponds to the
specifications on the rating label.
Thermal sensor activated
Leave the machine to cool for 5 minutes
Partially blocked jet
Clean the jet with a needle and by spraying
water rearwardly through the jet
Fuse blown
Fuse too small
Replace it with a fuse with higher amp
consumption than the washer.
Increase in the amperage
Try without the extension cable
Pulsing machine
Air in inlet hose / pump
Allow machine to run with open trigger until
regular working pressure resumes.
Inadequate supply of water
generated
Increase water pressure, check for blockages
and / or change the large pipe.
Partially blocked jet
Clean the jet with a needle and by spraying
water rearwardly through the jet
Water filter blocked
Clean the filter
Folded pipe
Unfold the pipe
The machine turns on
and off by itself
Pump fuse and/or trigger not
working correctly
Contact Vytronix Ltd
No water supply
Connect the inflow water.
The machine is on
but no water comes
out
Water filter blocked
Clean the filter
Blocked jet
Clean the jet with a needle and by spraying
water rearwardly through the jet
Troubleshooting

9
Warranty Registration
To register you free one year Vytronix warranty visit www.vytronix.com using product
code:
brandnew-vytronix-jetw1800
Safe Disposal
This marking indicates that this product should not be disposed with other household
waste throughout the EU. To prevent possible harm to the environment or human health
from uncontrolled waste disposal, recycle it responsibly to promote the sustainable
reuse of material resources. To arrange safe disposal of your used device, please use
the return and collection systems or contact the retailer where the product was
purchased.
If you have any queries or require assistance with using your product including set up,
on 0800 121 4034

Register your warranty at www.vytronix.com
