I. INTRODUCTION
he RICON S-Series and K-Series Public Use wheelchair lifts provide wheelchair access to public use vehicles in-
cluding buses, school buses and large multi-purpose vehicles which are DOT compliant. The patented move-
ment provides a smooth, safe entry and exit and lifts up to 800 pounds (363) kilograms. It is to be operated by a
trained attendant. The lift contains a powerful electro-hydraulic pump that includes a built-in manual backup pump. If
the lift loses electrical power, it can be raised or lowered manually.
The S-Series has a solid, one-piece platform that is raised and folded into the vehicle when stowed. The platform on
the K-Series has a two-piece folding platform that splits horizontally to reduce overall lift height when stowed. This re-
sults in a less obstructed view, either into or out of the vehicle. The mechanical linkages provide smooth movement to
both non-skid platforms where the wheelchair and occupant are situated during the “Up” and “Down” lift motions.
This manual contains warranty information, installation instructions; maintenance and repair instructions; troubleshoot-
ing guide; parts and diagram lists that apply to Ricon S-Series and K-Series Public Use wheelchair lifts. It is important
to user safety that the lift operator be completely familiar with the operating instructions. Once the lift is installed, it is
very important that the lift be properly maintained by following the Ricon recommended cleaning, lubrication, and in-
spection instructions.
S-Series K-Series
A. RICON PRODUCT SUPPORT
If you have questions about this manual, or additional copies are needed, please contact Ricon Product Support at one
of the following locations:
Ricon Corporation
1135 Aviation Place
San Fernando, CA 91340........................................................................................... [phone]
Outside (818) Area Code........................................................................................... [phone]
Website..............................................................................................................www.riconcorp.com
Vapor Ricon Europe Ltd.
Meadow Lane
Loughborough, Leicestershire ....................................................................................0044 (9) 1509 635 920
LE 1HS United Kingdom
Website.................................................................................................................................www.riconuk.com
T
-PRINT- -
TABLE OF CONTENT
S
-

1 - 2
INTRODUCTION MAY 2014
32DSKL02.A.1
S-SERIES AND K-SERIES
SERVICE MANUAL
B. RICON FIVE-YEAR LIMITED WARRANTY
RICON S-SERIES AND K-SERIES PUBLIC USE WHEELCHAIR LIFTS
FIVE-YEAR LIMITED WARRANTY
Ricon Corporation (Ricon) warrants to the original purchaser of this product that Ricon will repair or replace,
at its option, any part that fails due to defective material or workmanship as follows:
• Repair or replace parts for a period of one year from the date of purchase. A complete list of parts covered
by this warranty can be obtained from Ricon Corporation.
• Labor costs for specified parts replaced under this warranty for a period of one year from the date of pur-
chase. A Ricon rate schedule determines the parts covered and labor allowed.
• Repair or replace lift powertrain parts for a period of five years from the date of purchase. A list of parts
covered can be obtained from Ricon Product Support.
If you need to return a product: Return this product to Ricon following the Ricon RMA procedure. Please
give as much advance notice as possible, and allow a reasonable amount of time for repairs.
This warranty does not cover: Malfunction or damage to product parts caused by accident, misuse, lack of
proper maintenance, neglect, improper adjustment, modification, alteration, the mechanical condition of the ve-
hicle, road hazards, overloading, failure to follow operating instructions, or acts of nature (i.e., weather, light-
ning, flood).
Note: Ricon recommends that this product be inspected by a Ricon dealer or qualified service technician at
least once every six months, or sooner if necessary. Required maintenance should be performed at that time.
WARNING
THIS PRODUCT HAS BEEN DESIGNED AND MANUFACTURED TO EXACT SPECIFICATIONS.
MODIFICATION OF THIS PRODUCT IN ANY RESPECT CAN BE DANGEROUS.
This warranty is void if:
• The product has been installed or maintained by someone other than a Ricon dealer or qualified service
technician.
• The product has been modified or altered in any respect from its original design without written authoriza-
tion by Ricon.
Ricon disclaims liability for any personal injury or property damage that results from operation of a Ricon product that
has been modified from the original Ricon design. No person or company is authorized to change the design of this
Ricon product without written authorization by Ricon.
Ricon's obligation under this warranty is exclusively limited to the repair or exchange of parts that fail within the appli-
cable warranty period.
Ricon assumes no responsibility for expenses or damages, including incidental or consequential damages. Some
states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or ex-
clusion may not apply.
Important: The warranty registration card must be completed and returned to Ricon within 20 days after installation
of this Ricon product for the warranty to be valid. The warranty is not transferable.
The warranty gives specific legal rights, and there may be other rights that vary from state to state.

1 - 3
I
N
TRODU
C
TIO
N
MAY 2014
32DSKL02.A.1
S-SERIES AND K-SERIES
SERVICE MANUAL
C. SHIPMENT INFORMATION
• When the product is received, unpack the product and check for freight damage. Claims for any damage should be
made to the carrier immediately.
• Verify that the installation kit contains all items listed on the enclosed packing list. Please report any missing items
immediately to Ricon Product Support. The warranty and owner registration cards must be completed and returned
to Ricon within 20 days for the warranty to be valid.
NOTE: The Sales or Service personnel must review the Warranty and this Operator Manual with the user to be certain
that they understand how to safely operate the product. Instruct the user to follow the operating instructions
without exception.
D. GENERAL SAFETY PRECAUTIONS
The following general safety precautions must be followed during installation, operation, and maintenance:
• Under no circumstances should installation, maintenance, repair, and adjustments be attempted without the imme-
diate presence of a person capable of rendering aid.
• An injury, no matter how slight, should always be attended. Always administer first aid or seek medical attention
immediately.
• Protective eye shields and appropriate clothing should be worn at all times.
• To avoid injury, always exercise caution when operating and be certain that hands, feet, legs, and clothing are not
in the path of product movement.
• Batteries contain acid that can burn. If acid comes in contact with skin, flush affected area with water and wash with
soap immediately.
• Always work in a properly ventilated area. Do not smoke or use an open flame near a battery.
• Do not lay anything metallic on top of a battery.
• Check under vehicle before drilling to avoid drilling into frame, subframe members, wiring, hydraulic lines, brake flu-
id lines, fuel lines, fuel tank, etc.
• Read and thoroughly understand the operating instructions before attempting to operate.
• Inspect the product before each use. If an unsafe condition is noted, such as unusual noises or movements, do not
use lift until the problem is corrected.
• Never load or stand on the platform until installation is complete. Upon completion of installation, test load the lift to
100% of its rated load capacity.
• Stand clear of doors and platform and keep others clear during operation.
• The product requires regular periodic maintenance. Inspections are recommended at the intervals prescribed in
chapter three. The product must be maintained at the highest level of performance.
E. CUSTOMER ORIENTATION
IMPORTANT
- Customer Orientation -
Ricon Sales or Service personnel must review the warranty card and Operator manual
with the customer to be certain they understand how to safely operate the lift. The
customer should be instructed to follow the operating instructions without exception.

1 - 4
INTRODUCTION MAY 2014
32DSKL02.A.1
S-SERIES AND K-SERIES
SERVICE MANUAL
1. S-SERIES MAJOR LIFT COMPONENTS
The references used throughout this manual are illustrated in Figure 1-1 and defined in the Table 1-1. Refer to
Chapter IV “Parts Diagrams and Lists” for more details.
RSM0000900
DETAIL "A" DETAIL "B"
(REAR VIEW) CONTROL PENDANT
1
12 513 14
415
16
17
18 19
20
21 3
22
23
6
11
7
9
24
SEE DETAIL "B"
8
2
10
FIGURE 1-1: S-SERIES PUBLIC USE WHEELCHAIR LIFT

1 - 5
I
N
TRODU
C
TIO
N
MAY 2014
32DSKL02.A.1
S-SERIES AND K-SERIES
SERVICE MANUAL
TABLE 1-1: S-SERIES MAJOR COMPONENT TERM DEFINITIONS
REF NAME DESCRIPTION
1, 2,
3, 4 Left, Right, Front, Rear Position references when the lift is viewed from outside of the vehicle.
5 Bridgeplate Load
Sensor Senses if weight is present on the lowered bridgeplate.
6 Hydraulic Cylinder (Left and Right) Telescoping, single-acting cylinders convert
hydraulic pressure into platform lifting and folding force.
7 Hydraulic Power Unit Contains hydraulic pump driven by an electric motor that produces pres-
sure to raise and fold platform, and a pressure release valve to unfold and
lower platform.
8 Audible Alarm (Inside housing for hydraulic unit) Announces when something is passing
over threshold. Activated by threshold beam.
9 Cycle Counter Visible at rear of pump housing, it records number of times platform has
deployed from the vehicle floor to ground and stowed back to vehicle floor.
10 Visual Alarm Flashing light makes it known when something has passed over threshold.
Activated by threshold beams.
11 Manual Backup
Pump Handle Used to operate manual back up-pump (located on hydraulic power unit inside pump housing).
12 Stow-Lock Latch Engages ratchet block located on bottom of bridgeplate when platform is
fully stowed.
13 Baseplate
Assembly Bolts to vehicle floor; provides secure foundation for lift.
14 Threshold Beams Light-beams detect presence of objects in threshold area.
15 Serial Number This is the location of lift serial number decal.
16 Top and Bottom
Arms (Left and Right) Upper and lower links connecting vertical arm to baseplate assembly.
17 Vertical Arms (Left and Right) Connects platform to top and bottom arms.
18 Bridgeplate (Inboard Rollstop) Plate that bridges gap between platform and baseplate when platform is at floor level. Acts as barrier to prevent wheelchair from rolling off of the plat-
form during "Up" and "Down" platform motions.
19 Handrail (Left and Right) Provides a handhold for standing passenger.
20 Occupant Restraint Belt Electrically interlocked safety belt that is intended to prevent acceleration of wheelchair from platform. Lift will not operate unless belt is properly
connected.
21 Front Rollstop Front barrier prevents the wheelchair from inadvertently rolling off of the
platform during lift operation.
22 Platform Component of lift where the wheelchair and occupant are situated during
"Up" and "Down" lift motions.
23 Platform Light (Left and Right) Directs light onto platform surface.
24 Control Pendant Hand-held device controls platform motions.
END OF TABLE

1 - 6
INTRODUCTION MAY 2014
32DSKL02.A.1
S-SERIES AND K-SERIES
SERVICE MANUAL
2. K-SERIES MAJOR COMPONENTS
The terms used throughout this manual are illustrated in Figure 1-2 and defined in Table 1-2. Refer to the parts
diagrams and lists in Chapter IV for more details.
RSM0001400
DETAIL "A" DETAIL "B"
(REAR VIEW) CONTROL PENDANT
1
12 513 14
415
16
17
18 19
20
22 3
22
23
6
11
7
9
24
SEE DETAIL "B"
8
2
FIGURE 1-2: K-SERIES PUBLIC USE WHEELCHAIR LIFT

1 - 7
I
N
TRODU
C
TIO
N
MAY 2014
32DSKL02.A.1
S-SERIES AND K-SERIES
SERVICE MANUAL
TABLE 1-2: K-SERIES MAJOR COMPONENT TERM DEFINITIONS
REF NAME DESCRIPTION
1, 2,
3, 4 Left, Right, Front, Rear Position references when the lift is viewed from outside of the vehicle.
5 Bridgeplate Load
Sensor Senses if weight is present on the lowered bridgeplate.
6 Hydraulic Cylinder (Left and Right) Telescoping, single-acting cylinders convert
hydraulic pressure into platform lifting and folding force.
7 Hydraulic Power Unit Contains hydraulic pump driven by an electric motor that produces pres-
sure to raise and fold platform, and a pressure release valve to unfold and
lower platform.
8 Audible Alarm (Inside housing for hydraulic unit) Announces when something is passing
over threshold. Activated by threshold beam.
9 Cycle Counter Visible at rear of pump housing, it records number of times platform has
deployed from the vehicle floor to ground and stowed back to vehicle floor.
10 Visual Alarm Flashing light makes it known when something has passed over threshold.
Activated by threshold beams.
11 Manual Backup
Pump Handle Used to operate manual back up-pump (located on hydraulic power unit inside pump housing).
12 Stow-Lock Latch Engages ratchet block located on bottom of bridgeplate when platform is
fully stowed.
13 Baseplate
Assembly Bolts to vehicle floor; provides secure foundation for lift.
14 Threshold Beams Light-beams detect presence of objects in threshold area.
15 Serial Number This is the location of lift serial number decal.
16 Top and Bottom
Arms (Left and Right) Upper and lower links connecting vertical arm to baseplate assembly.
17 Vertical Arms (Left and Right) Connects platform to top and bottom arms.
18 Bridgeplate
(Inboard Rollstop) Plate that bridges gap between platform and baseplate when platform is at floor level. Acts as barrier to prevent wheelchair from rolling off of the plat-
form during "Up" and "Down" platform motions.
19 Handrail (Left and Right) Provides a handhold for standing passenger.
20 Occupant Restraint
Belt Electrically interlocked safety belt that is intended to prevent acceleration of wheelchair from platform. Lift will not operate unless belt is properly
connected.
21 Front Rollstop Front barrier prevents the wheelchair from inadvertently rolling off of the
platform during lift operation.
22 Front Platform
Section Front portion of platform that unfolds during deploy and folds during stow. See “Platform folding linkage”.
23 Platform Hinges Three hinges provide a flexible connection between front and rear platform
sections.
24 Rear Platform
Section Rear portion of platform that is folded by linkage located within the vertical arms.
25 Platform Folding
Linkage (Left and Right) Links that cause front platform section to unfold as it de- ploys or fold as it stows.
26 Platform Light (Left and Right) Directs light onto platform surface.
27 Control Pendant Hand-held device controls platform motions.
END OF TABLE

1 - 8
INTRODUCTION MAY 2014
32DSKL02.A.1
S-SERIES AND K-SERIES
SERVICE MANUAL
This page intentionally left blank.
-BACK TO TOP- - NEXT CHAPTER-
