INSTALLATION INSTRUCTIONS
159&139 – LED Outdoor
WS-W15912/ WS-W15918/WS-W15924/ WS-W13918
CAUTION: TO PREVENT ELECTRICAL SHOCK, ENSURE ELECTRICITY HAS BEEN TURNED OFF AT THE CIRCUIT
BREAKER BEFORE BEGINNING.
−Read all instructions before installing.
−System is intended for installation by a licensed electrician in accordance with the National Electrical Code (NEC)
and local regulations.
−When handling the fixture, do not apply pressure to the LEDs. Hold the fixture by the base only.
−Retain installation instructions for future maintenance reference.
WARNING: All parts must be used as indicated in these instructions. This product is designed for use only with the supplied parts and/or
accessories designated for use by dweLED. Substitution of parts or accessories not designated for use with this product by dweLED
could result in personal injury or property damage, and will void the warranty. Contact an authorized dealer or the manufacturer if any
parts are damaged or missing.
MAINTENANCE NOTE: Coastal conditions may cause mineral and residue build-up on the fixture. We recommend that customers in
coastal areas clean all external surfaces of the fixture once every two weeks with a wet cloth.
MISE EN GARDE: Pour éviter tout choc électrique, assurez-vous que le disjoncteur soit mis hors tension avant de
commencer.Lisez toutes les instructions avant l’installation.
−Le système doit être installé par un électricien licensié conformément au code national de l’électricité (NEC), et également aux
règlements locaux.
−Lors de la manipulation du luminaire, n’appuyez pas sur les LED. Tenez-le uniquement par la base.
ATTENTION: Toutes les pièces doivent être utilisées comme indiqué dans ces instructions. Ce produit est conçu pour être utilisé
seulement avec les pièces et/ou accessoires fournis pour être utilisés avec les produits dweLED. Remplacer des pièces ou
accessoires non conçus pour ce produit dweLED pourrait causer des dommages corporels ou matériels et pourrait également
causer l’annulation de la garantie. Veuillez contacter un revendeur autorisé ou le fabricant si des pièces manquent ou sont
endommagées.
NOTE D’ENTRETIEN: Les conditions côtières peut causer une accumulation de minéraux et de résidue sur le luminaire. Nous
recommendons aux clients qui resident dans les zones côtières de nettoyer toutes les surfaces externes du luminaire une fois toutes
les deux semaines avec un chiffon humide.
HARDWARE

WAC Lighting
www.waclighting.com
Phone [phone] • Fax [phone]
Headquarters/Eastern Distribution Center
44 Harbor Park Drive • Port Washington, NY 11050
Phone [phone] • Fax [phone]
Western Distribution Center
1750 Archibald Ave • Ontario, CA 91761
Phone [phone] • Fax [phone]
dweLED retains the right to modify the design of out products at any time as part of the company's continuous improvement program. Jan 2019 2
INSTALLATION INSTRUCTIONS
159&139 – LED Outdoor
WS-W15912/ WS-W15918/WS-W15924/ WS-W13918
Fig.1
PREPARATION
1. Shut off the power at the circuit breaker and remove existing fixture, including the crossbar.
2. Carefully unpack your new fixture and lay out all the parts on a clear area. Be careful not to lose any small parts necessary
for installation.
MOUNTING THE FIXTURE (Fig. 1)
3. Remove the mounting screw (B) and gasket (C) from the mounting back plate.
4. Secure the mounting back plate to the junction box using the screws provided with the junction box.
NOTE: The side of the mounting back plate marked "GND" must face out.
CONNECTING THE WIRES (Fig. 2)
5. Connect the fixture's wires to junction box wires as shown (Fig. 2). Make sure that all wire connectors (A) are secure.
If your outlet box has a green or bare copper ground wire, connect the fixture’s ground wire to it. Otherwise, connect
the fixture’s ground wire directly to the back plate using the green screw provided. After wires are connected, tuck
them carefully inside the junction box.
COMPLETING THE INSTALLATION (Fig. 1)
6. Secure the fixture to the mounting back plate using the mounting screw (B) and gasket (C).
7. To prevent moisture from entering the outlet box and causing a short, use clear caulking (i.e. indoor/outdoor
silicone sealant) to outline the outside of fixture back plate where it meets the wall. Leave a space at the bottom to
allow moisture to escape (Fig.3).
Fig.2Wiring
