Wacom DTU-2231 User manual

Interactive Pen Display
Wacom's first interactive pen display
featuring full HD resolution!
Work directly on screen with the cordless, battery-free pen
Generous 21.5" wide format LCD display
Full HD (1920 x 1080 pixel) resolution
Perfect for medical, GIS/mining and eDocuments markets
Both analog RGB and DVI input and video looping
21.5" wide format Full HD resolution EMR technology
www.wacom-asia.com

Display
Tablet
Screen size
Resolution
Aspect ratio
Pixel pitch
Colors
Response time
Luminance
Contrast ratio
Viewing angle
Video input
Input connector
Video output
Video connector
Technology
Active area
Resolution
Accuracy
Reading height
Pressure levels
Interface
Report rate
Tilt angle
Temperature, humidity
Input voltage
Power consumption
Dimensions
Weight
Certifications
System requirements
7.4 Kg（16.3 lbs)
OSD
manual control
Plug and play VESA DDC2B, DDC/CI
21.5" (476.64 x 268.11mm) active matrix TFT LCD
1920 x 1080 (full HD)
16:9
0.24825 x 0.24825 mm
16.77M colors
5 ms
200 cd/m2
700:1 (max)
170°/160° (typical)
Analog (RGB) / digital (DVI-I)
DVI-I 29 pin
Analog (RGB) / digital (DVI-I)
DVI-I 29 pin
Electromagnetic resonance technology (EMR)
476.64 x 268.11 mm
0.01 mm/point
± 0.5 mm (center)
5 mm
512 levels
USB (2-port USB hub built-in)
133 points/second
15° 〜72°
5° to 35° C, Humidity: 20% to 80% RH (non-condensing)
100 to 240 VAC, 50/60 Hz
39W (Max), 2W or less in sleep mode, 1W or less in off mode
374.0 x 564.0 x 55.5 mm excluding stand
Brightness, Contrast, Pitch, Phase, Vertical Position,
Transparency, Auto Adjust, Horizontal position, Language,
FCC part 15 class B & Subpart C, Industry Canada Class B,
CE, VCCI Class B, EDID 1.3, C-tick, BSMI, MIC, CCC,
GOST-R, CB, J-MOSS, The European Union RoHS Directive
2002/95/EC, Chinese RoHS
Back Light, Menu Position, Reset, Scaling, Color temperature
(9300K/6500K/5000K/Custom/User/Direct)
Windows 7 / Vista / XP / 2000, Mac OS X 10.4 or later
Specifications
DTU-2231A/G0-C
DTU-2231 main unit, battery-free pen, 5 spare pen nibs,
driver and bundled software CDs, AC adapter, 2 power cables,
Model Number Contents
1 adapter plug, USB cable, 2 video cables
Package contents
Features
21.5" wide display with full HD resolution
The LCD panel offers a generous 21.5" working area and full HD
(1920x1080) resolution. The wide viewing angle of 170°/160° allows
content on the screen to be easily seen in any situation. Other notable
features include the 700:1 brightness and the anti-glare surface.
The natural and comfortable way to work
Work directly on screen with the Wacom pen. Use
your hand eye coordination to naturally annotate
presentations, mark-up and sign documents,
draw and write handwritten notes. The comfort of
working directly on screen makes it the perfect
solution for the medical, GIS/mining
and eDocuments markets.
Side switch
Eraser
The multi-functional pen
The DTU-2231 uses patented EMR technology
and a cordless, battery-free pen. The lightweight
pen is incredibly durable and includes a tether to
prevent loss. The two side-switches on the pen
can be customized to perform often-used tasks
such as right-click, double-click, scroll, keystroke
shortcuts, and many more.
Excellent pen performance
In addition to the customizable switches, the pen
delivers 512 levels of pressure sensitivity. Press
lightly for thin lines and more heavily for thicker
lines, just like a regular pen or marker. This great
pen performance allows your drawings to look
more natural and your handwritten notes to be
more readable.
Adjust to the best position
The adjustable stand can be set to incline from 15 to 72 degrees. You can
quickly and easily find the best working angle for your particular work
situation. The unit includes a standard VESA mount that will attach to many
of the mechanical arms that are available in your market.
www.wacom-asia.com
Dimensions and connectivity
Windows PC /
Macintosh
RGB to DVI connector
USB cable
AC adapter
Analog RGB and digital DVI-I input and output
Mirror directly to a projector or another display
