Wacom DTI-520UB User manual

UM-0325(B)_EN.indd 1 09.8.31 6:06:10 PM

1
So that the DTI-520UB may be Used Safely...
The following symbols appear throughout this user guide in order to ensure safe use of the DTI-
520UB (hereafter referred to as “DTI-520UB,” “the product” or “this product”). Please read these
items carefully and always heed the Warning and Caution items when using your DTI-520UB.
This symbol indicates an item that, if ignored when handling the product, could
lead to the loss of life or serious injury.
Warning
This symbol indicates an item that, if ignored when handling the product, could
lead to injury or damage to personal property.
Caution
Meanings of Symbols:
Indicates that it is important to be careful when taking the action or actions noted.
Indicates that the action or actions noted are to be avoided.
Indicates it is important to take the action or actions noted.
Warning
■Do not use the product in a facility control
system that requires an extremely high
level of reliability.
This product may cause other electronic
devices to malfunction, or other devices
may cause this product to malfunction.
■Turn this product off in places
where the use of electronic equipment is
prohibited.
In airports, hospital intensive care units
and other such places where the use
of electronic equipment is prohibited,
this product may adversely affect the
operation of other electrical devices.
In order to prevent this, when in such
locations, always disconnect the product’s
USB connector from your computer and
turn off the switch.
■Do not open the back cover.
Inside this product there are several
high-voltage parts. Persons other than
professional service personnel should
never open the back cover of this
product. Unauthorized opening of the
back cover may lead to fire or electric
shock.
■When this product ceases to operate
normally due to being dropped or a
similar cause, remove the power
source cable from the electrical
outlet.
Leaving the power cable connected may
result in re or electric shock.
User's Guide
■Regarding the power plug and power
adapter.
-
Please remove dust from the power
plug regularly. The addition of moisture,
etc. to accumulated dust may lead to
re.
- Please do not use any power adapters
other than those included with the
product. Ignoring this warning may
result in re or product failure.
- Please do not damage or forcibly bend
or bundle the power adapter cord. Also,
please do not place heavy objects on it
or expose it to excessive heat. Ignoring
this warning may result in re, electric
shock or product failure.
- In the unlikely case that the power
adapter should produce smoke or a
strange odor, please disconnect it from
the wall outlet and return it to either the
store where you purchased it or to the
Wacom Customer Support Center for
repair service.
- Please do not connect or disconnect
the power adapter with wet hands.
Ignoring this warning may result in
electric shock or malfunction.
- Please do not open or otherwise
change the power adapter. Ignoring
this warning may result in re or electric
shock.
UM-0325(B)_EN.indd 1 09.8.31 6:06:16 PM

2
■Do not place heavy objects on
the product.
Do not put excessive weight, or place
heavy objects on the product. These
actions may cause product failure.
■When connecting the power
plug
When plugging the power adapter into
an electrical outlet, also connect a
grounded wire.
■When not using this product for a long
period of time
For safety reasons, when you will not
be using the product for a considerable
length of time, disconnect the power
adapter from the electrical outlet.
■Do not use this product in a
dusty environment.
Dust can cause damage to the product.
■Do not block the ventilation
holes on the backside of the
product.
Blocking these holes may cause internal
overheating and subsequent damage.
■Do not pick up the product by its
stand.
If excessive force is used in handling the
stand, its open and close function may
become damaged. When picking up the
product, always pick it up by the body.
■Regarding the Grip Pen
-Do not strike hard objects with
the metal Grip Pen. Doing so
may cause damage to the
product.
-Be careful to not allow small
children to put either the pen
or the spare nib into their
mouths. There is the danger
that the nib or side switch may
be accidentally swallowed or that the
grip pen may be damaged.
■Do not use organic solvents to clean
this product.
When cleaning the product, never use
such organic solvents as alcohol. Such
solvents may cause discoloration and
deterioration in quality.
■Do not let the product get
wet.
Please do not place containers
such as cups and vases
containing water near the
product. Coming in contact with
water or other liquids may cause
product failure.
■When cleaning this product,
always disconnect the USB connector.
When cleaning the product, always
disconnect the USB connector from the
USB port of the computer. Failure to do
so may result in electric shock.
■While this product is in use, avoid
placing any metal objects on it.
Do not place any metal objects on the
product while you are using it. This may
result in malfunction or product failure.
■Do not touch any liquids that may
be leaking from this product.
The liquid contained in the product is
an irritant. In the unlikely case that such
liquid should leak, never touch it with
bare hands. In case of contact with skin,
mouth or eyes, rinse immediately with
running water and continue rinsing for
15 minutes or longer. Also consult a
physician.
■Do not use excessive force with the cable.
Please do not step on, or place heavy
objects on any of the product’s
cables. Also, do not apply excessive
force to the base of the cable or
repeatedly bend and stretch it,
as this may cause it to break or
malfunction.
■Do not place the product on
unstable surfaces.
Do not place the product where it is
likely to totter, lean or be exposed to
strong vibrations. Doing so may lead
to the product falling, resulting in injury
and/or product failure.
Caution
UM-0325(B)_EN.indd 2 09.8.31 6:06:19 PM

3
■Do not place the product in either very
hot or very cold places.
Do not place the product in very hot (35
degrees centigrade or more) or very cold
(5 degrees centigrade or less) locations.
Also, avoid placing it in locations with
severe temperature fluctuations as this
may adversely affect the product and
cause product failure.
■Do not disassemble the product.
Do not disassemble or modify
the product, as these actions
may lead to fire, excessive
generation of heat, electrical
shock or injury. The guarantee
on the product will become null
and void if the product is ever
disassembled.
Caution
■Do not connect or disconnect any
cable while the product or your
computer is on.
Do not connect or disconnect any
cable (including the USB cable) or the
power adapter while your computer
or this product is turned on. This may
cause damage to the product or to
your computer.
UM-0325(B)_EN.indd 3 09.8.31 6:06:20 PM

4
1 Wacom Company, Ltd. holds the copyright to
the auxiliary tablet.
2 The unauthorized duplication or reproduction
in whole or in part of the tablet driver or this
user guide is expressly prohibited.
3 Wacom reserves the right to change the
configurations or specifications of the tablet
driver or the product, as well as the contents
of this user guide, without prior notice.
Please take the following precautions
to protect the health of your eyes.
●When using the product, make sure that the
room is sufciently illuminated and be careful
not to get your face too close to the screen.
●Take regular breaks when using the product
over an extended period of time.
Warranty Exclusions
Regarding warranty of the product
Wacom warrants the product, to the original
consumer purchaser, except software, to be free
from defects in materials and workmanship under
normal use and service as long as the product
remains in production, but not less than one (1)
year, from the date of original retail purchase, as
evidenced by a copy of the receipt or a registration
card that has been returned to Wacom within 30
days of purchase.
Regarding Trademarks
●Wacom are registered trademarks of WACOM
Company, Limited.
●Windows is a trademark of Microsoft
Corporation, registered in the United States
and other countries.
●Macintosh is a trademark of Apple Computer,
Inc., registered in the United States.
●Other product names and related items are
the trademarks or registered trademarks of
each concerned company.
Precautions
Depending on what is being displayed, bright or
dark green, red and blue dots may show up on
a very small portion of the LCD display screen.
These do not indicate product failure or a lack
of quality.
●Wacom will not bear any responsibility for
damage caused by re, earthquake, accidents
caused by third persons, intentional or
accidental abuse by the customer or any
other damage caused by abnormal use of the
product.
●Wacom will not bear any responsibility for
contingent damages (such as loss of business
profits, suspension of operations, alterations
to and disappearance of data, etc.) caused by
use of, or inability to use, this product.
●Wacom will not bear any responsibility for
damage resulting from the use of this product
in a fashion other than as explained in this
user guide.
●Wacom will not bear any responsibility for
damage resulting from malfunctions caused
by using this product in conjunction with
adaptation equipment or other company’s
software.
Regarding this User Guide
This user guide contains instructions regarding
the set up, installation, functions and methods
of use of this product. The product consists of
the LCD monitor and the tablet, which will act
as two distinct pieces of equipment to be used
in conjunction with your computer. First, you
will set up the display device and then you will
install the tablet driver in your computer. You
will then be able to use this product as a built-
in display tablet.
Analog RGB compatible video output is
necessary for the screen display of this
product. For information regarding how to use
video cards, refer to the instruction manual
accompanying the video card.
Please be aware of the following
regarding the LCD display.
UM-0325(B)_EN.indd 4 09.8.31 6:06:21 PM

5
Table of Contents
So that the DTI-520UB may be Used Safely... ...........................1
Table of Contents .........................................................................5
Component Functions .................................................................6
Opening the Stand.......................................................................................... 7
Using the Penholder ....................................................................................... 7
Installing DTI-520UB on a Mount Arm............................................................ 8
Accessory Check .........................................................................9
Connecting DTI-520UB ............................................................10
Installing DTI-520UB Driver.......................................................12
Windows Setup ............................................................................................ 12
Macintosh Setup........................................................................................... 13
Uninstalling the Tablet Driver ........................................................................ 13
The DTI-520UB Display..............................................................14
Switching Display Images............................................................................. 14
The Auto-Adjust Function............................................................................. 14
The DTI-520UB Power Saving Function....................................................... 14
Protrusion of the Picture from the LCD Panel and the Blurring of Characters... ....... 15
Button Functions .......................................................................................... 16
Adjusting the Brightness and Contrast of the Display.................................. 16
Pen...............................................................................................19
Basic Operations of the Pen......................................................................... 19
How to use the Tablet Button ....................................................................... 20
Using the Control Panel.............................................................21
Displaying the Control Panel ........................................................................ 21
Control Panel Basics .................................................................................... 21
Synchronizing the Positions of the Pen Tip and Pointer .............................. 22
Setup Procedures for when Multiple Interactive Pen Tablets are
Connected............................................................................................ 23
Supplementary Information ...................................................24
Removing Stains........................................................................................... 24
Replacing the Pen Nib.................................................................................. 24
Troubleshooting..........................................................................25
T
Display Troubleshooting.............................................................................. 25
The Pen and Side Switch do not Operate Correctly (For Both Windows and Macintosh).......... 26
General Troubleshooting............................................................................... 27
Troubleshooting for Windows....................................................................... 27
Troubleshooting for Macintosh..................................................................... 27
Specication...............................................................................28
Warranty......................................................................................29
Obtaining Technical Support.....................................................30
UM-0325(B)_EN.indd 5 09.8.31 6:06:21 PM

6
Component Functions
Integrated LCD Monitor and Tablet
+ Button
- Button
ENTER Button
Menu Button
Stand Adjustment Lever →P.7
→P.16
Connector →P.11
Stand →
P.7
Top
Power Switch
Pen Rest
Place the pen here while the pen is not in
use.
Power LED
Lights blue when power has been supplied the
DTI-520UB and the computer and video signals
is present. Glows orange when no video signal
is detected by the DTI-520UB.
Status LED
When the pen switch is on, this will become
blue.
Front
Back
For Application Software buttons
Enable you to create different functions for sup-
porting application software
Tablet Button
You can operate a zoom function and a scroll
function with a single touch of a button.
UM-0325(B)_EN.indd 6 09.8.31 6:06:24 PM

7
Opening the Stand
1
Pull up on the stand adjustment lever.
2
Let the stand down.
Using the Penholder
Pull the penholder towards you as shown in the illustration below.
1
2
Caution
Always close the stand and, as shown in the above illustration, lay the tablet on its side
before pulling the penholder out.
UM-0325(B)_EN.indd 7 09.8.31 6:06:27 PM

8
Installing DTI-520UB on a Mount Arm
This product conforms to the Video Electronics Standard Association’s (VESA) Flat Panel Monitor
Physical Mounting Interface Standard (FPMPMI).
This product can be removed from the stand and mounted on such apparatuses as a VESA-
standard mount arm. In order to do this, M4/0.7 mm screws, which are not included with the
product, are needed. Use screws that will, at the time of installation, penetrate the surface of the
product by no more than 15 mm. Use of longer screws may result in damage to internal parts of
the product.
1
Make sure that both your computer and the
product are turned off and that all cables are
disconnected.
2
Place the display unit face down on a at
surface. To prevent harm to the front of the
unit, rst spread a cloth or other similar
material on the at surface.
3
Remove the four screws that hold the stand
to the unit.
4
Using four M4/0.7mm screws, securely mount
the arm or similar apparatus to the back of the unit.
5
Connect the cables and save the screws that you
removed in step 3.
Caution
When installing the unit on a mount arm or
other stand, always follow the directions in
the instruction booklet for the mount arm or
stand, as well as the instructions contained
in this document. Incorrect installation may
result in the product coming loose and falling
and possibly causing product failure.
Unscrew
UM-0325(B)_EN.indd 8 09.8.31 6:06:28 PM

9
●USB Cable
●Power Adapter
●Power Cable
●Pen
●User Guide (This booklet)
●Serial Cable
User Guide
●Tablet Driver CD - ROM /
Application CD - ROM
Accessory Check
Important :Do no throw the box away; it is useful for the storage and transport of the product.
●Application Install Guide
Application
Install
Guide
UM-0325(B)_EN.indd 9 09.8.31 6:06:31 PM

10
1
Turn off both your computer and the product.
2
Connect the Analog-RGB connector to your computer’s display port.
3
Connect the power adapter to the power cable and connect the DC power connector to the
DC power input terminal. Next, plug the power cable into your electrical outlet.
Be sure to also connect a ground wire.
4
Turn on the product’s power switch.
The power indicator lamp will light up orange.
5
Turn on your computer.
6
While looking at the LCD screen, congure the color resolution and size settings.
Caution:- Do not modify the refresh rate. Setting the rate to a value that exceeds the DTI-520UB refresh
rate may result in loss of picture.
- The color palette settings and corresponding number of colors displayed are as follows:
High Color (16 bit) →65,536 colors / True Color (24 bit) →Roughly 1,619 colors
*The number of colors is limited by the efciency of your computer and video card. For details,
refer to the user’s manual provided by the manufacturers.
7
Turn off your computer and the product.
8
Connect a USB connector of the product to a USB port of your computer using a USB cable.
9
Turn on your computer and the product.
10
Install the DTI-520UB driver (Please refer to “Installing DTI-520UB Driver” on page 12).
Connecting DTI-520UB
UM-0325(B)_EN.indd 10 09.8.31 6:06:32 PM

11
USBconnector
ConnectorsArea
USBcable
Powercable
PowerAdapter
DCPowerInputTerminal
ToanalogRGBport
ToUSBport
DTI-520UBRearView
Computer
Outlet
GroundWire
Tomonitororprojector
(Output)
(Input)
AnalogRGBconnector
AnalogRGBcable
AnalogRGBconnector
Compositevideoconnector
Computer
2
3
8
UM-0325(B)_EN.indd 11 09.8.31 6:06:33 PM

12
Windows Setup
Before installation, connect the DTI-520UB USB cable to your computer and turn the unit on.
Installing the Tablet Driver
1
Insert the tablet driver CD into the CD-ROM drive. The install menu should automatically
display. If the menu does not display, double-click on the INSTALL icon (located on the CD).
2The install menu will appear. When you click on INSTALL TABLET, the LICENSE AGREEMENT
dialog will appear.
3Click Accept.
4 When the installation nishes, click OK.
5Next, install the button driver.
6
Click NEXT in the WELCOME TO WACOM BUTTON DRIVER VER.x.xx SETUP dialog.
7The LICENSE AGREEMENT dialog will appear. Click Next.
8Follow the prompts to install the driver software.
9The INSTALLWIZARD COMPLETE dialog will appear. Click FINISH.
10
Return to the install menu. Click FINISH.
11
See "How to use the Tablet Buttons" section (P.16) for more info about tablet buttons.
Hint: The latest information about the DTI-520UB driver is described in the technical note.
Please read it certainly after the driver is installed.
Installing DTI-520UB Driver
UM-0325(B)_EN.indd 12 09.8.31 6:06:33 PM

13
Macintosh Setup
1
Connect the USB cable to your computer, turn on the product and start up your Macintosh.
2
Close any open applications and temporarily turn off any virus-monitoring programs.
3
Insert the Tablet Driver CD-ROM into your computer’s CD-ROM drive. The install menu will appear.
If
it doesn’t appear, open the CD-ROM and double-click on Install or Install.app.
Hint: *After installing OS X, input your password.
4
Click on Install Wacom Tablet and installation will begin. Thereafter, follow the screen
instructions and continue the installation process. If during processing, the identity
conrmation dialog box displays, input your password *.
Hint: *After installing OS X, input your password.
5
After the tablet driver installation is complete, restart Macintosh.
Caution: Macintosh OS x 10.2 and newer versions include as a standard feature the Inkwell function.
If this function is on, the yellow Inkwell memo pad will appear after installation of the Tablet
Driver. To disable this function, click on Ink from the Control Panel, click on Settings and
remove the checkmark from Allow Me to Write Anywhere.
Uninstalling the Tablet Driver
Windows
1
Click on the Windows Start button and open the control panel. Double click the Add and De-
lete Program (Application) icon.
2
Select Pen Tablet from the list and click the Modify (Add) and Delete button. Follow the in-
structions in the dialog box to initiate uninstall.
If Windows is restarted, it is deleted.
Macintosh
1
Open the Applications folder and then open the Tablet folder.
2
Start up Remove Tablet and follow the instructions to initiate uninstall.
UM-0325(B)_EN.indd 13 09.8.31 6:06:33 PM

14
The DTI-520UB Display
Switching Display Images
Either an image input from the RGB – RGB cable (see P. 11) or an image input from the
composite video cable will be displayed on the DTI-520UB. Either of these images can be
replaced by using the following method:
●Switch at the INPUT CONVERSION screen, which can be accessed from the menu screen.
(
→P.18)
●Click on the ENTER button.( →P.16)
Hint: If both the RGB – RGB cable and the composite video cable are connected, and then you
turn the unit on, the image input from the RGB – RGB cable takes priority and is displayed.
The Auto-Adjust Function
In order to ensure optimal display image quality, this product utilizes the Auto-Adjust function.
When the Auto-Adjust function is operating, it may take a short time before the screen displays
properly. The settings initiated by Auto-Adjust are saved in the display.
Hint: If the Auto-Adjust function is operating, the horizontal and vertical positions as well as the
phase and pitch of the display are adjusted automatically when the display mode is received.
The Auto-Adjust function becomes operational when the horizontal frequency is in the
30-56.5KHz and the vertical frequency is in the 45-75Hz range.(When resolution is 1024 × 768
dot (XGA), vertical frequency is in the 45-70Hz range).
Important:When the Auto-Adjust function is operating, only the power switch is operational.
The DTI-520UB Power Saving Function
This product is in compliance with VESA power-saving guidelines. When connected to a Display
Power Management (DPMS)-compatible computer and graphics board, the power savings
indicated below are automatically realized during times of non-operation.
Computer
Activity
Horizontal
Synchronizing
Signal
Vertical
Synchronizing
Signal
Signal
Power
Consumption
Power Lamp
Turned On Yes Yes Yes 23W or less Blue
Stand-by Mode No Yes No Less than 2W Orange/Blue*
Suspend Mode Yes No No Less than 2W Orange/Blue*
Off Mode No No No Less than 1W Orange
Caution:*Depending on the specications and settings of your computer and video card, when
in standby and suspend modes, the power lamp may only light up orange.
UM-0325(B)_EN.indd 14 09.8.31 6:06:34 PM

15
Protrusion of the Picture from the LCD Panel and the Blurring of Characters...
Caution:This setting is effective when the product and computer are connected by a RGB cable.
Depending on the type of computer and graphics board, the Auto-Adjust function is sometimes
not able to operate at full power, resulting in the picture blurring and protruding from the LCD
panel. If this happens, adjust the pitch and phase. At 1024 x 768-bit, the resolution is optimally
adjusted.
Procedure:
1
Open the Tablet Control Panel (see
page 21) and select the Calibrate tab.
2
Click on the Calibrate... button. An
adjustment pattern for pitch and
phase will appear.
3
Using the OSD controls, open
the OSD Menu and the Pitch
icon. →P.16,18
4
Adjusut the pitch level so the pattern
of ne vertical stripes display evently.
5
In the OSD Menu, select the Phase
icon.
6
Adjust the phase level so the
adjusutment pattern shows
clearly. →P.16,18
7
After completing these
adjustments, press the ENTER
and MENU buttons to exit the
OSD Menu.
8
Click on the CANCEL button or
press the ENTER and MENU
buttons to exit the OSD Menu.
Hint: For Windows 2000, the pitch and phase may be calibrated after the Exit Windows screen is
displayed. If the frequency needs to be calibrated, light and dark vertical stripes will appear
in the dark areas of the screen. If the tracking needs to be calibrated, light and shade will
appear horizontally in the dark areas of the screen (for 1024 x 768-bit resolution).
This method is recommended in situations where the tablet driver has not been installed.
1
2
Adjustment pattern for pitch and phase
UM-0325(B)_EN.indd 15 09.8.31 6:06:35 PM

16
Adjusting the Brightness and Contrast of the Display
Adjusting picture quality and setting up the display are accomplished by using on-screen buttons
to establish and change adjustment items and values. Click on the Menu button and the menu
screen appears. Select the items to be adjusted and their desired settings.
How to Use the OSD Menu
1
Click on the Menu button to display the Main Menu Settings
screen.
2
Click on the + button and the− button and select the items to be
adjusted. When the option you want to adjust is highlighted, press
the ENTER button.
3
Use the + and - buttons to adjust numerical values and other
items.
4
After making your change, press the ENTER button to save.
5
To exit, press the Menu button.
Example: Adjusting the brightness
−buttons, + buttons:
You can select an option that can be
activated.After activatng a selected
option, press the + button to increase
a selected item value, and press the -
button to decrease it.
Menu button:
Opens or closes the OSD
Menu.
ENTER Button
Activates or deactivates the selected OSD
menu otion. Also switches the image input
from the RGB – RGB cable and the image
input from the composite video cable.
Button Functions
UM-0325(B)_EN.indd 16 09.8.31 6:06:36 PM

17
Menu Position
Reset
Brightness
Contrast
Select to increase
or decrease image
contrast.
Types of OSD Menus
Select to increase
or decrease image
brightness.
Select to move the
OSD menu around the
display.
Provides two options:
Use AUTO ADJUST
to reset only the
image parameters.
Use RECALL to reset
all screen options to
the factory default.
Selecting the exit
''icon exits the
RESEST window without resetting anything.
Color
Backlight
Language
Provides settings for 9300°, 6500°, and
5000°Kelvin.
Also provides a User
option that enables you
to adjust red, blue and
green independently.
Selecting DIRECT
displays the received
signal as it is without
any adjustment.
Choose a setting to
work with and press
Enter to activate your selection. You can change
the user setting by
selecting the icon ' '.
In the User Adjustment
window, change red,
blue and green to
calibrate color.To exit,
select the icon ' '.
Selects to increase or
decrease the backlight
brightness level.
Select to choose a
language option for the
OSD: English, Deutsch,
Francais, Espanol,
Italiano, or Japanese.
Some menu screen displays may vary depending on whether a RGB cable or a video cable
is connected. The following screens explained in Common Screens below are the same ones
regardless of the connection method.
●Common Screens
UM-0325(B)_EN.indd 17 09.8.31 6:06:38 PM

18
Vertical Center (VGA only)
Select to move the
screen image up or
down.
To automatically adjust,
use the Reset option.
Horizontal Center(VGA only)
Select to move the
screen image left or
right.
To automatically
adjust, use the Reset
option.
Pitch (VGA only)
Select to reduce or
eliminate vertical
distortion lines.
To automatically adjust,
use the Reset option.
Phase (VGA only)
Select to reduce or
eliminate horizontal
distortion lines.
To automatically adjust,
use the Reset option.
Signal Source
Select D-SUB and
the image input from
the RGB – RGB cable
displays.
Select VIDEO and the
image input from the
composite video cable
displays.
●Screens that Display with a RGB Cable Connection
●Screens that Display with a Video Cable Connection
Saturation Sharpness
Hue
Adjust sharpness of a
image.
Adjust saturation of a
image.
Adjust hue of a image.
UM-0325(B)_EN.indd 18 09.8.31 6:06:39 PM

19
Gripping the Pen
You can hold it just like a pen.
Pen
The Parts of the Pen and Their Functions
Pen Tip
• You can change the position of the screen
pointer by moving the tip of the pen.
• By varying the amount of pressure applied,
the boldness of lines and the size of points
can be adjusted.
• If the pen nib shows signs of ware, it can be
replaced. See page 24.
Eraser
It works like the eraser on a pencil.
Basic Operations of the Pen
Moving the Pointer
By raising the pen a little above the screen and moving it, you can
move the position of the screen pointer.
Clicking and Double-clicking
Clicking
Tap on the screen lightly once with the tip of the pen to click.
UM-0325(B)_EN.indd 19 09.8.31 6:06:41 PM
Table of contents
Other Wacom Monitor manuals
