Portable Solar Lamp

Portable Solar Lamp by Wagan Tech

USER’S MANUAL — Please read before using this equipment.

________________________________________________________________________________________________________________________________________________________________

www.wagan.com

Wagan and Wagan.com are trademarks used by Wagan Corporation.

The Portable Solar Lamp has a novel design, a 1 Watt high

efficiency solar panel, a direction adjustable lantern frame for 360°

illumination. It is an environment, emergency lamp, which can be

used in the place where facility power is not available or often fails.

It is also suitable for travel, camp, auto-maintenance, shop, school,

etc.

HOW TO OPERATE THE SPOTLIGHT AND FLUORESCENT

TUBES

1.) Slide the function selector for illumination. The duration time

is about 3.5 hours

2.) Adjust the lamp frame for best illumination

When the battery is on low level, the PCB will automatically cut off

the lantern, which is good for prolonging the using life of the battery

and prevent it from losing efficacy.

HOW TO REPLACE THE FLUORESCENT TUBES

1.) Pull the bottom cover open (See Figure 1)

2.) Carefully open the light casing and then replace the

fluorescent tubes

3.) Be careful when opening the light casing when replacing the

fluorescent tubes. The tubes might be easily detached and

broken if they are NOT handled with care

HOW TO RECHARGE THE BATTERY BY SOLAR PANEL

Turn over the solar panel to face the sun light, and then the battery

of the Portable Solar Lamp will be recharged by sun light. The

charging time is about 25-30 hours.

HOW TO RECHARGE THE BATTERY BY 12V DC POWER

Plug the DC power cord into your vehicle’s cigarette lighter socket, and

then the battery of the Portable Solar Lamp will be recharged and the

indicator light will be on. The charging time is about 10 hours.

The 12V DC power can be available from automobile or AC/DC adapter.

The output power of the adapter should be more than 300mA, 12V, and its

polarity should be matched with the specification indicated on the Portable

Solar Lamp.

PRECAUTIONS AND REMARKS

1. Do not put the Portable Solar Lamp in a place where it is too moist

2. Avoid rain when the Portable Solar Lamp is recharged by solar

light

SPECIFICATIONS

- 1 Watt mono crystalline solar cell

- 2 x 4 Watt fluorescent tubes, adjustable

optionally for 360° illumination

- Powerful spotlight

- 12V DC cigarette lighter jack

- Built-in lead acid battery

- Automatic over-discharge protection

Portable Solar Lamp by Wagan Tech
