WAHL James Martin ZX834 User manual

1
James Martin Citrus Juicer
Citrus Juicer
ZX834

2
James Martin Citrus Juicer
Please read all instructions carefully to familiarize yourself with the
Wahl James Martin Citrus Juicer before using.
THIS JUICER IS INTENDED FOR HOUSEHOLD USE ONLY.
Save these instructions for further reference.
For any further assistance or information call customer services on
T: 01227 740066
or visit
W: www.wahl.co.uk
E: customer[email protected]
CONTENTS
DESCRIPTION OF PARTS Page 3
IMPORTANT SAFEGUARDS Page 4
HOW TO USE Page 5
CLEANING AND MAINTENANCE Page 7
WIRING Page 8
PRODUCT REGISTRATION Page 9
GUARANTEE Page 10

3
James Martin Citrus Juicer
DESCRIPTION OF PARTS
A: Storage lid
B: Self-reversing large
cone
C: Self-reversing small
cone with stirrers
D: Strainer
E: Container
F: Stainless steel snap-
up juice spout
G: Base Stem
H: Motor base
I: Cord Storage
A
B
C
D
E
F
G
H
I

4
James Martin Citrus Juicer
IMPORTANT SAFEGUARDS
When using this electrical appliance, especially when
children are present, basic safety precautions should always
be observed including the following.
TO REDUCE THE RISK OF FIRE AND INJURY
1. This appliance can be used by children aged 8 years
and above and persons with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
if they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
2. Avoid contact with moving parts while in motion. Keep
hair clothing and other utensils away from the moving
parts during operation to prevent accident, injury or
damage to the appliance.
3. Switch off the appliance and unplug from outlet when not
in use, before putting on or taking off attachments and
also before cleaning the appliance.
4. Never use your appliance without paying attention!
Always unplug the unit when not in use, even for a
moment.
5. Do not operate the appliance with a broken cord or plug,
or if the appliance malfunctions, or is dropped or
damaged in anyway.
6. Any servicing or repair must be performed by an
authorized service representative.
7. Do not use outdoors or in damp areas.
8. Do not let the cord hang over the edge of the work
surface or let it touch any hot surfaces.
9. The use of attachments that are not supplied by the
manufacturer may cause fire, electric shock or injury and
damage to the appliance.

5
James Martin Citrus Juicer
10. To protect against risk of electrical shock, never immerse
the unit or let it come into contact with water or any
other liquids. Do not use the unit with wet hands. If the
appliance should become wet, damp or fall in water,
remove plug from mains socket immediately. Do not put
your hands in the water.
11. Never carry the unit by its power cord.
12. Use this appliance only for its intended purpose.
HOW TO USE
Before plugging in make sure that the voltage matches that shown on the
rating label.
BEFORE FIRST USE
1. Remove all packaging and familiarise yourself with your Citrus Juicer
components as listed in the Description Of Parts on page 3
2. Remove and save literature
3. Wash and clean the juicer parts as described in the section Cleaning
and Maintenance
IMPORTANT: Do not rinse or immerse base in water or any other liquid
ASSEMBLING YOUR JUICER
Place base on a dry level surface.
1. Lower the container through the base
stem onto the base (A)
2. Lower the strainer through the base stem
onto the container (B)

6
James Martin Citrus Juicer
USING YOUR CITRUS JUICER
1. Unwrap cord from the cord storage underneath
the base (E)
2. Plug the cord into a standard electrical outlet
3. Cut fruit in half (Orange, Lime, Lemon or Grapefruit)
4. Remove the storage lid from the citrus juicer
5. Place a glass under the stainless steel snap-up juice spout
NOTE: When the juicing action begins, the juice flows directly into the
glass.
6. Place fruit cut side down over the cone (F).
Using moderate to firm pressure, press
the fruit down to start the juicing action.
Which rotates the cone clockwise until the
pressure is released. By applying pressure
again the cone rotates anti-clockwise
NOTE: The cone changes direction every time you release the pressure
and stop pressing the fruit down on the cone.
3. The small cone fits inside the large cone (C)
NOTE: When using the large cone. Place the small
cone inside it or the small cone can be used by
itself.
4. Choose a cone and lower it through the base stem
onto the strainer (D)

7
James Martin Citrus Juicer
CLEANING AND MAINTENANCE
This product contains no user serviceable parts, refer service to qualified
personnel.
CLEANING
1. Always unplug the unit before cleaning or when not in use
2. Remove the strainer from the container
3. To remove the cone from the strainer, turn it and pull out. Rinse the
strainer and cone immediately after each use. Use a bristle brush to
remove fine pulp that may remain
4. Use warm soapy water to wash all removable parts or place in the dish
washer – top rack. ONLY wipe the base with a damp cloth or sponge;
do not immerse in water or place in the dishwasher
STORAGE
1. Unplug the unit. Wrap the cord around the cord storage underneath the
base (see E)
2. Assemble all parts. Place storage lid over the juicer to keep it dust free
WARNING: NEVER IMMERSE THE JUICER BASE IN WATER OR ANY
OTHER LIQUID.
7. For best results, alternate between pressing the fruit down firmly and
releasing pressure to extract all the juice from the fruit, do this several
times.
8. The motor stops automatically when you remove the fruit from the
cone or if the pressure is completely released.
9. When you finish juicing, lift the stainless
steel snap-up juice spout to stop the juicer
from dripping (G)
NOTE: Always lift the snap-up juice spout when
you have finished juicing.

8
James Martin Citrus Juicer
WIRING
WARNING: If the supply cord is damaged it must be replaced by the manu-
facturers service agent or a similarly qualified person in order to avoid a
hazard.
The wires in the mains lead of this Citrus Juicer are coloured in accordance
to the following code:
Blue Neutral (N) Brown live (L)
This appliance is fitted with a 3 pin plug which has a 3 amp fuse fitted.
If the plug supplied is not suitable for your socket or becomes damaged,
it should be cut off and disposed of, and a suitable plug fitted as detailed
below.
As the colours of the wires in the mains lead of this Citrus Juicer may not
correspond with the colour markings identifying the terminals in your plug,
proceed as follows.
The wire which is coloured BLUE must be connected to the terminal in the
plug which is marked with the letter ‘N’ or coloured BLACK or BLUE.
The wire which is coloured BROWN must be connected to the terminal in
the plug which is marked with the letter ‘L’ or coloured RED or BROWN.
DO NOT connect either wire to the terminal in the plug which is marked
with the letter ‘E’ or has the Earth symbol, or coloured GREEN or GREEN/
YELLOW.

9
James Martin Citrus Juicer
PRODUCT REGISTRATION
Wahl are constantly developing and launching new products in the UK.
We would like to understand your product needs and expectations and we
value any comments you may have. As part of Wahl Customer Care, we
are offering you the chance to be kept up to date with the latest product
launches, innovations and special offers.
Please take a minute to register your product online at www.wahl.co.uk.
WASTE ELECTRICAL & ELECTRONIC EQUIPMENT DIRECTIVE 2002/96/EC
(WEEE)
At the end of this products life it should not be disposed of
with general household waste.
Care should be taken to dispose of in a suitable manner in
accordance with your Local Authority regulation.

10
James Martin Citrus Juicer
GUARANTEE
This product is guaranteed against defects in material and workmanship for
a period of 2 years from the date of original purchase or receipt as a gift.
Should this product become defective during the guarantee period, return
it to the store of purchase together with your proof of purchase for repair
or replacement
Alternatively within the guarantee period you can return the product
to Wahl (UK) Ltd who will repair any such defect or elect to replace the
product or any part of it, without charge, provided that there is proof of
purchase. Should a replacement be offered this will not extend the original
guarantee period.
The guarantee becomes invalid in the case of misuse, alteration or repair
by unauthorised persons.
This product is designed for domestic use only and use within a
professional environment will invalidate the guarantee.
This guarantee in no way affects your rights under statutory law in the
United Kingdom.

11
James Martin Citrus Juicer
NOTES

12
James Martin Citrus Juicer
Wahl (UK) Ltd
Herne Bay Trade Park
Herne Bay
Kent
CT6 8JZ
www.wahl.co.uk
Customer Service T: 01227 740066
Form No. ZB212
Rev2 09-14
