Wahl James Martin Grind and Chop ZX889 User manual

1
James Martin Grind & Chop
Grind and Chop
ZX889
Safety rst
The blades of this appliance are extremely sharp, take great care.
Always unplug before adding or removing attachments.
Read all instructions before using for the rst time.

2
James Martin Grind & Chop
Please read all instructions carefully to familiarise yourself with the
Wahl James Martin Grind & Chop before using.
THIS GRIND & CHOP IS INTENDED FOR HOUSEHOLD USE ONLY.
Save these instructions for further reference.
For any further assistance or information call customer services on
T: 01227 7440066
or visit
W: www.wahl.co.uk
E: customer[email protected]
INDEX
DESCRIPTION OF PARTS Page 3
IMPORTANT SAFEGUARDS Page 4
BEFORE FIRST USE Page 5
HOW TO USE Page 5
CLEANING AND MAINTENANCE Page 6
WIRING Page 7
PRODUCT REGISTRATION Page 7
GUARANTEE Page 7

3
James Martin Grind & Chop
A: Lid
B: Grinder blade
C: Grinder cup
D: Chopper blade
E: Chopper cup
F: Body
G: Power cord
A
B
D
G
DESCRIPTION OF PARTS
E
C
F

4
James Martin Grind & Chop
IMPORTANT SAFEGUARDS
When using this electrical appliance, especially when children are present, basic
safety precautions should always be observed including the following.
TO REDUCE THE RISK OF FIRE AND INJURY
1. Always disconnect the appliance from the supply if it is left
unattended and before assembling, disassembling or
cleaning.
This appliance shall not be used by children. Keep the
appliance and its cord out of reach of children.
Appliances can be used by persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in
a safe way and if they understand the hazards involved.
Children shall not play with the appliance.
2. Never touch or allow contact with moving parts while in
motion. Keep hands, hair clothing and other utensils away
from the moving parts during operation to prevent accident,
injury or damage to the appliance.
3. Switch off the appliance and unplug from outlet when not
in use, before putting on or taking off attachments and also
before cleaning the appliance.
4. Never use your appliance without paying attention! Always
unplug the unit when not in use, even for a moment.
5. Do not operate the appliance with a broken cord or plug, or
if the appliance malfunctions, or is dropped or damaged in
anyway.
6. Any servicing or repair must be performed by an authorised
service representative.
7. Do not use outdoors or in damp areas.
8. Do not let the cord hang over the edge of the work surface
or let it touch any hot surfaces.
9. The use of attachments that are not supplied by the
manufacturer may cause fire, electric shock or injury and
damage to the appliance.

5
James Martin Grind & Chop
10.To protect against risk of electrical shock, never immerse
the unit or let it come into contact with water or any other
liquids. Do not use the unit with wet hands. If the appliance
should become wet, damp or fall in water, remove plug
from mains socket immediately. Do not put your
hands in the water.
11.Never carry the unit by its power cord.
12.Use this appliance only for its intended purpose.
WARNING: ALWAYS ENSURE THE POWER CORD IS UNPLUGGED FROM THE
POWER OUTLET BEFORE ADDING OR REMOVING ANY OF THE ATTACHMENTS.
IMPORTANT: Maximum operation should not exeed 30 seconds.
BEFORE YOUR FIRST USE
Remove all packaging and using the description of parts familiarise yourself with
your appliance and the different parts. Check that all the accessories are complete
and the unit is not damaged.
Wash the chopper and grinder cups and lid prior to use referring to the cleaning and
maintenance section.
Before plugging in check that the voltage matches that shown on the rating label.
WARNING: THE BLADES ARE SHARP, HANDLE CAREFULLY.
HOW TO USE
The Grinder cup
This is ideal for coffee beans (max capacity 80g) and dry spices.
The Chopper cup
This is ideal for nuts, vegetables, fruit, dry fruit, garlic ginger, herbs etc. A little water
or oil may be added if required to combine ingredients.
NOTE: Only use small amounts of liquid to combine ingredients, liquid may spill
from the cup if over filled.
1. Place the motor unit on the flat surface. Make sure the power outlet is unplugged.
2. Decide if you are using the grinder cup or chopper cup depending on your
ingredients.
3. Place the grinder cup or chopper cup onto the motor unit and following the arrow
on the motor unit turn clockwise to lock into position.
4. Put the food into the cup.
5. Place the lid onto the cup.
6. Plug the appliance into the power outlet.

6
James Martin Grind & Chop
7. Push the lid down and hold down to operate the appliance.
8. Once the ingredients are at the desired consistency to stop grinding release the
pressure from the lid.
9. Always unplug the appliance after use.
TIPS FOR CHOPPING
1. Ensure food pieces are not too large about 2cm or smaller is ideal.
2. Even sized pieces will give more consistent results.
3. When using the chopper you can add a little liquid such as oil, water or vinegar to
help combine the ingredients and make a paste or sauce.
4. Short pulse actions will allow you to see how fine your ingredients are and to
achieve the desired results.
5. When chopping certain ingredients you may need to use a small spatula or similar
to scrape food from the sides and return to the centre.
TIPS FOR GRINDING
1. The grinder attachment is designed for dry ingredients. Wet or oily ingredients will
work better in the chopper.
2. If grinding small quantities a pulse action will give a more even and effective result.
3. Most items do not require much grinding to achieve the desired effect.
4. Really hard ingredients such as Nutmeg should not be used in the grinder.
NOTE clean immediately after use to avoid strong flavours lingering and
contaminating other ingredients.
CLEANING AND MAINTENANCE
1. Unplug the appliance and remove grinder and chopping cups.
2. Wash the cups in warm soapy water taking care not to touch the blades.
WARNING: THE BLADES ARE SHARP, HANDLE CAREFULLY.
3. Dry thoroughly.
4. Wipe the motor unit with a damp cloth.
WARNING: NEVER IMMERSE THE MOTOR UNIT IN WATER OR ANY OTHER
LIQUID.
WASTE ELECTRICAL & ELECTRONIC EQUIPMENT DIRECTIVE 2002/96/EC (WEEE)
At the end of this products life it should not be disposed of
with general household waste.
Care should be taken to dispose of in a suitable manner in accordance with
your Local Authority regulation.

7
James Martin Grind & Chop
WIRING
WARNING: IF THE SUPPLY CORD IS DAMAGED IT MUST BE REPLACED BY THE
MANUFACTURERS SERVICE AGENT OR A SIMILARLY QUALIFIED PERSON IN
ORDER TO AVOID A HAZARD.
The wires in the mains lead of this Food Processor are coloured in accordance to
the following code:
Blue Neutral (N) Brown live (L)
This appliance is fitted with a 3 pin plug which has a 5amp fuse fitted.
If the plug supplied is not suitable for your socket or becomes damaged, it should
be cut off and disposed of, and a suitable plug fitted as detailed below.
As the colours of the wires in the mains lead of this Food Processor may not
correspond with the colour markings identifying the terminals in your plug, proceed
as follows.
The wire which is coloured BLUE must be connected to the terminal in the plug
which is marked with the letter ‘N’ or coloured BLACK or BLUE.
The wire which is coloured BROWN must be connected to the terminal in the plug
which is marked with the letter ‘L’ or coloured RED or BROWN.
DO NOT connect either wire to the terminal in the plug which is marked with the
letter ‘E’ or has the Earth symbol, or coloured GREEN or GREEN/YELLOW
PRODUCT REGISTRATION
Wahl are constantly developing and launching new products in the UK. We
would like to understand your product needs and expectations and we value any
comments you may have. As part of Wahl Customer Care, we are offering you
the chance to be kept up to date with the latest product launches, innovations and
special offers.
Please take a minute to register your product online at www.wahl.co.uk.
GUARANTEE
This product is guaranteed against defects in material and workmanship for a
period of 2 years from the date of original purchase or receipt as a gift.
Should this product become defective during the guarantee period, return it to the
store of purchase together with your proof of purchase for repair or replacement
Alternatively within the guarantee period you can return the product to Wahl (UK)
Ltd who will repair any such defect or elect to replace the product or any part of it,
without charge, provided that there is proof of purchase. Should a replacement be
offered this will not extend the original guarantee period.
The guarantee becomes invalid in the case of misuse, alteration or repair by
unauthorised persons.
This product is designed for domestic use only and use within a professional
environment will invalidate the guarantee.
This guarantee in no way affects your rights under statutory law in the United
Kingdom.

8
James Martin Grind & Chop
Wahl (UK) Ltd
Herne Bay Trade Park
Herne Bay
Kent
CT6 8JZ
www.wahl.co.uk
Customer Service T: 01227 7440066
Form No. ZB537
Rev0 04-15
